1Before you start
Introduction
The MaxiScan 1000 (M1000) is a CCD scanning and decoding engine designed for
integration into an OEM device. It is suitable for a wide range of retail and industrial
applications.
This Integration Guide explains how to install and set up your M1000.
You can use the EasySet setup software to set up the M1000.
See the inside cover for regulatory statements and license information.
Warnings
Do not touch reflector mirrors
Protect from dust
Protect from humidity
Electrostatic sensitive device

1Before you start
6MaxiScan 1000 - Integration Guide
Integration considerations
Environment Protect the M1000 from dust and humidity and make
sure your operating environment is suitable (see the
Technical characteristics section)
Reading distance High-density bar codes require a shorter reading
distance than low-density bar codes. Reading distance is
less critical for medium density bar codes (see the
Reading distance section)
Setup Test the setup before you install the M1000 permanently
Symbologies •Use standard symbologies best suited to your
application—some symbologies (Interleaved 2 of 5
for example) are less reliable than others
•Use as few symbologies as possible
•Fixed barcode lengths and check digits increase
reading efficiency and security
I/O synchronization •An external input synchronization device can be
used to activate the M1000
•The M1000 can send a synchronization output to
control external devices according to the read result
•See the Input/output synchronization section

1Before you start
MaxiScan 1000 - Integration Guide 7
Location and reading position
The M1000 can be mounted inside a hand-held or fixed device in any orientation.
Tilt •Prevents reading of a bar code if all the bars are not inside the
reading beam
no read
read OK
tilt
good read
Pitch •Reduces bar width and is much more critical for high-density
barcodes
•Reading may be possible with a pitch angle up to 70°
•Reduce pitch to increase reading efficiency
pitch

1Before you start
8MaxiScan 1000 - Integration Guide
Skew •Reduces bar height
•Reading may be possible with a skew angle up to 65°
•Reduce skew to increase reading efficiency
•A small skew angle (2-3° minimum) is good as it prevents
specular reflection
skew

MaxiScan 1000 - Integration Guide 9
2Installation
Fixing in position
1:1
plastic
M2
∅
= 2 mm

2Installation
10 MaxiScan 1000 - Integration Guide
Dimensions
4.2 cm (1.65")
4.8 cm (1.89")
0.35 cm (0.14")
0.35 cm (0.14")
0.25 cm (0.1")
4.7 cm (1.85")
5.65 cm (2.22")
2.73 cm (1.07")
1.66 cm (0.65")
4.7 cm (1.85")

2Installation
MaxiScan 1000 - Integration Guide 11
Mounting a window
The characteristics and position of the exit window are important for the performance
of your M1000.
•Recommended window angle = 30° from vertical (in either direction)
•An anti-reflection coating increases performance (and permits a lower window
angle)
•Recommended maximum wavefront distortion = 0.2 wavelengths (peak to valley)
over any 2.5 mm diameter area of the window
•A scratched window reduces performance
± 30°

12 MaxiScan 1000 - Integration Guide
3Connections
Connector and pinouts
14-pin female connector
(Molex or Berg)
P/N 3-384034-00
pin 1
reserved
reserved
ground
TX*
reserved
good read LED (external)
buzzer (external)
sync in
sync out
removed
+5V
RTS*
RX*
CTS*
reserved for download
reserved for download
reserved
*
version RS-232 C (P/N 3-380012-00) level -8V/+8V
version RS-232 TTL (P/N 3-380014-00) level 0V/+5V
1
3
5
7
9
11
13
2
4
6
8
10
12
14

3Connections
MaxiScan 1000 - Integration Guide 13
Optional adaptor cable
Stewart 10-pin
socket
14 pin female
connector
adaptor cable with buzzer
P/N 3-384034-00
power supply cable
MicroBar RS-232 C cable
P/N 0-234032-00
user
application
PC connection example
Stewart 10-pin
socket
14-pin female
connector null modem cable
(DTE/DTE)
PC
(COM1/COM2 port)
adaptor cable with buzzer
P/N 3-384034-00
M1000
14-pin connector Stewart 10-pin socket PC DB9 connector PC DB25 connector
1removed
2ground 10 ground 5ground 7ground
3+5V 1+5V
4TX 4TX 2RXD (PC input) 3RXD (PC input)
5RTS 5RTS 8CTS (PC input) 5CTS (PC input)
6reserved 3reserved
7RX 6RX 3TXD (PC output) 2TXD (PC output)
8good read LED (external)
9CTS 7CTS 7RTS (PC output) 4RTS (PC output)
10 buzzer (external) buzzer in cable housing
11 reserved for download 8reserved for download
12 sync in
13 reserved for download 9reserved for download
14 sync out
M1000
RS-232 TTL
M1000
RS-232 C

3Connections
14 MaxiScan 1000 - Integration Guide
External buzzer connection
The good read buzzer parameters can be set from EasySet. The buzzer must not
have an integrated oscillator.
buzzer with external
drive circuitry
(30 mA max)
+ 5V
MaxiScan
51 Ω
pin 10
470 nF
External LED connection
The good read LED can be deactivated from EasySet.
+ 5V
LED (20 mA max)
MaxiScan
220
Ω
pin 8

3Connections
MaxiScan 1000 - Integration Guide 15
Input / output synchronization
Input synchronization
Voltage level
(high) The M1000 is triggered when the voltage level is high on pin 12. It
remains active until the voltage is removed or until a good read
(according to setup).
Voltage level
(low) The M1000 is triggered when the voltage level is low on pin 12. It
remains active until a voltage is applied or until a good read
(according to setup).
Rising edge The M1000 is triggered by a rising edge voltage on pin 12. It remains
active until a good read or timeout (according to setup).
Falling edge The M1000 is triggered by a falling edge voltage on pin 12. It remains
active until a good read or timeout (according to setup).
Rising &
falling edge The M1000 is triggered by a rising or falling edge voltage on pin 12. It
remains active until a good read or timeout (according to setup).
Software The M1000 is triggered when a start character is received. It remains
active until it receives a stop character or timeout (according to
setup). The start and stop characters are user programmable. This
software trigger can be combined with any of the above. See
EasySet for more details.
Output synchronization
A good read or bad read by the M1000 triggers an action on pin 14 of the M1000.
Trigger Good read The output device is triggered when the M1000 performs a
good read.
Bad read The output device is triggered when the M1000 does not
perform a good read during an input synchronization cycle.
Action Voltage
level (high) The output trigger event (good read or bad read)
disconnects pin 14 from the ground. A high level voltage
applied to pin 14 by the output device remains at a high
level until time out.
Voltage
level (low) The output trigger event (good read or bad read) grounds
pin 14. A high level voltage applied to pin 14 by the output
device drops to a low level until time out.
Software The M1000 sends a specified character when it performs a good read or
does not perform a good read during an input synchronization cycle
(according to setup). This software output can be combined with an action
voltage level (high) or voltage level (low).

3Connections
16 MaxiScan 1000 - Integration Guide
Examples
Input synchronization: triggering by an opto-coupled cell
M1000
pin 12
10 kΩ
pin 2 Photelectric
sensor
+5 V +5 V
4.7 k
Ω
Vcc
Output synchronization:
–
+
30 mA max
M1000
pin 14
4.7 k
Ω
pin 2 Conveyor
command
block
Vcc

MaxiScan 1000 - Integration Guide 17
4Technical characteristics
Data
Host system interface RS-232 TTL (P/N 3-380012-00)
RS-232 C (P/N 3-380014-00)
Interface
I/O synchronization One input sync from external device
One output sync to external device
Decoding Symbologies Codabar, Code 39, Code 93, Code 128, MSI Code,
Plessey Code, EAN/UPC (including add-on 2-5),
Interleaved 2 of 5, ISBT 128, Matrix 2 of 5,
Standard / Industrial 2 of 5, PDF 417 (option)
Scan rate 100 to 800 scans/second
default 100 to 400 scans/second (autoadaptive)
Depth of field See the Reading distance section below
Minimum resolution See the Reading distance section below
Maximum code width See the Reading distance section below
Pitch ±70°
Skew ±65°
Scan performance
Print contrast ratio 25% minimum
Light source 4 LEDs at 640 nm
Optical
characteristics Image sensor High resolution CCD
Power requirements 5 VDC ±5%
Electrical
characteristics Current consumption 150 mA maximum at 5 VDC ±5% at constant beam
Width x depth x height 4.7 x 5.65 x 2.8 cm (1.85 x 2.22 x 1.1")
Mounting In any position using 3 x M2 screws
Physical
characteristics
Connector 14-pin (Molex or Berg)
Operating temperature 0°C to 40°C (32°F to 104°F)
Storage temperature -25°C to 60°C (-13°F to 140°F)
Relative humidity 10% to 90% non-condensing
Maximum ambient lighting 4000 lux
Electrostatic discharge Depends on mounting and enclosure
Shock resistance Depends on mounting and enclosure
Sealing (dust etc.) Depends on mounting and enclosure
Environmental
specifications
MTBF >50 000 hours
User interface Depends on user setup

4Technical characteristics
18 MaxiScan 1000 - Integration Guide
Reading distance
13
12
11
10
9
8
7
6
5
4
3
2
1
0
7 6 5 4 3 2 1 0 1 2 3 4 5 6 7
5.1’’
4.7"
4.3"
3.9"
3.5"
3.1"
2.8"
2.4"
2.0"
1.6"
1.2"
0.8"
0.4"
0"
cm
0.1 mm (4 mil)
0.3 mm (12 mil)
0.2 mm (8 mil)
1.0 mm (40 mil)
0.5 mm (20 mil)
2.8’’ 2.4’’ 2.0" 1.6" 1.2" 0.8" 0.4" 0" 0.4" 0.8" 1.2" 1.6" 2.0" 2.4’’ 2.8’’
This chart shows the horizontal reading range for 90% contrast Code 39 barcodes read in the dark.
The reading distance is measured from the edge of the electronic board.
Scale 1:1

4Technical characteristics
MaxiScan 1000 - Integration Guide 19
Accessories
Connector 14-pin female connector 2 mm pitch (Molex or Berg).
Use this connector to make a custom cable 3-380029-00
RS-232 TTL adaptor cable with Stewart 10-pin socket
(compatible with RS-232 C cable). This cable includes a
buzzer
3-384034-00
Cables
RS-232 C cable (compatible with RS-232 TTL adaptor
cable and TTL version of M1000 TTL P/N 3-380014-00) 0-234032-00
US 0-302029-01
Europe (except UK) 0-301029-01
Power supply
UK 0-303029-01

20 MaxiScan 1000 - Integration Guide
5Setup
There are 4 different ways to set up your M1000:
•Online setup with EasySet
•Online setup with commands (see the Slave mode section)
•Offline setup with barcodes printed from EasySet
•Basic setup using the barcodes in the Basic setup section
EasySet System configuration software is the easiest way to set up your M1000. You
can download your custom settings directly to the M1000 or print out and scan the
corresponding configuration bar codes.
If you want to configure your M1000 dynamically, or if your M1000 is not connected to
a PC, use the slave mode to send setup commands directly to your M1000 (see the
Slave mode section).
To set up your M1000 in a test configuration without using EasySet, scan the bar
codes in the Basic setup section. The basic setup does not include all the
configuration possibilities of the M1000.
