Intermec MaxiScan 2100 User manual

Getting Started Guide
P/N 3-410049-01
MaxiScan 2100
Fixed Station Scanner
Guida introduttiva
Leitfaden Wie starte ich Guía de inicio
Guide de démarrage Guia des primeiros passos
32
InstallationIntroduction
Full setup
Configuración completa
Configuration complète
Vollständige Konfiguration
Configurazione completa
Configuração completa
EasySet setup software
(on the CD-ROM)
(on the CD-ROM or to order)
Installation Manual
Basic setup
Configuración básica
Configuration de base
Grundkonfiguration
Configurazione di base
Configuração básica
Getting Started Guide
Operating
Uso
Utilisation
Betrieb
Utilizzazione
Operação
Operators Guide
EasySet
54
Customize parameters (optional)
QWERTY Swedish / Finnish
Postamble = none
Postamble = Enter (*)
Postamble = Tab
Inter-character delay = 20 msec
Inter-character delay = none (*)
QWERTY Norwegian
QWERTZ Swiss / French
QWERTY Danish
QWERTY Italian
QWERTY Spanish
Postamble = Carriage Return
(*) = default value
➏
Keyboard wedge (for PC)
Din/mini-Din adaptor cable
PC wedge cable
P/N : 3-414037-00
Connect cables
System power OFF
MaxiScan power ON
(if required)
System power ON
Select keyboard
AZERTY French
QWERTY English
QWERTZ German
➊
➋
➌
➍
➎
76
Customize parameters (optional)
(*) = default value
➏
RS-232
Connect cables
MaxiScan power ON
Direct RS-232 cable
P/N 0-234032-00
System power OFF
System power ON
Select basic RS-232 9600 baud, 7 data bits, even parity, 2 stop bits
postamble = carriage return + line feed
➊
➋
➌
➍
➎
9600 baud (*)
19200 baud
7 data bits (*)
8 data bits
Odd parity
Even parity (*)
No parity
Postamble = Carriage Return
Postamble = none
Postamble = Carriage Return + Line Feed (*)
98
Online setup
Reset
Connect RS-232 cable
(P/N : 0-234032-00)
MaxiScan power ON
System power OFF
System power ON
Start EasySet software
Scan EasySet setup code
➊
➋
➌
➍
➎
➏
Symbology
Select symbology
Disable all symbologies
Test
➊
➋
➌
UPC-A, UPC-E, EAN-8, EAN-13
(UPC-A -> EAN-13)
Code 39
UPC-A, UPC-E, EAN-8, EAN-13
(UPC-A -> UPC-A)
Code 128 / EAN 128
EAN 13
1234567890128
Code 39
CODE-39
Code 128
CODE-128 UPC-A
001234 50000 7
EasySet
1110
CAUTION  Use of controls or adjustments or performance of procedures other than those specified herein result in
hazardous laser light.
VORSICHT  Bei einer anders als hier beschriebenen Verwendung der Bedienelemente oder Veränderungen oder
einer anderen Ausführung der Arbeitsabläufe entsteht gefährliches Laserlicht.
ATTENTION  Lutilisation de contrôles/commandes ou de réglages ou lexécution de procédures autres que ceux
précisés par le présent document provoquent une lumière laser dangereuse.
Laser warnings (MaxiScan 2100 ST only)Reading distance
100% UPC / EAN
0.1 mm (4 mil)
MaxiScan 2100 SR
7 cm (2.8)
4.4 cm (1.7)
2 cm (0.8)
1 cm (0.4)
0
65°
MaxiScan 2100 ST
100% UPC / EAN
0.1 mm (4 mil)
29 cm (11.4)
16 cm (6.3)
12 cm (4.7)
2 cm (0.8)
0
65°
The MaxiScan 2100 ST is a Class 2 laser scanner. These warnings do not apply to the MaxiScan 2100 SR which is
a CCD scanner and does not contain a laser.
Fix these warning labels onto the product if they
are not already present.
Collez les étiquettes davertissement sur votre
produit.
Bringen Sie Warnetiketten auf dem Produkt an.
Fije la etiqueta de advertencia en el producto.
Unetichetta di avviso per il laser è da applicare
sul prodotto.
Cole as etiquetas de precaução no equipamento.
12
Regulatory statements
Intermec hereby declares that the MaxiScan 2100 has been tested and found compliant with the below
listed standards as required by the EMC Directive 89/336/EEC as amended by 92/31/EEC and by the Low
Voltage Directive 73/23/EEC as amended by 93/68/EEC:
EN55022 (1992) EN50082-1 (1998) EN60950 (1993)
USA: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment is intended for operation in a commercial environment, in compliance with the requirements for a
Class B digital device, pursuant to part 15 of the FCC Rules. It generates, uses and can radiate radio frequency
energy. If not installed and used in accordance with the instructions, it may cause interference to radio communica-
tions. If this equipment causes interference, the user will be required to correct the interference at the users own
expense.
Canada: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du
Canada.
Australia-New Zealand: This equipment has been tested and found to conform to the Australian EMC
framework concerning Class B digital devices, prescribed by the Australian and New-Zealander
standard AS/NZS 3548.
The information contained in this document is for informational purposes only and is subject to change without notice.
No part of this document may be copied or reproduced in any manner without the prior written permission of Intermec
Technologies Corporation.
MaxiScan products are covered by patents issued or pending in the USA and other countries.
The word Intermec, the Intermec logo, MaxiScan and EasySet are either trademarks or registered trademarks of
Intermec.
Throughout this document, trademarked names may be used. Rather than put a trademark ( or ®) symbol in every
occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and to the
benefit of the trademark owner, with no intention of infringement.
North America / Asia Pacific / Latin America  6001 36th Avenue West, PO Box 4280, Everett, WA 98203-9280
Tel: +1 425 348 2600  Fax: +1 425 348 2833  U.S. service and technical support, tel: 1.800.755.5505  Canadian
service and technical support, tel: 1.800.688.7043
Europe / Middle East / Africa  Sovereign House, Vastern Road, Reading RG1 8BT, England
Tel: +44 118 987 9420  Fax: +44 118 987 9416
Internet: http://www.intermec.com
E-mail:[email protected]
Support: http://datacapture.intermec.com
© 07/99 Intermec Technologies Corporation All Rights Reserved
N309
