Interquartz 9310 User manual

IQ10 Basic Phone 9310
General
This INTERQUARTZ telephone is intended for use on 2 wire analogue PSTN and PABX circuits within
Europe.
Declaration of Conformity
Interquartz (UK) Limited declares under its sole responsibility that this product
Model: IQ10 Basic Phone
Is in conformity with the following relevant harmonized standards
Electromagnetic Compatibility EN55022: 1998 & EN55024: 1998
Telecoms EN301437:1999 & TBR38:1998
Following the provisions of CouncilDirective on radio equipment and telecommunications terminal equipment
May 2003
Notes
1. The RENnumber of this telephone is 1.
2. The European code for emergency services is 112. You can still use 999 in the UK. An access code may
be required, if the phone is connected to a PABX.
Installation
1. Insert the line cord into the line socket (refer to Figure 2).
2. Insert the handset cord into the handset socket.
3. Set the ringer volume control as desired.
4. Position the telephone where you want to wall mount. Drill two holes and fix roundheaded screws,
leaving them slightly proud of the surface. Position the telephone over the screws and slide downwards
intoplace.
5. Before you attempt to change the ER/TBR Recall switch, you should disconnect the phone from the
network. Contact your PABX Manager or Network Supplier if you need to adjust the Recall switch
(ER/TBR) andVoice Message (S1/S2/N) switch.
A9310-03 3C931001-12B.p65 2003/7/10, ¤W¤È 11:011

HANDSET
CORD
HANDSET
RINGER
INDICATOR
KEYPAD
REDIAL KEY
RECALL KEY
PAUSE KEY
MUTE KEY
(Press to mute button)
FIGURE 1 - GENERAL APPEARANCE
1. Ringer Indicator
Flashes when the telephone rings with an incoming call.
2. Mute button (press-to-mute)
Pressing this button to cut off speech transmission during a conversation. Release it to resume normal
conversation.
3. Pause Button
Lift handset, dial any digits required before the pause. Press the Pause button to insert a 3.6 second
pause in the number sequence.
4. Redial Button
Lift the handset, wait for the dial tone, and press the Redial button. The last number that you dialled will
automatically be redialled (up to 32 digits).
5. Recall Button
For PABX use, to carry out call transfer, and access other PABX facilities.
3
1
24
5
A9310-03 3C931001-12B.p65 2003/7/10, ¤W¤È 11:012

TIMED BREAK /
EARTH RECALL
SWITCH
VOICE
MESSAGING
(S1 / S2 / N)
SWITCH
RINGER
HI / LOW / OFF
FIGURE 2 - BOTTOM VIEW
6. Ringer Volume switch (Hi/Low/Off)
Select for no sound (OFF), muted sound (LOW) or full sound (HIGH) ringing on incoming call.
7. Earth Recall / Timed Break (ER/TBR) switch
See installation section in full manual to select Earth Recall (ER) or Time break (TBR) for meeting your
system.
8. Voice Messaging (S1/S2/N) switch
See installation section in full manual to select normal or reverse message wait signal for meeting your
system.
9. Wall Mounting
See installation section in full manual for wall mounting.
10.Data Port
The data port provides access to the telephone line for equipment. e.g. computers with a modem.
6
7
8WALL MOUNT
9
LINE JACK DATA JACK
10
HANDSET
JACK
A9310-03 3C931001-12B.p65 2003/7/10, ¤W¤È 11:013

OPERATION
For details of maintenance, problem solving, warranty & service, please contact your PABX Manager
orNetwork Supplier. For further advice or a more detailed manual for this product, you may visit our
website www.interquartz.co.uk
