Intertec Data Systems E Series User manual

Operating Instructions
E-Serie
HOM511160459Ien-5 • 24/08/2021

www.intertec.info
Page 2 / 8 HOM511160459Ien-5
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
Table of contents
1 General ....................................................................................................................................................................3
2 Use ...........................................................................................................................................................................3
3 Explanation of symbols for warnings and signal words .................................................................................... 3
4 Safety information ..................................................................................................................................................3
5 Installation accessories ......................................................................................................................................... 3
6 Technical Data ........................................................................................................................................................4
7 Installation...............................................................................................................................................................4
8 Connection..............................................................................................................................................................6
9 Commissioning.......................................................................................................................................................6
10 Maintenance............................................................................................................................................................7
11 Troubleshooting .....................................................................................................................................................7
12 Deinstallation .........................................................................................................................................................7
13 Disposal...................................................................................................................................................................7
14 Certificate of Conformity ....................................................................................................................................... 7
15 Further information and service ........................................................................................................................... 7

www.intertec.info
Operating Instructions E-Serie
HOM511160459Ien-5 Page 3 / 8
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
1 General
These operating instructions describe the safe and
proper way to work with the device. The safety
information and instructions given as well as the local
accident prevention regulations and general safety
regulations valid in the area of application must be
complied with. These instructions are a constituent part
of the instrument and need to be kept in the immediate
vicinity of the device accessible to personnel at all times.
Before starting any work, the operating instructions
should be read in full.
2 Use
The E Series electrical heater is used for space heating
by convection in protection enclosures, switch and
protection cabinets where explosion protection and
complete encapsulation are not required.
WARNING
The heater is only designed for non hazardous
areas.
INTERTEC-Hess GmbH accepts no liability for improper
use.
The areas of application are:
• Frost protection
• Condensation protection
• Temperature maintenance
3 Explanation of symbols for warnings
and signal words
The safety information warns the user about risks and
provide information on how risks can be avoided.
Safety information can be found at the start of the
chapter before the instructions which may lead to a
hazardous situation. Additional safety information can be
found at the beginning of this manual.
Safety instructions which must be adhered to are
highlighted as follows:
DANGER
DANGER
This sign is warning about an extremely hazardous
situation which, if not heeded, will lead to death or
serious irreversible injury.
WARNING
WARNING
This sign is warning about a hazardous situation which,
if not heeded, may lead to death or serious irreversible
injury.
CAUTION
NOTICE
This sign is warning about a hazardous situation which,
if not heeded, may lead to slight, reversible injury.
NOTICE
NOTE
It is essential to pay attention to this safety advice as you
may otherwise incur material damage.
INFO
Important notes and useful additional information.
4 Safety information
CAUTION
Risk of injury at the rib ends
The sharp edges on the heating ribs may cause injury if
handled incorrectly.
CAUTION
Risk of burns from a hot surface
Attainable highest temperatures: Max. 180°C
Do not touch device during operation! Before working on
the device, allow it to cool down first.
5 Installation accessories
The following are included in the scope of delivery:
Piece Description
1 Heating unit
1 Angle bracket made of flat steel 160x55mm

www.intertec.info
Operating Instructions E-Serie
Page 4 / 8 HOM511160459Ien-5
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
Piece Description
1 Packet of screws containing the following:
2 Hexagon bolts M 6x12
1 T-head bolt type 28/15, M 6x15
2 Flat square nut M6, st.st.
5 Washer shape A 6.4. st.st.
If one of the components listed here is not included in
the scope of delivery, then please contact the
manufacturer.
6 Technical Data
E 155 E 156 E 158
Rated output 500 W 250 W 500 W
Rated voltage/
Operating voltage
230 V AC 230 V AC 250 V AC
Adjustment range 5…45°C
Protection class IP30
Weight 1,7 kg
Dimensions Length
x Width x Height
177 x 69 x 160 mm
Material Aluminium, black anodized
Connecting cable Flexible PVC sheathed cable 3 G
0,75 mm², Ø 5,7 mm
Mean Time Before
Failure
50.000 h
Storage temperature -50 to +80°C
INFO
You will find the precise technical data for your
instrument on the label.
Rated output
Rated voltage/Operating voltage
Illustration1: Example: Label E155
7 Installation
WARNING
The heater is only designed for non hazardous
areas.
INTERTEC-Hess GmbH accepts no liability for improper
use.
NOTICE
Risk of Damage
When removing from the packaging and during
transport, the connection line must not be stressed or
bent.

www.intertec.info
Operating Instructions E-Serie
HOM511160459Ien-5 Page 5 / 8
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
Illustration2: E series heater with dimensions in mm
The heater is mounted with vertical ribs by using the
mounting bracket supplied. In order to allow free air
convection, a space of 100 mm above and 50 mm
beneath the heater should remain clear.
The mounting bracket can be attached to the long or
short sides of the heater using sliding nuts on each rib.
We reccommend, first loosely screwing the sliding nuts
to the mounting bracket and then inserting them into the
desired rib channels.
The label needs to remain legible.
Example of different mounting types:
Illustration3: E series heater: Mounting example with C-rails in
a protection enclosure
Illustration4: E series heater: Mounting example on a plate

www.intertec.info
Operating Instructions E-Serie
Page 6 / 8 HOM511160459Ien-5
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
Illustration5: E series heater: Mounting example with C-rails in
a protection cabinet
Additional mounting materials such as rails and plates
are not included in the standard scope of delivery (see
mounting accessories) and must be ordered separately.
8 Connection
WARNING
The heater is only designed for non hazardous
areas.
INTERTEC-Hess GmbH accepts no liability for improper
use.
INFO
The device may only be connected up and secured by a
trained person, taking into account the "rated voltage"
and "rated current" specified on the nameplate.
Where operating voltage = measured voltage (rated
voltage), then the heater is at its rated output. Mains
voltage fluctuations up to 10 % are then permissible.
Each heater with integrated TS thermostat must be
preceded by a 10 A fuse or a motor protection switch
with short-circuit and thermal quick release (set to 10 A)
as short-circuit protection. When using a heater without
integrated thermostat, the fuse protection can be
selected according to the cross-section of the supply
cable.
In a TT or TN system, a residual current device (RCD)
must be used where the measured triggering residual
current does not exceed 100 mA. Residual current
devices with a measured triggering residual current of 30
mA are preferable. In an IT system, an insulation
monitoring device needs to be used which switches off
the supply as soon as the insulation resistance is no
greater than 50 Ω per Volt of the rated voltage.
J
L
N
PE
Terminal box
6A
E150
br=brown bl=blue ye/gn=yellow/green
br bl ye/gn
Illustration6: Wiring diagram E series
9 Commissioning
If the heater is installed in accordance with the notes in
theInstallation [}Page 6] section and Connection [}
Page4] section, then the heater may be commisioned.
CAUTION
Sufficient heat dissipation must be ensured.
Unauthorised covers must be removed as otherwise
there is the risk of the heater overheating.
The controller housing is equipped with an infinitely
adjustable thermostat located below the heating profile.
The red indicator lamp lights up during the heating

www.intertec.info
Operating Instructions E-Serie
HOM511160459Ien-5 Page 7 / 8
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
process and goes off when the set temperature is
reached. The integrated bimetallic thermostat activates
the heating process again if the ambient temperature
falls below the set value.
10 Maintenance
The design of the device does not require any
maintenance.
Functional and safety test intervals can be freely
selected by the operator in accordance with the
applicable regulations.
Repairs may only be carried out by the manufacturer in
the factory.
All components have to be kept clean and free of dust
and harmful substances that could lead to excessive
temperature rise.
11 Troubleshooting
If the heater fails, check the installation. Carry out a
continuity test on the heating circuit. Pay attention to the
connection diagram and switching point of the
thermostat!
12 Deinstallation
Disassembly may only be carried out by a trained
person.
DANGER
Risk of fatal injury from electric current!
If contact is made with live components, there is the risk
of fatal injury.
For this reason, switch off the voltage supply, secure
against being switched on again and check that no more
voltage is present.
Disconnect connection line from the clamps and from the
connection socket, disconnect device from bracket and
remove it.
13 Disposal
Disassemble the components of the product, taking the
applicable local labour protection and environmental
regulations into consideration and make sure that the
components are recycled:
• Scrap metal
• Send plastic elements to recycling
• Sort other components according to their material
properties and dispose of them.
NOTICE
Environmental damage may be caused if
disposed of incorrectly!
Electrical scrap and electronics components are subject
to hazardous waste treatment and must only be
disposed of by certified specialists!
The local community authorities or specialist waste
disposal companies can provide information on
environmentally friendly disposal.
14 Certificate of Conformity
The manufacturer, INTERTEC-Hess GmbH,
Raffineriestrasse 8, 93333 Neustadt/Donau, Germany,
hereby declares in sole responsibility that the product
Product / Type designation:
E Series
complies with the provisions of the following directives
2014/35/EU (LVD), 2014/30/EU (EMC), 2011/65/EU
(RoHS), 2012/19/EU (WEEE) complies with the following
standards, harmonized standards, where appropriate
and/or standardized documents:
EN IEC 60364
EN IEC 61000-6-4:2007+A1:2011
Harmonized Standard (RoHS):
DIN EN IEC 63000:2019
Designation:
Neustadt, August 18th, 2021
Dipl.-Ing. Martin Hess, Managing Director
15 Further information and service

www.intertec.info
Operating Instructions E-Serie
Page 8 / 8 HOM511160459Ien-5
INTERTEC-Hess GmbH · Raffineriestr. 8 · 93333 Neustadt/Donau · Germany · [phone] · [email protected]
If the information contained in this instruction manual
should not be sufficient in any way, then INTERTEC
would be glad to be at your disposal to provide further
information and service.
Please contact your INTERTEC contact person or
directly contact
INTERTEC-Hess GmbH
Raffineriestr. 8
93333 Neustadt/Donau
Germany
Phone: [phone]
e-mail: [email protected]
Website: www.intertec.info
Warranty
The legally defined warranties and warranty periods of
24 months are applicable to our scope of supply and
services.
You will find more detailed information in the
manufacturer warranty from INTERTEC for heating
systems and accessories.
These instructions do not claim to take all
designs, options or changes into
consideration, even in association with
installation, operation or maintenance.
INTERTEC does not accept responsibility
for providing information about changes
made retrospectively.
