intervre IVR-OTS-1 User manual

www.intervre.com
IVR-OTS-1
Optical Talk Set
User Manual
Before operating the equipment, please carefully read this instruction manual
Do follow all safety instructions and warnings covered in this manual.
Take the manual for safe keeping

IVR-OTS-1 Manual
2
Contents
1. Warnings and Cautions................................3
2. Accessories (Standard edition) ................ 4
3. Description... ........................................... ..........4
4. Installing the batteries.. ..... ........................5
5. Connecting fiber and earphone ............... 5
6. On/Off.................................................................6
7. Communication Distance...............................6
8. Adjusting volume ............................................ 7
9. Calling ................................................................. 7
10. Low Power Indication.................................. 8
11. Charging ............................................................ 8
12. Meter Maintenance ......................................9
13. Detail Parameters ...................................... 10

IVR-OTS-1 Manual
3
1. Warnings and Cautions
You are cautioned that changes or modifications not expressly approved in this document could void your
authority to operate this equipment.
To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture.
To avoid electrical shock, do not open the cabinet. Refer technical support to qualified personnel only.
Note
As the laser is harmful to the eyes, do not attempt to disassemble the cabinet.
Precautions for Use
Use batteries
At the same time, can not use different style or different capacitance batteries. And only charge the re-
chargeable batteries.
Avoiding condensation problems
As much as possible, avoid sudden temperature changes. Do not attempt to use the drive immediately after
moving it from a cold to a warm location, to raising the room temperature suddenly, as condensation may
form with in the drive. If the temperature changes suddenly while using the drive, stop using it and take out
batteries for at least an hour.
Storage
When long time no use,must take out the batteries to avoid destroying the device.

IVR-OTS-1 Manual
4
2. Accessories (Standard edition)
Headset x 2
User's manual
Host BHost A
3. Description
1 - Fiber optic adapter (FC/PC)
2 - State Indicator
3 - Charging Indicator
4 - USB Charging Interface
5 - Power Key
6 - Communication Distance Select Button
7 - Volume Increase Button
8 - Calling Button
9 - Volume Decrease Button
10 - 2.5mm Earphone Socket
11 - 3.5mm Earphone Socket
12 - 3.5mm Microphone Socket
1
3
4
5 6
2
10 11 12
8
7
9
Carryng bag

IVR-OTS-1 Manual
5
4. Installing the batteries
5. Connecting fiber and earphone
1. Pull the battery cover
lock
2. Raise the battery
cover
3. Install the batteries
correctly
4. Push the battery
cover and lock
The optical fiber telephone achieves full-duplex
communication in single fiber by using WDM (wave-
length division multiplex) Technology. WDM is a
technology of transmitting with different wave-
length in single fiber.
The optical fiber telephone divides into Telephone A
and B. Telephone A and B have completely the same
operation except Telephone A modulates the signal
on 1310 mm wavelength, while Telephone B is on
1550 mm wavelength. They must be used in couple.
This telephone can use 2.5 mm traffic special head-
set and common 3.5 mm PC headset, but they can
not be used at the same time.
SFM 3.5mm PC headset
2.5mm traffic special
headset

IVR-OTS-1 Manual
6
6. On/Off
7. Communication Distance
Press the On/Off button so the device start
working. The power indication light is will turn on.
Press this button again and the telephone will shut
down.
Do not wear headsets before booting to avoid ear
damage caused by loud volume. The correct way is
turning down the volume after booting, then wear
the headset. After wearing the headset, adjust the
volume to clarity and without distortion.
According to the communication and line loss be-
tween two telephones, you must choose the appro-
priate communication distance. The optical fiber
telephone has two modes, remote communication
and near field communication. When the line loss is
more than 20 dB, you must use remote mode. The
maximum communication range of remote mode is
120 km. When one side is using optical fiber holder,
you must use remote mode too. The maximum com-
munication range is 60 km. When the line loss is less
than 20 dB, you must turn off remote mode, or will
cause howling and lead to no communication. The
maximum NFC distance is 60 km.
By pressing the Long button you can switch
between remote communication mode and near
field communication mode.

IVR-OTS-1 Manual
7
8. Adjusting volume
9. Calling
Volume button is used for adjusting the vol-
ume. "+" button is for increasing the volume and "-"
button is for decreasing it. The equipment will save
the volume automatically after setting and will keep
the last setting information when next booting.
Through the call button you can call the
other person when he is online.
During calling, press the call button for one
second or more, the other person's device will make
a sound to announce the call.

IVR-OTS-1 Manual
8
10. Low Power Indication
11. Charging
When the remaining battery power is less than 20%,
the low power indicator light will turn on.
If you use alkaline batteries, you will need to change
them with new ones. If you use rechargeable batter-
ies, you will need charge them at once.
The device has a charging function. When using
rechargeable batteries and turning up a low battery
indication, you should promptly shut down and
recharge it. Long time under voltage will shorten
the lifetime of the rechargeable batteries. Connect
the AC adapter to the device correctly, it can charge
Automatically. Besides, computer USB port can also
be used for charging. The battery remaining indica-
tor keeps flashing during charging. It will stop when
the charging is finished. The battery has finished the
fast recharge and can be used directly. If you do not
stop charging at this time, the device will continue
the trickle charge state, using small current to sup-
ply natural discharge. But this process is not more
than 48 hours. The device can still be used while
charging. But do not plug in the AC adapter when it
is not rechargeable batteries inside, or it will cause a
high temperature and combustion, even explosion.

IVR-OTS-1 Manual
9
12. Meter Maintenance
General maintenance
Optical fiber connect the adapter should avoid contacting with hard objects and keep clean. Should be
stored in a dry and ventilated place to avoid moisture. When un use for long time,should remove the bat-
teries before storage.
Failure and solution
Failure name Failure Cause Solution
Cannot boot Check the battery has power or not Check the batteries are installed
correctly
Immediately shutdown after
booting Check the battery has power or not Replace or recharge the batteries
Can display, but all operations are
valid
The instrument program is
disordered Reboot
Cannot charge Using non-rechargeable battery Reinstall the rechargeable batteries

IVR-OTS-1 Manual
10
13. Detail Parameters
Model IVR-OTS-1
Output (nm) 1310 nm ± 20 nm(A) / 1550 nm ± 20 nm (B)
Dynamic range 45 dB
Transmission distance Short mode >60 km / Long mode >120 km
Modulaon Analog
Opc adapter FC/PC
Laser Type FP
Output power < +1 dBm
Baery Type Size AA rechargeable baery or Lr6
Baery lifeme >25 hrs
Waterproof Can prevent small splash
Operate temp. -10 °C ~ +50 °C
Storage temp. -20 °C ~ +60 °C
Relave humidity <90 % HR
Size 170 mm x 97 mm x 38 mm
Weight 380 g
