Intraphex MRB-UNO1 User manual

Bluetooth and Backup Camera Mirror
Installation Manual
MRB-UNO1

2
General Description
Features
Technical Specications
System Operation
Panel TFT LCD (Digital) Power Supply DC12V
Screen Size 4.3” Brightness 1000cd/m2
Resolution 480x272 OSD Menu Available
Aspect Ratio 16:9 Signal System PAL/AUTO/NTSC
Power Consump-
tion
3.6W(Working)
0.3W (Standby)
Two Video Inputs AV1-DVD etc.
AV2-Camera
What’s In The Box
Auto–Adjusting Brightness Feature
Factory mirror upgrade with a 4.3” High-Resolution LCD Monitor hidden behind
the mirror surface. Bluetooth Handsfree (SCR BC3 V2.0) built-in.
• Factory Style Rear-View Mirror with 4.3” LCD Monitor
• Wiring Harness
• OEM Style Wire Harness Cover
• Installation / User’s Guide
• OEM Look and Feel Mirror
• 4.3” High-Denition LCD Monitor with Auto-adjusting brightness
• OEM Wire Harness Cover for Factory Look
• Two (2) Video Inputs
• Anti-Glare Mirror
• Built-in Bluetooth Hands Free
• Easy Installation
This system is completely signal-sensing. When the Video 1 or 2 inputs see a
signal, the display will automatically turn on. When the signal is removed, it will
automatically turn off. If both inputs see a signal, Input 2 will override Input 1.
The brightness of the 4.3” LCD screen will adjust automatically to its
environment’s lighting conditions. In brighter conditions, the display will brighten
to increase the image’s view ability. In darker conditions, it will decrease its
brightness so as not to over-stimulate the driver’s eyesight.

3
Operation
Installation
87
8586 87a
NA
30
To ACC Input of Camera
GNDVehicle
Reverse Lamp Wire
ACC Input
(From Vehicle)
Mirror
Camera
Black-Ground
Video 2 (To Camera)
Video 1 (Additional Input)
Black-Ground
Red-Accessory
Red-From 87 of Relay
RCA Output to Video
2 Input of Mirror
Bluetooth Setup / Operation
1. While using the Video 1 Input, you can press the Power button to turn the monitor ON/OFF
2. While using the Video 2 Input (Backup Camera), you can press the Power button for 1.5 seconds to turn
the monitor ON/OFF, or use a short press to adjust the image brightness.
1. Remove OEM mirror and replace with supplied LCD mirror.
2. Run your wiring harness into the headliner and down the vehicles A-Pillar, making sure to
avoid any factory airbags. Secure your wiring with zip-ties.
3. Make all necessary wiring connections (See wiring diagram - make sure to use a relay)
1. Go to your phone’s Bluetooth Settings and search for “Car Kit.” Once you’ve selected the
device, you will be prompted for a password. The password is: 1234
2. When the phone has successfully paired, a Bluetooth icon will appear in the top left corner
of the mirror’s display.
3. When you receive a phone call, the monitor will display the number of the incoming call.
you can answer by pressing the Phone Button. To hang up the call, simply press the Phone
Button. Note: This system will not display the Caller ID.

Toll Free Tech Support: 888-228-5560
Local: 727-803-0324
Email: suppor[email protected]
