Invacare®Ranger II™Power Wheelchair Mid-Wheel Drive
Specifications
Dimensions Captain Seat Sling Seat
Overall
Height 35"-39" 32.5"-36.5"
Width open 24.75" with MKIV joystick 23.75"-27.5" with MKIV joystick
23.75" without MKIV joystick 22.5"-26.5" without MKIV joystick
Width closed 14.25" with MKIV joystick 14.5" with MKIV joystick
14" without MKIV joystick 14" without MKIV joystick
Depth* 43.5" 43.5"-45.5"
Seat-to-floor height 22" 18.25"
Arm Height 9" fixed 9" fixed
9.4"-13.4" adjustable 9.4"-13.4" adjustable
Rear wheel size 12.5"x2.25" 12.5"-2.25"
Casters
8"x1.75" Semi-pneumatic standard standard
8"x2" Pneumatic optional optional
Weight
with 22NF batteries and front riggings 210 lb.-217 lb. 178 lb.-182 lb.
without batteries and front riggings 135 lb.-142 lb. 110 lb.-114 lb.
Maximum speed 3.6 mph Standard 5.5 mph Standard
3.6 mph Basic 5.5 mph Basic
Battery (not included)
16",18", 20" models 22NF deep-cycle gel cell 22NF deep-cycle gel cell
dual-mode automatic battery charger dual-mode automatic battery charger
Incline capability 9º grade 9º grade
Shipping weight 161 lb.-165 lb. 135 lb.-153 lb.
Ground clearance 4" 4"
Full turning radius >23" >23"
All specifications are approximate.
*Base at 16" seat depth and P93 front riggings.

Invacare®Ranger II™Power Wheelchair Mid-Wheel Drive
Invacare
Ranger II™
Power
Wheelchair
MWD

Invacare®Ranger II™Power Wheelchair Mid-Wheel Drive
Electronics Features
•MKIV-RII control system
•Invacare®Virtual ServiceSM software
•Ranger II standard allows upgrades to
higher level electronics for utilization
of switch options
For those who need to drive where space is limited, the highly maneuverable mid-wheel drive
power chair is an outstanding choice. The Invacare®Ranger II™mid-wheel drive power chair
offers impressive performance, reliability and transportability with its folding frame and
removable seat. The Ranger II mid-wheel drive features the patented HexaFlex suspension system
with six wheels on the ground for outstanding stability. The Invacare Ranger II mid-wheel drive is
available with a folding sling seat or a removable captain seat which are not only beautiful, but
comfortable and functional. And to enhance the Ranger II mid-wheel drive’s unique combination of
function, comfort, and performance, beautifully styled shrouds are available as well.
Highlights
•Extremely maneuverable, with a front
turning radius starting as low as 16"*
•Folding frame and removable seat for
transportability
•Patented HexaFlex suspension for
stability
•Accommodates knee range-of-motion
limitations such as hamstring
contractures
•The battery charger port is located in
the hand control (joystick) for user
convenience
•Trunk space available in shroud
covering for storage of personal items
•300 lb. weight capacity on Ranger II
standard
•250 lb. weight capacity on Ranger II
basic
* Measured with a flip-up footboard.
n
ALiquid Black - LBK
n
BCandy Apple Red - CRD
n
COcean Blue - OBL
n
D Emerald Green - ERG
Style
Beautiful high gloss shrouds with
color molded into the shrouds
complete the look of this
innovative and incomparable
power wheelchair – the Invacare
Ranger II.
Optional Features
•Oxygen tank holder available
with LOB model
•6" caster option
•Full range of swing-away front
riggings available
Height-, depth-, and angle-adjustable flip-up footplate.
Trunk for storage of personal items.
Standard Features
•Separate, removable battery boxes
•Closed-loop system to help maintain
speed and direction, even downhill
•Automatic motor locks
•Dynamic (on-demand) braking with
regeneration
•Easily accessible clutch for free-
wheeling
•True free-wheeling with motor lock
release
•Angle-adjustable back of 85° to 105°
in 5° increments
•Low back captain seats can be
ordered with a solid seat, to
accommodate pressure-relief
wheelchair cushions like the Invacare®
Personal Seat, Infinity™cushions, or
Ulti-Mate®cushion
•Low back captain seats are available in
gray fabric, gray vinyl, or tan vinyl
•Pin-and-saddle front riggings optional
•Telescoping front rigging attachment
•Available on a standard or basic
platform
Disassembled for transport.
A
B
D
C

Invacare®Ranger II™Power Wheelchair Mid-Wheel Drive
High Back Captain Seat
•Provides greater support with a back height of 20"
•Adjustable lumbar support and swing-back arms on
HIB only
•Standard with drive lockout that prevents driving while
at more than 115º of recline
•Full assisted recline of 85º to 170º
•Optional headrest available (shown)
Low Back Captain Seat in
Gray orTanVinyl Upholstery
•Easy-to-clean
•Durable vinyl fabric
•Optional headrest extension available
(shown)
•Assisted recline of 80º to 115º
•Swing-back arms
Low Back Captain Seat
with Solid Seat Base
•Provides the option of using a pressure relief cushion
(i.e. the Personal Seat or the Ulti-Mate®cushion) with
a Captain seat
•Optional headrest extension available (shown)
These high quality seats offer beautiful styling and another level of functionality. The contact surfaces
are covered with gray automobile-quality fabric, while the sides are trimmed with vinyl for added
durability. A contoured design provides excellent comfort and support. The new seats are available
in two models:the high-back seat (HIB) and the low-back seat (LOB). (Optional headrest extension shown.)
Captain Seat Highlights
•Captain seats are available in low back (LOB), standard, and
optional high back (HIB) models
•Low back captain seats can be ordered with a solid seat to
accommodate pressure-relief wheelchair cushions like the
Invacare®Personal Seat, Infinity™
, or Ulti-Mate®cushion
•Low back captain seats are available in gray fabric or gray vinyl
Captain Seat Specifications
LOB Seat HIB Seat
Width 18" 18"
Depth 16" 16"
Back height 15" 20.75"
Extension height 6" 8"
Weight
Without extension 31 lb. 38 lb.
With extension 37 lb. 44 lb.
Base without seat*175 lb. Basic 175 lb. Standard
*With 22NF batteries and front riggings
