IOGear 8-Port DVI KVMP Switch User manual

1
GCS1108
PART NO. M1207
8-Port DVI KVMP Switch with VGA support
User Manual

2
©2012 IOGEAR. All Rights Reserved. Part No. M1207
IOGEAR, the IOGEAR logo, MiniView®, VSE are trademarks or registered trademarks of IOGEAR. Microsoft and Windows
are registered trademarks of Microsoft Corporation. IBM is a registered trademark of International Business Machines, Inc.
Macintosh, G3/G4 and iMac are registered trademarks of Apple Computer, Inc. IOGEAR makes no warranty of any kind
with regards to the information presented in this document. All information furnished here is for informational purposes only
and is subject to change without notice. IOGEAR. assumes no responsibility for any inaccuracies or errors that may appear
in this document.

3
Table of Contents
Package Contents 4
System Requirements 4
Overview 5
Foot Pad Set Installation 6
Rack Mounting 6
Console Monitor Connection Options 8
Single Level Installation 9
2-Level Installation (Cascading) 11
3-Level Installation (Cascading) 12
LED Indication 13
Port Switching 13
On-screen Display (OSD) Operation 14
Hotkey Setting Mode (HSM) 31
Mac Keyboard Emulation 32
Sun Keyboard Emulation 32
Factory Default Settings 33
Firmware Upgrade 33
Upgrade Fail 36
Restore Factory Default Settings 37
Federal Communications Commission (FCC) Statement 38
CE Compliance 38
Limited Warranty 39
Contact 39

4
System Requirements
Recommended Console
• Display Option #1 – A display with both DVI and VGA connection*
• Display Option #2 – A DVI-I Display for DVI computers
• Display Option #3 – One each of DVI and VGA displays to support DVI and VGA computers
• 1 set of USB keyboard and mouse
Computers
• 1 DVI port or 1 VGA port
• 1 USB port
Operating Systems
• Windows XP, Windows Vista (32-bit / 64-bit)
• Windows 7 (32-bit / 64-bit)**
• Mac OS X v10.3.9 or later
• Sun Solaris
• Linux
*IOGEARrecommendsDisplayOption#1forbestdisplayconguration
**IOGEAR's Display Emulation Technology provides the EDID support for Windows 7
Cable
OnlycustomUSBDVIorVGAKVMcablesets,whicharespecicallydesignedtoworkwith
this switch, may be used to link to the computers. Two cable sets are provided with this
package.
Note: The quality of the display is affected by the quality and length of the cables. If you need
additional cable sets, please contact your dealer to purchase the appropriate ones for your switch.
Package Contents
1 x GCS1108 8-port USB DVI KVMP Switch
2 x Custom USB DVI-D KVM Cable Sets
1 x Firmware Upgrade Cable
1 x Power Adapter
1 x Foot Pad Set (4 pcs)
1 x User Manual
1 x Rack Mount Kit
1 x Warranty Card
Type Length Part Number
USB DVI-D Single Link
6ft (1.8m) G2L7D02U
10ft (3.0 m) G2L7D03U
15ft (5.0 m) G2L7D05U
USB DVI-I Single Link* 6ft (1.8 m) G2L7D02UI *
10ft (3.0 m) G2L7D03UI
*For cascading setup, IOGEAR recommends to use USB DVI-I Single Link cable
(G2L7D02UI) for best performance use.
Tyep Length Part Number
USB VGA
Cable
6ft (1.8m) G2L5102U
DVI-A Adapter GDVIMVGAF

8-Port USB DVI KVM Switch
AUTO SCAN K/M RESET
12 3 4 5 6 7 8
5
1
5 4 23
2
1
34
Overview
Front view
1. Port 1~8 switch Button
2. Power LED
3. Reset Button
4. USB Sharing Port
5. Firmware Upgrade Recovery Switch
Back view
1. Powe Jack
2. CPU 1 - 8 Port
3. Console Port
4. Grounding

Step 1
Remove the screws from the left and right sides of the switch (2 screws total) near the front
of the switch.
8-Port USB DVI KVM Switch
AUTO SCAN K/M RESET
12345678
6
Foot Pad Set Installation
FliptheKVMswitchupsidedown.Peeltheprotectivelmsoffofthefootpads,thenstickthe
pads to the four corners, as shown in the diagram below.
Rack Mounting

8-Port USB DVI KVM Switch
AUTOSCAN K/M RESET
12345678
Step 2
Use the M3 x 8 Phillips hex head screws supplied with the rack mounting kit to screw the
rack mounting brackets into the sides near the front of the unit.
Final Step
Place the KVM switch in the rack. Position it so that the holes in the mounting brackets line
up with the holes in the rack. Secure the mounting brackets to the front of the rack.
8-Port USB DVI KVM Switch
AUTOSCAN K/M RESET
12345678
7

(a) One DVI monitor (DVI-I connector)
One DVI monitor (DVI-I) – plug your DVI
console monitor into the DVI console port
located on the unit’s rear panel;
(b) One DVI monitor (DVI-D + VGA connectors)
One DVI (DVI-D + VGA) monitor – plug your
dual-interface console monitor into both the
DVI and VGA console ports
(c) Two Monitors (1 x DVI-D; 1 x VGA)
Two Monitors (1 x DVI-D; 1 x VGA) – plug
your DVI monitor into the DVI console port,
and plug your VGA monitor into the VGA
console port.
8
DVI-I
DVI-D + VGA
DVI-D
VGA
Console Monitor Connection Options

8-Port USB DVI KVM Switch
AUTO SCAN K/M RESET
12 3 4 5 6 7 8
9
1
2
3
Single Level Installation
1. Plug your USB keyboard and USB mouse into the USB console ports located on the
unit’s rear panel.
2. Depending on your console monitor’s interface, connect your monitor using one of the
following methods (see Console Monitor Connection Options, page 8), and power
on:
Note: The GCS1108 supports DVI, VGA, and dual interface monitors, but only one video
signal (DVI or VGA) can be displayed at a time – the signal will display on either the DVI
monitor or the VGA monitor, depending on the OSD settings.
See Set Computer Viedo Input, page 26 for details about setting the correct video
input and output for your video requirements.
a. One DVI monitor (DVI-I) – plug your DVI console monitor into thhe DVI console
port located on the unit’s rear panel;
b. One DVI (DVI-D + VGA) monitor – plug your dual-interface console monitor into
both the DVI and VGA console ports;
c. Two Monitors (1 x DVI; 1 x VGA) – plug your DVI monitor into the DVI console
port, and plug your VGA monitor into the VGA console port.
3. Plug your main microphone and speakers into the console microphone and speaker jacks
located on the unit’s front panel. The microphone and speakers plugged into this panel
have priority over those in the rear panel.

10
4
6
5
87
4. Plug your secondary microphone and speakers into the console audio ports located on
the unit’s rear panel.
5. Using the custom USB DVI KVM cable set provided with this package, plug the DVI
connector into any available DVI socket in the KVM port section of the switch, then plug
the accompanying USB and audio connectors into their corresponding USB, microphone,
and speaker sockets.
6. At the other end of the cable, plug the USB, video, microphone, and speaker cables into
their respective ports on the computer.
7. Plug your USB peripherals into the type A sockets in the USB hub section.
8. Plug the power adapter that came with your switch into an AC power source, then plug
power adapter cable into the switch’s Power Jack.
Note: Verify that all the plugs
are in the same KVM Port
sockets (all in Port 1, all in
Port 2, etc.).
9. Turn on the power to the computers.

11
2-Level Installation (Cascading)
To control even more computers, additional GCS1108 units can be cascaded from the KVM
ports of the First Stage unit. The cascaded GCS1108s that connect back to the First Stage
unit are considered Second Stage units. As many as 64 computers can be controlled in a
complete two stage installation.
Note: Plug the USB Type A connector into the upper USB port in the Console section
(they are both marked with a similar icon to remind you of the correct USB port).
To set up a two stage installation, refer to the Two Stage Installation diagram on the next
page as you do the following:
1. Make sure that power to all the devices you will be connecting up, including all preexisting
devices on the installation, have been turned off.
2. Use a custom USB DVI-I (G2L7D02UI) KVM cable set (see Cables, page 4), to connect any
available KVM Port on the First Stage unit to the Console ports of the Second Stage unit.
3. Using another custom USB DVI KVM cable set (provided with this package), plug the
DVI connector into any available DVI socket in the KVM port section of the switch, then
plug the accompanying USB Type A, microphone and speaker connectors into their
corresponding USB, microphone, and speaker sockets.
Note: Verify that all the plugs are in the same KVM Port sockets (all in Port 1, all in Port 2,
etc.), and that each socket is marked with an appropriate icon to indicate itself.
4. At the other end of the cable, plug the USB Type B, video, microphone, and speaker
cables into their respective ports on the computer.
5. Repeat steps 3 and 4 for any other computers you are connecting up.
6. For each Second Stage unit, plug the power adapter cable into its Power Jack, then plug
the power adapter into an AC source.
7. Plug the First Stage unit's power adapter cable into its Power Jack, then plug the power
adapter into an AC source.
8. Turn on the power to all the computers.
Note:ThePowerOnsequencerequiresthatallSecondStageunitsbepoweredonrst.
After all the Second Stage units have been powered on, then the First Stage unit must
be powered on next. After the Second and First stage units have been powered on, the
computers can be powered on.

12
3-Level Installation (Cascading)
The procedures for setting up a three stage installation are essentially the same as for a two
stage installation. With a three stage setup, as many as 512 computers can be controlled in
a complete installation.
Note: Switches cannot be cascaded beyond the third level.
Onceyouhavenishedcablingup(seeTwoStageInstallation,page11ifnecessary),power
up according to the following sequence:
1. For each Third Stage unit, plug the power adapter cable into the switch's Power Jack;
plug the power adapter into an AC source
2. For each Second Stage unit, plug the power adapter cable into the switch's Power Jack;
plug the power adapter into an AC source.
3. Plug the First Stage unit's power adapter cable into its Power Jack, then plug the power
adapter into an AC source.
4. Turn on the power to all the computers.
Note:ThePowerOnsequencerequiresthatallThirdStageunitsbepoweredonrst.After
they are all on, the Second Stage units must be powered on next. After all the Second
Stage units are on, the First Stage unit must be powered on. Only after all the switches
have been powered on in this sequence, can the computers be powered on.

13
LED Indication
LED Description
No LED Nocomputerisconnectedtothespecicportorthecomputer
isconnectedtothespecicportbutitisnotpoweredon
Orange Thespecicporthasacomputerconnectedanditispowered
on, but does not focus on the KVM
Green ThespecicporthasfocusontheKVM
Port Switching
Port Switching via Front Panel Switch Button
Simplypressthespecicpushbuttontoswitchthefocustothespecicport
Port Switching via On-Screen DIsplay (OSD)
Please refer to OSD Operation section.
Port Switching via Hotkey
Please refer to Hotkey Setting Mode (HSM) section.

OSD Main Screen
When you invoke the OSD, a screen similar
to the one below appears:
Notes:
1. The diagram depicts the administrator’s
main screen. The user main screen does
not show the F4 and F6 functions, since
these are reserved for the administrator
and can’t be accessed by users.
2. The OSD always starts in list view, with
the highlight bar at the same position it
was in the last time it was closed.
3. Only the ports that have been set
accessible by the administrator for the
current logged in user are visible.
4. If there is a next to the monitor icon,
which means that port is attached to
another KVM (Cascading). Click on a
switch number, or move the highlight
bar to it then press the right arrow key
to expand the list. Similarly, to collapse
a switch’s port list, click on the switch
number, or move the highlight bar to it
then press the left arrow key to collapse
the list.
OSD Login
One Level Main OSD Screen
Cascading 2nd level screen
Cascading 2nd Main OSD Screen
14
Trigger OSD
Simply press [Scroll Lock] [Scroll Lock] rapidly.
Note: This hotkey sequence can be changed to [Ctrl] [Ctrl] for Mac users. Please refer to
Hotkey Setting Mode (HSM) section.
On-screen Display (OSD) Operation
OSD Login
By default, the Login and Password are
blanks, so simply press [Enter] [Enter] to
login. If you have set a user name and
password on the KVM, simply enter them
and press enter to login.

15
OSD Main Screen Headings
Heading Description
PN This column lists the port ID numbers for all the KVM ports on the
installation. The simplest method to access a particular computer is
move the highlight bar to it then press Enter.
QV QV If a port is selected for quick view scanning an arrowhead shows in
this column.
☼The computers that are powered on and are online will a sun symbol in
this column to indicate so
Name If a port has been given a name, its name appears in this column.
OSD Navigation
• To dismiss the menu, and deactivate OSD, click the X in the upper right corner of the OSD
window; or press [Esc].
• To log out, click F8 at the top of the main screen, or press [F8].
• To move up or down through the list one line at a time, click the up and down triangle
symbols () or use the up and down arrow keys on the keyboard. If there are more list
entries than what appears on the main screen, the screen will scroll down.
• To move up or down through the list one screen at a time, click the up and down arrow
symbols (), or use the [PgUp] and [PgDn] keys. If there are more list entries than what
appears on the main screen, the screen will scroll.
• To activate a port, double-click it, or move the highlight bar to it then press [Enter].
• After executing any action, you automatically go back to the menu one level above.
OSD Function
There are eight options showing on top of the OSD screen. Simply click the function key
onthetopofthescreenorpressthespecicfunctionkeyonthekeyboardonaccessthe
specicfunction.
F1: GOTO
F2: LIST
F3: SET
F4: ADM
F5: SKP
F6: BRC
F7: SCAN
F8: LOUT

If [2] was chosen then you can go to a
specicportbyenteringtheportID.You
can also move the red highlight bar to the
specicportthatyouwanttogotoand
press [Enter].
16
F1: GOTO
ThisfunctionistoletyouswitchtoaspecicportviaportIDorport’sname.Enter[1]to
choose from Port Name and [2] to choose from Port Number in the yellow box locating in the
bottom of the pink bar.
F1: GOTO
If [1] was chosen, then type in the port’s
name that you want to go to and then press
[Enter].Youcanalsomovetheredhighlight
bartothespecicportthatyouwanttogo
to and press [Enter].

17
F2: LIST
Function Description
All List out all ports that the administrator has set as accessible for the
current logged in user
Quick View List out only the ports that have been set as quick view ports
Powered ON List out only the ports that have been powered on
Quick View +
Powered ON
List out only the ports that have been set as quick view ports and they
have been powered on
F2: LIST
This function allows you to choose a way that you wish to list the ports in the OSD display
on the main screen. Simply move the red highlight bar to the option that you wish to choose
andpress[Enter].Youwillseethehandsymbolwillbepointingattheoptionthatyouchose,
then simply press [Esc] to exit the function.

18
F3: SET
There are 10 different settings within the
SET section, which they are as follow:
OSD Hotkey
Port ID Display Position
Port ID Display Duration
Port ID Display Mode
Scan Duration
Scan-Skip Mode
Screen Blanker
Hotkey Command Mode
Hotkey
OSD Language
OSD Hotkey
This function allows you to switch the way
to trigger the hotkey between [Scroll Lock]
[Scroll Lock] and [Ctrl] [Ctrl]. Simply move the
red highlight bar to the hotkey setting that
you would like to choose and press [Enter].
Then press [Esc] to exit from this function.
F3: SET
Port ID Display Position
This function allows you to change the
position of the port ID that’s showing on the
screen as the image below. Simply change
the position by using the up, down, left and
right arrows to adjust to the place that you
want the port ID to show in the future and
press [Enter].
Port ID Display Duration
This function allows you to change the port
ID display duration between 3 seconds and
off. Simply move the red highlight bar to the
option that you would like to choose and
press [Enter]. Then, press [Esc] to exit this
function.

19
Port ID Display Mode
This function allow you to choose the way
you want to show the ports in the OSD
main screen – port number only, port name
only or both. Simply move the red highlight
bar to the option that you like to use and
press [Enter]. Then, press [Esc] to exit from
this function.
Scan Duration
This function allows you to set the autoscan
time interval between 0 second to 255
seconds (5 second is set by default). Simply
enter the number between 0-225 and press
[Enter].
Function Description
All Scan all ports that the
administrator has set as
accessible for the current
logged in user
Quick
View
Scan only the ports that
have been set as quick view
ports (This option will only
show up for administrator
account)
Powered
ON
Scan only the ports that
have been powered on
Quick
View +
Powered
ON
Scan only the ports that
have been set as quick view
ports and they have been
powered on
Scan-Skip Mode
This function allows you to set the behavior in autoscan mode. Simply move the red highlight
bar to the behavior you want and press [Enter]. Then, press [Esc] to exit from this function.

20
OSD Language
This function allows you to choose the
OSD language between English, Deutsch,
Japanese,SimpliedChineseandTraditional
Chinese. Simply move the red high light bar
to the language that youwish to choose and
press [Enter]. Then, press [Esc] to exit from
this function.
Screen Blanker
This function allows you to set the time
interval to have the KVM goes to a black
screen. Simply enter the number between 0
to 30 and press [Enter]; then, press [Esc] to
exit from this function.
Hotkey Command Mode
This function allows you to enable or
disable the hotkey commands. Simply
pressYforyesandNforno.Then,press
[Esc] to exit from this function.
Hotkey
This function allows you to set the hotkey
sequence that you wish to use to trigger
hotkeys commands. Simply move the red
high light bar to choose the sequence that
you wish to use and press [Enter]. Then,
press [Esc] to exit from this function.
