ION PARTY ROCKER User manual

Confidential ION Audio Service Manual
ION Audio
Party Rocker
[iPA22]
Service Manual
v1.0
2013.07.23
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by ION Audio. If you are not the authorized, intended
recipient, you are hereby notified that any review, dissemination, distribution or duplication of this
document is strictly prohibited. If you are not authorized, please contact ION Audio and destroy
all copies of this document. You may contact ION Audio at [email protected].
Copyright ION Audio
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH ION AUDIO.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT

Confidential ION Audio Service Manual
PREFACE
This document is intended to assist the service technician in the operation, maintenance and
repair of the ION Audio device. Together with the User Reference Manual, this document
provides a complete description of the functionality and serviceability of the Device. Any
comments or suggestions you may have pertaining to the document are welcome and
encouraged.
READ THIS!
In addition to any purchase price that ION Audio may charge as consideration for ION Audio
selling or otherwise transferring this service manual (“Manual”) to you, if you are not a service and
repair facility (“Service Center”) authorized by ION Audio in writing to be an authorized Service
Center, ION Audio sells or transfers the Manual to you on the following terms and conditions:
Only Service Centers authorized by ION Audio in writing are authorized to perform service and
repairs covered by an ION Audio warranty (if any), and transfer of the Manual to you does not
authorize you to be an authorized Service Center. Therefore, if you perform, or if the Manual
is used to perform, any service or repairs on any ION Audio product or part thereof, any
and all warranties of ION Audio as to that product and any service contract with ION Audio
for that product shall be voided and shall no longer apply for such product, even if your
services or repairs were done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your
responsibility, and ION Audio shall have no liability for any such repairs or service work. All such
service or repairs are performed at the sole risk of the person performing the service or
repairs. You agree that all such work will be performed in a competent, professional and safe
manner at all times and to indemnify and fully hold ION Audio and its successors and assigns
harmless in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of
resale or other transfer.
As the owner of the copyright to the Manual, ION Audio does not give you the right to copy the
Manual, and you agree not to copy the Manual without the written authorization of ION Audio.
ION Audio has no obligation to provide to you any correction of, or supplement to, the Manual, or
any new or superseding version thereof.
ION Audio shall have the right to refuse to sell or otherwise transfer repair parts or materials to
you in its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts
supplied by ION Audio to you (i) to repair or be used in products manufactured for or by third
parties or (ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of ION Audio or the
use thereof on behalf of ION Audio or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you,
and no other terms shall apply unless in a writing signed by an authorized representative of ION
Audio.
All Trademarks are property of their respective companies.

Confidential ION Audio Service Manual
WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE
THIS PRODUCT TO WATER OR MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the enclosed product which may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point inside a triangle is intended to alert the user
to the presence of important operating, maintenance and servicing
instructions in the literature which accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ION
AUDIO SERVICE CENTER WILL VOID THE ION AUDIO WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO
COMPETE WITH ANY ION AUDIO DISTRIBUTOR OR AUTHORIZED REPAIR
SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE
OR MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED ION
AUDIO SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF
THAT ENTITY, AND ION AUDIO SHALL HAVE NO LIABILITY TO THAT
ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
CAUTION: The product under service may employ the use of a
replaceable fuse. Danger of fire or electrocution if fuse is incorrectly
replaced. Replace with only the same type or equivalent type
recommended by the equipment manufacturer.
Regarding the Internal Battery
CAUTION: The product under service may employ the use of a
internal battery. Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instruction.

Confidential ION Audio Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions
before using this product. Use extra care to follow the warnings written on the product itself and in
the operating instructions. Keep the operating instructions and safety suggestions for reference in
the future.
1. Power Source. The product should only be connected to a power supply which is described
either in the operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely to
step on the cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the product's
AC power supply cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into any
openings of the product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators or
other heat producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate
ventilation. Improperly ventilating the product may cause overheating, which may damage the
product.
8. Mounting. The product should only be used with a rack which the manufacturer
recommends. The combination of the product and rack should be moved carefully. Quick
movements, excessive force or uneven surfaces may overturn the combination which may
damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in
the operating instructions for the user. For any other service required, the product should be
taken to an authorized service center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain
situations including without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate
normally, or
e. The enclosure of the product has been damaged.

Bill of Materials (BOM)
Part number Part name Description Unit Q'ty Remark
CR010394 PRE module IPA22 PRE ASSY PCS 1
17020021 Sub-electrolytic capacitor 3.3uF/25V,±20%,-40/+85℃,Φ4*7mm,P=1.5mm,黑色,剪脚为4mm PCS 4
17020084 Sub-electrolytic capacitor 100uF/16V,±20%,-40/+105℃,Φ5*7mm,P=2mm,黑色,剪脚为4mm PCS 2
17030012 Low leakage electrolytic capacitor 0.22uF/50V,±20%,-40/+85℃,Φ5*11mm,P=2.0mm,橙色,剪脚为4mm PCS 2
17020010 Sub-electrolytic capacitor 0.47uF/50V,±20%,-40/+85℃,Φ4*7mm,P=1.5mm,黑色,剪脚为4mm PCS 2
17020032 Sub-electrolytic capacitor 10uF/50V,±20%,-40/+85℃,Φ5*7mm,P=2.0mm,黑色,剪脚为4mm PCS 6
17020013 Sub-electrolytic capacitor 1uF/50V,±20%,-40/+85℃,Φ4*7mm,P=1.5mm,黑色,剪脚为4mm PCS 1
17020049 Sub-electrolytic capacitor 47uF/25V,±20%,-40/+85℃,Φ5*7mm,P=2.0mm,黑色,剪脚为4mm PCS 1
17010282 electrolytic capacitor 1000uF/16V,±20%,-40/+85℃,Φ8*16mm,P=3.5mm,黑色,不剪脚 PCS 2
12040001 Touch switch AN-S401,TSF6273DJ-250AH,品源 PCS 1
10490015 insert JP-13,13*7*0.8mm,瑞固 PCS 1
40370002 male jack AN-JP401,XH2.5-3P,HT-2.5-03P-01A,180度,P=2.5mm)三元泰美,卓志 PCS 1
40030051 6.35 jack AN-J0350,SJ6305-5P(配螺垫).正威 PCS 1
40040017 3.5 jack AN-J0418,PJK-0358,镀银,艺西欧 PCS 1
40370001 male jack AN-JP401,XH2.5-2P,2532-02,高勇/柏盛(180度,P=2.5mm),卓志 PCS 2
15010459 rotational potentiomete
r
AN-V1162,R0915N1D2-17.5F7-7-A10K-R90,单联,L=17.5MM,高星 PCS 2
18040122 LED AN-L0122,DIP,SBR-03W4C-3B7W,Φ3*5mm,,蓝光,雾状普亮,全安 PCS 2
20260067 LED sleeve LED3B-10-B,瑞固 PCS 1
30010004 heat-shrinkable T bush
Φ
2*10*0.20mm,UL,黑色 PCS 2
16050142 Shield cable AN-W5140,3P,24#,UL2547,70mm,一端X2.5H母端一端SCN2.5公端,百康 PCS 1
16050206 Shield cable AN-W5203,3P,24#,UL2547,200mm,一端2530母端一端2520公端 PCS 1
16040458 cable AN-W46M,2P,22#,UL1007,120mm,黑棕,一端2530H母端一端剥5mm,卓志 PCS 1
CR010395 RoHS :IPA22 PRE SMT IPA22 PRE SMT ASSY PCS 1
26020626 PCB AN-B20466,PRE,FR4双面,141.3*126.5*1.6mm,1盎司,绿油,V1.2 PCS 1
50050051 SMT ceramic capacitor 102,VDC50,±10%,X7R,0805,编带式 PCS 1
50050344 SMT ceramic capacitor 10UF,VDC10,±10%,X5R,0805,编带式 PCS 4
50050351 SMT ceramic capacitor 1.1PF,VDC50,±0.25%,NPO,0402,编带式 PCS 2

50050069 SMT ceramic capacitor 104,VDC25,±10%,X7R,0603,编带式 PCS 2
50050036 SMT ceramic capacitor 47PF,VDC50,±5%,NPO,0603,编带式 PCS 7
50050047 SMT ceramic capacitor 101,VDC50,±5%,NPO,0805,编带式 PCS 6
50050059 SMT ceramic capacitor 102,VDC16,±10%,X7R,0805,编带式 PCS 2
50050075 SMT ceramic capacitor 104,VDC50,±10%,X7R,0805,编带式 PCS 7
50050116 SMT ceramic capacitor 221,VDC50,±5%,NPO,0805,编带式 PCS 3
50050138 SMT ceramic capacitor 331,VDC50,±5%,NPO,0805,编带式 PCS 6
50050030 SMT ceramic capacitor 33PF,VDC25,±5%,NPO,0805,编带式 PCS 2
50050037 SMT ceramic capacitor 47PF,VDC50,±5%,NPO,0805,编带式 PCS 2
11170364 SMT resistor 1/10W,100Ω,±5%,0603 PCS 2
11170398 SMT resistor 1/10W,4.7KΩ,±5%,0603 PCS 2
11170421 SMT resistor 1/10W,47KΩ,±5%,0603 PCS 2
11170413 SMT resistor 1/10W,20KΩ,±5%,0603 PCS 8
11170377 SMT resistor 1/10W,470Ω,±5%,0603 PCS 1
11170001 SMT resistor 1/8W,0Ω,±5%,0805,编带式 PCS 1
11170022 SMT resistor 1/8W,100Ω,±5%,0805 PCS 1
11170092 SMT resistor 1/8W,100KΩ,±5%,0805 PCS 2
11170266 SMT resistor 1/8W,10KΩ,±1%,0805 PCS 1
11170080 SMT resistor 1/8W,30KΩ,±5%,0805 PCS 1
11170075 SMT resistor 1/8W,18KΩ,±5%,0805 PCS 2
11170044 SMT resistor 1/8W,1KΩ,±5%,0805 PCS 6
11170288 SMT resistor 1/8W,20KΩ,±1%,0805 PCS 3
11171119 SMT resistor 1/8W,40.2KΩ,±1%,0805 PCS 2
11170011 SMT resistor 1/8W,22Ω,±5%,0805 PCS 1
11170239 SMT resistor 1/8W,4.53KΩ,±1%,0805 PCS 2
11170032 SMT resistor 1/8W,330Ω,±5%,0805 PCS 2
11170059 SMT resistor 1/8W,4.7KΩ,±5%,0805 PCS 4
11170242 SMT resistor 1/8W,4.99KΩ,±1%,0805 PCS 2
11170694 SMT resistor 1/8W,5.1KΩ,±1%,0805 PCS 2
11171091 SMT resistor 1/10W,9.1KΩ,±1%,0805 PCS 2
11170072 SMT resistor 1/8W,15KΩ,±5%,0805 PCS 2
11170355 SMT resistor 1/10W,15Ω,±5%,0603 PCS 1
11170124 SMT resistor 1/4W,22Ω,±5%,1206 PCS 1
14010161 NPN audion KTC2875-B-RTK/P,SOT-23,KEC PCS 2
24040045 SMT inductor 2.2UH 30MA 0805 ,鸿捷 PCS 4
24040035 SMT inductor AN-I4029 2.2NH,220MA,0402,(FCI1005F-2N2S),线艺 PCS 1

24010033 SMT deads FCM1608K-721T,200MHZ,720Ω,0603,线艺 PCS 4
24010009 SMT deads 600Ω@100MHZ,0.5A,±25%,0805,FB0805-601,奋发 PCS 1
60190108 ESD interference suppressor 0603ESDA-TR1 PCS 2
14040740 IC MC78M05BDTRKG,DPAK(TO-252),ON PCS 1
40330016 connector IPEX板端连接器,IPEX-001,SMD,博讯PCS 1
GR000389 RoHS:IPA22 PRE SMT IPA22 PRE板SMT PCS 1
14040771 IC TJM4558,SO8,ST PCS 4
14040279 IC NJM062M,SOP8,JRC, PCS 4
CR010357 RoHS:IPA BLUETOOTH V3.0 IPA BLUETOOTH V3.0 ASSY PCS 1
26060053 PCB AN-B60043,FR4四层,BT,29*20.5*1.0mm,1盎司,镀金,绿油,V1.1 PCS 1
50050340 SMT ceramic capacitor 104,VDC16,±10%,X5R,0402,编带式 PCS 5
50050350 SMT ceramic capacitor 0.75PF,VDC50,±0.25%,NPO,0402,编带式 PCS 1
50050386 SMT ceramic capacitor 1P8,VDC50,+/-0.25pNP0,0402,GRM1555C1H1R8CZ01D Murata PCS 1
50050268 SMT ceramic capacitor 10PF,VDC50,±5%,NPO,0402,编带式 PCS 2
50050334 SMT ceramic capacitor 105,VDC6.3,±10%,X7R,0603,编带式 PCS 3
50050347 SMT ceramic capacitor 105,VDC6.3,±10%,X7R,0402, 编带式 PCS 3
50050365 SMT ceramic capacitor 4.7UF,VDC10,+80/-20%,Y5V,0603,编带式 PCS 1
50050323 SMT ceramic capacitor 10UF,VDC10,+80/-20%,Y5V,0805,编带式 PCS 2
50050343 SMT ceramic capacitor 10UF,VDC6.3,±20%,X5R,0603,编带式 PCS 3
11171122 SMT resistor 1/16W,1Ω,±1%,0402 PCS 2
11171121 SMT resistor 1/16W,1KΩ,±1%,0402 PCS 1
11171116 SMT resistor 1/16W,4.7KΩ,±1%,0402 PCS 1
24040053 SMT resistor AN-I4042,2n2,0402,+/-0.3nH,,Murata_LQG15HS PCS 1
24040059 SMT resistor 22UH,LQH32CN220K53L,Murata PCS 1
25020030 SMT crystal resonator AN-0227,GQC12-R16M000B09,16MHz,SMD3.2*2.5,4PAD,港中兴PCS 1
14040898 IC 24C32,TSSOP8,1.8-5V PCS 1
14040899 IC IS1684S,QFN56 PCS 1
14040835 IC ELM88331BA-S,(3.3V) SOT23 PCS 1
CR010400 RoHS :IPA22 AMP IPA22 AMP ASSY PCS 1
17010112 electrolytic capacitor 100uF/16V,±20%,-40/+85℃,Φ5*11mm,P=2mm,黑色,剪脚为4mm PCS 3
17010247 electrolytic capacitor 470uF/16V,±20%,-40/+85℃,Φ8*12mm,P=3.5mm,黑色,剪脚为4mm PCS 2
17010282 electrolytic capacitor 1000uF/16V,±20%,-40/+85℃,Φ8*16mm,P=3.5mm,黑色,不剪脚 PCS 2
50030210 Metal film capacitor 225,VDC100,±5%,立式盒装型,编带式,灰色,7.2*11*6mm,粤瓷 PCS 2
18010117 Common diode DO-201AD,1N5822,編帶式 PCS 1
14040034 IC 78L09,TO92直脚,UTC PCS 1

24060112 magnetic core inductor AN-I6053,LBP1010-15uH,15uH,3.5A,脚距5mm,线艺 PCS 2
24100002 dead core PFR011-08403509,3.5*9*0.8J5C,1.8uH±25%,编带式,普丰瑞 PCS 1
40360350 pin header AN-JP413,1P,HT-TJC1-1A,三元泰 PCS 1
40370098 male jack AN-JP410,3961-02,(P=3.96mm,180度)，恒泰安 PCS 2
40370197 male jack AN-JP426,2600PS-04,高勇/柏盛(180度,P=2.54mm) PCS 1
40370001 male outlet AN-JP401,XH2.5-2P,2532-02,高勇/柏盛(180度,P=2.5mm),卓志 PCS 1
16060099 ground cable AN-W697,18#,UL1015,100mm,绿注黄,一端打187端子+胶套,一端剥5mm PCS 1
GR000388 RoHS:IPA22 AMP IPA22 AMP板PCS 1
40370002 male outlet AN-JP401,XH2.5-3P,HT-2.5-03P-01A,180度,P=2.5mm)三元泰美,卓志 PCS 1
40370003 male outlet AN-JP401,XH2.5-4P,2532-04,(180度,P=2.5mm)HT-2.5-04P-01A,卓志 PCS 1
CR010401 RoHS:IPA22 AMP SMT IPA22 AMP SMT ASSY PCS 1
26020628 PCB AN-B20468,AMP,FR4双面,130*116*1.6mm,1盎司,绿油,V1.1 PCS 1
50050313 SMT electrolytic capacitor 471,VDC50,±5%,NPO,0603,编带式 PCS 2
50050052 SMT electrolytic capacitor 102,VDC50,±10%,X7R,0603,编带式 PCS 1
50050069 SMT electrolytic capacitor 104,VDC25,±10%,X7R,0603,编带式 PCS 6
50050320 SMT electrolytic capacitor 474,VDC25,±20%,Y5V,0603,编带式,怡丰 PCS 2
50050332 SMT electrolytic capacitor 105,VDC50,±10%,X7R,0603,编带式 PCS 4
11170350 SMT resistor 1/10W,0Ω,±5%,0603 PCS 2
11170364 SMT resistor 1/10W,100Ω,±5%,0603 PCS 2
11170385 SMT resistor 1/10W,1KΩ,±5%,0603 PCS 2
11170406 SMT resistor 1/10W,10KΩ,±5%,0603 PCS 4
11170410 SMT resistor 1/10W,15KΩ,±5%,0603 PCS 3
11170417 SMT resistor 1/10W,33KΩ,±5%,0603 PCS 1
11170429 SMT resistor 1/10W,100KΩ,±5%,0603 PCS 3
11170009 SMT resistor 1/8W,10Ω,±5%,0805 PCS 1
11170592 SMT resistor 1/4W,10Ω,±5%,1206 PCS 2
11170394 SMT resistor 1/10W,3KΩ,±5%,0603 PCS 1
24010033 SMT dead core FCM1608K-721T,200MHZ,720Ω,0603,线艺 PCS 1
18010075 Common diode AN-D10075,LL-34,1N4148,编带式,翔盈 PCS 2
18030105 voltage-regulator diode LL-34,1/2W,5.1V,编带式 PCS 1
18030165 voltage-regulator diode AN-D30165,LL34,1/2W,10V,ZMM10,台晶 PCS 1
14010077 NPN audion MMBT3904LT1,SOT23,ONSEMI PCS 3
14040841 IC TPA3112D1,TSSOP-28 PCS 1
GR000394 RoHS:IPA22 AMP SMT IPA22 AMP SMT PCS 1

11230050 Jump
Φ
0.8*7.5mm,直式 PCS 1
14060010 PFET CEM4435A,SO-8,CET, PCS 1
CR010396 RoHS:IPA22 CONTROL IPA22 CONTROL ASSY PCS 1
17010168 electrolytic capacitor 47uF/16V,±20%,-40/+85℃,Φ5*11mm,P=2mm,黑色,剪脚为4mm PCS 1
17010282 electrolytic capacitor 1000uF/16V,±20%,-40/+85℃,Φ8*16mm,P=3.5mm,黑色,不剪脚 PCS 1
24060116 magnetic core inductor PK0608-47UH,47uH,1A,加UL套管(工字型磁芯) PCS 3
12040036 Touch switch AN-S436,RM-021-01B,艺西欧 PCS 1
12010113 Slide switch AN-S247,SS-13E05-G7,品源 PCS 1
40370149 male jack AN-JP418,2021-02,高勇/柏盛(P=2mm,180度) PCS 1
40370197 male jack AN-JP426,2600PS-04,高勇/柏盛(180度,P=2.54mm) PCS 1
40370321 male jack 2600PS-06,180度,P=2.54mm PCS 1
40370001 male jack AN-JP401,XH2.5-2P,2532-02,高勇/柏盛(180度,P=2.5mm),卓志 PCS 1
40370002 male jack AN-JP401,XH2.5-3P,HT-2.5-03P-01A,180度,P=2.5mm)三元泰美,卓志 PCS 2
40370004 male jack AN-JP401,HT-2.5-05P-01A,三元泰 PCS 1
40360300 pin header AN-FP364,松辉:P1022-1*04SGF11,A=2.8,L=8.8,H=2.0,P=2.0 PCS 1
16040766 cable AN-W4331,2P,26#,UL1007,200mm,一端打2020母端,一端2010公端 PCS 1
16010184 cable AN-W13N,3P,24#,UL1007,200mm,黑棕红,(一端打2530H母端,一端 PCS 1
GR000390 RoHS:IPA22 CONTROL IPA22 CONTROL选件 PCS 1
40370002 male jack AN-JP401,XH2.5-3P,HT-2.5-03P-01A,180度,P=2.5mm)三元泰美,卓志 PCS 2
40370003 male jack AN-JP401,XH2.5-4P,2532-04,(180度,P=2.5mm)HT-2.5-04P-01A,卓志 PCS 2
CR010397 RoHS:IPA22 CONTROL SMT IPA22 CONTROL SMT ASSY PCS 1
26020627 PCB AN-B20467,CONTROL,FR4双面,130*114*1.6mm,1盎司,黑,两拼板,V1.3 PCS 1
50050042 SMT electrolytic capacitor 82PF,VDC50,±5%,NPO,0603,编带式 PCS 1
50050069 SMT electrolytic capacitor 104,VDC25,±10%,X7R,0603,编带式 PCS 8
50050322 SMT electrolytic capacitor 105,VDC25,+80/-20%,Y5V,0603,编带式 PCS 1
50050321 SMT electrolytic capacitor 2.2UF,VDC50,±20%,Y5V,0805,编带式 PCS 1
50050353 SMT electrolytic capacitor 10UF,VDC50,±20%,Y5V,0805,编带式 PCS 2
11170385 SMT resistor 1/10W,1KΩ,±5%,0603 PCS 1
11170394 SMT resistor 1/10W,3KΩ,±5%,0603 PCS 1
11170406 SMT resistor 1/10W,10KΩ,±5%,0603 PCS 6
11170413 SMT resistor 1/10W,20KΩ,±5%,0603 PCS 2
11170901 SMT resistor 1/10W,75KΩ,±1%,0603 PCS 2
11171152 SMT resistor 1/8W,0.15Ω,±1%,0805 PCS 3
11171153 SMT resistor 1/4W,5.6Ω,±5%,1206 PCS 1

11170949 SMT resistor 1/4W,61.9Ω,±1%,1206 PCS 1
11170378 SMT resistor 1/10W,510Ω,±5%,0603 PCS 3
24010020 SMT dead core FB2012-301,奋发 PCS 1
24010016 SMT dead core FB120,3A,1206,BLM31PG121SN1L MURATA PCS 1
18010123 Common diode AN-D0123,SS14,DO-214AC,VISHAY PCS 3
18010075 Common diode AN-D10075,LL-34,1N4148,编带式,翔盈 PCS 1
14010077 NPN audion MMBT3904LT1,SOT23,ONSEMI PCS 1
14060010 PFET CEM4435A,SO-8,CET, PCS 1
14040920 IC MCP6001T-I/OT,SOT23-5,Microchip PCS 1
14040900 IC STM8S103F3P6,TSSOP20 PCS 1
14040921 IC PT4115-89E,SOT89-5,POWTECH PCS 3
14040052 IC TAR5SB50,TOSHIBA/LP2985AIM5-5.0,NATIONAL,5.0V LDO,SOT23-5 PCS 1
14040922 IC ULN2003ADR,SOIC16,TI PCS 1
GR000391 RoHS选件:IPA22 CONTROL SMT IPA22 CONTROL SMT PCS 1
14070008 IC procedure STM8S103F3P6,烧录程序 PCS 1
14070009 IC procedure STM8S103F3P6,烧录程序,ERP2功能 PCS 1
CR010398 RoHS:IPA22 LED IPA22 LED ASSY PCS 1
26100001 PCB single player board IPA22,LED,铝基单面板,45*45*1.6mm,黑油,1盎司,V1.0 PCS 1
18040187 LED VZK1WBAV12CAZ1Z4,高亮,3W,红光,SMD PCS 2
18040188 LED VZK1WBAG72CAZ1Z4,高亮,3W,绿光,SMD PCS 2
18040189 LED VZK1WBAB12CAZ1Z4,高亮,3W,蓝光,SMD PCS 2
16040767 cable AN-W4332,6P,26#,UL1569,250mm,一端2510母端一端剥线2mm PCS 1
10330033 spring DN-MP3026,弹簧-2,弹簧钢,V1.0 PCS 1

2013.03.06
V1.3
IPA22 CONTROL&LED
SHEET: OF
Zhang H
1SCALE: REV:
HOMNI ENTERPRISES CO,.LTD.
DWG NO.: PT-X-XXXXX-XX SIZE:A3
DATED:APPROVED:DATED:CHECKED:DATED:DRAWN:
TITLE:
4
DCBA
4
3
2
1
ABCD
1
2
3
COMPANY:
1
LIMIT SW
TO LED PCB TO J3-A
LED PCB
Simulation JACK
TO PRE J3
TO AMP J5-B
TO AMP J2-A
TO FAN
TO MOTOR
OFF
ON(party mode)
ON(beats mode)
Beats mode: would be the current program that spins fast and flashes to the
music, like HMS sample 1 when music is playing.
Party mode: would be spinning quickly even though there is no more music.
12
3
4
5
U1
MCP6001
1PD4
2PD5
3PD6
4NRST
5OSCIN/PA1
6OSCOUT/PA2
7VSS
8VCAP
9VDD
10 PA3 11
PB5
12
PB4
13
PC3
14
PC4
15
PC5
16
PC6
17
PC7
18
PD1
19
PD2
20
PD3
U2
STM8S103F3P6
1SW
2GND
3DIM 4
CSN
5
VIN
U3
PT4115
D1 SS14
C5
104
R5
0.15
L1 47uH
C6
104
C7
105
C8
104
R6 1K
1
2
J1-A 1
2
J1-B
1
2
3
4
J6
1SW
2GND
3DIM 4
CSN
5
VIN
U4
PT4115
D2 SS14
C9
104
R7
0.15
L2 47uH
1SW
2GND
3DIM 4
CSN
5
VIN
U5
PT4115
D3 SS14
C10
104
R8
0.15
L3 47uH
1
2
3
4
5
6
J3-A
R1
10K
R2
75.0K
C12.2uf
C2
82pF
R3
10K
R4
10K
C3
10uf
12
LED1
R
12
LED2
R
12
LED3
G
12
LED4
G
12
LED5
B
12
LED6
B
1
2
3
4
5
6
J3-B
C4
47uF
C11
104 C13 104
1
2
3
J4-A
1
2
3
4
J5-A
1
2
3
4
J2-B
R9
10K
1
2
J7-A
R10 61.9
FB
L4 301
FB
L5 121
1
2
3
4
5
J8-A
11B
22B
33B
44B
55B
66B
77B
8E9
COM
10
7C
11
6C
12
5C
13
4C
14
3C
15
2C
16
1C
U7
ULN2003ADR S1
1
S2
S3
S4
G
5D
6D
7D
8D
Q4
CEM4435A
1
2
3
J9-A
1
2
3
J9-B
1
2
3
4
S2
D4
1N4148
R14 5.6
2
1
3
Q1
MMBT3904
R15
3K
R16
10K
R17
10K
R18
20K
C15
1000uF
1IN 2
GND
3EN 4BYP
5
OUT
U8
LP2985AIM5-5.0
C14
104
R11
75K
R12
20K
C12
10uF
R13 510
R19 510
R20 510
R-
R+
+VDD
RED_LED
RED_LED
GREEN_LED
BLUE_LED
+5V
NRST
SWIM
D
C
B
A
+5V
SWIM
NRST
G-
G+
+VDD
GREEN_LED
B-
B+
+VDD
BLUE_LED R+
R-
G+
G-
B+
B-
+5V
+5V
R+
G+
B+
R-
G-
B-
+VDD_ON/OFF
GND
GND
GND GND GND
+VDD
A
B
C
D
+VDD
GND
+5V
DGND
DGND
DGND
DGND
DGND
DGND
+VDD
AMP_ON/OFF
+VDD_ON/OFF
AMP_ON/OFF
