IPC Eagle RO CHEM User manual

1
RO CHEM
REMOTE CONTROL SPRAYER
Rev A May 2010

2
WARNING!
WARNING!!!! THIS PRODUCT IS DESIGNED TO APPLY
CHEMICALS THAT MAY BE HARMFUL AND COULD CAUSE
SERIOUS PERSONAL INJURY IF INHALED OR BROUGHT INTO
CONTACT WITH THE USER. FAILURE TO READ AND FOLLOW
THE CHEMICAL SAFETY INSTRUCTIONS BEFORE USE AND/OR
MISUSE OF THIS PRODUCT COULD RESULT IN MAJOR
INJURIES OR EVEN DEATH. THIS PRODUCT IS NOT TO BE
USED WITH FLAMABLE OR EXPLOSIVE LIQUIDS. USE SAFETY
GLASSES, GLOVES AND PROTECTIVE CLOTHING WHEN
STATED BY CHEMICAL SAFETY INSTRUCTIONS.
POINTS FOR ATTENTION
1. The battery has been charged before being delivered. However, it will self-
discharge in the course of transportation and storage. Additional charging before
initial use is required.
2. Try your best to avoid operating the sprayer without water in it. This may
damage the diaphragm. Never place the sprayer upside down. Otherwise, the
battery may be damaged.
3. In case a noise is heard from inside the sprayer, or poor atomization occurs after
long periods of use, the sprayer may have a low battery voltage and requires
charging. Connect the plug to an electrical outlet without removing the battery
from the sprayer. A charging time of at least 8 hours is required. The charger
should be placed in a dry, well-ventilated safe place.
4. Trial spraying with clean water is necessary for initial use-to make sure neither
leakage or poor atomization occurs.
5. There are a few points the user should remember while spraying. Wear a mask
and gloves to protect skin and to avoid direct contact of harmful liquids. Never
spray against the wind or spray towards humans, animals or food. Never operate
for extended periods of time under high temperatures. Strict compliance with safety
instructions of chemicals is required. Never operate with flammable liquids.
6. For short-term use, charging is not usually required. For long-term storage,
regular full discharging and recharging are required, with an interval of 2 weeks, a
month, or two months, to ensure the service life of the battery.

3
7. Don’t operate sprayer in temperatures exceeding 100 degrees or lower than 35
degrees.
8. After use for half a year, you should dismantle the base and check whether the
screws are loose. If they are loose, please tighten them. Also, be sure to switch off
power before storage.
9. It is strictly prohibited to keep this sprayer near fire or expose base to water or
immerse the sprayer in the water to clean or to fill it with water. Unauthorized
removal of the charger’s housing is prohibited.
FEATURES
1. Smooth and streamline appearance. The sprayer is ergonomically designed to
conform to the human back making it easy to carry.
2. The sprayer comes with a mini-diaphragm pump which is compact in size, light-
weight, creates good pressure and has an extended service life. It features a
pressure protection switch to prevent over-pressurization.
3. Triple screens prevent foreign matter or particles from clogging the nozzle. The
screen is uniquely designed to allow easy dismantling and cleaning.
4. This sprayer has an under-voltage alert circuit. An alarm will sound when the
voltage of the battery decreases to 10.5 volts. This will protect the battery. The
supplied charging socket can be used as a 12 volt power supply in addition to a
charging unit.
5. Special charger features intelligent three section charging (constant
current/constant voltage/maintenance) and short-circuit/over current/
inverse-connection protection. The indicator lamps of charger: RED-
charging; Green-charged/stand-by.

4
Package Contents
Battery and Battery
Charger
****************
IMPORTANT INFORMATION
****************
The product you have just purchased is a
recharge eable sprayer. Its
performance and the life of the battery
will be greatly reduced if it is not fully
charged before its initial use.
Before the sprayer is used for the first
time it will need an initial charge of 10 to
12 hours. The charger supplied with your
sprayer is equipped with a ready light
that will be red when initially plugged in.
The battery should be charged until this
light turns green.
It is typical for the battery to last from 8
to 10 hours of actual spraying before
having to be recharged. With a full
charge the battery will last for about 20
tanks of 15-Liters or 4-gallons of liquid.
With proper care the battery will last for
100 to 120 charges. Every three months
you should fully charge once. Otherwise
it will reduce the battery charging
capacity.
Connecting the battery charger
Remove the cap. Align and insert the
connector. Screw the connector finger tight.
Plug the charger into an AC outlet. The red
light on the charger should illuminate
indicating the charging process has started.
When the light turns green the battery is
charged and ready for use.
Installing the Nozzle and Bracket
Position bottom bracket piece about 3-4” (7-
10 cm) from end of brush. Insert bolt and
washer.
3-4 inches
Rounded
slot for
nozzle
Straight
slot to
gooseneck
ROChem
Sprayer
Batter y
Charger
Remotes
2
Hose
Nozzle &
bracket
Assembly Instructions
IF YOU HAVE ANY QUESTIONS OR CONCERNS, OR ARE MISSING PARTS PLEASE CONTACT YOUR LOCAL DISTRIBUTOR!

5
Attach top bracket and use washer and wing
nut to loosely attach bracket to gooseneck.
Position bracket as shown.
Position the front of the nozzle so that
the slot is parallel to brush as shown and
insert into bracket.
Position the rear of the nozzle as shown. The
main body of the nozzle should be about
1/16
th
of an inch out from the bracket. If it is
too close you will not be able to connect the
hose properly. Tighten wing nut to clamp
nozzle.
Connecting the Hose
Connect the male end of the hose to the unit.
Connect female end of hose to nozzle and
attach hose to pole as shown.
1/16
th
inch
from
bracket
Attach hose
to pole
Nozzle
slot
should be
parallel to
brush

6
Connecting the harness – Optional
(Remove if you do not want to use)
Take each strap and straighten to remove
any twist in the strap. Connect one clip into
the slot in the base of the unit. Connect the
other strap and clip to the other side of the
base.
Operational Controls
Main unit
Remote Control
OPERATION
Be sure to charge the battery sufficiently prior to operation. The flow rate of the
pump is ½ gallon per minute and the spray nozzle angle is 120 degrees.
1. Fill the sprayer with prepared liquid through the screen and close the sprayer
cover.
2. Turn on the main power switch on the unit.
3. Turn the pump ON by pushing the UNLOCK button on the remote control.
4. Turn the pump OFF by pushing the LOCK button on the remote control.
5. When the tank is empty turn the pump off to prevent damage.
6. When done using the ROChem unit, turn the main power switch off on the main
unit. Only turning off the unit with the remote does not completely shut the unit off.
Battery Charger
connection Main Power
Switch
Hose
connector
ONOFF

7
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The motor fails to start after
being powered on.
-The power cable has
come off.
-The battery needs
recharging.
-The power switch has
been damaged.
-Dismantle the base to
connect the cables
soundly.
-Charging
-Replace the switch.
Abnormal sound heard in the
motor.
- The fastening screws for the
pump are loose.
- Tighten the screws.
Leakage occurs to the bottom
of the base.
- The inlet and outlet tubes of
pump are broken or are loose
at the connection.
- Dismantle the base and
tighten the tube clamps.
Poor Spray Pattern
(Atomization)
-The spraying hole was
clogged.
-Spraying hole and o-
ring worn.
-Seal is upside down.
-Filter screen was
clogged.
-Leakage occurred to
tubes at joints.
-Battery short of power.
-Air remained in the
pump.
-Remove foreign
matter.
-Replace o-rings.
-Correct by reversing.
-Clean with clear water.
-Tighten screws.
-Alarm maybe out of
order, replace it,
charge.
-Remove the nozzle or
extension rod to
discharge the air.
PARAMETERS AND SPRAY-HEAD FLOW RATE
1. Type: RO Chem 6. Size: 1.58”x7.5”x21.85” / 40 x 190 x 555mm
2. Pump: Mini-Diaphragm 7. Capacity: 4 Gallons / 15 liters
3. Charger: Input AC100-240V 8. New Weight: 16 lbs / 7.4kg
50/60 hz, Output DC12v 12a
9. Battery: 12v10ah (fully enclosed,
4. Flow rate: ½ GPM / 2.2 LPM maintenance free) Max Pressure: 0.4-0.45
Mpa
5. Nozzle: 120 degree

8
IPC Eagle warrants to the original purchaser only that this
product will continue to function as intended if used in accordance with
operating instructions (under NORMAL CONSUMER USE) for 90
DAYS. If this product fails to function as intended – PLEASE
CONTACT THE LOCAL DISTRIBUTOR. We will, at our option,
repair or replace any non-functioning parts without charge (shipping
and handling charges will apply) IPC Eagle shall have the option of
requiring the return of the non-functioning product to the address listed
below together with the proof of purchase to establish a claim under this
warranty. This warranty does not apply to damage resulting from
accident, misuse, neglect, alterations, operation not in accordance with
instructions, commercial use, or normal wear.
ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND FITNESS FOR
CONSUMER USE, ARE LIMITED TO THE DURATION SPECIFIED
ABOVE. IPC EAGLE’S LIABILITY IS LIMITED SOLELY TO THE
REPAIR OR REPLACEMENT OF THE NON-FUNCTIONING
PRODUCT OR PART. IPC EAGLE EXCLUDES LIABILITY
UNDER THIS WARRANTY FOR ANY AND ALL INCIDENTAL
AND CONSEQUENTIAL LOSS OR DAMAGE.
IF YOU HAVE ANY QUESTIONS OR CONCERNS, OR ARE
MISSING PARTS PLEASE CONTACT YOUR LOCAL
DISTRIBUTOR!
IPC EAGLE
2955 Lone Oak Drive
Eagan, MN 55121
Ph. 800-486-2775 www.ipceagle.com
