Iper Ceramica NEPTUM User manual

INSTALLATION MANUAL
NEPTUM Sliding Doors Shower Enclosure- Reversible
(For a complete Shower Enclosure you need two cartons)
Step 7
Step 8
3.2mm
View from inside
View from inside
7
3.2mm
Screw M4x8
Screw M4x8
BayKer Italia S.p.A. via Ghiarola Nuova, 85/87 – 41042 Fiorano Modenese (MO) – ITALY
www.iperceramica.it

1
3.2mm
6mm
Step 5
The longer ones
are for door
panels.
The shorter ones
are for fixed
panels.
Step 6
6
View from inside

1xInstallation
Instruction.
[4] 6xScrews M4x8.
2
Box Contents x2:
[3] 1xWall Profiles.
[5] 1xFixed Panel.
[10] 2x Rails.
4xScrews M4x12.
4xScrew Caps.
[9] 1xHandle Sets.
[11] 1xCorner Connectors.
[8] 1xMagnet Seals.
[7] 2xBottom Rollers.
1xDoor Panels.
2xTop Rollers.
[6] 1xLonger Deflectors
1xShorter Deflectors
[1] 4xWall Plugs.
8xScrews M4x35.
[2] 6xScrew Caps.
Step 3
Step 4
5
The bottom rollers are
with springs.
Screw M4x8
Screw M4x8

3
Assembly Drawing
[1] 8xWall Plugs
[2] 16xScrews M4x35
[3] 20xScrew Caps
[4] 2xWall Profiles
[5] 12xScrews M4x8
[6] 2xFixed Panels
[7] 4xRails
[8] 4xDeflectors
[9] 4xBottom Rollers
[10] 2xDoor Panels
[11] 2x Magnet Seals
[12] 2xHandle Sets
[13] 4xTop Rollers
[14] 2xCorner Connectors
[1]
[2]
[3]
[4]
[5]
[9]
[10]
[7]
[8]
[14]
[11]
[12]
[6]
[13]
Installation Steps
Step 1
View from inside Notes:Make sure the base is level
before installation View from inside
Step 2
4
Screw M4x35
Screw M4x35
Screw
M4x35 Screw
M4x35
