IPM DM-101 Parts list manual

DM-101
Drum Mixer Instructions
& Parts
OPERATING MANUAL
IPM, INC.
Manufactured by International Pump Manufacturing, Inc.

2
DM-101
Air Drum Mixer
OPERATIONS MANUAL
WITH PARTS IDENTIFICATION
This manual contains IMPORTANT WARNINGS and INSTRUCTIONS. Read and
retain for reference.
International Pump Mfg, INC.
3107, 142nd Avenue E Suite 106,
Sumner, WA 98390
U.S.A.
TEL: [phone]
FAX: [phone]
Website : www.ipmpumps.com
For Technical Service Call Your Local Distributor
Copyright 2008; International Pump Mfg, Inc.
Printed December 2008
WARNING: The equipment described herein must only be operated or serviced by
properly trained individuals, thoroughly familiar with the operating instructions and
limitations of the equipment.
Notice: All statements, information and data given herein are believed to be accurate and reliable but are presented without
guarantee, warranty or responsibility of any kind expressed or implied. Statements or suggestions concerning possible use of IPM
equipment are made without representation or warranty that any such use is free of patent infringement, and are not
recommendations to infringe any patent. The user should not assume that all safety measures are indicated or that other measures
may not be required.

3
TABLE OF CONTENTS
1.0
SAFETY WARNING………………………...
4
2.0
INSTALLATION, Tips, Operations..……...
5-6
3.0
OPERATIONS……………………………….
6
4.0
TECHNICAL SPECIFICATIONS...………...
7
4.5
TECHNICAL BROCHURE …………………
8
5.0
PARTS / IDENTIFICATION………………….
9-10
6.0
WARRANTY AND DISCLAIMER …….…...
11
7.0
DC ELECTRIC, Limited Production………..
12

4
1.0 SAFETY WARNINGS
Please read and observe all warnings contained in this operations manual before any
attempt to operate the equipment.
Misuse of Equipment
Misuse of the Equipment can cause serious injury. Use the equipment only for its
intended purpose. Care should be taken to prevent over pressurization of the pump or
accessories connected to it. Use only proper parts in good condition. Use the pump only
with compatible fluids. Improper use or misuse of this equipment could result in fluid
being splashed on the skin or in the eyes, serious bodily injury, property damage, fire or
explosion.
Make daily check on the equipment and repair damaged or worn parts immediately.
Do not alter this equipment, doing so could cause it to function incorrectly and could
cause serious injury.
Material & Fluid compatibility
Always ensure the chemical compatibility of the fluids and solvents with the wetted parts
in the pump and any components. Check the fluid manufacturer’s data sheets and
specifications before using the fluids or solvents in this pump.
Pressurized Hoses
Because the hoses are pressurized, they present a danger should the fluid escape at
high pressure. This escaping fluid pressure can spray out and cause serious bodily
injury or property damage. Ensure that the hoses do not leak or rupture due to wear,
misuse or damage.
The hoses should be handled properly - do not pull on the hoses to move the equipment
around. Use the hoses only for fluids in which they are compatible both for the inner
liner of the hose and the outer covering. Use care not to exceed the temperature rating
of the hose.
Before each use, ensure that the fluid couplings are tight and that the entire length of
hose is not worn or damaged. Check the entire hose for leaks, bulging cover, damage,
abrasion or cuts. These conditions may cause the hose to fail that could result in
splashing of pressurized fluid on the skin, or in the eyes and cause serious bodily injury
or property damage.
Pressure Specification
The maximum working fluid pressure of this equipment is 180 psi (12.5bar) at the
maximum incoming air pressure of 180 psi (12.5bar). Ensure all equipment and
accessories used with this pump are rated to withstand the maximum working pressure
of this mixer. Never exceed the maximum working pressure of the mixer or any device
attached to air.

5
2.0 INSTALLATION TIPS AND OPERATIONS
THROUGH BUNG AIR DRUM MIXER OPERATING TIPS:
We have installed an 8" blade on the mixer to get maximum pull of heavy materials from the
bottom of the drum. Upper blades are 6" to help clear the side of the drum as the mixer comes
through the bung.
NOTE: If you do Not have a Center bung in your drum: To prevent blades from hitting
the sides, we recommend taking an 18" piece of 2" pipe threaded on one end and screw into
your bung, gently!! pull the top of the pipe away from the center of the drum tilting the bung for
better mixer clearance. Reverse of this is bung bend procedure is easy after mixing if desired.
It does not take much to get this clearance.
Depending on the viscosity of the material and speed determines the amount of air that you will
need. Usually one mixes at a slower speed and can get by on a 10-15 CFM air compressor.
Try to give your product a good 15-20 min. mix. Remember, slower speeds do not entrain as
much air into the material, but you need to pull some vortex to get good mix.
Looking from the top down over the air motor, the rotation should be clockwise for
proper swing-out of the blades.
Some products are the type that set up or seize the folding blades if they set out in the open air.
We have found a relative easy way to clean the blade. Make sure that you are in a SAFE
BREATHING AND NON FIRE HAZARD AREA. Since the blades are stainless steel a welding
cutting torch works well to actually burn off the hardened material, and then lubricate the hinge
parts with WD-40 or any equivalent. Working them together will bring them back to a loose
swing out state again. You do NOT need to get the metal red hot !
You can use the 3/8” needle valve as a metering or speed control. A small amount of air tool oil
in the air inlet helps to lubricate the air motor. If you have moisture in your air, in long-mixing,
the muffler can cause freezing. Simply take the muffler apart and wash in warm water and dry
out.
Try NOT to drop the air motor on the hex top cap, it is plastic! Parts are available.
THIS MIXER WILL WORK FOR MANY YEARS WITH PROPER MAINTENANCE.
The DM -101 Drum Mixer is a very effective tool in mixing in 55 gallon drums. Complete mixing
can be achieved in short periods of time, usually within 30 minutes. The unique design of the
blade allows the mixing blade to pass through the 2” NPT opening in the drum. With two -6”
and one 8” blade, optimum mixing is achieved throughout the drum.

6
Tips:
Don’t pull too deep of
vortex.
on Vortex
This will entrain air.
A vortex is always
vertical.
Tilting the barrel will help
keep from entraining air
into your product
Technical Specifications
For proper mixing the blades should be 1/3 the diameter of the drum,
24” drum needs a 8” blade.
Auger type mixers don’t work.
Mix time: ½ hour
ISO Drum – Never mix! Only use in the “B” Resin drum.
IPM sells these 6” & 8” mixer blades
Collapsible Mixer Blades
No, you do not need to use a drum mixer in the Spray Polyurethane
Foam Industry but, if you are using the fast set coatings like the
Polyurea’s, then the “B” Component does need to be mixed.
THROUGH BUNG AIR DRUM MIXER
THE MOST EFFICIENT AND ECONOMICAL AIR MIXER ON THE MARKET
KEEPS DRUM SEALED WHILE MIXING AT ANY SPEED
BLADES CANNOT SPIN ON HEXAGON SHAFT
AIR MOTOR
Maximum power............……………………............................................................ 1.7 HP
Maximum air flow.......................................……………………................................ 65 CFM
Maximum inlet air pressure..................................................…………………........ 100 PSIG
Maximum torque.................................................................................…………… 57 In. lbs.
BLADES
TWO upper 6" dia. each with 5 SS blades
ONE bottom 8" dia. with 5 SS blades
WEIGHT
Total weight of complete unit ...…………………….............................................. 12 lbs.

7
4.0 TECHNICAL SPECIFICATIONS

8
5.0 PARTS IDENTIFICATION
DM112
DM106
6745-2
DM111
DM102
DM107
DM108
DM103
DM104
DM113
DM109
DM110

9
PART NUMBERS:
New
Part
Old Part
Number
Number
Qty/Assy.
Description
604001
DM-101
1
Drum Mixer
500504
DM-102
1
Drum Adapter
700036
DM-103
2
#6 Mixing Vane Assy.
700037
DM-104
1
#8 Mixing Vane Assy.
700052
DM-105
-
Mixing Shaft Assy. (w/out
Coupling)
612001
DM-106
1
Air Motor
610014
DM-107
1
Coupling
500513
DM-108
1
Mixing Shaft
610015
DM-109
1
3/8" x 1/4" Bushing
610016
DM-110
4
Set Screw
610017
DM-111
3
Mounting Bolt
500028
6745-2
1
Male Coupling
500029
DM-112
1
Needle Valve
602001
DM-113
1
Muffler

10
6.0 WARRANTY AND DISCLAIMER
International Pump Manufacturing, Inc. (IPM) warrants the equipment it
manufactures to be free of defects in material and workmanship for a period of
one year from the day of sale by an authorized IPM distributor to the original
purchaser. IPM will at its discretion repair or replace any part of the equipment
proven to be defective. This warranty applies only when the equipment is used
for the intended purpose and has been installed, operated and maintained in
accordance with the written recommendations.
A condition of the warranty is the prepaid return of the equipment to an
authorized distributor of IPM who shall provide verification of the warranty claim.
IPM will repair or replace, free of charge any parts found and verified to be
defective. Transportation will be prepaid for the repaired or replaced parts under
warranty. Should the inspection of the equipment not reveal any defect in
material or workmanship, repairs will be made at standard charges, which
include parts, labor and transportation.
The warranty does not apply or nor will IPM be liable for damage, wear, or
malfunction of equipment caused by improper installation, misuse, abrasion,
corrosion, negligence, accident, tampering, lack of improper maintenance, or by
substitution of non-IPM parts. Additionally IPM shall not be liable for and the
warranty does not apply to wear, damage, or malfunction caused by
incompatibility of accessories, components, structures, equipment or materials
not supplied by IPM. The warranty does not apply to nor will IPM be responsible
for the improper operation, maintenance, design, manufacture, installation of
components, accessories, equipment or structures not supplied by IPM.
The warranty is void unless the Warranty Registration Card is properly completed
and returned to International Pump, Inc. within ONE month of the date of the
sale.
LIMITATIONS AND DISCLAIMERS
This warranty is the sole and exclusive remedy for the purchaser. No other
warranties (expressed or implied), including warranties for fitness of purpose or
merchantability, or non-contractual liabilities are made, including product liability,
whether on negligence or strict liability basis. Liability for directly special or non-
contractual damages or loss is expressly excluded and denied. IPM’s liability
shall in no case exceed the amount of the purchase price.
IPM does not warrant and disclaims implied warranties of merchantability and
fitness for a particular purpose, components, accessories, equipment, materials
sold but not manufactured by IPM. These items (switches, hoses, etc.) are
subject to the provisions of the warranty of the manufacturer of these items. IPM
will provide reasonable assistance with warranty claims on these items.

11
7.0 DC ELECTRIC MIXER
DC electric, gear reduced drum mixer
Types: Air, Hydraulic, DC Electric motors
Electric model, no air needed, Quiet!
Variable up to 700 rpm
2.25 ft. lbs for ¾ hp motor, torque x’s 3.2 gear ratio
equals 7.2 ft lbs. torque output.
36 in./lbs torque for a ¾ hp motor, torque x’s 3.2
gear ratio, equals 115 in/lbs torque.
.75 hp x’s 3.2 equals 2.4 hp of torque
This is a unique and powerful mixer!

3107 142nd Avenue East, Suite 106
Sumner, Washington
Telephone: [phone] Fax: [phone]
Website:
ipmpumps.com
Revised 12/16/08
