IQsocket IQSW-RS232 User manual

User manual www.IQsocket.eu
Intelligent power
sockets
IQsockettm WALL / IQSW-RS232
…makes your life more comfortable
User manual
IQSW-RS232
documentation v1.4 R1
(firmware 1.4)

User manual www.IQsocket.eu
Table of Contents
1. Introduction..................................................................................... 3
2. Device description ............................................................................ 3
3. Installation ...................................................................................... 4
4. Basic control commands .................................................................... 4
4.1 Controlling output power by commands .......................................... 4
4.2 Watchdog feature......................................................................... 4
5. Default values .................................................................................. 5
6. Firmware upgrade ............................................................................ 5
7. LED lights ........................................................................................ 5
8. Technical specification....................................................................... 5
9. Maintenance and security instructions ................................................. 6
10. Ordering ........................................................................................ 6
11. Declaration of conformity................................................................. 6
Appendix A .......................................................................................... 7
Serial interface pinout ........................................................................ 7
Output power socket switching scheme ................................................ 7

2008 NETCONS, s.r.o.
Page 3 of 7
1. Introduction
Noone doubt in this information age, that communication technologies help us
with everyday life. Communication skills are more and more required at
devices, which had no networking features in the past. Intelligent power socket
IQsocket IQSW-RS232 is a member of wide portfolio of intelligent power
sockets which help to people perform many tasks remotely. IQsocket products
can provide:
Various communication interfaces
Various output power sockets
Sockets and plugs for different countries
Various input/output interfaces
2. Device description
Intelligent power socket IQsocket IQSW-RS232 control otput power socket
different ways on serial RS232 interface. Power can be controlled manually by
serial commands or automatically when the event is present. In general we can
control output power socket different ways:
Turning on/off manually by AT command
Restarting on serial interface inactivity (Watchdog feature)
Manual restarting by AT command
Output power socket: This socket is
controlled over serial interface
Input power plug : Input power for
this power socket
Output power socket has 230V with maximal load current 16A.
Serial interface: RS232
communication interface

2008 NETCONS, s.r.o.
Page 4 of 7
3. Installation
Attach serial cable with DB9
connector and configure serial
interface of device connected to
IQS-RS232 to send keep-alive
data periodically.
Serial interface of monitored device must be configured for following
parameters:
9600 Baud, bits 8, No parity, stop bits 1, No flow control
4. Basic control commands
4.1 Controlling output power by commands
Commands which control output power socket over serial RS232 interface has
following syntax:
Command
Description
Answer
AT+TURNON
Turn output power socket on. Applicable only if
WATCHDOG=OFF.
-–-
AT+TURNOFF
Turn output power socket off. Applicable only if
WATCHDOG=OFF.
-–-
AT+RESET
Interrupt ouput power for 10 seconds. Applicable
anytime.
-–-
AT+TURN?
Request for output power status
ON
OFF
4.2 Watchdog feature
Command
Description
Answer
AT+WATCHDOGON
Turn on watchog feature. Power socket monitor
serial interface for activity and provides power until
no data are received within 4 minutes.
-–-
AT+WATCHDOGOFF
Turn off watchog feature.
-–-
AT+ECHOON
Turn on all ECHO messages. Useful feature with
some applications.
-–-
AT+ECHOOFF
Turn off all ECHO messages. Useful feature with
some applications.
-–-
If watchdog feature is activated and no data are coming within 4 minutes (it’s
expected that monitored device stopped to work from some reasons), IQsocket
interrupts power on output power socket for 10 seconds. Sending keepalive
data must be performed by any way (form linus by echo command, or by any
special OS tool).

2008 NETCONS, s.r.o.
Page 5 of 7
IQsocket is switched into monitoring mode 10 minutes after it is
powered on.
5. Default values
Each new device is preconfigured with default parameters.
5.2. Default values
Parameter
Value
Output power
ON
WATCHDOG
ON
ECHO
OFF
6. Firmware upgrade
Firmware upgrade can be performed only by authorised specialist or by
authorised service center.
7. LED lights
POWER/ACT
CHANGING RED AND GREEN 5 minutes from socket is turned on
LIGHTS GREEN Output power is ON
LIGHTS RED Output power is OFF
POWER/ACT
Indicator of output power socket status and
data activity
8. Technical specification
Model
IQSW-RS232-F, IQSW-RS232-E
Input power plug
230V / 50Hz , CEE 7/7
Output power socket
230V , CEE 7/4 German "Schuko" earthed
230V, CEE 7/4 French type
Data interfaces
RS232 , DB9 connector
Power switching
Output power: Relay, 230V/16A (2s), 10A long-term

2008 NETCONS, s.r.o.
Page 6 of 7
Management
Configuration over serial interface
Indicators
POWER/ACT: two-color LED
Software features
Turn on/off manually
Manual restart
Watchdog
Weight netto/brutto
275 g / 315g
Operating temperature
-10 up to +50 Celsius degrees
9. Maintenance and security instructions
Product is designed for indoor use such as house, block of flats or office.
Keep against humid, wet or chemically aggresive environment. Products is not
designed for heavy industry applications in aggressive environment. Keep
against shaking, bumps or any breaks because it can be damaged.
Improper use, unauthorised disassembling or additional manual changes on
device can cause termination of warranty. Device doesn’t guaranties
disconnection from power source, only functional switching is performed.
10. Ordering
Product family IQsocketWALL uses following ordering scheme:
IQSx-y-z Example: IQSW-RS232-E
Product family: W=WALL | R=RACK | D=DIN | B=BOARD
Product model: GSM | IP | RS232 | HDO | IPGSM
Output Socket type: F=Schuko | E=French
11. Declaration of conformity

2008 NETCONS, s.r.o.
Page 7 of 7
Appendix A
Serial interface pinout
Output power socket switching scheme
