This is the safety alert symbol. It is used to alert you to potential physical injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
This appliance can be used by children aged from eight years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Safety Information
Important Safety Instructions
BFP
Risk of electric shock Class II equipment Read operator’s
manual
Risk of fire For indoor use only Keep out of reach
of children
Backfeed Protection
General symbol for
recycling
Short-circuit-proof safety
isolating transformer
Switch mode power supply
Separate Supply Unit
This owner’s guide includes information for Regulatory Model(s): RVF-Y1
SAVE THESE INSTRUCTIONS
WARNING: When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USE
WARNING: To reduce the risk of injury or damage, read and follow the safety precautions
when setting up, using and maintaining your robot.

EN
• Do not use in extremely hot or cold
environments (below -5˚C/23˚F or above
40˚C/104˚F).
• Keep hair, loose clothing, fingers, and all
parts of body away from any openings
and moving parts.
• Do not operate the Appliance in a room
where an infant or child is sleeping.
• Do not use Appliance on wet surfaces or
surfaces with standing water.
• Do not allow the Appliance to pick up
large objects like stones, large pieces
of paper or any item that may clog the
Appliance.
• Do not use Appliance to pick up
flammable or combustible materials such
as petrol, printer or copier toner, or use in
areas where they may be present.
• Do not use Appliance to pick up anything
that is burning or smoking, such as
cigarettes, matches, hot ashes, or
anything that could cause a fire.
• Take care not to damage the power cord.
Do not pull on or carry the Appliance or
charging station by the power cord, use
the power cord as a handle, close a door
on the power cord, or pull power cord
GENERAL
WARNING
• The Appliance must be used in
accordance with the directions in this
Instruction Manual. iRobot cannot be held
liable or responsible for any damages or
injuries caused by improper use.
• For the purposes of recharging the battery,
only use the Charging Station Model
ADH-N1 provided with the appliance.
• The supply terminals are not to be short-
circuited.
• Please make sure your power source
voltage matches the power voltage
marked on the charging station.
• For INDOOR household use ONLY. Do not
use the Appliance in outdoor, commercial
or industrial environments.
• Do not operate the Appliance in an area
where there are lit candles or fragile
objects.
WARNING: Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury.
NOTICE: Indicates a hazardous situation that, if not avoided, could
result in property damage.

EN
• Remove the Appliance from the charging
station and turn OFF the power switch
to the Appliance before removing the
battery.
• Exhausted batteries are to be removed
from the Appliance and safely disposed
of.
• Please dispose of used batteries
according to local laws and regulations.
• The power supply is not to be repaired
and not to be used any longer if it is
damaged or defective.
• Do not incinerate the Appliance even if it
is severely damaged. The batteries can
explode in a fire.
• Do not charge other iRobot robots with
the provided Home Base charging station.
CAUTION
• Clear the area to be cleaned. Remove
power cords and small objects from the
floor that could entangle the Appliance.
Tuck rug fringe under the rug base, and lift
items such as curtains and tablecloths o
the floor.
around sharp edges or corners. Do not
run Appliance over the power cord. Keep
power cord away from hot surfaces.
• Do not use with a damaged power cord
or receptacle. Do not use the Appliance
or charging station if it is not working
properly, has been dropped, damaged,
left outdoors, or come in contact
with water. It must be repaired by the
manufacturer or its service agent in order
to avoid a hazard.
• If the power cord is damaged, it must
be replaced by the manufacturer or its
service agent in order to avoid a hazard.
• The plug must be removed from the
receptacle before cleaning or maintaining
the charging station.
• Turn OFF the power switch before cleaning
or maintaining the Appliance.
• The robot contains batteries that are only
replaceable by skilled persons. To replace
or remove the battery, please contact
Customer Care.
• Use only the original rechargeable battery
and charging station provided with the
Appliance from the manufacturer. Non-
rechargeable batteries are prohibited.

EN
• Do not put objects into the suction intake.
Do not use if the suction intake is blocked.
Keep the intake clear of dust, lint, hair, or
anything that may reduce air flow.
NOTICE
• The battery must be removed and
discarded according to local laws and
regulations before recycling or disposal of
the Appliance.
• Do not use non-rechargeable batteries.
Use only the rechargeable battery supplied
with the product. For replacement,
purchase identical iRobot battery or
contact iRobot Customer Care for
alternative battery options.
• If the robot will not be used for a long time,
fully charge the robot and power OFF for
storage and unplug the charging station.
• When not using the charging station for a
long period of time, please unplug it.
• Do not use without dust bin and/or filters in
place.
• To satisfy RF exposure requirements, a
separation distance of 20 cm (7.9 in) or
greater should be maintained between
this device and any persons during
device operation. To ensure compliance,
operation at any distance closer than the
stated minimum is not recommended. The
antenna used for this transmitter must not
be co-located or operated in conjunction
with any other antenna or transmitter.
• To disable the Wi-Fi module on Roomba
Combo, turn the robot’s power ON. Place
the robot on the charging station, making
sure that the charging contacts on the
robot and the charging contacts on the
charging station make a connection.
Press and hold the CLEAN button on
the robot for 20 seconds, until Roomba
Combo emits 3 beeps. To enable the Wi-
Fi module on Roomba Combo, turn the
robot’s power OFF, and then back ON.
The Wi-Fi module will be enabled when
Roomba Combo is restarted.

EN
Specifications
* Technical and design specifications may change as we continue to improve our product.
Output power of the Wi-Fi module is less than 100 mW.
Model RVF-Y1, Roomba Combo™
Rated Input 20V - 0.8A
Charging Station Model ADH-N1
Rated Input Voltage 100-240 V AC Rated output
voltage 20 V DC
Rated Output Current 0.8 A Rated power 25 W
Frequency Bands 2400-2483.5 MHz
Maximum EIRP Output
Power 15.46 dBm at 2442 MHz
O Mode Power Less than 0.50 W
Networked Standby Power Less than 2.00 W

1 For more information, visit global.irobot.com
EN
Top View
About Your Roomba Combo™ Robot Vacuum & Mop
Under the Cover
Buttons & Indicators
Cover
LiteTouch® Sensor
Tank Release
Button Status Indicator
Wi-Fi Indicator
CLEAN Button
Power Switch
RESET Button
Dust Bin and Filter
Multi-Function
Cleaning Tool
Bottom View
Cli Sensor
Cli Sensor
Cli Sensor
Charging Contacts
Edge-Sweeping
Brush Edge-Sweeping Brush
Main Brush
Wheels
Caster Wheel
Battery Door
Tank
Rear Wheel
Water Outlets

Roomba Combo™ Owner’s Guide 2
EN
Advanced Mopping System
Washable Microfibre
Cleaning Pad
Cleaning Pad Plate
Tank
Water Inlet
Home Base Charging Station
IR Sensor Window
Charging Contacts
Dust Bin and Filter
Sponge Filter
High Performance Filter
Dust Bin Handle
Dust Bin Lock
Pre-Filter

3 For more information, visit global.irobot.com
EN
• Make sure to turn your robot’s power
switch to the ON position before charging.
‘I’ = power ON, ‘O’ = power OFF
• Place your robot on the charging station making sure the metal
charging contacts on your robot and charging station make a
connection.
• Empty any remaining water from the tank and remove the cleaning
pad plate before charging your robot.
• When your robot is not cleaning, it is best to keep it powered ON and
charging instead of powered OFF.
• For long-term storage, fully charge your robot, turn o the robot by
switching the robot’s power switch to the OFF position and unplug the
charging station.
Positioning the Home Base Charging Station
Place the charging station on a level floor surface against the wall.
Keep the immediate area 1.5 m (5 ft) in front of the charger and
0.5 m (1.6 ft) on both sides of the charging station clear of objects
and reflective surfaces.
Charging
Setting Up Your Roomba Combo™ Robot Vacuum & Mop
CLEAN Button Lights While Charging
Pulsing: Charging
O: Fully Charged
Good Wi-Fi®Coverage
*Objects are not to scale.
1.5 m (5 ft)
in front
0.5 m (1.6 ft)
both sides
0.5 m (1.6 ft)
both sides Note: Charge your robot for at least four hours before the first use.

Roomba Combo™ Owner’s Guide 4
EN
Before you start cleaning, remove any obstacles from the area.
Home Prep
Before using your robot
near an area rug or on
a short-pile area rug
with tasseled edges,
please fold the edges
of the area rug under
themselves.
Remove excess clutter
from floors before
cleaning.
Do not use your robot on
surfaces with standing
water. If water has got
into your robot, it must
be repaired by iRobot in
order to avoid a hazard.
1
2
3
iRobot Home App
Note: 5.0 GHz Wi-Fi is not compatible with this robot.
Download the iRobot Home App and connect to Wi-Fi ®
• Follow step-by-step instructions to set up and use your Roomba
Combo™ robot vacuum and mop.
• Customise your robot’s settings. You can control the suction
power of the vacuum and the water output of the mop in the app.
• Set an automatic cleaning schedule.
• Utilise Spot Clean to clean specific areas using your robot.
• Link to your smart home accounts to enable voice control
of your robot.
• View tips, tricks, and answers to commonly asked questions
including how to pair your Roomba Combo™ robot vacuum
and mop with other smart devices.

5 For more information, visit global.irobot.com
EN
Cleaning
• To ensure the best performance, it is recommended to keep the
water tank attached to the robot during cleaning jobs, even when
mopping is not desired.
• When starting a cleaning job, the status indicator lights will blink
to indicate the cleaning navigation selected. When straight-line
cleaning navigation is selected, the status indicator lights will blink
from left to right. When reactive cleaning navigation is selected,
the status indicator lights will blink simultaneously.
• The CLEAN button on the robot stops glowing after the robot is
paused for more than 10 minutes. Press the CLEAN button on the
robot to wake up the robot.
• Your robot will return to the charging station at the end of a
cleaning job or whenever it needs to recharge.
Just Press CLEAN
Tap to Start/Pause/Resume
Tap twice to switch between
cleaning navigation patterns
Spot Clean
Your robot has a spot clean mode that can be accessed through
the iRobot Home App. This is applicable for an area of highly
concentrated dirt or dust. In spot clean mode, your robot will
spiral outward about 2 feet (0.6 meter) and then spiral inward to
end where it started.

Roomba Combo™ Owner’s Guide 6
EN
When straight-line cleaning navigation is set:
• Your robot automatically conducts route planning when cleaning. If
your robot is paused during cleaning, it will reconfigure the route and
restart.
• Your robot may pause temporarily to recalculate its cleaning
path. This is normal. The frequency and duration of the pause is
determined by room complexity.
• If the cleaning area contains both bare floors and carpet, barriers
(e.g. a closed door) should be set between dierent floor types and
cleaning navigation patterns should be set accordingly. If both floor
types are to be cleaned in one cleaning cycle, reactive cleaning
navigation should be set.
Cleaning Navigation Selection
Your robot has two cleaning patterns to choose from to eectively clean
dierent floor types. The cleaning pattern can be switched by tapping
the CLEAN button twice or through the iRobot Home App.
Reactive Cleaning Navigation
should be set when cleaning
carpet. Your robot cleans in a
straight-lined, random pattern
and changes direction when it
encounters an obstacle.
Straight-Line Cleaning Navigation
is the robot’s default pattern and
should be set when cleaning bare
floors. The robot plans the most
ecient route, cleans in a back and
forth straight-line pattern, returns
to clean missed spots, then cleans
room edges before completing the
cleaning cycle.
If the mopping pad plate and
mopping pad are attached, your
robot will automatically use this
pattern.

7 For more information, visit global.irobot.com
EN
4 capfuls
per tank
Retail: Full size
(Sold separately)
Add water and cleaning
solution (optional) into the
tank.
Attach the cleaning pad and the
cleaning pad plate. Install the tank.
Your robot has an optional mopping system using a
washable microfibre cleaning pad and cleaning pad plate
attached to a proprietary tank. The washable cleaning pad
automatically damp mops the floor.
• Residual water may be present in the tank as a result of
quality testing.
• Empty the tank and remove the cleaning pad plate before
cleaning on carpet. Be sure to replace the empty tank.
• When using the mopping system, fold area rug edges
under themselves so your robot will avoid the rug.
• After your robot finishes mopping, empty any remaining
water from the tank and replace the tank.
• Empty any remaining water from the tank and remove the
cleaning pad plate before charging your robot.
• If wetter mopping is desired, wet the cleaning pad before
attaching the pad to the cleaning pad plate.
Mopping System
1 2
Cleaning Solution
When mopping, you may
add Braava jet®Hard Floor
Cleaning Solution to the tank
before adding water. This
product is a concentrate.
Important: Please visit the Help section in the iRobot Home App
for a list of cleaning solutions that can be safely used and won’t
risk damage to your robot.
Note: When the robot is operating with the mopping attachment,
only the straight-line cleaning navigation will be available.
Retail: Full size
(Sold Separately)
4 capfuls
per tank

Roomba Combo™ Owner’s Guide 8
EN
If your robot detects a problem and needs your assistance, it emits alarm beeps and the status indicator light illuminates.
Alarm Sound Status Indicator Light Problem Solution
/Flashes twice and turns o once
your robot is powered ON. Low battery Power ON the robot. Manually place your robot on the charging station and charge.
One Beep Flashes RED. Wheel malfunction Clean and remove any hair or debris from the wheels.
Two Beeps Flashes RED. Main brush malfunction Clean and remove any hair or debris from the main brush.
Three Beeps Flashes RED.
Wheel malfunction
Turn over the robot and press down on the wheels to
check for a clicking sound. If they do not click, please
contact Customer Care.
Encountered a problem while running
and stops Manually remove any obstacles and restart the robot.
Four Beeps Flashes RED. Dust bin malfunction Remove and reinstall the dust bin. If the robot still emits
the alarm, please contact Customer Care.
Five Beeps Flashes RED. Low battery Place the robot on the charging station to charge.
Six Beeps Flashes RED. Edge-sweeping brush malfunction Clean and remove any hair or debris from the edge-
sweeping brush.
Seven Beeps Flashes RED. Cli sensor malfunction Clean any dust and debris o of the cli sensors.
Troubleshooting
Further support and instructional videos are available in the iRobot Home App.

9 For more information, visit global.irobot.com
EN
Emptying the Bin
Care and Maintenance
Care and Maintenance Instructions
To keep your robot running at peak performance, perform the
procedures on the following pages. A multi-function cleaning
tool is provided for easy maintenance. Handle with care, this
cleaning tool has sharp edges.
There are additional instructional videos in the iRobot Home
App. If you notice the robot picking up less debris from your floor,
empty the bin, clean the filters, and clean the brushes.
Part Care Frequency Replacement
Frequency
Dust bin, tank, and
cleaning pad plate After each use
Cleaning pad After each use Every 50
washes
Sponge filter/high
performance filter
Once per week (twice
per week if you have a
pet at home)
Every 4-6
months
Main brush Once per week Every 6-12
months
Edge-sweeping brush Once every 2 weeks Every 3-6
months
Caster wheel, cli
sensor, bumper, and
charging contacts
Once per week
Note: iRobot manufactures various replacement parts and
assemblies. Please contact iRobot Customer Care for more
information on replacement parts.
Lift open the robot’s cover
and remove the dust bin.
Open the bin door.
Empty the dust bin.
1
2
3
1
2
Cleaning the High
Performance Filter
Remove the sponge filter and
the high performance filter.
Important: Do not wash the high
performance filter.
Remove debris by tapping
the high performance filter
against your trash container.

Roomba Combo™ Owner’s Guide 10
EN
1
3
2Rinse the dust bin and pre-filter under
running water.
Remove the sponge filter and the high
performance filter from the tank. Turn the robot over and push down both buttons on the brush frame to
remove the brush frame.
Dry the dust bin completely
before reinstalling.
Cleaning the Edge-Sweeping
Brushes
Remove the edge-sweeping brushes. Remove
any hair or debris tangled around the brushes
with the provided multi-function cleaning tool
and wipe with a clean cloth.
1
2
3
Cleaning the Main BrushWashing the Bin
Note: A multi-function cleaning tool is provided
for easy maintenance. Handle with care, this
cleaning tool has sharp edges.
Remove the main brush.
Use the multi-function cleaning tool to cut
o and remove any hair tangled around
the main brush. Clean any tangled hair or
debris from the main brush.
Important: Do not wash the high performance
filter. Remove the filter before washing the bin.

11 For more information, visit global.irobot.com
EN
Wipe the bumper with the brush on the multi-function cleaning tool.
Wipe the cli sensors with the brush on the multi-function
cleaning tool to maintain their eectiveness.
Other Components
Use the multi-function cleaning tool to cut o and remove
any hair tangled around the caster wheel.
Wipe the robot’s and charging station’s charging contacts with a dry
cloth to maintain their eectiveness.

Roomba Combo™ Owner’s Guide 12
EN
Cleaning the Mopping System
After your robot finishes mopping, remove the tank from your
robot, and clean the tank, the cleaning pad, and the cleaning
pad plate immediately.
Press the release button and pull to remove the tank.
Remove the cleaning pad plate and the cleaning pad.
Wash the cleaning pad and lay flat to dry.
Empty any remaining water from the tank.
Wipe the outside of the tank with a dry pad and lay flat to
dry. Avoid direct sunlight.
1
2
3
4
5

13 For more information, visit global.irobot.com
EN
USA & Canada
If you have questions or comments about your Roomba Combo™ robot
vacuum and mop, please contact iRobot before contacting a retailer.
You can start by visiting global.irobot.com for support tips, frequently
asked questions, and information about accessories. This information
can also be found in the iRobot Home App. If you need further
assistance, call our Customer Care team at [phone].
iRobot USA Customer Care Hours
• Monday to Friday, 9 AM – 9 PM Eastern Time
• Saturday and Sunday 9 AM – 6 PM Eastern Time
Outside USA & Canada
Visit global.irobot.com to:
• Learn more about iRobot in your country
• Get hints and tips to improve your Roomba Combo™ robot vacuum
and mop’s performance
• Get answers to questions
• Contact your local support centre
iRobot Customer Care
Hereby, iRobot Corporation declares that this robot
vacuum cleaner model RVF-Y1 is in compliance with the
EU Radio Equipment Directive 2014/53/EU. The full text
of the EU Declaration of Conformity is available at the
following internet address: www.irobot.com/compliance.
Hereby, iRobot Corporation declares that this robot
vacuum cleaner model RVF-Y1 is in compliance with the
EU Radio Equipment Directive 2014/53/EU. The full text of
the UKCA Declaration of Conformity is available at the
following internet address: www.irobot.com/compliance.
Chemical information report listing SVHC (substances of very high
concern) per EU Regulation EU 1907/2006 can be found here:
www.irobot.com/compliance.
This symbol on the product indicates that the appliance must
not be disposed of with unsorted common municipal waste.
As the end-user, it is your responsibility to dispose of the end-
of-life appliance in an environmentally sensitive manner as
follows:
(1) returning it to the distributor/dealer from whom you
purchased the product; or
(2) depositing it in a designated collection point.
Disposing of this product correctly will help save valuable
resources and prevent any potential negative eects on human
health and the environment, which could otherwise arise
from inappropriate waste handling. Please contact your local
authority for further details or your nearest designated collection
point. Penalties may be applicable for incorrect disposal of
this waste, in accordance with your national legislation. More
information may be found at the following source:
http://ec.europa.eu/environment/waste/weee/index_en.htm
Regulatory Information

Roomba Combo™ Owner’s Guide 14
EN
© 2020 iRobot Corporation, 8 Crosby Drive, Bedford, MA 01730 USA. All rights reserved.
iRobot, Braava jet, and LiteTouch are registered trademarks of iRobot Corporation. Home Base and Roomba Combo are trademarks of iRobot Corporation. Wi-Fi
and the Wi-Fi logo are registered trademarks of Wi-Fi Alliance. App Store is a trademark of Apple, Inc., registered in the U.S. and other countries. Google Play is a
trademark of Google, Inc.
