IS5 COMMUNICATIONS iTS12GP User manual

UM-iTS12GP-1.92.2-EN.docx
iTS12GP User Manual
iTS12GP
Intelligent 12 Port Managed PoE Gigabit Card Type Ethernet Switch
NEMA TS 2 and IEEE 802.3az Energy-Efficient Ethernet compliant
Version 1.92.2, Nov. 2022
© 2022 iS5 Communications Inc. All rights reserved.

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 2
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
COPYRIGHT NOTICE
© 2022 iS5 Communications Inc. All rights reserved.
No part of this publication may be reproduced in any form without the prior written consent of iS5 Communications
Inc. (iS5).
TRADEMARKS
iS5Com is a registered trademark of iS5. All other trademarks belong to their respective owners.
REGULATORY COMPLIANCE STATEMENT
Product(s) associated with this publication complies/comply with all applicable regulations. For more details,
refer to the Technical Specifications.
WARRANTY
iS5 warrants that all products are free from defects in material and workmanship for a specified warranty period
from the invoice date (5 years for most products). iS5 will repair or replace products found to be defective within
this warranty period including shipping costs. This warranty does not cover product modifications or repairs
done by persons other than iS5-approved personnel, and this warranty does not apply to products that are
misused, abused, improperly installed, or damaged by accident.
Refer to the Technical Specifications for the actual warranty period(s) of the product(s) associated with this
publication.
DISCLAIMER
Information in this publication is intended to be accurate. iS5 shall not be responsible for its use or infringements
on third parties because of the use of this publication. There may occasionally be unintentional errors on this
publication. iS5 reserves the right to revise the contents of this publication without notice.
CONTACT INFORMATION
iS5 Communications Inc
5895 Ambler Dr., Mississauga, Ontario, L4W 5B7
Tel: 1+ 905-670-0004
Website: http://www.is5com.com/
Technical Support
E-mail: [e-mail]
Sales Contact
E-mail: [e-mail]

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 3
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Authorization
Name & Title
Signature
Date
Prepared
Zornitza Doneva
Reviewed
Afsaneh Rostami
Approved
Boris Tseitin
Document History
Revision
Date
Notes
1
Nov, 2018
Source document User manual_IGPCS-9084GP_V2.0 for iS5.doc
received from Oring.
1A/ 1B
Nov 8, 2018
The source document converted to the corporate template.
Captions added for all figures and tables. To add screen captures
for is5Com’s software. Removed STP from table 1 and table 3 in
the Product Specification section as per Mahbod’s edit of the DS.
Nov 4: a new technical spec added as per DS-iTS12GP-3-
EN.docx. New dimensions and Hardware features, switch
description added as per DS-iTS12GP-3-EN.docx
2
Nov 4, 2019
Ready for Release as per Boris’ email from Nov 4, 2019.
1.86.A
May 14, 2021
1.86.1
May 14, 2021
Revision changed to correspond to sw version – now 1.86. In
“RSTP is enabled by default” added in 4.2.4.3.1 “Bridge Setting”
section. The year changed to 2021 where applicable.
Product spec deleted from the end of the documents. A new
section 6.APPENDIX A: IES12G Modbus Information added.
1.89.1
Aug 30, 2021
Added section 4.2.1.6 SNTP. Ntp section moved to be 4.2.1.7
1.92.1
Nov 23, 2021
3.2.5 MRP section added; MRP section added in CLI; MRP added in 1.4 SW
Features; added 1.3 Acronyms. 1 and 2 sections combined – now sec. 1.
1.92.2
Nov 7, 2022
Fax number removed
Controlled Distribution
Copy
No
Name
Location
1
Hard copy with signatures (pdf)
P:\Product User Manuals and Datasheets\Released User
Manuals
2
Master copy (Word)
J:\Teams\Documentation

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx i
© 2019 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Contents
CHAPTER 1: GETTING STARTED ...........................................................................................1
1.1 About the iTS12GP ................................................................................1
1.2 References .............................................................................................1
1.3 Acronyms ...............................................................................................1
1.4 Software Features .................................................................................4
1.5 Hardware Features ................................................................................4
1.6 Dimensions ............................................................................................5
CHAPTER 2: HARDWARE OVERVIEW....................................................................................6
2.1 Front Panel .............................................................................................6
2.2 Front Panel LEDs...................................................................................6
2.3 Cables .....................................................................................................7
2.3.1 Ethernet Cables.......................................................................................7
2.3.2 1000/100BASE-TX/10BASE-T Pin Assignments ....................................7
2.4 SFP.......................................................................................................... 9
2.5 Console Cable........................................................................................9
CHAPTER 3: WEB MANAGEMENT........................................................................................10
3.1 Configuration by Web Browser..........................................................10
3.1.1 About Web based Management............................................................10
3.1.2 Preparing for Web Management ...........................................................10
System Login--------------------------------------------------------------------10
3.2 Main Interface.......................................................................................11
3.2.1 Basic Setting..........................................................................................12
System Information ------------------------------------------------------------12
Admin & Password-------------------------------------------------------------12
Authentication Method Configuration--------------------------------------13
IP Setting -------------------------------------------------------------------------13
IPv6 Setting ----------------------------------------------------------------------14
SNTP Configuration (only for SNTP Version) ---------------------------14
NTP (only for NTP Version)--------------------------------------------------15
Daylight Saving Time----------------------------------------------------------15
HTTPS ----------------------------------------------------------------------------17
SSH--------------------------------------------------------------------------------17
LLDP ------------------------------------------------------------------------------18
3.2.1.11.1 LLDP Configuration-----------------------------------------------------------18
3.2.1.11.2 LLDP Neighbor Information-------------------------------------------------18
3.2.1.11.3 Port Statistics-------------------------------------------------------------------19
3.2.1.11.4 Global Counters ---------------------------------------------------------------19
3.2.1.11.5 Local Counters-----------------------------------------------------------------19
Modbus TCP---------------------------------------------------------------------20
Backup/Restore Configuration ----------------------------------------------20
Firmware Update ---------------------------------------------------------------20
3.2.2 DHCP Server.........................................................................................20
Setting-----------------------------------------------------------------------------20
DHCP Dynamic Client List ---------------------------------------------------21
DHCP Client List----------------------------------------------------------------21
DHCP Relay Agent ------------------------------------------------------------21
3.2.2.4.1 Relay -----------------------------------------------------------------------------21
3.2.2.4.2 Relay Statistics ----------------------------------------------------------------22
3.2.3 Port Setting............................................................................................23
Port Control ----------------------------------------------------------------------23

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx ii
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Port Alias -------------------------------------------------------------------------24
Port Trunk ------------------------------------------------------------------------25
3.2.3.3.1 Trunk Configuration-----------------------------------------------------------25
LACP Port Configuration -----------------------------------------------------26
LACP System Status ----------------------------------------------------------27
LACP Status ---------------------------------------------------------------------28
Loop Gourd ----------------------------------------------------------------------29
3.2.4 Redundancy ..........................................................................................30
iRing -------------------------------------------------------------------------------30
iChain -----------------------------------------------------------------------------30
MSTP------------------------------------------------------------------------------31
3.2.4.3.1 Bridge Settings-----------------------------------------------------------------31
3.2.4.3.2 MSTI Mapping -----------------------------------------------------------------32
3.2.4.3.3 MSTI Priorities -----------------------------------------------------------------33
3.2.4.3.4 CIST Ports ----------------------------------------------------------------------33
3.2.4.3.5 MSTI Ports ----------------------------------------------------------------------34
3.2.4.3.6 STP Bridges --------------------------------------------------------------------35
3.2.4.3.7 STP Port Status ---------------------------------------------------------------36
3.2.4.3.8 STP Statistics ------------------------------------------------------------------36
3.2.4.3.9 Fast Recovery Mode ---------------------------------------------------------37
3.2.5 MRP.......................................................................................................38
Introduction ----------------------------------------------------------------------38
Configuration --------------------------------------------------------------------38
3.2.6 VLAN .....................................................................................................38
VLAN Membership Configuration ------------------------------------------38
VLAN Port Configuration -----------------------------------------------------39
3.2.6.2.1 How is Unaware、C-Port、S-Port、S-Customer Port ? ------------40
VLAN Setting Example--------------------------------------------------------43
3.2.6.3.1 VLAN Access Mode Setting ------------------------------------------------43
3.2.6.3.2 VLAN 1Q Trunk Mode -------------------------------------------------------44
3.2.6.3.3 VLAN Hybrid Mode -----------------------------------------------------------45
3.2.6.3.4 VLAN Management Vlan ID Setting --------------------------------------46
Private VLAN --------------------------------------------------------------------47
3.2.6.4.1 Private VLAN Membership Configuration -------------------------------47
3.2.6.4.2 Port Isolation Configuration -------------------------------------------------47
3.2.7 SNMP ....................................................................................................48
SNMP System Configuration ------------------------------------------------48
SNMP System Configuration ------------------------------------------------48
SNMP-Communities -----------------------------------------------------------50
SNMPv3 Users------------------------------------------------------------------50
SNMP-Groups-------------------------------------------------------------------51
SNMPv3 Views -----------------------------------------------------------------52
SNMP Access -------------------------------------------------------------------52
3.2.8 Traffic Prioritization................................................................................53
Storm Control--------------------------------------------------------------------53
Port Classification --------------------------------------------------------------53
Port Tag Remaking ------------------------------------------------------------55
Port DSCP -----------------------------------------------------------------------55
Port Policing ---------------------------------------------------------------------56
Queue Policing------------------------------------------------------------------57
QoS Egress Port Scheduler and Shapers--------------------------------57
3.2.8.7.1 Strict Priority --------------------------------------------------------------------58
3.2.8.7.2 Weighted ------------------------------------------------------------------------59
Port Schedulers-----------------------------------------------------------------60
Port Shaping---------------------------------------------------------------------60
DSCP Based QoS--------------------------------------------------------------60
DSCP Translation --------------------------------------------------------------61
DSCP Classification -----------------------------------------------------------62
QoS Control List ----------------------------------------------------------------62
QoS Counters -------------------------------------------------------------------64
QCL Status ----------------------------------------------------------------------64
3.2.9 Multicast ................................................................................................66

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx iii
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
IGMP Snooping -----------------------------------------------------------------66
IGMP Snooping- VLAN Configuration-------------------------------------66
IGMP Snooping Status--------------------------------------------------------67
IGMP Snooping Groups Information---------------------------------------68
3.2.10 Security..................................................................................................69
Remote Control Security Configuration -----------------------------------69
Device Binding ------------------------------------------------------------------69
3.2.10.2.1 Advanced Configuration -----------------------------------------------------70
ACL --------------------------------------------------------------------------------74
3.2.10.3.1 Ports------------------------------------------------------------------------------74
3.2.10.3.2 Rate Limiters -------------------------------------------------------------------74
3.2.10.3.3 ACL -------------------------------------------------------------------------------75
AAA --------------------------------------------------------------------------------81
3.2.10.4.1 Common Server Configuration---------------------------------------------81
3.2.10.4.2 RADIUS Authentication Server Configuration--------------------------81
3.2.10.4.3 RADIUS Accounting Server Configuration------------------------------82
RADIUS Overview -------------------------------------------------------------82
3.2.10.5.1 RADIUS Authentication Servers-------------------------------------------82
3.2.10.5.2 RADIUS Accounting Servers-----------------------------------------------83
RADIUS Details-----------------------------------------------------------------84
NAS(802.1x)---------------------------------------------------------------------86
3.2.10.7.1 NAS Configuration ------------------------------------------------------------87
3.2.10.7.2 NAS Switch Status------------------------------------------------------------90
3.2.11 Warning .................................................................................................93
System Warning ----------------------------------------------------------------93
3.2.11.1.1 SYSLOG Setting --------------------------------------------------------------93
3.2.11.1.2 SMTP Setting ------------------------------------------------------------------93
3.2.11.1.3 Event Selection ----------------------------------------------------------------94
3.2.12 Monitor and Diagnostics ........................................................................95
MAC Table -----------------------------------------------------------------------95
3.2.12.1.1 Configuration -------------------------------------------------------------------95
3.2.12.1.2 MAC Table ----------------------------------------------------------------------97
Port Statistic ---------------------------------------------------------------------98
3.2.12.2.1 Traffic Overview ---------------------------------------------------------------98
3.2.12.2.2 Detailed Statistics -------------------------------------------------------------98
Port Mirroring--------------------------------------------------------------------99
System Log Information ---------------------------------------------------- 101
Cable Diagnostics ------------------------------------------------------------ 101
SFP Monitor ------------------------------------------------------------------- 102
Ping ------------------------------------------------------------------------------ 102
IPv6 Ping ----------------------------------------------------------------------- 103
3.2.13 PoE......................................................................................................104
Configuration ------------------------------------------------------------------ 104
Status --------------------------------------------------------------------------- 105
PoE Schedule ----------------------------------------------------------------- 107
PoE Auto-Ping ---------------------------------------------------------------- 107
3.2.14 Factory Defaults ..................................................................................108
System Reboot---------------------------------------------------------------- 109
CHAPTER 4: COMMAND LINE INTERFACE MANAGEMENT............................................110
4.1 About CLI Management ....................................................................110
4.1.1 CLI Management by RS-232 Serial Console (115200, 8, none, 1, none)110
4.1.2 CLI Management by Telnet .................................................................112
Command Groups------------------------------------------------------------ 114
4.1.3 System.................................................................................................115
CHAPTER 5: APPENDIX A: ITS12GP MODBUS INFORMATION.......................................126

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx iv
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Table of Figures
Figure 1: System Login .........................................................................................................................................10
Figure 2: Login screen...........................................................................................................................................11
Figure 3: Main interface.........................................................................................................................................11
Figure 4: System Information interface .................................................................................................................12
Figure 5: System Password ..................................................................................................................................12
Figure 6: Authentication Method Configuration.....................................................................................................13
Figure 7: IP Configuration .....................................................................................................................................13
Figure 8: IPv6 Setting............................................................................................................................................14
Figure 9 - IP Configuration Interface .....................................................................................................................14
Figure 10: NTP Configuration................................................................................................................................15
Figure 11: Time Zone Configuration .....................................................................................................................15
Figure 12: Daylight Saving Time Mode .................................................................................................................16
Figure 13: Start Time Settings...............................................................................................................................16
Figure 14: End Time settings ................................................................................................................................16
Figure 15: Offset settings ......................................................................................................................................17
Figure 16: HTTPS Configuration...........................................................................................................................17
Figure 17: SSH Configuration ...............................................................................................................................17
Figure 18: LLDP Configuration..............................................................................................................................18
Figure 19: LLDP Neighbor Information .................................................................................................................18
Figure 20: Port Statistics .......................................................................................................................................19
Figure 21: MODBUS Configuration.......................................................................................................................20
Figure 22: Configuration Save...............................................................................................................................20
Figure 23: Configuration Upload ...........................................................................................................................20
Figure 24: Firmware Update..................................................................................................................................20
Figure 25: DHCP Server Configuration.................................................................................................................21
Figure 26: DHCP Dynamic Client List ...................................................................................................................21
Figure 27: DHCP Dynamic Client List ...................................................................................................................21
Figure 28: DHCP Relay Configuration ..................................................................................................................21
Figure 29: Server Statistics ...................................................................................................................................22
Figure 30: Client Statistics.....................................................................................................................................23
Figure 31: Client Statistics.....................................................................................................................................24
Figure 32: Port Alias..............................................................................................................................................25
Figure 33: Aggregation Mode Configuration .........................................................................................................25
Figure 34: Aggregation Group Configuration ........................................................................................................26
Figure 35: LACP Port Configuration......................................................................................................................26
Figure 36: LACP System Status ...........................................................................................................................27
Figure 37: LACP Status.........................................................................................................................................28
Figure 38: LACP Statistics ....................................................................................................................................28
Figure 39: Loop Guard General Settings ..............................................................................................................29
Figure 40: Port Configuration ................................................................................................................................29
Figure 41: Redundancy .........................................................................................................................................31
Figure 42: STP Bridge Configuration ....................................................................................................................31
Figure 43: MSTI Configuration ..............................................................................................................................32
Figure 44: MSTI Configuration ..............................................................................................................................33
Figure 45: STP CIST Ports Configuration .............................................................................................................33
Figure 46: MSTI Port Configuration ......................................................................................................................35
Figure 47: STP Bridges .........................................................................................................................................35
Figure 48: STP Port Status ...................................................................................................................................36
Figure 49: STP Bridges .........................................................................................................................................36
Figure 50: Fast Recovery Mode Interface.............................................................................................................37
Figure 51 - MRP ....................................................................................................................................................38
Figure 52: VLAN Membership Configuration ........................................................................................................39
Figure 53: VLAN Port Configuration......................................................................................................................39
Figure 54: VLAN Access Mode Setting.................................................................................................................43
Figure 55: VLAN Membership Configuration ........................................................................................................43
Figure 56: VLAN 1Q Trunk Mode..........................................................................................................................44
Figure 57: Switch Setting VLAN Membership Configuration ................................................................................44
Figure 58: Ports VLAN Membership Configuration...............................................................................................44
Figure 59: VLAN ID 10 & 20 VLAN Membership Configuration............................................................................45
Figure 60: Ports Port Type C-port VLAN Membership Configuration ...................................................................45

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx v
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Figure 61: VLAN QinQ mode ................................................................................................................................45
Figure 62: VLAN ID 200 VLAN Membership Configuration ..................................................................................46
Figure 63: Ports Port Type Unaware and C-port VLAN Membership Configuration.............................................46
Figure 64: IP Configuration ...................................................................................................................................46
Figure 65: Private VLAN Membership Configuration ............................................................................................47
Figure 66: Port Isolation Configuration..................................................................................................................47
Figure 67: SNMP System Configuration ...............................................................................................................48
Figure 68: SNMP Trap Configuration....................................................................................................................48
Figure 69: SNMPv3 Communities Configuration ..................................................................................................50
Figure 70: SNMPv3 Users Configuration ..............................................................................................................50
Figure 71: SNMPv3 Groups Configuration............................................................................................................51
Figure 72: SNMPv3 Views Configuration..............................................................................................................52
Figure 73: SNMPv3 Accesses Configuration ........................................................................................................52
Figure 74: Storm Control Configuration ................................................................................................................53
Figure 75: QoS Port Configuration........................................................................................................................53
Figure 76: QoS Egress Port Tag Remarking ........................................................................................................55
Figure 77: QoS Port DSCP Remarking.................................................................................................................55
Figure 78: QoS Ingress Port Policers....................................................................................................................56
Figure 79: QoS Ingress Queue Policers ...............................................................................................................57
Figure 80: QoS Ingress Port Scheduler and Shapers Port 1 Strict Priority ..........................................................58
Figure 81: QoS Ingress Port Scheduler and Shapers Port 1 Weighted................................................................59
Figure 82: QoS Egress Port Schedulers ...............................................................................................................60
Figure 83: QoS Egress Port Shapers....................................................................................................................60
Figure 84: DSCP-Based Egress Port Classification .............................................................................................60
Figure 85: DSCP Translation ................................................................................................................................61
Figure 86: DSCP Classification .............................................................................................................................62
Figure 87: QoS Control List...................................................................................................................................62
Figure 88: QoS Counters ......................................................................................................................................64
Figure 89: QoS Control List Status .......................................................................................................................64
Figure 90: IGMP Snooping Configuration .............................................................................................................66
Figure 91: IGMP Snooping VLAN Configuration...................................................................................................67
Figure 92: IGMP Snooping Status ........................................................................................................................67
Figure 93: IGMP Snooping Group Information......................................................................................................68
Figure 94: Remote Control Security Configuration ...............................................................................................69
Figure 95: Device Binding .....................................................................................................................................69
Figure 96: Alias IP Address...................................................................................................................................70
Figure 97: Alive Check ..........................................................................................................................................70
Figure 98: DDoS Prevention .................................................................................................................................71
Figure 99: Device Description ...............................................................................................................................72
Figure 100: Device Description .............................................................................................................................73
Figure 101: ACL Ports Configuration ....................................................................................................................74
Figure 102: ACL Rate Limiter Configuration .........................................................................................................74
Figure 103: ACE Configuration .............................................................................................................................75
Figure 104: MAC Parameters................................................................................................................................76
Figure 105: VLAN Parameters ..............................................................................................................................76
Figure 106: IP Parameters ....................................................................................................................................77
Figure 107: ARP Parameters ................................................................................................................................78
Figure 108: ICMP Parameters...............................................................................................................................79
Figure 109: UDP Parameters................................................................................................................................80
Figure 110: Authentication Server Configuration ..................................................................................................81
Figure 111: RADIUS Authentication Server Configuration ...................................................................................81
Figure 112: RADIUS Accounting Server Configuration ........................................................................................82
Figure 113: RADIUS Authentication Server Status Overview...............................................................................82
Figure 114: RADIUS Accounting Server Status Overview....................................................................................83
Figure 115: RADIUS Accounting Statistics for Server #1 .....................................................................................84
Figure 116: RADIUS Authentication Statistics for Server #1 ................................................................................85
Figure 117: Network Access Server Configuration ...............................................................................................87
Figure 118: Network Access Server Switch Status...............................................................................................90
Figure 119: Network Access Server Switch Status...............................................................................................91
Figure 120: System Warning – SYSLOG Setting interface...................................................................................93
Figure 121: System Warning – SMTP Setting interface........................................................................................93
Figure 122: System Warning – Event Selection interface.....................................................................................94
Figure 123: MAC Address Table Configuration ....................................................................................................95

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx vi
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Figure 124: MAC Table Learning ..........................................................................................................................96
Figure 125: Static MAC Table Configuration.........................................................................................................96
Figure 126: MAC Address Table ...........................................................................................................................97
Figure 127: Port Statistics Overview .....................................................................................................................98
Figure 128: Detailed Port Statistics Port 1 ............................................................................................................99
Figure 129: Mirror Configuration .........................................................................................................................100
Figure 130: System Log Configuration................................................................................................................101
Figure 131: VeriPHY Cable Diagnostics .............................................................................................................101
Figure 132: SFP Monitor .....................................................................................................................................102
Figure 133: ICMP Ping ........................................................................................................................................102
Figure 134: IPv6 Ping..........................................................................................................................................103
Figure 135: Power Over Ethernet Configuration.................................................................................................104
Figure 136: Power Over Ethernet Status ............................................................................................................105
Figure 137: Power Over Ethernet Schedule Configuration.................................................................................107
Figure 138: Auto-Ping Check Configuration........................................................................................................107
Figure 139: Factory Defaults ...............................................................................................................................108
Figure 140: System Reboot Warm Restart .........................................................................................................109
Figure 141: Accessing Hyper Terminal ...............................................................................................................110
Figure 142: Connection Description New Connection ........................................................................................111
Figure 143: Connect to terminal screen ..............................................................................................................111
Figure 144: COM1 Properties .............................................................................................................................112
Figure 145: Command Line Interface..................................................................................................................112
Figure 146: Run Dialog Box ................................................................................................................................113
Figure 147: Login Screen ....................................................................................................................................113
Figure 148: Commander Groups ........................................................................................................................114

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 1
© 2019 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Getting Started
1.1 About the iTS12GP
The iTS12GP is a managed card type 12 port PoE Gigabit Ethernet switch with 8 x 10/100/1000Base-T(X) P.S.E.
ports and 4 x 100/1000Base-X SFP ports.
The iTS12GP provides redundancy support through functions such as MSTP (RSTP/STP compatible) assuring
protection of all mission critical network applications. The switch supports 8 ports P.S.E. fully compliant with
IEEE802.3at standard, providing up to 30 Watts per port, PoE (Power over Internet) on/off scheduled
configuration & PoE alive check and auto reboot functions. The iTS12GP can be managed via the Web UI,
iManage Software Suite, Telnet /SSH, and CLI.
IEEE 802.3az Energy-Efficient Ethernet allows decrease of power consumption by 50% or more.
The switch is made of IP-40 galvanized steel and has a wide operating temperature range from -40°C to +85°C,
which is suitable for the harshest of environments without the use of fans.
1.2 References
[1] RFC 821 - Simple Mail Transfer Protocol, https://datatracker.ietf.org/doc/rfc821/ , Online, Accessed on Aug
22, 2019.
1.3 Acronyms
The following table shows all acronyms used in this document.
Acronym Explanation
AAA Authentication, authorization, and accounting (network security services)
ACE Access Control Entry
ACL Access Control List
AF Assured Forwarding
ARP Address Resolution Protocol
BPDU Bridge Protocol Data Unit
CIST Common and Internal Spanning Tree
CLI Command Line Interface
DCHP Dynamic Host Configuration Protocol
DDM Digital Diagnostic Monitoring
DEI Discard Eligibility (subfield in an IEEE 802.1Q frame header)

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 2
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Acronym Explanation
DNS Domain Name Server
DSAP Destination Service Access Point
DSCP Differentiated Services Code Point
DP Drop Precedence
EAP Extensible Authentication Protocol
EAPOL EAP Over LAN
HLN Hardware Address Length
HRD hardware address space (i.e. ARP hardware address type (ar$hrd)))
HSR High-availability Seamless Redundancy
HTTPS Hyper Text Transfer Protocol Secure or HTTP over SSL
ICMP Internet Control Message Protocol
IGMP Internet Group Management Protocol
IP Internet Protocol (IP)
IPMC(v4) IP(v4) MultiCast
LAG Link Aggregation Group
LACP Link Aggregation Control Protocol
LLDP Link Layer Discovery Protocol
LLDP- MED LLDP - Media Endpoint Discovery
LLDPDU LLDP Data Unit
MIB Management Information Base
MRP Media Redundancy Protocol
MSTI Multiple Spanning Tree Instances
MSTP Multiple Spanning Tree Protocol
NTP Network Time Protocol
OID Object Identifier
OUI Organizationally Unique Identifier (In Linux)

CHAPTER: GETTING STARTED
UM-iTS12GP-1.92.2-EN.docx 3
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Acronym Explanation
PDU Protocol Data Unit
PID Process Identifier
P2P Point-To-Point (link)
PSH Push Function (a value for the ACE)
PWR Power
QCE QoS Control Entry
QCL QoS Control List
QoS Quality of Service
RARP Reverse Address Resolution Protocol (Reverse ARP)
RIP Routing Information Protocol
RMON Remote Monitoring
RSTP Rapid Spanning Tree Protocol
SIP Source IP
SMAC Source MAC Address
SNMP Simple Network Management Protocol
SNTP Simple Network Time Protocol
SSAP Source Service Access Point
SSH Secure Shel
TACACS Terminal Access Controller Access Control System
TCN Topology Change Notification
TCP Transmission Control Protocol
THA target Hardware Address
TLV Type-Length-Value
TPID Tag protocol identifier
TTL Time to live
SSH Secure Shell

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 4
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Acronym Explanation
UDP User Datagram Protocol
URG Urgent Pointer Field Significant (an ACE value)
USM User-based Security Model
UTC Coordinated Universal Time
VACM View based Access Control Model
VCXO Voltage Controlled Crystal Oscillator
VID VLAN ID
1.4 Software Features
•Web or CLI based Management (Console or Telnet / SSH)
•Redundancy— MSTP (RSTP compatible) and Device Binding
•DHCP Server/ /Client/Relay
•VLAN (802.1Q) for segregating and securing network traffic
•SMTP Client and NTP server; Supports SNMPv1/v2/v3
•Traffic Prioritization— TOS/Diffserv and Quality of Service (QoS), DOS/DDOS auto prevention
•Multicast traffic—IGMP Snooping (IGMP v1/v2 / v3)
•Warnings (Syslog and SMTP) and Fault Alarm (power and ports failure)
•Monitoring and Diagnostics—MAC Table and Port configuration, status, statistics, monitoring, security
•Supports standard IEC 62439-2 MRP (Media Redundancy Protocol) functionality
1.5 Hardware Features
Interface
10/100/1000Base-T(X) RJ45 PoE ports RJ45 Auto MDI/MDIX
8
100/1000Base-X SFP 4
RS-232 Serial Console Port
RS-232 in RJ45 connector with console cable:
115200 bps, 8, N, 1
Power Requirements
Power Input 12-48 VDC
Power Terminal PCB Golden Finger
Power Consumption < 40 W
Overload Protection 10 A
Reverse Connection Protection Supported
Redundancy Protection Not supported
Physical Characteristics
Enclosure IP-40 Galvanized Steel
Dimensions (W x D x H) 56.6 (W) x 114.5 (H) x 205.3 (D) mm
Weight (g) ~790 g
Operating Temperature: -40 to 75oC
Storage Temperature: -40 to 85 oC

CHAPTER: GETTING STARTED
UM-iTS12GP-1.92.2-EN.docx 5
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Operating Humidity: 5% to 95%, non-condensing
Casing: IP-40
8x 10/100/1000Base-T(X) P.S.E.
4 x 100/1000Base-X SFP
Console Port
1.6 Dimensions
All dimensions are shown in inches.

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 6
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Hardware Overview
2.1 Front Panel
The following table describes the labels that stick on the iTS12GP series.
Port
Description
SFP ports
4 100 /1000Base-X
Copper Port
8 10/100/1000Base-T(X) P.S.E.
Console
Use RS-232 with RJ-45 connector to manage switch.
2.2 Front Panel LEDs
LED
Color
Status
Description
PWR
Green
On
DC power module up
R.M
Green
On
Ring Master.
Ring Green
On
Ring enabled.
Slowly blinking
Ring has only One link. (lack of one link to build the ring.)
Fast blinking
Ring work normally.
Fault
Amber
On
Fault relay. Power failure or Port down/fail.
Gigabit Ethernet ports
SPEED
(Dual color)
Green On
Port link up on 1000Mbps
Data transmitted on 1000Mbps
Amber On
Port link up on 10/100Mbps
Data transmitted on 10/100Mbps
LINK/ACK
Green
Blinking
Port LINK/ACK
SFP ports
LNK/LNK Green
On
Port link up.
Blinking
Data transmitted.

CHAPTER: HARDWARE OVERVIEW
UM-iTS12GP-1.92.2-EN.docx 7
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
2.3 Cables
2.3.1 Ethernet Cables
The IGPCS-9084GP switch had standard Ethernet ports. According to the link type, the switches use CAT 3, 4,
5,5e UTP cables to connect to any other network device (PCs, servers, switches, routers, or hubs). Please refer
to the following table for cable specifications.
Cable Types and Specifications
Cable
Type
Max. Length
Connector
10BASE-T
Cat. 3, 4, 5 100-ohm
UTP 100 m (328 ft)
RJ-45
100BASE-TX
Cat. 5 100-ohm UTP
UTP 100 m (328 ft)
RJ-45
1000BASE-TX
Cat. 5/Cat. 5e 100-ohm UTP
UTP 100 m (328ft)
RJ-45
2.3.2 1000/100BASE-TX/10BASE-T Pin Assignments
With 1000/100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 are used
for receiving data.
10/100Base-T(X) P.S.E. RJ-45 port
Pin Number
Assignment
#1
TD+ with PoE Power input +
#2
TD- with PoE Power input +
#3
RD+ with PoE Power input -
#6
RD- with PoE Power input -
10/100 Base-T RJ-45 Pin Assignments
Pin Number
Assignment
1
TD+
2
TD-
3
RD+
4
Not used
5
Not used
6
RD-
7
Not used
8
Not used
1000Base-T P.S.E. RJ-45 port
Pin Number
Assignment
#1
BI_DA+ with PoE Power input +
#2
BI_DA- with PoE Power input +
#3
BI_DB+ with PoE Power input -
#4
BI_DC+
#5
BI_DC-
#6
BI_DB- with PoE Power input -
#7
BI_DD+
#8
BI_DD-
1000 Base-T RJ-45 Pin Assignments
Pin Number
Assignment
1
BI_DA+
2
BI_DA-
3
BI_DB+

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 8
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
Pin Number
Assignment
4
BI_DC+
5
BI_DC-
6
BI_DB-
7
BI_DD+
8
BI_DD-
The IGPCS-9084GP Series switches support auto MDI/MDI-X operation. You can use a straight-through cable to
connect PC to switch. The following table below shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin
outs.
10/100 Base-T MDI/MDI-X pins Assignments
Pin Number
MDI port
MDI-X port
1
TD+(transmit)
RD+(receive)
2
TD-(transmit)
RD-(receive)
3
RD+(receive)
TD+(transmit)
4
Not used
Not used
5
Not used
Not used
6
RD-(receive)
TD-(transmit)
7
Not used
Not used
8
Not used
Not used
1000 Base-T MDI/MDI-X pins Assignments
Pin Number
MDI port
MDI-X port
1
BI_DA+
BI_DB+
2
BI_DA-
BI_DB-
3
BI_DB+
BI_DA+
4
BI_DC+
BI_DD+
5
BI_DC-
BI_DD-
6
BI_DB-
BI_DA-
7
BI_DD+
BI_DC+
8
BI_DD-
BI_DC-
Note: “+” and “-” signs represent the polarity of the wires that make up each wire pair.

CHAPTER: HARDWARE OVERVIEW
UM-iTS12GP-1.92.2-EN.docx 9
© 2021 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
2.4 SFP
The switch has fiber optical ports with SFP connectors. The fiber optical ports are in Multimode (0 to 550M, 850
nm with 50/125 µm, 62.5/125 µm fiber) and Singlemode with LC connector. Remember that the TX port of Switch
A should be connected to the RX port of Switch B.
Switch A Switch B
2.5 Console Cable
iTS12GP switch can be managed by a console port. The DB-9 to RJ-45 cable can be found in the package. You
can connect them to PC via a RS-232 cable with DB-9 female connector and the other end (RJ-45 connector)
connects to console port of switch.
PC pin out (male) assignment
RS-232 with DB9 female connector
DB9 to RJ 45
Pin #2 RD
Pin #2 TD
Pin #2
Pin #3 TD
Pin #3 RD
Pin #3
Pin #5 GD
Pin #5 GD
Pin #5
Fiber cord

ITS12GP USER MANUAL
UM-iTS12GP-1.92.2-EN.docx 10
© 2022 IS5 COMMUNICATIONS INC. ALL RIGHTS RESERVED
WEB Management
3.1 Configuration by Web Browser
This section introduces the configuration by Web browser.
3.1.1 About Web based Management
An embedded HTML web site resides in the flash memory on the CPU board. It contains advanced management
features and allows you to manage the switch from anywhere on the network through a standard web browser
such as Microsoft Internet Explorer.
The Web based Management function supports Internet Explorer 5.0 or later. It is based on Java Applets with an
aim to reduce network bandwidth consumption, enhance access speed, and present an easy viewing screen.
Note: By default, IE5.0 or later version does not allow Java Applets to open sockets. You need to explicitly modify the browser setting in order
to enable Java Applets to use network ports.
3.1.2 Preparing for Web Management
The default value is as below:
IP Address: 192.168.10.1
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.10.254
User Name: admin
Password: admin
System Login
1. Launch the Internet Explorer.
2. Type http:// and the IP address of the switch. Press “Enter”.
Figure 1: System Login
3. The login screen appears.
4. Key in the username and password. The default username and password is “admin”.
5. Click “Enter” or ”OK” button, then the main interface of the Web-based management appears.
