ISAFE MOBILE M53A01 User manual

IS530.RG
OPERATING MANUAL
MODEL M53A01

Document No. 1036MM10REV00
Version: 2022-05-25
(c) 2022 i.safe MOBILE GmbH
i.safe MOBILE GmbH
i_Park Tauberfranken 10
97922 Lauda-Koenigshofen
Germany
Tel. [phone]
[email protected]
www.isafe-mobile.com Template: TEMPMM01REV10

CONTENTS
English.............................................................................. 4
Deutsch............................................................................ 16
Česky .............................................................................. 28
Dansk.............................................................................. 40
Español ............................................................................ 52
Suomi..............................................................................64
Français............................................................................ 76
Magyar ............................................................................ 88
Italiano ...........................................................................100
Nederlands .......................................................................112
Norsk .............................................................................124
Polski .............................................................................136
Português (BR) ....................................................................148
Русский...........................................................................160
Svenska ...........................................................................172
Korean ...........................................................................184
Japanese ........................................................................196
Chinese.......................................................................... 208
Arabic ............................................................................220
This Operating Manual complies with these standards:
IEC 60079, IEC 82079, ANSI Z535.6
Diese Bedienungsanleitung erfüllt die Anforderungen der folgenden Normen:
IEC 60079, IEC 82079, ANSI Z535.6

4
ENGLISH
READ AND UNDERSTAND THE INSTRUCTIONS
PROTECT YOUR LIFE AND READ THE OPERATING MANUAL
This Operating Manual is part of the device IS530.RG (model M53A01). This Operating
Manual provides important information for safe use of the device.
Before using the device, read this Operating Manual carefully and pay particular attention
to the “Safety” section and the warnings highlighted with the warning symbol.
Also read the Safety Instructions before using the device.
You can nd these at www.isafe-mobile.com/en/support/downloads
Make sure you have access to this Operating Manual when you need it. You can nd the
current Operating Manual at www.isafe-mobile.com/en/support/downloads
Follow all instructions given on the device and on the packaging.
Follow local safety regulations.
INTENDED USE
The IS530.RG is an Internet-capable communication device for industrial use.
Only use the device as described in this Operating Manual. Any other use is considered impro-
per and can lead to death, severe injuries and damage to the device.
The manufacturer i.safe MOBILE GmbH does not assume any liability for damage caused by
improper use. The warranty expires in the event of improper use.

EN 5
WARRANTY
You can nd the warranty conditions at www.isafe-mobile.com/en/support/service
For any damage caused by computer viruses that you download while using the Internet
functions responsibility is at your hand.
There is no right of recourse against i.safe MOBILE GmbH.
EU DECLARATION OF CONFORMITY
You will nd the EU declaration of conformity at
www.isafe-mobile.com/en/support/downloads
FCC/IC STATEMENT
The FCC/IC declaration can be found at
www.isafe-mobile.com/en/support/downloads

6
DEVICE OVERVIEW/FUNCTIONS
14
7
5
8
15
14
9
2
12 1011
6
21
20
16
13
17 18 19
3

EN 7
1 STATUS LED: Display for notications and charging status.
2 SOS KEY: A long press of the SOS key sends an emergency call to a pre-saved emer-
gency number (only in connection with a Lone Worker Protection app).
3 LOUDSPEAKER
4 POWER KEY: A long press switches the device on/o. A short press switches the stand-
by mode on/o.
5 FRONT CAMERA
6 ISM INTERFACE: Connection for approved accessories. Also see section “Connecting
approved accessories”.
7 MAGNETIC CHARGER PORT: Connection for the Magnetic Charger Cable. Also see
section “Charging”.
8 SIDE KEY RIGHT: Optional function, e.g. camera - function can be assigned via Button
App (system integrated).
9 CURRENT APPLICATION: Shows all open applications.
10 HOME KEY: Switch to the main screen.
11 BACK KEY: Go to the previous screen.
12 USB INTERFACE: Connection for the USB-C Cable or for connection to other devices.
Also see sections “Charging” and “Connecting approved accessories”.
13 MICROPHONE
14 LOUDNESS CONTROL: Volume up/Volume down.
15 SIDE KEY LEFT: Optional function - function can be assigned via Button App (system
integrated).
16 SENSORS: Proximity sensor, light sensor.
17 LED FLASH
18 NOISE CANCELLING: Noise cancelling microphone.
19 LOUDSPEAKER: Loudspeaker for hands-free function.
20 BACK CAMERA
21 BATTERY

8
SAFETY
Read the “Safety” section of this Operating Manual carefully before using the device. If you
do not follow these instructions or do not understand them, this could lead to death, severe
injuries and damage to the device.
USER
Only trained users who have read and understood this Operating Manual may use this device.
USE OUTSIDE OF EXPLOSION HAZARDOUS AREAS
DANGER
Improper use can result in death or severe injuries!
Do not use the device in explosion hazardous areas.
Make sure that no gap can be seen between the two halves of the device.
Do not use the device in places where its use is prohibited.
Turn o the device in clinics or other medical facilities.
Always keep a safety distance of at least 15cm between the device and a pacemaker or
hearing aid. The device can aect the functioning of medical devices such as pacemakers and
hearing aids.
When using the device while driving a motor vehicle, be sure to comply with applicable
national laws.
Make sure you prevent the user errors described in the section entitled “Possible User Errors”.
Only charge the device as described in the “Charging” section.
CAUTION
When using earphones or headsets at the maximum volume setting, you can
damage your hearing.
First set the volume control on the device to 50% of the maximum volume.
Gradually adjust the volume.
NOTICE
Incorrect use can damage the device.
Only use accessories approved by i.safe MOBILE, as described in the section on
“Connecting approved accessories”.
Protect the device and the Power Adapter from strong electrical magnetic elds as for
example those emitted by induction cookers or microwave ovens, for example.
Do not touch the display with sharp objects.

EN 9
POSSIBLE USER ERRORS
DANGER
Improper use can result in death or severe injuries! Follow the instructions below:
Do not modify the device structurally.
Do not expose the device to high temperatures.
Do not expose the device to strong UV radiation.
Do not expose the device to processes with high electrical charges.
Do not expose the device to aggressive acids or bases.
SCOPE OF DELIVERY
Your device packaging contains the following:
1 x IS530.RG
1 x Battery
1 x Quick Start Manual
1 x Safety Instructions
1 x Display Protection Foil
1 x USB-C Cable
1 x Magnetic Charger Cable
1 x Power Adapter universal (power supply unit and various country-specic adapters)
1 x Torx Screwdriver
1 x Display cleaning cloth
CELL BROADCAST
The device supports cell broadcast. Cell broadcast is a cellular service for sending messages to
all recipients within a cell.

10
INSTALLING THE BATTERY
Place the battery in the battery compartment as shown.
Hand-tighten the screws using the Torx Screwdriver provided.
Check that the battery is seated correctly and securely.
INSERT/REMOVE SIM CARD
NOTICE
Proceeding incorrectly when inserting/removing the SIM card can damage the device and
the SIM card. Switch o the device before inserting or removing a SIM card. Do not charge the
device while inserting or removing a SIM card.
Loosen the screws on the battery using the Torx Screwdriver provided.
Remove the battery from the battery compartment.

EN 11
Insert the SIM card into the slot. The device has two slots for one SIM card each. The slots are
marked “SIM 1” and “SIM 2”.
If you have inserted two SIM cards, select a favorite card. Information on operating the device
can be found at www.isafe-mobile.com/en/support/service under the menu item „FAQ“.
Reinstall the battery. See section “Installing the battery”.
INSERT/REMOVE microSD CARD
NOTICE
Proceeding incorrectly when inserting/removing the microSD card can damage the device
and the microSD card. Switch o the device before inserting or removing a microSD card. Do
not charge the device while inserting or removing a microSD card.
Loosen the screws on the battery using the Torx Screwdriver provided.
Remove the battery from the battery compartment.
Insert the microSD card into the slot provided. The device has a slot for a microSD card up to
128GB. The slot is marked “microSD”.
Reinstall the battery. See section “Installing the battery”.

12
CHARGING
DANGER
Improper use can result in death or severe injuries! Do not charge the device in the vicinity of
ammable substances.
NOTICE
Incorrect charging can cause damage to the device. Please note the following when charging:
Only charge the device at ambient temperatures between +5°C to +35°C (+41°F to +95°F).
Charge the device under dry indoor conditions only.
Do not charge the device in environments dusty or humid.
Your device package contains a power supply unit, various country-specic adapters, an
USB-C Cable and an Magnetic Charger Cable.
Connect the adapter suitable for your country to the power supply unit.
Connect the USB-C Cable or the Magnetic Charger Cable to the power supply unit.
Connect the USB-C Cable to the USB interface of the device, or connect the Magnetic Charger
Cable to the magnetic charging port on the device.
SWITCHING ON/OFF
Press and hold the on/o key for about 3 seconds.
Enter the device or SIM PIN when the input dialog for the device or SIM PIN appears after
switching on.
Select the <Switch o> menu item if the power o menu appears when switching o.
USING THE DEVICE
When turning on the device for the rst time, follow the instructions on the screen.
Further information on operating the device can be found at
www.isafe-mobile.com/en/support/service under the menu item “FAQ”.
Detailed information on operating the Android operating system can be found at:
https://support.google.com/android
CONNECTING APPROVED ACCESSORIES
Only connect accessories approved by i.safe MOBILE to the device. Accessories approved by
i.safe MOBILE can be found at www.isafe-mobile.com/en/products
Approved accessories can be connected to any ISM interface and to the USB interface.

EN 13
ISM INTERFACE
Loosen the screw on the ISM interface cover using the Screwdriver provided and remove the
cover as shown. The Screwdriver is included in the accessory package.
Connect the plug of the approved accessory to the ISM interface as shown.
Hand-tighten the screws using the Screwdriver provided.
Check that the plug is seated correctly and securely.
USB INTERFACE
The USB interface is used for charging and data transfer.
Connect approved accessories or other devices to the USB interface only by using the
USB-C Cable.

14
CHANGING THE BATTERY
An approved replacement battery can be found on the website
www.isafe-mobile.com/en/products
Loosen the screws on the battery using the Torx Screwdriver provided.
Remove the battery from the battery compartment as shown.
Place the approved replacement battery in the battery compartment as shown.
Hand-tighten the screws using the Torx Screwdriver provided.
Check that the battery is seated correctly and securely.
POSSIBLE DEVICE PROBLEMS
You can nd information on possible device problems and how to rectify them at
www.isafe-mobile.com/en/support/service under the menu item “FAQ”.
If you have any further questions, please contact the i.safe MOBILE repair service at
www.isafe-mobile.com/en/support/service
MAINTENANCE/REPAIR
The device itself has no serviceable parts.
WARNING
Incorrect repairs present a risk of explosion or re, which can result in death or severe injuries!
Do not open the device or carry out any repairs yourself.
Contact the i.safe MOBILE repair service at www.isafe-mobile.com/en/support/service if
the device is not working normally, if the device needs to be repaired or if a replacement part
is required.
RETURN SHIPMENT
Contact the i.safe MOBILE repair service at www.isafe-mobile.com/en/support/service

EN 15
DISTRIBUTION PARTNER
You can nd the specialist distribution partner responsible for your country at
www.isafe-mobile.com/en/contact
CLEANING
NOTICE
Incorrect cleaning can cause damage to the device. Please note the following when cleaning:
Turn o the device before cleaning.
Do not charge the device while cleaning.
Do not use chemical agents for cleaning.
Clean the device and the Power Adapter with a soft, moistened antistatic cloth.
Clean the display screen regularly with a soft, antistatic cloth.
STORAGE
NOTICE
Incorrect storage can cause damage to the device. Store the device at ambient temperatures
between +5°C to +35°C (+41°F to +95°F) and a humidity between 10% to 60%.
RECYCLING
NOTICE
Incorrect disposal of electronic products, batteries and packaging material puts the environ-
ment at risk. Please note the following when disposing of items:
DO NOT throw away batteries with household waste.
Always dispose electronic products, batteries and packaging material at the appropri-
ate collection points. This way, you prevent uncontrolled waste disposal and promote
the recycling of material resources.
You can obtain further information from regional waste disposal companies, state authorities or
the i.safe MOBILE service centre responsible for your country or region at
www.isafe-mobile.com/en/support/service
TRADEMARKS
i.safe MOBILE and the i.safe MOBILE logo are registered trademarks of the
i.safe MOBILE GmbH.
EEA Version: Comes with the Google™ app and Google Chrome™
Google and Google Play are trademarks of Google LLC.
All other trademarks and copyrights are the properties of their respective owners.

16
DEUTSCH
ANWEISUNGEN LESEN UND VERSTEHEN
SCHÜTZEN SIE IHR LEBEN UND LESEN SIE DIE BEDIENUNGSANLEITUNG
Diese Bedienungsanleitung ist Teil des Geräts IS530.RG (Modell M53A01). Die Bedienungsan-
leitung liefert wichtige Informationen für eine sichere Verwendung des Geräts.
Lesen Sie vor der Verwendung des Geräts diese Bedienungsanleitung sorgfältig durch und
beachten Sie insbesondere den Abschnitt „Sicherheit“ und die mit dem Warnsymbol hervor-
gehobenen Warnhinweise.
Lesen Sie vor der Verwendung des Geräts auch die Sicherheitsvorschriften. Diese nden Sie
unter www.isafe-mobile.com/de/support/downloads
Sorgen Sie dafür, dass Sie bei Bedarf Zugri auf diese Bedienungsanleitung haben. Die
aktuelle Bedienungsanleitung nden Sie unter
www.isafe-mobile.com/de/support/downloads
Beachten Sie alle Anweisungen auf dem Gerät und auf der Verpackung.
Befolgen Sie die örtlichen Sicherheitsvorschriften.
BESTIMMUNGSGEMÄSSE VERWENDUNG
Das IS530.RG ist ein internetfähiges Kommunikationsgerät für den industriellen Einsatz.
Verwenden Sie das Gerät nur, wie in dieser Bedienungsanleitung beschrieben. Jede andere
Verwendung gilt als nicht bestimmungsgemäß und kann zu Tod, schweren Verletzungen und
Schäden am Gerät führen.
Der Hersteller i.safe MOBILE GmbH übernimmt keine Haftung für Schäden, die durch nicht
bestimmungsgemäße Verwendung entstanden sind. Die Garantie erlischt bei nicht bestim-
mungsgemäßer Verwendung.

DE 17
GARANTIE
Die Garantiebestimmungen nden Sie unter
www.isafe-mobile.com/ de/ support/service
Für Schäden durch Computerviren, die Sie beim Verwenden der Internetfunktionen
herunterladen, sind Sie selbst verantwortlich. Ein Regressanspruch gegenüber der
i.safe MOBILE GmbH besteht nicht.
EUKONFORMITÄTSERKLÄRUNG
Die EU-Konformitätserklärung nden Sie unter
www.isafe-mobile.com/de/ support/downloads
FCC/IC ERKLÄRUNG
Die FCC/IC Erklärung nden Sie unter
www.isafe-mobile.com/ de/support/downloads

18
GERÄTEÜBERSICHT/FUNKTIONEN
14
7
5
8
15
14
9
2
12 1011
6
21
20
16
13
17 18 19
3

DE 19
1 STATUSLED: Anzeige für Benachrichtigungen und Ladestatus.
2 SOSTASTE: Langer Druck sendet einen Notruf an eine vorabgespeicherte
Notfallnummer (nur in Verbindung mit einer Lone Worker Protection-App).
3LAUTSPRECHER
4AN-/AUSTASTE: Langer Druck schaltet das Gerät an/aus. Kurzer Druck schaltet den
Standby-Modus a n/aus .
5KAMERA VORDERSEITE
6 ISMSCHNITTSTELLE: Anschluss für freigegebenes Zubehör.
Siehe auch Abschnitt „Freigegebenes Zubehör anschließen“.
7MAGNETLADEANSCHLUSS: Anschluss für das Magnetladekabel. Siehe auch Abschnitt
„Laden“.
8 SEITENTASTE RECHTS: Optionale Funktion, z.B. Kamera - Funktion kann über Button
App (systemintegriert) zugewiesen werden.
9 AKTUELLE ANWENDUNGEN: Zeigt alle geöneten Anwendungen.
10 HOMETASTE: Wechsel zum Hauptbildschirm.
11 ZURÜCKTASTE:Wechsel zum vorherigen Bildschirm.
12 USBSCHNITTSTELLE:Anschluss für das USB-C-Kabel oder für die Verbindung
mit anderen Geräten.
Siehe auch Abschnitte „Laden“ und „Freigegebenes Zubehör
anschließen“.
13 MIKROFON
14 LAUTSTÄRKEREGELUNG:Lauter/Leiser.
15 SEITENTASTE LINKS: Optionale Funktion - Funktion kann über Button App (systemin-
tegriert) zugewiesen werden.
16 SENSOREN: Näherungssensor, Lichtsensor.
17 LEDBLITZ
18 NOISE CANCELLING: Mikrofon zur Geräuschunterdrückung.
19 LAUTSPRECHER: Lautsprecher für Freisprechfunktion.
20 KAMERA RÜCKSEITE
21 BATTERIE

20
SICHERHEIT
Lesen Sie vor der Verwendung des Geräts den Abschnitt „Sicherheit“ in dieser Bedienungs-
anleitung sorgfältig durch. Wenn Sie die Sicherheitshinweise nicht beachten oder nicht
verstehen, kann dies zu Tod, schweren Verletzungen und Schäden am Gerät führen.
BENUTZER
Nur geschulte Benutzer, die diese Bedienungsanleitung gelesen und verstanden haben, dürfen
dieses Gerät benutzen.
EINSATZ AUSSERHALB EXPLOSIONSGEFÄHRDETER BEREICHE
GEFAHR
Durch falsche Verwendung besteht Gefahr von Tod und schweren Verletzungen!
Verwenden Sie das Gerät nicht in explosionsgefährdeten Bereichen.
Stellen Sie sicher, dass zwischen den beiden Gerätehälften kein Spalt erkennbar ist.
Benutzen Sie das Gerät nicht an Orten, an denen das Benutzen verboten ist.
Schalten Sie das Gerät in Kliniken oder anderen medizinischen Einrichtungen aus.
Halten Sie immer einen Sicherheitsabstand von mindestens 15cm zwischen Gerät und
einem Herzschrittmacher oder einer Hörhilfe ein. Das Gerät kann die Funktion von
medizinischen Geräten wie Herzschrittmachern oder Hörhilfen beeinussen.
Achten Sie bei der Verwendung des Geräts während der Steuerung eines Kraftfahrzeugs
auf die entsprechenden Landesgesetze.
Verhindern Sie unbedingt die Benutzerfehler, die im Abschnitt „Mögliche Benutzerfehler“
beschrieben sind.
Laden Sie das Gerät nur so, wie es im Abschnitt „Laden“ beschrieben ist.
VORSICHT
Bei der Verwendung von Kopfhörern oder Headsets, können Sie bei maximaler
Lautstärkeeinstellung Ihr Gehör schädigen.
Stellen Sie die Lautstärkeregelung am Gerät zuerst auf 50% der maximalen
Lautstärke ein.
Passen Sie die Lautstärke schrittweise an.
ACHTUNG
Durch falsche Verwendung, können Sie das Gerät beschädigen.
Verwenden Sie nur von i.safe MOBILE freigegebenes Zubehör, wie im Abschnitt
„Freigegebenes Zubehör anschließen“ beschrieben.
Schützen Sie das Gerät und den Netzadapter vor starken elektrischen Magnetfeldern,
wie sie z.B. von Induktionsherden oder Mikrowellenöfen ausgehen.
Berühren Sie das Display nicht mit scharfkantigen Gegenständen.
