ISDT Q6 Nano User manual

Q6 Nano
200W SMART CHARGR
Instruction Manual

Never use the charger without supervision, please stop using the
charger and refer to the manual for reasons if any functional abnormity.
Keep the charger away from dust, humidity, rain and high temperature,
as well as avoid direct exposure to the sunlight and intense vibration.

surface. Do not use it on the car’s seats, carpet or other similar places.

the charger.
Read the instruction manual carefully to be familiar with the features of
the charger, and set proper charging parameters before operating.
Setting the parameters incorrectly will result in damage to the product,

Warnings and Safety Tips
•
•
•
•
For your safety and a better user experience, please read this
manual and follow the instruction before using the new charger.
Please visit: www.isdt.co for more details on the functions of this
smart charger, as well as purchase various accessories.Functions of
products will be kept on upgrading, the manual in your hand may be

Thanks for purchasing the ISDT Q6 Nano Smart Charger.

Function Buttons
Power
input
Display
Screen
Three-way
navigation
key
USB
connection
Power
output
Balance
port
Fan Vent
Three-way navigation key:
Press the top half: the screen scroll up
Press the bottom half: the screen scroll down
Press the middle part:
press to enter the task settings,
press and hold to enter the system settings.

Input voltage: DC 10~30V
Output voltage: DC 1.0~30.0V
Max. input current: 9A
Balance current: 0.5A/Cell Max


Abnormal voltage alarm: Support
Incorrect cell count setting alarm: Support
Supported battery types and cell: LiFe,LiIon,LiPo,LiHv 1~6S;
Pb 1~12S; NiMH/Cd 1~16S

Charging current: 0.1~8.0A
Discharging current: 0.1~1.0A
Max. charging power: 200W
Max. discharging power: 10W
Dimension: 72×72×32mm
Weight: 120g
Make sure to know the maximum charging current of the battery before charging,
never use excessive current to charge to damage your battery, which will result in
over heat even explosion during the charging process.The charging and discharging
capacity of battery is usually marked with C value. Multiplying the charging C value
and battery capacity equals to the maximum charging current supported by the
battery. For example, for a 1000 mAh battery with a charging capacity of 5C, the
maximum charging current would be 1000*5=5000mA; therefore, the maximum

supported charging C value, please set the charging current below 1C, for the
sake of its (lithium battery) safety. The reference relation between C value and





Preset Battery Type of Charger and Task Parameters
Rated voltage
Full charge voltage
Storage voltage
Discharge voltage
Preset voltage
Balance charge
Unbalanced charge
Supported cell count
Max. charging current
NiCd/MH Pb LiFe Lilon LiPo LiHv
3.60V
4.10V
3.70V
3.20V
2.90V
1~6S
8.0A
3.20V
3.65V
3.30V
2.90V
2.60V
1-6S
8.0A
3.70V
4.20V
3.80V
3.30V
3.00V
1~6S
8.0A
3.80V
4.35V
3.85V
3.40V
3.10V
1~6S
8.0A
1.20V
1.40V
1.10V
0.90V
1~16S
8.0A
2.00V
2.40V
1.90V
1.80V
1~12S
8.0A
Power on Q6 Nano smart charger, connect the battery, and short press

Operating the Charger

Charge
Balancing port is strongly recommended when charging lipo battery, which
can make sure to monitor voltage on each cell battery and balance it when
charging. Warning beeper will yell before start charging lipo if in
non-balance mode(no connecting with balance port).
Current setting range: 0.1~8.0A
The battery type, cell count and charging current are auto set accordingly
when connecting with BattGo battery.
Discharge
Current setting range: 0.1~1.0A
The battery type, cell count and discharging current are auto set
accordingly when connecting with BattGo battery.
DC Power
The charger can be used as a DC power supply when choosing this
~30.0V, and current 0.2~5.0A.
The battery type, parameter and current are not optional in this task.
Storage
Current setting range: 0.1~8.0A.
The battery type, cell count and storage current are auto set accordingly
when connecting with BattGo battery.

Destroy
Connect the battery to be scrapped, and select the scrap function in task
options, which capable to discharge the battery to 0V.
Current setting range: 0.1~1.0A
The battery type and cell count are are auto set accordingly
when connecting with BattGo battery.
Task
Battery
Battery and
cell count
Current


LiFe,LiIon,LiPo,LiHv(1~
Pb(1~~16S)
0.1~8.0A
Charging Screen
Shift the parameters on display by three-way navigation keys while
working, as cell voltage, cell internal resistance, BattGo information,
working parameter. The cell voltage and internal resistance only on display
in balancing charging mode. The BattGo information will display only when
connected to the BattGo battery, and the cell voltage is able to display
without connected to the balance port.

BattGo information Working parameter
Cell voltage Cell internal resistance
4.15V
4.15V
4.15V
4.15V
4.15V
4.15V
Voltage






Cells IR
23.5V / 200W
22.5V / 160W
60°C / 130°F
23 / 109pcs
System info
ISDT
LiPo 6S 99999mAh
5.0C / 35.0C
2019-01-23
123
3
Under the standby interface, Press and hold the middle position of the
three-way navigation keys to display the system setting menu:
System Setting Menu

Min. input voltage protection 10~24V: all tasks in operation will be
stopped at once and hint warning of low voltage, when the input voltage
is lower than the input voltage as set up. It will protect the battery from
being discharged when using battery pack as power supply.
Max. input power setting 30~230W: if the input power is smaller than
the max working power (230W), please set up the parameter as the actual
output power as max input, to protect the input power and enable the
charger to work stable.
Buzzer volume: The operation sound will be shielded when the volume

Self-test: Enter system setting. select self-test task
Calibration: the input voltage, output voltage and balance voltage of the
charger can be calibrated with this task.
*All product photos, statements and literature are for reference only.


