ISDT N Series User manual

N Series Smart Charger Instructions
www.isdt.co
Scan the QR code for details
N SERIES

Thank you for purchasing the ISDT N8/N16/N24 Smart Charger.
The Series N is an intelligent battery charger that is compatible with multiple types of AA/AAA size
cylindrical batteries. Each channel works independently of each other which means that dierent types
and dierent sizes of batteries can be charged at the same time.
For safety and for a better user experience, please read this user manual in detail and follow the
instructions carefully before using your new charger.
1) Never attempt to charge a damaged battery or a non-rechargeable battery.
2) Keep the charger away from humidity and high temperature while it’s working and ensure that the
charger is not covered in any way which may prevent ventilation required for cooling.
3) Do not let young children operate the charger.
4) Make sure that the charging and discharging parameter settings are suitable for the batteries being
charged as incorrect setting could lead to damage to the batteries and the charger or even re .
1) USB Upgrade Port (and USB Type-C Power Input for N8)
2) Touch Key
3) LCD Display
4) Indicator Light
5) Battery Slot
6) DC Power Input Port
1 1
6
1
5
432

Specication of N8
DC Power Input Port: USB Type-C
Input Voltage: 5-12V
Input Power: 18W
Battery Slot Count: 1-8 single cylindrical cells
Battery Type: Li-Ion, LiHv, Ni-MH, Ni-Cd, LiFePO4, Eneloop
Charge Current Range: 0.1A - 1.5A/slot
Discharge Current Range: 0.1A - 1.0A/slot
Display: 240 x 320 IPS LCD
Operating Temperature: 0℃- 40℃
Dimensions (L x W x H) : 188.5 x 79 x 28mm
Weight: 283g
Specication of N16
DC Power Input Port: DC input
Input Voltage: 5-12V
Input Power: 36W
Battery Slot Count: 1-16 single cylindrical cells
Battery Type: Li-Ion, LiHv, Ni-MH, Ni-Cd, LiFePO4, Eneloop
Charge Current Range: 0.1A - 1.5A/slot
Discharge Current Range: 0.1A - 1.0A/slot
Display: 240 x 320 IPS LCD
Operating Temperature: 0℃- 40℃
Dimensions (L x W x H) : 308.4 x 79 x 28mm
Weight: 450g
Specication of N24
DC Power Input Port: DC input
Input Voltage: 5-12V
Input Power: 48W
Battery Slot Count: 1-24 single cylindrical cells
Battery Type: Li-Ion, LiHv, Ni-MH, Ni-Cd, LiFePO4, Eneloop
Charge Current Range: 0.1A - 1.5A/slot
Discharge Current Range: 0.1A - 1.0A/slot
Display: 240 x 320 IPS LCD
Operating Temperature: 0℃- 40℃
Dimensions (L x W x H) : 428.2 x 79 x 28mm
Weight: 810g

Task Select task : Charge,Discharge,
Analysis，Activation
Battery Type
Capacity Plus
Input Power
Limit
BackLight
Buzzer
Language
Self Check
About
Back
Select battery type
On/O
Power limit (applies to N16/N24 )
Three settings: High, Medium, Low
Four settings: High, Medium, Low , O
Default language setting
System self-check
System software information
Back
How To Determine The Battery Type
Usually, the battery chemistry type and the rated voltage are stated on the sleeve of the battery. The
charger will attempt to automatically identify the battery type based on the built-in detection
algorithm but please select the battery types manually if the charger chooses the wrong one.
* NiZn and LiHv batteries need to be selected manually.
Rated Voltage(V)
Full Charge Voltage(V)
Storage Voltage(V)
Discharge Voltage(V)
1.20
1.65
X
0.90
1.50
1.90
X
1.20
3.70
4.20
3.70
3.10
NiCd/NiMH NiZn Li-Ion
3.80
4.35
3.80
3.30
LiHv
3.30
3.65
3.20
2.90
LiFePo4
1.20
1.65
X
0.90
Eneloop
Operation Instructions
With the N Series of battery charger, 8 / 16 / 24 cells of AAA or AA batteries of the same chemistry can
be charged, discharged, analyzed and activated increased in a variety of combinations. When charging
with the battery type selected to be 'Auto', NiMH and Lithium batteries can be charged simultaneously.
1) If you are using the N8, the charger is powered via the USB socket. Connect the auxiliary USB cable
with any USB power adapter and the N8 is turned on and ready for use. The N8 can be powered from a
wide range of USB power adapters and it can automatically identify and adapt to the optimal charging
power.
When the charger is N16 / N24, connect the power adapter supplied with the charger, the N16 / N24 is
turned on and ready for use.
2) Before the battery is inserted, please long press the ○touch key to enter the system setting interface
to preset the task and parameters in the charger.

Interface Denition
1) Current operating slot
3) Charge completed
5) Operation status
7) Working time
9) Battery resistance &temperature
11) Input voltage&power
2) Battery percentage
4) Battery type
6) Battery charge/discharge percentage
8) Voltage&current
10) Battery voltage recording curve
12) Slot without battery inserted
Standby Mode
No batteries are inserted or when the batteries are fully charged, if the charger is not operated within
ve minutes, it will automatically set the display backlight to the minimum brightness level and the
charger will enter standby mode to reduce power consumption. In standby mode, inserting or
removing a battery or pressing any button will activate the charger automatically.
Capacity Plus Charge
When the user selects the battery type as NiMH/NiCd/Eneloop and the task as Charge, an additional
charging option of the task setting interface can be set. If this mode is selected, the charger will
automatically discharge the battery rst and then automatically recharge to full capacity so as to
eliminate the memory eect of the battery, and where possible, increase the capacity of the battery.
3) After correctly setting the parameters and inserting a battery, the charger will beep and sound a
prompt tone. Charge or discharge will start based on the setup parameters selected and the working
status will be displayed on the screen as shown below:
*The taskbar shows the status of each task visually.
means charging, means discharge, means analyze, means activate. After any task is
completed, the tick√will be displayed on the screen instead of the battery percentage. Users can switch
to display the task details of each channel by touching the button ○.
1
4 5
2
12
3
7
6
10
11
7
8
9

Overview Of Channel State
When the charger is N16 / N24, the user will press the touch key to enter the channel state overview
under the working interface. Under this interface, the current working state of all channels will be
displayed, and the user can clearly browse the current battery state of all channels as shown in the
following gure:
Firmware Update
At ISDT we continually strive in the pursuit of perfection to all our products. Our R&D engineers
concentrate their eort over days and months to the enhancement of the functions and control
algorithms, as well as the visual optimization of the user interface. Continuous improvement of
the performance is reected in the rmware upgrade program.
Latest upgrade rmware can be downloaded from the ISDT ocial website.
The upgrade steps of N8 smart charger are as follows:
1) Connect PC and N8 with USB cable.
2) Start the rmware update program (downloaded from the ISDT website) to update the N8
rmware.
The upgrade steps of N16/N24 smart charger are as follows:
1) Connect PC and N16/N24 with USB cable.
2) Plug in the power supply to turn on the N16 / N24.
3) Start the rmware update program and update the N16/N24 rmware according to the
software guidelines.
Packaged Items:
1) N8/N16/N24 smart charger
2) USB cable (applies to N8)
3) Power adapter (applies to N16/N24)
All pictures, statements and text information of this product are for reference only. Please refer
to the actual information on the ocial website www.isdt.co. SHENZHEN ISD TECHNOLOGY
CO.,LTD reserves the right for nal explanation and modication of the specication.
