Isenberg TVH.2705F User manual

www.isenbergfaucets.com
Ver. 2.54
BEFOREYOUBEGIN

•Youmustobservealllocalplumbinglawsandcodes.

•Donotinstallthisvalveifitdoesnotmeetlocalplumbingcodes.
•Shutoffthemainwatersupply.

InstallationManual
3/4”ThermostaticValveWith2or3OutputDiverter
HORIZONTALorVERTICALInstallation
TVH.2705F
3OUTPUT
TVH.2717F
2OUTPUT

NOTICETOHOMEOWNER
• We recommendthatthisproductisinstalledbyaqualified 
professionalplumber.
•Pleasecheckthisproductimmediatelytoensurethatithas
notbeendamagedandiscomplete.Beforeinstallation,please
makesurethisproductisthecorrectmodelandyouhaveall
thepartsrequiredforinstallationanduse.
•Pleaseflushthewatersystemtoensurethatnometalswarf,
solder,andotherimpuritiescanentertheproduct.
•
Turnoffwatersupplybeforecommencingwork. 
•Pleasereadtheseinstructionscarefullyandretainforfuture
reference.
www.isenbergfaucets.com

TABLEOFCONTENTS
• OperatingSpecifications . . . . . . . 1
ValveInstallationAndTolerance
 Cut-OutDimensions . . . . . . . 1
RoughInSpecification . . . . . . 2
ConnectingTheSupply&OutputLines . . . . . 3
FinishedTilePosition . . . . . . . . 5
UsingTheSupplyStops . . . . . . . 6
FlushingTheValve . . . . . . . . 6
InstallingTheTrim . . . . . . . . 7
ReplacingTheThermostaticCartridge . . . . . 11
ReplacingDiverterCartridge . . . . . . . 11
InstallingTheExtensionKit . . . . . . . 12

•
•
•
•

•
•
•
•
•
•
•


WATERTEMPERATURE
ThisvalvemeetsorexceedsANSIA112.18.1andASSE1016
ThisvalveiscertifiedbyIAPMO

WATERPRESSURE

Thisproductistobeusedwithawater
pressurerangeof15PSIto80PSIONLY

Ifwaterpressureisgreaterthan80PSI
installapressurereducingvalve(PRV)

Thisproductistobeusedwithwaterat
atemperaturerangeof40˚F-120˚F
ONLY!

www.isenbergfaucets.com
OPERATINGSPECIFICATIONS

CUTOUTDIMENSIONS
IsenbergʼsTVHSeriesvalvescomeswithablack
pre-attachedmud-guard.Thismud-guardisnot
toberemovedordiscarded.Itspurposeisto
guidetheinstallationprofessionalontheproper
cut-outdimensionsofthedrywall.
Wall Cut Out Dimensions
From Center Point of Valve:
X = 200.5 mm / 7.89”
Y = 48 mm/ 1.89”
Shown Here: Vertical Installation.
Horizontal Installation also possible.
X
Y
1

www.isenbergfaucets.com
ROUGHINSPECIFICATION
The distance between back of
the valve to the nished tile
surface should be between
2.77” and 3.44” inches.
Minimum = 70.5mm [2,77"]
Maximum = 87.5mm [3,44"]
Finished tile should fall
between Min & Max.
If valve is installed too deep
into the wall, extensions are
available.
2

www.isenbergfaucets.com
CONNECTINGTHESUPPLY&OUTPUTLINES
FixValveonwoodenplank LevelValve
AttachHot/ColdLines
3

www.isenbergfaucets.com
CONNECTINGTHESUPPLY&OUTPUTLINES
TWOOUTPUTCONFIGURATION
VALVE:TVH.2717F
Connectthetwooutputsupplylinesas
seenontheleft.
Donotconnectanyotherway.
THREEOUTPUTCONFIGURATION
VALVE:TVH.2705F
Connectthethreeoutputsupplylinesas
seenontheleft.
4

www.isenbergfaucets.com
FINISHEDTILEPOSITION
InstallDrywallandTile.Ensurefinishedtile
surfaceisbetweentheminandmaxmarks
onthemudguards.
5

www.isenbergfaucets.com
USINGTHESUPPLYSTOPS
TurnClock-wise5timestostopwaterflow.
[Threeoutputvalveversionshowerhere]
FLUSHINGTHEVALVE
Inordertocleardirtinthelines-
youmustflushthevalvebeforethe
wallisclosedandwateristurnedon
forthefirsttime.
1)Removethe2supplystopsby
turningwithaspanner
2)Removethermostaticcartridge
byturningwithaspanner
3)Turnonwatersupplyandlet
waterflowremovinganydirtinthe
lines.
6

www.isenbergfaucets.com
INSTALLINGTHETRIM-TRIMPLATESIZEANDSHAPEMAYVARY-ILLUSTRATIONONLY
Removemudguards Install42mmring
Ahardpushmayberequired The42mmringmustbeflush.Otherwisethehandle
willnotfitproperly
7

www.isenbergfaucets.com
INSTALLINGTHETRIM-TRIMPLATESIZEANDSHAPEMAYVARY-ILLUSTRATIONONLY
Inserttrimplate
AlignTrimplatetillitisstraight
Insertadaptorbaseandtighten Insertcenteringknob&screws
8

www.isenbergfaucets.com
INSTALLINGTHETRIM-TRIMPLATESIZEANDSHAPEMAYVARY-ILLUSTRATIONONLY
Insertdiverterhandle.Tightenhexscrew&insert
coverbutton.
Removeanti-scaldtemperaturering
9
Caliberatecartridgebeforeinsertingtemperature
handle.Redmarksmustalign.
Correctlyre-insertanti-scaldtemperatureringinthe
rightposition

www.isenbergfaucets.com
INSTALLINGTHETRIM-TRIMPLATESIZEANDSHAPEMAYVARY-ILLUSTRATIONONLY
Inserttemperaturehandle.Tightenhexscrew&
insertcoverbutton
Thisphotoshowsacompletelyinstalledtrim
Thebuttononthetemperaturehandleisananti
scaldfeature.Inordertorotatethehandlefurther
to“HOT”thebuttonmustbepressed
10

REPLACINGTHEDIVERTERCARTRIDGE
www.isenbergfaucets.com
REPLACINGTHETHERMOSTATICCARTRIDGE
1.RemoveAnti-ScaldRing
2.Thetemperaturecartridgecanbe
removedeasilyinoneoperationby
usingaspanner.
1.RemoveThreadedRodusingaspanner
2.Removediverterflange
3.Removecartridgebyturningwithaspan-
nerandpullingoutwithapairofpliers.
11

www.isenbergfaucets.com
INSTALLINGEXTENSIONSTOTHEVALVE-OPTIONAL-ACTUALVALVEMAYVARY
Installdiverterextensionkit-3Piecesasshown
above
Removeantiscaldtemperaturering
Installtemperatureextensionpieceasshown
above.TightenScrew
12
