iSimple iSimple Connect GM User manual

Expand Your Factory Radio
GM
Owner’s Manual
iSimple Connect

Non-Navigation Radios
1. iPod, iPhone or iPad Operation
The iSimple Connect allows you to use either USB input or Bluetooth for iPod, iPhone
or iPad operation (Bluetooth mode is only supported by iPod Touch, iPhone or iPad).
Entering Mode Select Menu
Press the BAND button a few times until “XM” is displayed on the screen.
Immediately turn the rotary TUNE KNOB in the top right hand corner to scroll
through
available sources. Once “IPODUSB” or “IPODBT” is displayed, press
the FWD>> butto
n to select the displayed mode.
Next Track
Turn the rotary TUNE KNOB clockwise one notch to advance to the next track.
Previous Track
Turn the rotary TUNE KNOB counter-clockwise one notch to move back to the previous
track.
Fast Forward
Press ►I SEEK to fast forward the song that is playing. Press ►I SEEK
again to resume play.
Rewind
Press I◄ SEEK to rewind the song that is playing. Press I◄ SEEK again to resume
play.
Entering Browse Menu / Select
Press the
FWD>> button to enter the browse menu or to make a selection while in
the browse menu.
Menu UP
Press the <<REV button to move back one step in the browse menu.
Exit Browse menu
After 10 seconds on inactivity, the browse menu will exit automatically.
Steering Wheel Controls
Press the ▲ button to advance to the next track.
Press the ▼ button to return to the previous track.
Press the ►I button to enter into the browse menu and to make a selection while in
the browse menu.
Press the ▲ or ▼ buttons while in the browse menu to scroll through the options.

Browse Function Example: Browsing by Artist
Please Note: 80G & 160G iPods with large amounts of music on them
require time to synchronize with the Connect. While this process is
taking place neither the Browse Menu or Mode Select Menu will be
available. This process takes place every time you enter into iPod mode
and can last up to one minute.
Press the
FWD>> button to enter the browse menu.
”PL:LIST” will appear on your display.
Turn the rotary TUNE KNOB until “AR:ARTIST” is displayed.
Press “ FWD>> ” to select browse byArtist.
The list of Artists on your iPod will be displayed one at a time in alphabetical
order. “AR” will be displayed in front of the artist’s name to indicate that you are
searching for an artist.
Turn the rotary TUNE KNOB to cycle through the artists.
When the desired artist is displayed on the radio,
Press the “
FWD>> ” button to select the artist and display the albums by that artist.
The Albums from the selected Artist will be displayed one at a time in alphabetical
order. “AL” will be displayed in front of the name of the album to indicate you are
searching for an album.
Turn the rotary TUNE KNOB to cycle through the albums.
Once the desired album is displayed,
Press the “
FWD>> ” button to select the desired Album.
The rst song in the album will be displayed. “TR” will be displayed in front of the
song title to indicate that a “track” or song title is being displayed.
Turn the rotary TUNE KNOB to cycle through the songs in the selected
album.
Songs are listed in the order in which they appear in the album, not alphabetically .
Once the radio displays the name of the desired song.
Press the “
FWD>> ” button to select and play the desired song.
The display will automatically update to display and scroll the title of the
chosen song.
2. USB Operation
The iSimple Connect allows you to use USB mode with a USB thumb Drive or phone
with mass storage. These devices MUST be formatted to FAT 32 in order for the
Connect to recognize them. The connect will only sipport les in MP3 format. The
maximum amout of les the Connect supports is 8000.
Entering Mode Select Menu
Press the BAND button a few times until “XM” is displayed on the screen.
Immediately turn the rotary TUNE KNOB in the top right hand corner to scroll
through
available sources. Once “USB” is displayed, press the FWD>> butto n to
select the displayed mode.
Next Track
Turn the rotary TUNE KNOB clockwise one notch to advance to the next track.

Previous Track
Turn the rotary TUNE KNOB counter-clockwise one notch to move back to the previous
track.
Fast Forward
Press ►I SEEK to fast forward the song that is playing. Press ►I SEEK
again to resume play.
Rewind
Press I◄ SEEK to rewind the song that is playing. Press I◄ SEEK again to resume
play.
Entering Browse Menu / Select
Press the
FWD>> button to enter the browse menu or to make a selection while in the
browse menu.
Menu UP
Press the <<REV button to move back one step in the browse menu.
Exit Browse menu
After 10 seconds on inactivity, the browse menu will exit automatically.
Steering Wheel Controls
Press the ▲ button to advance to the next track.
Press the ▼ button to return to the previous track.
Press the ►I button to enter into the browse menu and to make a selection while in
the browse menu.
Press the ▲ or ▼ buttons while in the browse menu to scroll through the menus.
Browse Function Example: Browsing by Folder
Press the FWD>> button to enter the browse menu.
”FOLDER” will appear on your display.
Press
FWD>> to select browse by Folder.
The list of Folders on your device will be displayed one at a time in alphabetical
order.
Turn the rotary TUNE KNOB to cycle through the Folders.
When the desired Folder is displayed on the radio,
Press the
FWD>> button to select the Folder and display the Files in that folder.
The Files from the selected Folder will be displayed one at a time in
alphabetical order.
Turn the rotary TUNE KNOB to cycle through the Files.
Once the desired File is displayed,
Press the
FWD>> button to select and play the desired File.
The display will automatically update to display and scroll the title of the
chosen song.

3. Selecting AUX Input
Entering Mode Select Menu
Press the BAND button a few times until “XM” is displayed on the screen.
Immediately turn the rotary TUNE KNOB in the top right hand corner to scroll
through
available sources. Once “AUX 1” or “AUX 2” is displayed, press the
FWD>> butto
n to select the displayed mode.
4. Selecting Factory Installed Sat
(if equipped)
Entering Mode Select Menu
Press the BAND button a few times until “XM” is displayed on the screen.
Immediately turn the rotary TUNE KNOB in the top right hand corner to scroll
through
available sources. Once “SAT” is displayed, press the “FWD>>” butto n to
select the displayed mode.
Factory Sat Operation
Refer to the owners’ manual that came with your vehicle.
Navigation Radios
5. iPod, iPhone or iPad Operation
The iSimple Connect allows you to use either USB input or Bluetooth for
iPod, iPhone or iPad operation (Bluetooth mode is only supported by iPod Touch,
iPhone or iPad).
Entering Mode Select Menu
Press the XM icon on the navigation screen. Immediately turn the rotary TUNE
KNOB in the top right hand corner to scroll through available sources.
Once
“IPODUSB” or “IPODBT” is displayed
, press the ► icon on the screen to select
the displayed mode.
Next Track
Turn the rotary TUNE KNOB clockwise one notch to advance to the next track.
Previous Track
Turn the rotary TUNE KNOB counter-clockwise one notch to move back to the previous
track.
Fast Forward
Press ►I SEEK to fast forward the song that is playing. Press ►I SEEK again to
resume play.
Rewind
Press I◄ SEEK to rewind the song that is playing. Press I◄ SEEK again to resume
play.

Entering the Browse Menu / Select
Press the ►icon on the screen to enter the browse menu or to make a selection
while in the browse menu.
Menu Up
Press the ◄icon on the screen to move back one step in the browse menu.
Steering Wheel Controls
Press the ▲ button to advance to the next track.
Press the ▼ button to return to the previous track.
Press the ►I button to enter the browse menu or to make a selection while in the
browse menu.
Press the ▲ or ▼ buttons while in the browse menu to scroll through the menus.
Browse Function Example: Browsing by Artist
Please Note: 80G & 160G iPods with large amounts of music on them
require time to synchronize with the Connect. While this process is
taking place neither the Browse Menu or Mode Select Menu will be
available. This process takes place every time you enter into iPod mode
and can last up to one minute.
Press the ► icon on the screen to enter the browse menu.
”PL:LIST” will appear on your display.
Turn the rotary TUNE KNOB until AR: ARTIST is displayed.
Press the ► icon to select browse by Artist.
The list ofArtists on your iPod will be displayed one at a time in alphabetical order.
“AR” will be displayed in front of the artist’s name to indicate that you are searching for
an artist.
Turn the rotary TUNE KNOB to cycle through the artists.
When the desired artist is displayed on the radio,
Press the ► icon to select the artist and display the albums by that artist.
TheAlbums from the selectedArtist will be displayed one at a time in alphabetical
order. “AL” will be displayed in front of the name of the album to indicate you are
searching for an album.
Turn the rotary TUNE KNOB to cycle through the albums.
Once the desired album is displayed,
Press the ► icon to select the desired Album.
The rst song in the album will be displayed. “TR” will be displayed in front of the song
title to indicate that a “track” or song title is being displayed.
Turn the rotary TUNE KNOB to cycle through the songs in the selected album.
Songs are listed in the order in which they appear in the album, not alphabetically.
Once the radio displays the name of the desired song,
Press the ► icon to select and play the desired song.
The display will automatically change to display and scroll the title of the chosen song.

6. USB Operation
The iSimple Connect allows you to use USB mode with a USB thumb Drive or phone
with mass storage. These devices MUST be formatted to FAT 32 in order for the
Connect to recognize them. The connect will only sipport les in MP3 format. The
maximum amout of les the Connect supports is 8000.
Entering Mode Select Menu
Press the XM icon on the navigation screen. Immediately turn the rotary TUNE
KNOB in the top right hand corner to scroll through available sources. Once
“USB” is displayed, press the ► icon on the screen to select the displayed
mode.
Next Track
Turn the rotary TUNE KNOB clockwise one notch to advance to the next track.
Previous Track
Turn the rotary TUNE KNOB counter-clockwise one notch to move back to the previous
track.
Fast Forward
Press ►I SEEK to fast forward the song that is playing. Press ►I SEEK
again to resume play.
Rewind
Press I◄ SEEK to rewind the song that is playing. Press I◄ SEEK again to resume
play.
Entering Browse Menu / Select
Press the
FWD>> button to enter the browse menu or to make a selection while in the
browse menu.
Menu UP
Press the <<REV button to move back one step in the browse menu.
Exit Browse menu
After 10 seconds on inactivity, the browse menu will exit automatically.
Steering Wheel Controls
Press the ▲”button to advance to the next track.
Press the ▼ button to return to the previous track.
Press the ►I button to enter into the browse menu and to make a selection while in
the browse menu.
Press the ▲ or ▼ buttons while in the browse menu to scroll through the menus.

Browse Function Example: Browsing by Folder
Press ► on the screen to enter the browse menu.
”FOLDER” will appear on your display.
Press ► on the screen to select browse by Artist.
The list of Folders on your device will be displayed one at a time in the order
they are loaded.
Turn the rotary TUNE KNOB to cycle through the Folders.
When the desired Folder is displayed on the radio,
Press ► on the screen to select the Folder and display the Files in that folder.
The Files from the selected Folder will be displayed one at a time in
alphabetical order.
Turn the rotary TUNE KNOB to cycle through the Files.
Once the desired File is displayed,
Press ► on the screen to play the desired File.
The display will automatically update to display and scroll the title of the
chosen song.
7. Selecting AUX Input
Entering Mode Select Menu
Press the XM icon on the navigation screen. Immediately turn the rotary
TUNE KNOB to scroll through available sources. Once “AUX 1” or “AUX 2” is
displayed, press the ► icon on the screen to select the displayed mode.
8. Selecting Factory Installed Sat
(if equipped)
Entering Mode Select Menu
Press the XM icon on the navigation screen. Immediately turn the rotary TUNE
KNOB in the top right hand corner to scroll through available sources. Once
“SAT” is displayed, press the “►” icon on the screen to select the displayed
mode.
Factory Sat Operation
Refer to the owners’ manual that came with your vehicle.

9.Bluetooth Operation
Pair Your Phone
To use the iPhone with the Connect you must rst pair it. Enter your phone’s
Bluetooth menu and search for a new device. It should discover the device
named “iSimple Connect”. If prompted for a PIN code enter 0000, otherwise just
select “Pair”.
Selecting Bluetooth Mode
Navigation Radios
Press the XM icon on the screen. Immediately turn the TUNE KNOB until “BT” is
displayed. Press the ► icon on the screen to select the displayed mode.
Non-Navigation Radios
Press the BAND button a few times until “XM” is displayed. Immediately turn
the TUNE KNOB until “BT” is displayed. Press the FWD>> button to select the
displayed mode.
Bluetooth Functions & Controls
1. Answer/End Call - Allows you to make, recieve & end phone calls
directly from the factory radio. Press SEEK>> to answer/end a call. You can
also press the ►I button on the SWC to answer/end a call.
2. Call Waiting - Allows you to receive a call while on another call. Press
SEEK>> while in a call to answer a third party call. You can then use
SEEK>> to switch between the callers. Press and HOLD SEEK>>
to end third party calls.
3. Privacy Mode - Allows you to transfer the audio from the vehicle
speakers to the handset. Press <<SEEK while in a call to switch
to privacy mode.
4. Reject Call - Allows you to reject any incoming call. Press <<SEEK
to reject an incoming call.
5. Voicedial - Allows you to press a button on the radio and say the
name of the person you wish to call.
Navigation Radios
While in Bluetooth mode, press the BROWSE icon, then press the
VOICECALL icon & then press the BACK icon to activate voicedial.
Non-Navigation Radios
While in Bluetooth mode, press the CAT button & then press the VOICECALL
button to activate voicedial.

6. Call History - Allows you to scroll through a list of the most recent
incoming calls to your phone. Turn the TUNE KNOB while in Bluetooth
mode to scroll through a list of your previous incoming calls. You can
also use the ▲ & ▼ buttons on the SWC to scroll through a list of your
previous incoming calls.
7. Call Last # - Allows you to call the last incoming number to your
phone. Press SEEK>> while in Bluetooth mode to call the last
incoming number to your phone.
8. In Call Volume Adjust - Allows you to adjust the volume output of the
interface while in a call. Turn the TUNE KNOB while in a call to adjust
the volume.
9. Menu - Allows you to adjust settings such as phone volume, streaming
audio volume (A2DP), microphone volume, search for other Bluetooth
devices, pair/ remove devices & reset the interface. See below for menu
functions and operation.
IMPORTANT NOTE
In order to access the Voicedial, Call History, Call Last Number & Menu
functions, the factory radio MUST be in Bluetooth mode.
Menu Functions
Navigation Radios
While in Bluetooth mode press the ► icon to enter the menu. Once in the menu
you can use the TUNE KNOB to scroll through the options. Press the ► icon
while in the menu to select the displayed option.
Non-Navigation Radios
While in Bluetooth mode press the CAT button then press the >>>>> button
to enter the menu. Once in the menu you can use the TUNE KNOB to scroll
through the options. Press the >>>>> button while in the menu to select the
displayed option.
1. Settings - Allows you to perform a search for other Bluetooth enabled
devices, adjust the phone volume and adjust the microphone volume.
2. Device - Allows you to see if a device is paired and the name of the paired
device. Allows you to connect and disconnect with paired devices as well as
permanently delete paired devices.
3. Revision # - Allows you to see the rmware revision number of the Connect.

Menu Function Example: Adjusting the Microphone
>Press the ► icon while in Bluetooth mode to enter the menu.
>Radio displays “Settings”.
>Press the ► icon to select Settings.
>Radio displays “BT Search”.
>Turn the TUNE KNOB until “Mic Volume” is displayed.
>Press the ► icon repeatedly to adjsut the microphone volume. Once
the volume has reached its max limit it will roll back to one and begin to
go up again.
Menu Function Example: Viewing Revision #
>Press the ► icon while in Bluetooth mode to enter the menu.
>Radio displays “Settings”.
>Turn the TUNE KNOB until “Revision #” is displayed.
>Press the ► icon to view the revision number. Turn the TUNE KNOB to toggle
between the NXP & IMX revision numbers.
A2DP Streaming Audio
A2DP StreamingAudio allows you to stream audio wirelessly from your device.To
stream audio to your radio you must be in Bluetooth mode.
1. Play/Pause - Allows you to play/pause A2DP audio with the touch of a
button. Press <<SEEK to Play/Pause the song that is selected. You
can also press the ►I button on the SWC to Play/Pause the song that
is selected.
2. Track Forward/Back -Allows you to change tracks while streaming
audio. Turn the TUNE KNOB to change tracks. You can also use the
▲ & ▼ buttons on the SWC to change tracks.

Symptom Cause Remedy
Radio shows “DEV
INIT” Connect device is initializing This only occurs the rst time the Connect is powered on or after it has
been reset. It may take up to one
minute for the device to initialize. Once
this process is over you can begin
Connect operation.
Radio shows iPod
not connected iPod cable is not connected to iPod or
Connect; the iPhone
is not paired via
Bluetooth
Verify the USB docking cable is
plugged into the Connect and the
iPod. If you are using Bluetooth mode
make sure that the device is paired
with the Connect.
I don’t see iPod,
iPhone, or iPad
artist or song
information on the
screen
You are in Bluetooth
mode. Switch to IPODBT mode using the mode select menu.
USB Device is not
recognized Device must be formatted to FAT32 Use a PC to format device to FAT32
Phone is not
recognized as a
USB device
Phone is not set to
disk drive mode or
does not support
the mass storage
protocol.
Disconnect and reconnect the phone.
Immediately set the phone to disk
drive mode when prompted. If the
phone does not give you a disk drive
mode option, this means that it does
not support the mass storage protocol.
These devices can only be used
through the Bluetooth or auxiliary
modes.
My tablet will not
stay connected via
Bluetooth.
The tablet does not
support the hands
free prole (HFP)
hands free prole
The connect requires that the paired
device support the hands free prole
(HFP). If your tablet does not support
this type of connection it can only be
used through USB or auxiliary mode.
11. Troubleshooting
PAC ELECTRONICS ACCESSORIES AUDIO ACCESSORIES
