Isimple Gateway Reference guide

GateWay (PXAMG) / DuaLink (PXAUX)

Reset Procedure

Technical Support

1.With a #1 Philip head screwdriver remove the two screws on the bottom of the module and

remove the circuit board from the housing.

2. Locate the 24 Pin connector that plugs into the vehicle specific harness, next to it you will

see a bank of nine capacitors.

3.Within the group of nine capacitors there will be one that is larger than the rest and have a“+”

symbol on the top of it. (see Fig. 1)

Fig. 1

4. Flip the module over and find the two leads from that capacitor. (see Fig. 2)

5.Take your screw driver or any other metal object and touch these two leads together temporarily

to drain the residual voltage from this capacitor.

6. Place module back into the housing and secure the housing back together using the screws

that were removed in Step #1.

7. Install module back into vehicle ensuring that the iPod or other accessories are connected to the

module prior to plugging the module into the vehicle.

Fig. 2

** MODULE MUST BE DISCONNECTED FROM THE VEHICLE BEFORE PERFORMING THE FOLLOWING STEPS **

The HDRT (High Definition Radio Tuner) is an expansion interface for iSimple’s

GateWay. By using the HDRT you will receive the standard analog stations as

well as the available HD stations in your area. HD radio stations vary based on

location.

Connecting the HDRT

• If GateWay interface has already been installed, remove from the vehicle and

leave it disconnected for no less than 5 minutes.

• The original radio tuner is no longer needed. Disconnect the vehicles antenna

from the original radio and connect to the HDRT. A vehicle antenna adapter

may be needed in order to change the vehicle antenna connection into the

standard Motorola connection type. If you wish to retain the original radio tuner

in conjunction with the HDRT you will need a BAWM200 universal windshield

mount antenna. DO NOT split the vehicle antenna between the HDRT and the

original radio tuner. This will degrade the radio signal for both the HD tuner and

the original radio tuner resulting in poor radio reception. Instead connect the

vehicle’s antenna into the HDRT. Connect the BAWM200 into the factory radio’s

antenna port.

Vehicle Connections:

Connect the 2 devices (HD Radio and iPod or AUX) to GateWay vehicle specific

interface. The HDRT will connect in place of the AUX or iPod cable. The two

selected device cables must be connected to GateWay vehicle specific

interface before connecting to the vehicle. Below are interface specific

installation notes and operation tips. Make sure to read all notes and tips before

connecting to the vehicle. Once connected to the vehicle wait 60 seconds

before using the interface. This time is needed for initialization.

ISFD571

The HDRT should be connected to Device 2. Switch 2 should be in the down

(On) position.

• Press AUX or SAT button until HD-FM1, HD-FM2, HD-FM3 or HD-AM is displayed.

•SEEK ►will seek up to the next available station based on signal strength.

•◄SEEK will seek down to the next available station based on signal strength.

• Pressing and holding SEEK ►for more than 2 seconds will change from

MANUAL to AUTO or from AUTO to MANUAL. The radios display will confirm the

selected mode.

• Storing stations - Tune to the desired station. Press a PRESET 1-6 and hold for

approximately 3 seconds until is displayed. To recall a preset station press the

desired PRESET button. HD and analog stations can be stored. HD stations are

identified by HD1, HD2 or HD-3 following the station frequency.

•TEXT/SCAN will change the display to show artist or song title if available.

ISTY571

• The HDRT should be connected to Device 2.

• Press SAT or AM/SAT until is HD RADIO displayed. Press Preset 3 to select the

source. By pressing the AM/SAT or SAT button after has been selected you will

switch between HD-FM1, HD-FM2, HD-FM3 or HD-AM.

• Tune up - turn the rotary TUNE KNOB to the right to move up one frequency at

a time.

• Tune down - turn the rotary TUNE KNOB to the left to move down one

frequency at a time.

•SEEK ►will seek up to the next available station based on signal strength.

•◄SEEK will seek down to the next available station based on signal strength.

• Storing stations - Tune to the desired station. Press Preset 1-6 and hold for

approximately 3 seconds until PR SAVED is displayed. To recall a preset station

press the desired Preset button. HD and analog stations can be stored. HD Radio

stations are indicated by HD1, HD2 or HD3 following the station frequency.

•TEXT will change the display to show artist or song title if available.

Note for vehicles with a diversity antenna: In the large 20-pin main power and audio connector

pin 13 is the amplified antenna turn on wire. This wire must be cut from the original connector

and attached to pin 11, the radio accessory +12v wire. During SAT emulation this circuit is not

energized by the radio. It must be energized for HD radio signal. The circuits can be verified with

a volt meter.

ISGM575

• The HDRT should be connected to Device 2.

• Press the BAND button until XM is displayed. Turn the rotary TUNE KNOB until HD

RADIO is displayed. Wait 4 seconds and the source will be automatically be

selected. Pressing the BAND button after HD Radio has been selected will switch

between HD-FM and HD-AM.

• Tune up - turn the rotary TUNE KNOB to the right to move up one frequency at

a time.

• Tune down - turn the rotary TUNE KNOB to the left to move down one

frequency at a time.

•SEEK ►will seek up to the next available station based on signal strength.

•◄SEEK will seek down to the next available station based on signal strength.

• Storing stations - Tune to the desired station. Press Preset 1-6 and hold for

approximately 3 seconds until a beep is heard. To recall a preset station press

the desired Preset button. HD and analog stations can be stored. HD stations are

indicated by HD1, HD2 or HD3 following the station frequency.

•DISP will change the display to show artist or song title if available.

ISGM571 and ISGM572

• The HDRT should be connected to Device2.

• Press the BAND button until is displayed. Turn the rotary TUNE KNOB until is

displayed. Press the FWD>> button to select HD Radio as the source. If you are

currently in the XM mode you will need to press ►ISEEK instead of FWD>>. To

change between HD-FM and HD-AM press the CAT button until HD1, HD2 or HD3

is displayed. Press a button below the displayed text to select that band.

• Tune up - Turn the rotary TUNE KNOB to the right to move up one frequency at

a time.

• Tune down - Turn the rotary TUNE KNOB to the left to move down one

frequency at a time.

• ►ISEEK will seek up to the next available station based on signal strength.

•◄SEEK will seek down to the next available station based on signal strength.

• Storing stations - Tune to the desired station. Press FWD>> and use the TUNE

knob to select 1-18. PRE 1-18 will be displayed. Press I◄SEEK to store the station

into memory. To recall a preset station press the FWD>> button and use the TUNE

knob to select a preset 1-18. Press the ►ISEEK button to select the displayed

preset. HD and analog stations can be stored. HD stations are indicated by HD1,

HD2 or HD3 following the station frequency.

• i - will change the display to show artist or song title if available.

ISHD571

• The HDRT should be connected to Device 2.

• Press the XM button and then turn the TUNE KNOB until HD-FM is displayed.

Press PRESET 6 to select the source. By pressing the XM button after HD-FM has

been selected you will switch between HD-FM or HD-AM.

• Tune up - turn the rotary TUNE KNOB clockwise to move up one frequency at a

time.

• Tune down - turn the rotary TUNE KNOB counter-clockwise to move down one

frequency at a time.

•SEEK > will seek up to the next available station based on signal strength.

•< SEEK will seek down to the next available station based on signal strength.

• Storing stations - Tune to the desired station. Press PRESET 1-6 and hold for

approximately 3 seconds until PR SAVED is displayed. To recall a preset station

press the desired Preset button. HD and analog stations can be stored. HD Radio

stations are identified by HD1 or HD2 following the station frequency.

•DISP will change the display to show artist or song title if available.

ISHY571 & ISHY572

The HDRT should be connected to Device 2.

• Press the XM button until HD-FM1, HD-FM2, HD-FM3 or HD-AM is displayed.

• Tune up - turn the rotary TUNE KNOB clockwise to move up one frequency at a

time.

• Tune down - turn the rotary TUNE KNOB counter-clockwise to move down one

frequency at a time.

•SEEK > will seek up to the next available station based on signal strength.

•< SEEK will seek down to the next available station based on signal strength.

• Storing stations - Tune to the desired station. Press a PRESET 1-6 and hold for

approximately 3 seconds until PRSAVED is displayed. To recall a preset station

press the desired PRESET button. HD and analog stations can be stored. HD

stations are identified by HD1or HD2 following the station frequency.

• INFO will change the display to show artist or song title if available.

ISNI571 & ISNI572

Radios Equipped with a RADIO or FM/AM/SAT button:

• The HDRT should be connected to Device 2.

• Press the RADIO or FM/AM/SAT button until is SAT displayed. Press the SEEK >

button until HD-FM or HD-AM is displayed. Press the < TUNE button to select HD

Radio as the source.

• Tune up - Press the TUNE > button to move up one frequency at a time.

• Tune down - Press the < TUNE button to move up one frequency at a time.

•SEEK > will seek up to the next available station based on signal strength

• < SEEK will seek down to the next available station based on signal strength.

• Storing stations - Tune to the desired station. Press the SCAN button to enter the

Preset Menu. Use the SEEK > or < SEEK buttons to select a Preset location. Press

TUNE > to store the station into memory. The radio will display PRSAVED. To recall

a preset station press the SCAN button to enter the Preset Menu. Use the SEEK >

or < SEEK buttons to select a Preset. Press the < TUNE button to select the

displayed preset. HD and analog stations can be stored. HD stations are

identified by HD1 or HD2 following the station frequency.

•DISP will change the display to show artist or song title if available.

Radios Equipped with a SAT button:

• The HDRT should be connected to Device 2.

•Press the FM button and then the SAT button. Press the SEEK > button until HD-

FM or HD-AM is displayed. Press the < TUNE button to select HD Radio as the

source.
