iSimple SoundByteX ISCH73 User manual

Peripheral Electronics®,
a division of AAMP of America™
13160 56th Court Clearwater, Florida 33760
Ph. 866-788-4237
[email protected]
©2007 AAMP of Florida, Inc.
Owner’s
Manual
Media Gateway
PXAMG
Expand Your Factory Radio
iSimple®
a division of AAMP of America™
13190 56th Court Suite 401 Clearwater, Florida 33760
Ph. 866-788-4237
[email protected]
©2009 AAMP of Florida, Inc.
add
iPod®
& Audio Input
Rev. 08-28-09
Inst025
Chrysler/Dodge
Jeep
Owner’s Manual
SoundByteX
ISCH73

Installation:
The factory radio model name can usually be found in the front lower left corner
of the radio. If the vehicle has a VES (Video Entertainment System), it must
be disconnected! This interface is not compatible with REF model radios.
They do not have a VES input available.
1. Remove factory radio. Remove factory female 10 pin Satellite cable, if avail-
able. Plug the ISCH73’s 10 pin SAT plug into the radio. Plug the factory Satel-
lite cable that was just removed into the ISCH73’s 10 pin connector.
2. Insert the ISCH73’s 22 pin main power Plug (T-Harness) in between the fac-
tory radio and factory harness.
3. If the vehicle has both factory Satellite and VES, you must disconnect the VES
at the overhead unit. The Satellite radio will still be available for use. If the
vehicle has factory single disc radio (REF), this interface is NOT com-
patible. Refer to vehicle’s repair manual for location and removal of the VES
plug.
4. The ISCH73 output plug (3 pin connector) must be connected to the VES
input harness of the 10 pin T-harness (Purple, Black, Green).
5. To activate iPod® mode, press the MODE button until VES is selected. When
Chp 1 is displayed the iPod® will be the selected source. If Chp 2 is selected
Aux 2 (standard RCA input) mode will be the selected source. Pressing the
MODE button will select either Chp 1 or Chp 2, alternating each time the VES
mode is selected.
Chp 1 - iPod® mode
Chp 2 - Auxiliary mode
Note: The ISCH73 will emulate the VES only! If the vehicle has factory VES
it MUST be disconnected. VES does NOT operate in R.A.P. mode. The
radio will automatically switch to tuner mode during R.A.P. (Retained
Accessory Power)
The RED wire with fuse holder: This wire provides a +12 volt output when key
is in accessory or ignition position. The output is 1 amp max. Insulate end
if not used. Warning! Do Not connect this wire to the vehicle’s accessory/
ignition wiring.
10 pin
22 pin
Auxiliary 2 audio input
(Chp 2)
Accessory Output +12volts 1amp max.
iPod
(Chp 1)
Purple, Black, Green (VES input)
White, Brown, Gray (Satellite input)
DO NOT USE
Output
Aux
Acc. ON
iPo d
L
R
L
R
Use with radio m odels :
3&$t3"2t3",
ISCH73
iPod & Aux Audio
for select C hrysler ve hicles

Operation:
Controlling your iPod from the Radio
RAK and RAQ Radio Buttons:
REC Radio Buttons:
►►l
SEEK
l◄◄
SEEK
►►
FF
◄◄
RW
RND
PTY
SCAN
Previous Playlist - The interface will automatically play the rst track in
that folder upon entering it. There must be a song in the playlist or it will
be skipped.
Track Down - This will select the previous track in the selected playlist.
Track Up - This will select the next track in the selected playlist.
Seek Up - This button will act the same as the Track Up button if pressed
for less than 1 second. If pressed and held, it will fast forward the
selected track.
Seek Down - This button will act the same as the Track Down button if
pressed for less than 1 second. If pressed and held, it will rewind into the
selected track at a rapid rate.
Next Playlist - This will jump into the next available playlist and begin
playing the rst track. There must be a track in the playlist in order to
enter it.
►►l
l◄◄
SET / RND
Seek Down - If pressed for less than 1 second this the previous track will
be selected. If pressed and held, it will rewind into the selected track at
a rapid rate.
Seek Up - If pressed for less than 1 second, the next track will be
selected. If pressed and held, it will fast forward the selected track.
Next Playlist - This will jump into the next available playlist and begin
playing the rst track. There must be a track in the playlist in order to
enter it.
** There is no syncing text display on any of these radio’s with this
interface. The iPod® click wheel will be available for use with this
interface in conjunction with the radio’s control buttons. Charging
of the iPod will occur during Accessory, Ignition and R.A.P. modes.
On the steering wheel, only the Track Up and Track Down buttons
will control the iPod.
DISCLAIMER: Under no circumstances shall the manufacturer or the distributors of the
ISCH73 parts be held liable for consequential damages sustained in connection with
the ISCH73. The manufacture and it’s distributors will not, nor will they authorize any
representative or any other individual to assume obligation or liability in relation to the
ISCH73 other than its replacement.
