SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
No part of this publication may be reproduced by any mechanical, photographic or
electronic process, or in the form of a phonographic recording, nor may it be stored in a
retrieval system, transmitted or copied for public or private use, without written
permission of the publisher.
The game play, all graphic designs, this manual and its accompanying schematic
diagrams are protected by the US Copyright Act of 1976.
This act provides substantial penalties for violating federal copyright laws. Courts can
impound infringing articles while legal action is pending. If infringers are convicted,
courts can order destruction of the infringing articles.
In addition, the Act provides for payment of statutory damages of up to $50,000 per
infringing transaction, in certain cases. Infringers may also have to pay cost and
attorney’s fees and face an imprisonment of up to five years as well as fines of up to
$250,000 in the case of individuals, and up to $500,000 in the case of Corporations.
ISLAND DESIGN will aggressively enforce its copyrights against infringers. We will use
all legal means to immediately halt any manufacturing, distribution of operation of a copy
of any games made by us. Anyone who purchases such copies risk forfeiting such a
game.
Published by:
ISLAND DESIGN, INC.
1005 Ventana Drive
Windsor, CA 95492
Phone: [phone]
Fax: [phone]
Produced and printed in the USA by the Island Technical Staff.
Copyright (c) 1996 Island Design, Inc.
2

SPIDER STOMPIN’ DELUXE OWNER’S MANU
TABLE OF CONTENTS
Disclaimers & Safety Guide
Notice Regarding Non-Island Design Parts
Game Specifications
Out of Box Assembly Instructions
Game Description
Ticket Dispenser
Plasma Display
Service Panel
Self-Test Mode
Part Numbers
Switch Settings
Wiring Diagrams
5
6
6
7
8
8
8
9
10
13
I4
I7
Copyright (c) 1996 Island Design, Inc.
3

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
ISLAND DESIGN INC.
1005 Ventana Dr.
Windsor, Ca. 95492
Phone: [phone]
Fax: [phone]
ISLAND
DESIGN
INC.
Copyright (c) 1996 Island Design, Inc.
4

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
DISCLAIMERS & SAFETY GUIDE
The following safety precautions apply to all game operators and service personnel.
Specific warnings and cautions will be found in this manual whenever they apply.
WAEiVING!
Properly Ground the Game
Players may receive an electrical shock if this game is not properly grounded! To avoid
electrical shock, do not plug in the game until it has been inspected and properly
grounded. This game should only be plugged into a grounded three-wire outlet. If you
have only a two-wire outlet, we recommend you hire a licensed electrician to install a
three-wire grounded outlet. If the coin door is not properly grounded, players may
receive an electrical shock! After servicing any part on the doors, check that the
grounding wire is firmly secured. After you have verified this , lock up the game.
AC Power Connection
Before you plug in the game, be sure that the game’s power supply can accept the AC line
voltage in your location. The line voltage requirements are contained within this manual.
Disconnect Power During Repairs
To avoid electrical shock, disconnect the game from the AC power before removing or
repairing any part of the game. The power supply capacitor retains energy for a period of
time even after the AC power is removed. Use care when working near them or on any
circuitry connected to them.
Use the Proper Fuses
To avoid electrical shock, use replacement fuses which are specified in the parts list for
this game. Replacement fuses must match those replaced in fuse type, voltage rating, and
current rating. In addition, the fuse cover must be in place during game operation. Refer
to the Power Supply wiring diagram for more information.
CAUTION!
Properly Attach All Connectors
Make sure that the connectors on each printed circuit board (PCB) are properly plugged
in. The connectors are keyed to fit only one way. If they do not slip into place easily, do
not force them. If you reverse a connector, you may damage your game and void your
warranty.
Copyright (c) 1996 Island Design, Inc.
5

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
NOTICE REGARDING NON-ISLAND DESIGN PARTS
WARNING!
Use of non-ISLAND DESIGN parts or modifications of any Island Design game circuitry
may adversely affect the safety of your game, and may cause injury to you and your
players.
NOTE: This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instruction manual, may cause interference
to radio communications. It has been tested and found to comply with the limits for a
Class A computing device pursuant to Subpart J of part 15 of Federal Communications
Commission (FCC) Rules, which are designed to provide reasonable protection against
such interference when operated in a commercial environment. Operation of this
equipment in a residential area or modification to this equipment is likely to cause
interference, in which case the user, at his own expense, will be required to take whatever
measures may be required to correct the interference. If you suspect interference from an
ISLAND DESIGN game at your location, check the following:
* All ground wires in the game are properly connected as shown in the game
wiring diagram.
* The power cord is properly plugged into a grounded three wire outlet.
GAME SPECIFICATIONS
Temperature
Humidity
Sunlight
Line Voltage
Width
Depth
Height
Wei pht
+6 to +45 Degrees C
Not to exceed 90% relative
Do not store, operate or use in direct sunlight
105-132 VAC 60Hz (US Games)
4 1 .OO”
57.50”
66.00 “
Approx. 225 lbs.
CAUTION: For indoor use only.
CAUTION: Disassemble before moving.
Copyright (c) 1996 Island Design, Inc.
6

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
OUT OF BOX ASSEMBLY INSTRUCTIONS
Items Required to Properly Assemble the Game:
lHand truck. This is used to move the machine from it’s box to it’s final operating
Steps to Setting Up Your Spider Stompin’ Deluxe Game:
Unpack the game and carefully check each cabinet for shipping damage.
1.
2.
Move the 2 separate cabinet sections to the to the final location of operation for
assembly.
3.
4.
Remove the 3 shipping screws in the top of the foot pad assembly.
Position coin door cabinet in the correct position and slide the foot pad under the I
C ,oin
door cabinet.
5.
6.
7.
8.
9.
Plug in the 2 mating connectors between the two cabinets.
Verify that the AC line voltage is correct and power up the machine.
Use the test mode or play the game to test all of the lights on the foot pads.
After verifying all lights work, take the 4 black fender washers and the 2 %” X 5/16”
bolts out of the cash box and from the side of the coin box cabinet bolt together the 2
cabinet sections.
Add tickets and your finished.
~OCPwlhlX, Inr!atinn
u~z&lu”rJ I”“UCI”II.
l5/l 6” Allen Head Driver
and
Copyright (c) 1996 Island Design, Inc.
7

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
GAME DESCRIPTION
Spider Stompin’ Deluxe is an easy to play game in which all players can play and enjoy
from toddlers to adults. The internal programmed intelligence of the game makes
adjustments to make it easy for young players and more difficult for the more skillful
players. When a coin is inserted into either coin slot the game start lights will start to
3, “ ~~ _ ,‘- _.__ __. A,__ “l___.Jx l___u__
Tq__ l__&&___ __ +L_
flash. The piayer can press the “easy , meuwrl or me IIWU UULLUII. I 11t; UULLUII~ UI~ LIIC
foot pad will randomly start to flash. The object of the game is to hit the buttons before
the light goes out. The player scores points each time the button is hit while the light is
on. The player DOES NOT get extra points for hitting the buttons harder.
Each time a button is successfully stomped one stomp will be register in the animated the
score display. Ticket payouts are based on the how well you did against your opponent ,
whether human or computer, depending on your selected dip switch setting.
TICKET DISPENSER
Each Spider Stompin’ Deluxe game is shipped from the factory with 2 Deltronics Labs,
Inc. model DL-1275 Ticket Dispensers installed. Tickets are dispensed when the game
has completed play. The number of tickets dispensed is a fixed number or based on the
final percentage and is determined by the dip switches on the game PCB.
The Ticket
Dispenser Door Includes:
l Ticket counter
l Low Ticket Switch
lLow Ticket Indicator - lights when the ticket count falls below approx. 200.
For maintenance and troubleshooting instructions concerning the Ticket Dispenser, refer
to the Deltronics manual included with the game.
The manufacturer reserves the right to change equipment and features at any time in its
efforts to produce the best product possible.
PLASMA DISPLAY
The Plasma Glass display contains the scoring for the game as well as an attraction for
spectators and players.
Copyright (c) 1996 Island Design, Inc.
8

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
SERVICE PANEL
The Service Panel is located on top of the cash box assembly, and includes:
I
Coin Counter - Increments once each time a coin is dropped through either
coin slot.
Service Switch - The bottom black button on the service panel, it is used to
add credits to the game without incrementing the coin counter.
Test Switch - The upper red button on the service panel, it is used to put
t
game into the self-test mode.
Copyright(c) 1996 Island Design, Inc.
9

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
SELF-TEST MODE
Spider Stompin’ Deluxe tests itself and provides visual and audible indications of the
condition of the game controls and circuitry. No equipment other then the game is
required to operate the self-test mode.
We suggest that you perform a self-test when you first set up the game, once a day, when
you collect coins from the game and whenever you suspect game failure.
Turn on the game. If anything strange happens such as bright flashes indicating blown
fuses or lights immediately power down the game. Re-inspect all connections and
consult an authorized skilled technician for help.
The self-test switch is located on the service panel behind the coin door on top of the coin
bucket. Depress the switch once to enter self-test mode. Once the self-test has been
entered you must completely run the test to it’s completion or turn the game off in order
to exit the self-test mode.
During the self-test mode all output devices (i.e. lamps, LED digits, ticket dispenser and
counter, coin counter and speaker) are cycled through. At times while an output device
is being tested and input switch may also be tested. The devices and switches are tested
in the following order.
Three (3) coins are added to the coin counter.
The three sets of lights behind the queen on the marquee cycled and finally all the lights
behind the queen on the marquee will come on and go off.
The four cartoon box lights will cycle from the top box to the bottom box. After the
cartoon box lights have cycled all cartoon boxes, they will all come on at once and then
go off.
The light on the EASY button will come on. The EASY light will only stay on for 15
seconds or until the button is pressed. If the EASY button is prissed you will hear an
audible ‘GO!’ and the self-test mode will immediatelyu contunue with step #5.
One (1) ticket will be dispensed along with a ticket dispense sound effect. If one ticket
was successfully dispensed then one ticket will be added to the ticket counter.
Copyright (c) 1996 Island Design, Inc.
10

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
6.
7.
8.
The light on the MEDIUM button will come on. The MEDIUM light will only stay on
for 15 seconds or until the button if pressed. If the MEDIUM button is pressed you will
hear an audible ‘GO’ and the self-test will continue with step #7.
Two (2) tickets will be dispensed along with a ticket dispense sound effect. If three
tickets were successfully dispensed then two tickets will be added to the ticket counter.
The light on the HARD button will come on. The HARD light will only stay on for 15
seconds or until the button if pressed. If the HARD button is pressed you will hear an
9.
audible ‘GO’ and the self-test will immediately continue with step ff 9.
Three (3) tickets will be dispensed along with a ticket dispense sound effect.
If three
tickets were successfully dispensed then three tickets will be added to the ticket tour
10. All foot pad lights will be cycled starting with the bottom right-most light and endiq
with the bottom left-most light. Each button will stay on for a maximum of 10 secor
If the lit button is pressed you will hear a swish sound effect and the button light will
immediately go out and the next one will come on until all lights and switches have 1
tested.
All sound effects and phrases will then be played in the following order:
Four (4) Background drum clips
Five (5) Crunch sound effects
Two (2) Ouch sound effects
New Light sound effect
Game End sound effect
Coin Drop sound effect
Ticket Dispense sound effect
Very nice Stompin’ Human. Your a Winner!
Ah ha spiders win.
1 But I hope you’ll stick around to try again!
One more coin please!
Get Ready!
GO!
Hello!
Well, Well, Well, Look what we caught!
Now for round number 2
Gulp!
Spin my spiderlings Spin!
Oh Humans! Won’t you stick around for a bit!
Hello! Please select Easy, Medium, or Hard game.
Humans! Won’t you try Spider Stompin’
Wow! That was some fancy footwork!
Fantastic! Great! An expert spider stomper!
Your good! Very Good! But perhaps next time
ter.
ds.
een
Copyright (c) 1996 Island Design, Inc.
11

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
CAUTION
Turn the game off before inspecting the inside of the game (i.e. Connectors, Fuses, PCB,
bulbs or power supply).
CAUTION
~11 playfield Button lights, cartoon box lights and lights behind Characters on Marquee
are to be replaced with
#67 bulbs only!
Copyright (c) 1996 Island Design, Inc.

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
PART NUMBERS
Part number Description
*005-0001-00 Rectifier
GBPCZS-02
‘0 I o-000 I -00
03 I-000 I-00
034-000 I-00
036-000 l-00
036-0002-00
036-0003-00
036-0004-00
036-0006-00
036-0008-00
036-00 I O-00
036-001 I-00
036-00 12-00
036-0015-00
036-00 16-00
036-0020-00
036-0063-00
036-0064-00
036-0065-00
036-0066-00
036-0067-00
036-0068-00
040-000 I-00
040-0002-00
040-0003-00
040-0004-00
041-0001-00
060-000 l-00
090-000 l-00
090-0002-00
120-0006-00
125-0002-00
125-001 l-00
150-000 I-00
165-0001-00
I65-0002-00
170-0001-00
170-0002-00
ISO-ooo1-00
180-0001-02
I RO-0002-00
180-0004-02
180-0004-04
IRO-0004-05
I80-0008-00
200-000 l-00
200-0003-00
Transformer P-8643
Speakers 50-9003-00
Power cord I W950
Service panel harness
Shadow boxl Queen harness
Speaker harness
Ribbon cable
Power s\+itch harness
Marquee power harness
Control panel harness
Pad switch harness
Pad light harness
Coin ticket extension harness
Pad light extension harness
Pad switch hamess
PCB power harness. 4 pin
PCB side harness, CP/Doors, 34 pin
Speaker PCB side harness. 3 pin
Pad/Marquee PCB side harness. 40 pin
Capacitor ground harness
Capacitor ground harness
Nylon tie wraps
Nylon cable clamps
Nylon self retaining spacers
Stick downs
Fish paper cover
Fuse holder
Coin counter 42-0750-00
Ticket meter 42-0754-00
IK ohm,l/4W resistor
Capacitor, eletrolytic, 6OOOufI4OV
Capacitor, electrolytic, 42OOuf74Ov
EMI filter
Fluorescent light bulb
#67 mini bulbs
Fluorescent fixture
#67 light sockets 14IT3152F
Black button
Red button
On/Off switch
Red button. Hard
Yellow button. Medium
Green button. Eas!
Button leaf switch
Fuse. 4A fast
Fuse. 8A fast
Part number Description
Button spring
Main cab/net
Rear door
Foot pad
Control panel
Marquee board
Power supply chassis
Label, FCC
Label, FBI
Label, UL
Label Serial Number, Spider Stompin Deluxe
Label, Servicened
Label. On/Off switch
Label. 4A fuse
Label. 8A fuse
Coin door
265-0001-00
366-0001-00
366-0002-00
366-0003-00
366-0004-00
366-0006-00
366-0007-00
4o6-oo01-00
406-0002-00
406-0003-00
4o6-ooo4-05
406-0005-00
406-0006-00
406-0007-00
406-00 I C-00
5 I o-000 I-00
5 15-0006-00
5 15-00 14-00
520-0006-00
53 5-000 I -00
535-0002-00
535-0003-00
535-0004-00
535-0005-00
535-0009-00
535-00 I O-00
535-0013-01
535-0018-00
535-002 I-00
535-0030-00
545-0001-01
660-0004-00
705-0001-00
705-0002-00
705-0003-00
705-0004-00
780-0002-00
780-0006-00
820-0001-01
820-0001-02
820-0002-00
830-0001-00
830-0001-01
830-0003-00
Ticket dispensor
Dot Matrix display board
Spider deluxe main cpu (T&H)
Service panel
Speaker grill
Marquee retainer
Mountin: feet
On/Off switch plate
Ticket door with LED & harness
Ground strip
Button box
Mounting hardware VR3
Heat sink plate
Foot pad plate
Red button cap, foam with mylar
Foot pad plex
Stiched tube
Plywood base
DST
Pad
Ticket manual
Spider Stompin deluxe ntanual
Spider deluxe side decal, right
Spider deluxe side decal, left
Spider deluxe foot pad decal
Queen deluxe plex
Spider deluxe marquee plex
Spider deluxe control panel plex
Copyright (c) 1996 Island Design, Inc.

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
SWITCH SETTINGS
DIP SWITCH BANK #l - Ticket Pay Out Select
NOTE: * Recommended Setting for .020 Ticket Value
** Recommended Setting for .015 Ticket Value
* * * Recommended Setting for .O 10 Ticket V&e
DIP SWITCH BANK #l - Game Time Select
Copyright (c) 1996 Island Design, inc.
14

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
OFF OFF OFF 1 Annrox. 15 seconds
OFF OFF
OFF ON
OFF ON
ON Approx. 22 Seconds
OFF Approx. 29 Seconds
ON Approx. 36 Seconds
I
I I
ON 1 OFF 1 OFF 1 Abprox. 43 Seconds
1 oji 1 OFI; I 0~ I A-~- <n cPrnnrlr
rypvn. ;I” “V”“llYLJ
ON ON OFF Approx. 57 Seconds
ON ON ON Approx. 64 Seconds
I
DIP SWITCH BANK #2 - If No Game Is Selected
OFF
OFF
OFF
ON
Say ‘Hello!” Every 20 Seconds
Automatically start EASY game
ON 1
OFF 1 Return to attract while waiting for start button I
I
I
I
ON ON
1 Eat the credit
I
DIP SWITCH BANK #2 - Coins Per Credit
OFF OFF
OFF
ON
ON OFF
ON ON
One Coin Per Credit
Two Coins Per Credit
Two Coins First Credit , One coin per credit while game
already has one credit.
Free Play
DIP SWITCH BANK #2 - Attract Mode Sounds
OFF
ON
Normal Attract
Less Frequent Attract Sounds “Quieter”
Copyright (c) 1996 Island Design, Inc.
15

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
DIP SWITCH BANK #2 - Number of Rounds
1 One,(l) Round I
i ON 1 Two (2) Rounds I
DIP SWITCH BANK #2 - Light Intensity
ON
Brighter lights
DIP SWITCH BANK #2 - Bonus Mode
ON Bonus
Mode Disabled “Off
Normal game play mode
Copyright (c) 1996 Island Design, Inc.
16

SPIDER STOMPIN’ DELUXE OWNER’S MANUAL
Wiring Diagram
34 Pin Pcb Connector
Ticket Power (+)
Ticket Ground(-)
Ticket Enable
rg GniWh
16,
Counter Common (+)
Ticket Counter (-)
Coin Counter
(-)
Credit Switch
Test Switch
Ticket Notch
Coin Switch
Easy Switch
QGn
~21 Gn
Hard Switch
c-l
52 Rd
Medium Switch :23,YI
Switch Ground
2$Bk
Switch Ground
K-
25 Bk
i26;
Easy Light
1 27 GytWh
Medium Light
28’Vi
Hard Light
12$Bu
130
Coin Light
‘33 Wh
i-.;
l32
Light Common (+)
p-3 Or
Coin Light Common (+) l34YI
L ~_ ~,
40 Pin Pcb Connector
Foot Light Common (+)
Cartoon Light Common (+)
Queen Light Common (+)
Foot Light #6
Queen Light Common (+)
Foot Light #5
Foot Switch #I
Foot Light #4
Foot Switch #2
Foot Light #3
Foot Switch #3
Foot Light #2
Foot Switch #4
Foot Light #l
Foot Switch #5
Queen Voice Light #1
Foot Switch #6
Cartoon Light #4
Cartoon Light #3
Cartoon Light #2
Cartoon Light #I
Foot Light #7
Queen Voice Light #2
Queen Voice Light #3
Foot Switch #7
Switch Ground
v
19,WhlBn
pn WhNl
m1Bu
‘34’
351
r
36’
~._
37,
Copyright (c) 1996 Island Design, Inc.
I7
