Atronic Cashline™
Wide Body Cabinet (WBC)
Installation Manual
Rev. 2.4
February 2008

2
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
RELEASE INFO
Release Info:
Atronic Cashlin™
Wide Body Cabinet (WBC)
Installation Manual
Rev. 2.4
February 2008
WARNING!
This manual is intended to provide QUALIFIED TECHNICAL PERSONNEL ONLY with
the information necessary to routinely maintain, service, and repair the Atronic
Cashline™ Wide Body Cabinet (WBC) and components. To avoid personal injury or
damage to the equipment, do not perform any serviceing other than that contained in
this manual.
Copyright Notice:
© 2000-2008, Atronic. All rights reserved.
No part of this publication may be copied or distributed, transmitted, transcribed,
stored in a retrieval system, or translated into any human or computer language, in
any form or by any means, electronic, mechanical, magnetic, manual, or otherwise, or
disclosed to third parties without the express written permission obtained from a
properly authorized official of Atronic.
DISCLAIMER
Atronic makes no representation or warranties, express or implied, with respect to
this publication, or any product of Atronic, including but not limited to warranties of
merchantability or fitness for any particular purpose. Atronic reserves the right to
make changes, enhancements, revisions and alterations of any kind to this publication
or the product(s) it covers without obligation to notify any person, institution or
organization of such changes, enhancements, revisions and alterations.
TRADEMARKS
This document may contain trademarks of Atronic. All other brand and product names
are trademarks or registered trademarks of their respective companies.

3
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
Introduction
About this Manual
Scope, Target Audience, Included Software Releases ....
Related Publications ...................................................
Safety Instructions .........................................................
Machine Components .......................................................
Dimensions ......................................................................
Technical Data ................................................................
Machine Installation
Overview ..........................................................................
Machine Mounting ............................................................
Drilling Template ...............................................................
Install Toplight ..................................................................
Replace Shipping Locks .....................................................
Prepare Coin Acceptor .......................................................
Prepare Hopper .................................................................
Check Connectors ..............................................................
Check Commboard Settings ................................................
Apply Power ......................................................................
Switch On .........................................................................
Basic Setup (Overview only) ..............................................
Tests ...............................................................................
Technical Support Telephone Numbers ..............................
4
5
7
10
12
13
15
16
17
18
18
19
19
19
20
20
20
21
22
23
CONTENT

4
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
ABOUT THIS MANUAL
Scope
This Installation Manual describes how to install an
Atronic Cashline™ - Wide Body Cabinet (WBC) gaming
machine.
It describes how to mount the machine to a base
stand and relevant procedures to be carried out before
the machine can be put into operation. Further it
contains important safety instructions, technical data
and cabinet drawings.
Target Audience
We address qualified technical personnel, who are
involved in installation, setup and configuration of
Atronic gaming machines. With this user group we
assume that they are basically familiar with gaming
machines and casino related terminology.
Please read this document and the contained safety
notes carefully before you start machine installation.
Included Software Releases
The installation procedures described in this manual
do not relate to a certain software version.
INTRODUCTION

5
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
ABOUT THIS MANUAL
Related Publications
More detailed information about Atronic Cashline™
Wide Body Cabinet (WBC) gaming machines may be
found in the following publications:
Software Manuals
• Software Manual / O-Level
• Software Manual / O-Level (Multidenom)
• Software Manual / P-Level
Operation Manuals
• Cashline™ Operating Manual / O-Level
• Cashline™ Operating Manual / P-Level
Spare Parts
• Atronic Cashline™ WBC / Parts Catalogue
Peripherals
(Coin- and bill acceptors, hopper, printer, etc.)
• See folder "Peripherals" on the Atronic Service
Manual CD.
Note: All mentioned manuals can be found on a CD-
ROM titled "Atronic Service Manual 2008"
If this manual did not came with this CD-ROM, please
ask Atronic Technical Service for a free copy of the
latest revision.
INTRODUCTION

6
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
- blank page -

7
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
SAFETY INSTRUCTIONS
Follow the precautions below to en-
sure safe operation.
Caution! High Voltage
The power cable must be disconnected from the
main power socket, before the machine is free from
electrical current. The main power switch is
intended for service purposes only.
Caution! Tipping Hazard
Machine must be fastened to an appropriate base,
to prevent tipping over.
Caution! Moving Parts
Make sure to disconnect the hopper, when working
on it.
Precautions before operating
• The machine weighs about 100kg (220 lb). At least
two persons should carry or lift it. Use a cart to
transport the machine.
•Machine must be fastened to an appropriate
base, to prevent tipping over.
• Check that all connectors are seated correctly. Fal-
se connections can cause irreparable damage, not
covered by warranty.
• Verify voltage specifications stated on type plate,
before connecting to a main power socket.
Machine must be connected to a grounded main
power socket.
• Read the Service Manual carefully before operating
the machine.
Continued on next page...
230 50 2VHzA
SAFETY INSTRUCTIONS

8
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
Safety Instructions
Precautions during Service and Maintenance
• Only qualified service personnel should perform re-
pairs.
• Unplug from the main power socket, before wor-
king on the machine. The power cable must be dis-
connected from the main power socket, before the
machine is free from electrical current.
• Electronic assemblies should only be changed with
the power switched off.
• Use only original Atronic parts for replacement.
• Atronic Commboard
Danger of explosion if battery is incorrectly repla-
ced! Check for correct polarity and replace with
the same or equivalent type only!
• Please refer to the Atronic Service Manual CD for
further instructions on service and maintenance.
Additional Information
The X-rays, which develop in this machine, are suffi-
ciently shielded through the Cathode-ray tube's own
shielding. Max 24-24,5kV, Beam current max 630mA.
This corresponds with Paragraph 5 of the German
X-ray Orders from 1987.
SPARE PARTS
SAFETY INSTRUCTIONS

9
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
- blank page -

10
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
NRI
systematischgut
NationalRejectors,Inc.GmbH
D-21614Buxtehude
Tel.[phone]
EMP
D
10-28VDC
G-40.0601-0010
023093/0164
00010882
ACHTUNG!!!
EMPnichtunter
Spannungtauschen
-
-,10
-
1,-
2,-
5,-
01
02
03
04
05
06
--
09
10
11
--
12
--
--
01
03
04
05
3
4
2
1
C
F
çè
CAUTION: DONOTLIFT BAIL UNLESS CUTTER ARMSARE IN THIS POSITION.
Monitor
Logic Door Switch
Logic Door Lock
Comm Board
Sound Board
Graphic Board
Master Board
Hopper
Coin Bowl
Bill Door Button Board
Bill Door Key
Latch Bar
Coin Validator
Main Door Lock
Door Switch
Hardmeters
Power Switch
Audit Key
Bill Validator Unit
Bill Head
Stacker
Jackpot Key
Power Supply
Backplane
Power Board
Hopper Board
Toplight
Top Box
Ticket Printer
MACHINE COMPONENTS
MACHINE COMPONENTS

11
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
LOCKS, KEYS AND SWITCHES
Jackpot Key
Audit Key
Bill Door Lock
Main Door Lock
(2nd lock optional)
Audit Key
This key activates the Audit Menu
and illuminates hardmeters. It also
clears status and error messages.
Jackpot Key
Jackpot events and hand pay admin-
istration are controlled by this key.
It also controls remote credit func-
tion (if applicable) .
Bill Door Lock
Unlocking the bill door allows the
validator and stacker to be removed
without unlocking the main door.
Main Door Lock
Allows access to the machine com-
ponents via main door.
Stacker Locks
Unlock stacker locks to remove the
stacker (bill box).
Bill Validator Switch
Removal of the validator and stack-
er is detected by this switch.
Logic Door Lock and Switch
Unlock logic door lock to get access
to the boards. The (optional) logic
door switch detects logic box
openings.
Service Button (Green)
Pressing the service switch acti-
vates the Service Menu.
Reset Button (Red)
Used for resetting the machine and
clearing the machines memory.
Main Door Switch
Registers all main door openings.
Power Switch (Red)
Switches power supply on/off
LOCKS, KEYS & SWITCHES

12
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
Cashline WBC Cabinet
Weight: approx. 220 lbs. / 100 Kg
DIMENSIONS
Drawing shows WBC cabinet
with Square Top and 3 element
candle.
1H
)thgiehllarevO(
2H
)eldnacowthgieH(
1D
)htpedxobpoT(
poTerauqS
eldnactnemele3htiw mm5041/"3.55mm0421/"8.84mm534/"1.71
poTerauqS
eldnactnemele2htiw mm2631/"6.35mm0421/"8.84mm534/"1.71
poTdnuoR
eldnactnemele3htiw mm3241/"65mm0421/"8.84mm673/"8.41
poTdnuoR
eldnactnemele2htiw mm0831/"3.45mm0421/"8.84mm673/"8.41
poTwoL
eldnactnemele3htiw mm9821/"7.05mm4111/"6.34mm014/"1.61
poTwoL
eldnactnemele2htiw mm6421/"94mm4111/"6.34mm014/"1.61
Dimensions depend on installed top box model and
toplight (candle) version. Use the table below to figure
out actual dimensions.
Approximately values
23.4” / 595 mm
18.5”/470 mm
23.9” / 606 mm
32.7” / 830 mm
21.7” / 550 mm
(H2)
see table
(H1)
see table
(D1) see table
Note:
Table refers to recent cabinets
utilizing Top Boxes with 3"
(system) brackets. Older
cabinets utilizing Top Boxes
with 2,5" brackets are slightly
lower.
DIMENSIONS

13
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
Electrical Specifications
Required Voltage: 220V-240V, 2.0A, 50Hz
100V-120V, 4.0A, 60Hz
Power Consumption
Idle mode: approx. 185W
1.60A / 115V, 0.8A / 230V
Payout mode: approx. 200W
1.75A / 115V, 0.9A / 230V
Power Supply
Secondary Voltage: + 24V / 4A
+ 12V / 4A
- 12V / 0.3A
+ 5V / 10A
Fuses
Power Supply: F 5A / 250V
Monitor: T 3A / 250V
Power Board: T 2A / 250V
Backplane F1: + 5V T 5A / 250V
Backplane F2: + 12V T 5A / 250V
Backplane F3: - 12V T 0.315A / 250V
Backplane F4: + 24V T 3.15A / 250V
Lamps
Fluorescent Lamps: 15W, 17" / 438 mm
Button Lamps, small LED
Button Lamps, large LED
Environmental Specifications
Operating Temperature: 32°F / 0°C - 113°F / 45°C
Operating Humidity: 0% to 85%
Combustible Weight: < 20 lbs. / 9 Kg
Primary Voltage
Secondary Voltage
Primary Fuses
Secondary Fuses
Suggested Limits
TECHNICAL DATA
TECHNICAL DATA

14
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
- blank page -

15
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
MACHINE INSTALLATION - OVERVIEW
This section should only be carried out by
Qualified Technical Service Personnel.
Review the list below and perform as needed.
Explanations are located on the following pages and
in additional manuals.
Inspect machines for transport damage. Any
transport damage should be noted and witnessed
by the freight forwarder. The manufacturer accepts
no responsibility for transport damage.
Check machines for the correct Paytable, Glasses,
Hardware configuration and that Software EPROMs
are correctly installed on the PCBs.
Prepare the base by drilling the mounting holes.
Use the Atronic drilling template for proper
mounting hole placement.
Place and mount the machine to the base.
Run the power cable into the base. Do not connect
power to the machine.
Install the Toplight.
Replace shipping locks with Casino specific locks.
Install and connect Online/Accounting system.
Check that all internal and external connections
are seated correctly.
Prepare Coin Comparator and Hopper.
Apply power to the machine.
Load paper into the Printer.
Execute basic machine setup (Initial Setup)
Configure game.
Test Bill and Coin handling.
MACHINE INSTALLATION
Note:
Depending on machine
configuration and/or
jurisdictional requirements,
additional tasks may have to be
carried out before the machine
can be put into operation (e.g.
acceptance inspection, logicbox
sealing, etc.).

16
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
MACHINE INSTALLATION
Following pages contain a description of machine
fitting and commissioning. We recommend to follow
all cross-references to get the necessary information.
Precautions
Caution! High Voltage
The power cable must be disconnected
from the main power socket, before the
machine is free from electrical current.
The main power switch is intended for
service purposes only.
Prepare bases for machine mounting
Prepare the base stand by drilling the mounting holes.
Use the Atronic WBC Drilling Template for hole
placement. Leave enough space between two
machines. The main door should open without touching
the next machine and the key switches should be
easy to access.
If the WBC Drilling Template is not at hand, please
use the drawing on the next page.
Mount machine on base
• Lift the machine onto the base stand (with the
main cable inside the cabinet) and allign the cabi-
net with the drilled holes.
• Fix it with the 4 round head square neck bolts
M8x80 DIN603, washers and wingnuts, delivered
with the machine.
• Run the main cable into the base.
Do not yet connect main cable to power outlet!
Do not yet apply power to the machine!
MACHINE INSTALLATION
Note:
The machine weighs about
100kg (220 lb). At least two
persons should carry or lift it.

17
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
Note: Footprint is without coinbowl.
MACHINE INSTALLATION
DRILLING TEMPLATE
Make sure to leave min. 180mm (7.1") distance to the next machine or
a wall on both sides of the cabinet.

18
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
MACHINE INSTALLATION
Install Toplight
• Remove the top glass.
• Remove the lighting reflector panel by loosening
the 4 screws and disconnect the power cable.
• Run the toplight harness through the opening on
top of the top box (1).
• Fix the toplight to the top box (2) and secure it
with one nut (square top model) or two nuts (round
top and low top models) (3).
• Connect the toplight Molex connector (4).
• Reinstall the lighting reflector panel and connect
its power cable.
Replace shipping locks
If not ordered otherwise, Atronic machines are
equipped with shipping locks for easy commisioning.
These locks have to be replaced by casino specific
locks to provide appropriate security.
3
4
2
1
1
4
2
3
MACHINE INSTALLATION

19
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
MACHINE INSTALLATION
Prepare Coin Comparitor CC16/MC16
• Slide the reference coin holder rightwards, remove
the (plastic) transport token and replace it with
an appropriate reference coin or casino token.
• Fine tune the coin comparitor (if necessary) later
when machine setup is completed.
Quick guide for fine tuning:
• Turn the potentiometer fully clockwise (all coins
are rejected).
• Then turn the potentiometer anti-clockwise until
proper coins are accepted and falsified coins are
rejected.
• Test acceptance with at least 10 coins and re-
adjust, if necessary.
-> See manuals Peripherals / Coin Acceptors for
details.
Prepare Hopper
The hopper high level switch detects the filling level
of the hopper by the weight of the coins. When the
switch is activated, further accepted coins are
separated to the drop box. The switching threshold
can be altered with an adjustment screw.
• Fill the hopper with that amount of coins/tokens at
which you want the switch to be activated.
• Adjust the switching threshold with the adjustment
screw that operates the high level switch.
-> See manuals Peripherals / Hopper for details.
Check cable and connectors
Check that all cables and connectors are seated
correctly, prior to the first power up. False
connections can cause irreparable damage, not
covered by warranty.
MACHINE INSTALLATION

20
February 2008
Cashline™ Wide Body Cabinet (WBC) - Installation Manual
MACHINE INSTALLATION
Check Commboard Settings (optional)
The commboard DIP switches and rotary switches
configure SAS address, APL address, progressive
mode and SAS (dual) channel allocation.
Use the DIP switch tables within the Software Ma-
nual for a particular software version (e.g. P-Level) to
check or alter the commboard settings. Then connect
to the online system components.
Apply power
• Verify voltage specifications stated on type plate,
before connecting to a main power socket.
• Connect main cable to a grounded main power
socket, that is capable to deliver the specified cur-
rent rating.
Switch on the machine
• Press the power switch to switch on the machine.
The LED's on the Master Board (they inicate cor-
rect voltages) should all be lit.
• To operate the machine while the main door is open,
pull the main door switch to set it to closed positi-
on.
Execute basic machine setup (if needed)
If any changes to the factory pre-set basic machine
setup are needed, further procedures are necessary.
• Init Setup (requires RAM-Reset)
• Selectable Paytable Configuration
(requires Config Key EPROM)
• PC-Setup (requires external configuration software)
-> See manual "Software" for details
230 50 2VHzA
MACHINE INSTALLATION
