Universal Space Checky Monkey User manual

Operation Manual
www.universal-space.com

Operation Manual
1
CONTENT
Important Safety Instructions ................................................................................. 1
1. SPECIFICATIONS ..................................................................................................... 5
2. PACKAGE CONTENTS.............................................................................................. 6
3. PART NAMES ........................................................................................................... 7
4. SET UP & INSTALLATION........................................................................................ 9
5. HOW TO PLAY ........................................................................................................13
6. GAME OPTION .......................................................................................................14
7. MAINTENANCE, INSPECTION...............................................................................22
8. OVERALL CONSTRUCTION ...................................................................................23

Operation Manual
2
Thank you for purchasing [ Check Monkey ] from UNIVERSAL SPACE. We hope
you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.

Operation Manual
3
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Operation Manual
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install
outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
•Places subject to rain/moisture, or places subject to high humidity.
•Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
•Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
•On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
•Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
Note: The contents of this manual may be updated without notice.
WARNING
Non-technical personnel who do not have technical knowledge and Expertise
should refrain from performing such work that this manual require or
perform tasks which are not explained in this manual. Failing to comply
can cause severe accidents such as electric shock or other serious injuries.
WARNING: To reduce the risk of fire, electric shock or personal injury, unplug
or disconnect the machine from the power supply before servicing.

Operation Manual
5
1.SPECIFICATIONS
Rated power supply：110V 50/60Hz
Mix. Power consumption：： 140W
Max. Power consumption：160W
Dimensions：W1840×D870×H2030(mm)
Weight：About189Kg
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game parameters are subject to change without notice.

Operation Manual
6
2.PACKAGECONTENTS
Open the package and make sure all the items are included:
•1 x Body Assembly
•Following accessories
No. Part No. Name Spec. Qty. Illustration Note
1 C118-804-000 AC power 10A/250V 1.8m 1
2 C118-416-000 Fuse
T3A/250V
（T6A/125V）
Φ5-20mm
1
Choose by
area
3 C118-756-000 Manual English 1
Choose by
area
4 C118-424-000 Key 171 2 Service door
5 C118-425-000 Key 2222 2 Coin box door
6 C118-426000 Basketball 10
7 C118-427-000 Bearing with shaft
6002ZZ 2
8 C118-117-000 Guide shaft Φ18 电泳黑色 2
9 C118-428-000 B_Cir-clip Do16 2
10 C118-301-000 Cross hexagon
head kit bolt M6×20 4
11 C118-302-000 Hex lock nut M6 4
Tot.
NOTE: Part models are subject to change without notice.
Make sure keep number of basketball to use in game:5.
The pressure of the basketball :0.5MPA.
NOTICE

Operation Manual
7
Coin door Assy.
3.PARTNAMES
FRONT VIEW
Ball gate upper board
Header ASSY.
JP LED
Socre LED
Time/ticket LED R_side net
Front net
R_speaker
Ball gate
L_speaker
Swing Assy.
L_side net

Operation Manual
8
3. PART NAMES
REAR VIEW
Back door(up)
Back door(down)
Wire box Cabinet

Operation Manual
9
4.SETUP&INSTALLATION
zRefer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
zPlace the unit on a dry level surface
zVentilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area：50cm
Play area：100cm
安全遮板
This product is an indoor game machine. Do not install outdoors.
Notice

Operation Manual
10
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause a malfunction.
To fix the game, adjust the Leveler down until it touches the floor, lifting the casters off the
ground by 5mm. Repeat the same for all levelers.
Make sure the machine is level with the ground and all the
adjustable legs should stick to the floor closely.
NOTICE
Leveler Caster
About 5mm
Move Fix

Operation Manual
11
4.3 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position so the casters
touch the ground.
NOTICE
•Be careful not to damage the machine during transport.
•The machine should be handled with care when bringing it down from a
higher level.
•Always unplug the game before moving.
•Keep the machine in upright position during transport.
•For longer distance transport, package the game properly to prevent
damages
Leveler Caster
Move

Operation Manual
12
4.4 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to
an electrical outlet to ensure that the required voltage and frequency match
the available power source. Please refer the label of the machine.
•Do not plug the equipment power cables into an electrical outlet if the power cable
is damaged.
•Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
•Connect the grounding conductor to the earth terminal (GND):
WARNING
Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet
does not sit on the power cord as this could damage the cord and become hazardous.
To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the
cord.
To prevent electric shock, do not touch the power plug when hand is wet.
Ensure that nothing rests on the power cord and that it is not located where it can be
stepped on or tripped over.

Operation Manual
13
5.HOWTOPLAY
Insert coin(s). Game starts.Balls release.
Time is counting down. Rim is not moving. 2 points per shot.
Time is up. Pay out tickets if not passing the Stage 1.
Get the required points to pass the next stage.
Time is counting down. Rim is moving. 3 points per shot.
Get he required points to pass stage 2 and win the BONUS. Game is over.

Operation Manual
14
6.GAMEOPTION
6.1 Switches control singal
Refer the attached I/O chart and the schematic.
To adjust DIP, please refer the the I/O chart. The initial setting is in capitalization.
Main board ：

Operation Manual
15
6.GAMEOPTION
To test method:
Press the TEST button in the mainboard.
LED Display:
BONUS LED<2>3-1 Time LED<1>7-5 Score LED<1>3-1
Test method：
Testing LED displays is normal or not when it shows< 1.2.3.4.5.6.7.8.>
Press TEST button again and LED displays 1, it shows the LED 1and LED2 of 1# in DIP SW
state.
Press TEST button again and LED displays 2, it shows the number of on-off SW
Press TEST button again and LED displays 3.
Press TEST button and LED displays 4. Hold IN1-40 and it shows OUT1-40 corresponding
lighting ouput.
Press TEST button again and LED displays 5, it shows OUT1-40 corresponding lighting
ouput.
ERROR CODE:
The foolowing error codes will displayed if the input signal is not in normal state when
power up the game. Then continue to work after alarm.
E01 Ticket Assy. Reset error
E02 Score sensor error
E03 Ball gate sensor error
E04 Ball test 1 error
E05 Ball test 2 error
E07 Service button error
E83 Coin mech error
E84 Coin mech error

Operation Manual
16
6. GAME OPTION
6.2 Parameter setting:
DIP Ajdust 1（SW1）
（1）Coin(s) per game
Item Content
DIP Ajdust（SW1）Note
1 2
Coin(s) per game
1 ON ON
2 off on
3 on off
4 off off
（2）BONUS
Item Content
DIP Ajdust（SW1）Note
3 4 5
BONUS
100 on on on
150 off on on
200 ON Off ON
250 off off on
300 on on off
350 off on off
400 on off off
600 off off off
（3）BONUS+
Item Content
DIP Ajdust（SW1）Note
6 7
BONUS
+
0 on on
1 Off ON
2 on off
3 off off

Operation Manual
17
6.GAMEOPTION
(4）Score memory
Item Content DIP Ajdust（SW1）Note
8
Score memory
YES ON
NO off
DIP Ajdust 2（SW2）
（5）Game play time(s)
Item Content DIP Ajdust（SW2）Note
1 2
Game play time(s)
20 on on
30 OFF ON
40 on off
50 off off
（6）Points for passing
Item Content DIP Ajdust（SW2）Note
3 4 5
Points for passing
20 on on on
30 OFF ON ON
40 on off on
50 off off on
60 on on off
70 off on off
80 on off off
90 off off off

Operation Manual
18
6.GAMEOPTION
（7）Merey ticket
Item Content
DIP Ajdust（SW1）Note
6 7 8
Merey ticket
0 on on
1 off ON
2 on off
3 off off ON
DIP Ajdust 3（SW3）
（8）Game play time(s)
Item Content DIP Ajdust（SW2）Note
1 2
Game play time(s)
10 on on
15 Off ON
20 on off
25 off off
（9）Adding points for passing
Item Content DIP Ajdust（SW2）Note
3 4 5
Adding points for passing
+20 on on on
+30 off on on
+40 ON OFF ON
+50 off off on
+60 on on off
+70 off on off
+80 on off off
+90 off off off

Operation Manual
19
6. GAME OPTION
（10）Points per ticket
Item Content
DIP Ajdust（SW1）Note
6 7 8
Points per ticket
10 on on
20 Off ON
30 on off
40 off off ON
DIP Ajdust 4 (SW4）
（11）Max .ticket per play
Item Content
DIP Ajdust（SW4）Note
1 2 3 4
Infinity ON ON ON ON
Max .ticket per play
60 off on on on
40 on off on on
30 off off on on
25 on on off on
20 off on off on
15 on off off on
10 off off off on
8on on on off
6off on on off
5on off on off
4off off on off
3on on off off
2off on off off
1on off off off
No pay off off off off
Demo NO ON ON
Demo w/t motion off on
Demo OFF
-- off
ON
