ISOtunes PLUS User manual

Heavy-Duty Noise Blocking Earbuds

Table of Contents
Table of Contents
English (EN)
Location of Controls � � � � � � � � � � � � � � � � � � � � � �3
LED Light Indicator � � � � � � � � � � � � � � � � � � � � � � �4
Charging � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �5
Power On/O� � � � � � � � � � � � � � � � � � � � � � � � � � � �6
Bluetooth Pairing� � � � � � � � � � � � � � � � � � � � � � � � �7
Dual Connect Mode � � � � � � � � � � � � � � � � � � � � � �8
Music� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9
Phone Calls � � � � � � � � � � � � � � � � � � � � � � � � � � � �10
Legalities � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �11
Español (ES)
Localización de los controles � � � � � � � � � � � � � �15
Indicador de luz LED � � � � � � � � � � � � � � � � � � � � �16
Carga � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �17
Encendido/apagado � � � � � � � � � � � � � � � � � � � � �18
Conexión Bluetooth� � � � � � � � � � � � � � � � � � � � � �19
Modo de conexión doble � � � � � � � � � � � � � � � � �20
Música� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �21
Llamadas telefónicas� � � � � � � � � � � � � � � � � � � � �22
Legalidades � � � � � � � � � � � � � � � � � � � � � � � � � � � �23
Table of Contents

EN |3
Location of Controls
1� Volume Up
2� Multi-Function Button (MFB)
3� Volume Down
4� LED Indicator Light
5� Bluetooth Mic
6� Charging Port
2
1
5
3
46
English (EN)

EN |4
LED Light Indicator
Product Operation LED Indicator Light Voice Prompt Tone Flashing Pattern
Charging l----- Solid
Charged l----- Solid
Power OFF l“Power O” Flash
Power ON l“Power On” Flash
Pairing ll“Bluetooth Pairing Mode” Alternate
Dual Connect Mode ll“Bluetooth Pairing Mode” Alternate
ISOtunes PLUS

EN |5
Charging
The earplugs are charged with a micro-USB charger and hold up to 10 hours of music
and talk time between charges.
Please charge with the included micro-USB
cable by plugging it into the Charging Port (6)(6)�
*Charging voltage should not exceed 5v.
1 2
While the cable is plugged into the Charging
Port (6)(6), the LED Indicator Light (4)(4) will let you
know if the battery is charging or f ully charged�
LED Indicator Light (4)
Solid Red = Charging (Cable Plugged In)
Solid Blue = Fully Charged (Cable Plugged In)
6
4
Please refer to the LED Indictor Light page for more information.

EN |6
Power On/O
Power On: Press and hold MFB (2)(2) for 3 seconds�
(you will hear “Power On”)
Power O: Press and hold MFB (2)(2) for 3 seconds�
(you will hear “Power O”)
LED Indicator Light (4)(4)
Blue Flash = Power ON
Red Flash = Power OFF
2
4
Please refer to the LED Indictor Light page for more information.

EN |7
Bluetooth Pairing
Open your Bluetooth settings on your
device�
1 2
Search “ISOtunes PLUS.”
Pair and connect�
Once connected you will hear
“Bluetooth Connected.”
After powering on, the headphones will automatically enter Pairing Mode.
You will hear “Bluetooth Pairing Mode” and the LED Indicator Light (4)(4) will ash,
alternating Blue and Red�

EN |8
Dual Connect Mode
This product can connect to two devices at the same time such as your phone and
your computer.
1. Pair and Connect to your rst device as
described in Bluetooth Pairing�
This will be device A�
2� Press and Hold the MFB (2)(2) for 7 seconds
until you hear “Bluetooth Pairing Mode”
(you will hear Power O, keep holding the
button until you hear “Bluetooth Pairing
Mode”).
3� Pair and Connect to the 2nd device as
described in Bluetooth Pairing�
This will be device B�
4� On Device A, go to the Bluetooth menu and
manually connect to ISOtunes PLUS�
5� Both devices are now connected�
Pairing Reset
If you have issues connecting to any
device, we recommend a Pairing Reset:
1� The headphones need to be powered on�
2� Press and Hold the Volume Up (1) and the
Volume Down (3) for 4 seconds�
3� Continue holding, listen for a double tone
and then release�
LED Indicator Light (4)(4)
Alternating Blue & Red = Pairing Mode
Please refer to the LED Indictor Light page for more information.

EN |9
Music
Play/Pause: Short single press MFB (2)(2)
Next Track: Double press MFB (2)(2)
Previous Track: Triple press MFB (2)(2)
Music Volume Up: Short single press Volume Up (1)(1)
Music Volume Down: Short single press Volume Down (3)(3)
2
1
3

EN |10
Phone Calls
Answer/End Call: Short single press MFB (2)(2)
Reject Call: Press and hold MFB (2)(2) for 1 second
Siri / Google Assistant
Press and hold MFB (2) for 1 second�
2

EN |11
Fitting
ANSI S3.19-1974 Table (NRR Table)
EN352-2:2002 Table (SNR Table)
B5:
SNR: 36 dB
H= 37 dB
M= 34 dB
L= 29 dB
APVf=MF-SF9 (dB)
Models
IT-06 PLUS
Important
Please read, understand, and follow all safety information� This
product is designed to protect against harmful noise�
Fitting
ISOtunes® PLUS comes with a pair of One-Size-Fits-All TRILOGY™
Universal foam eartips and 3 sets of silicone eartips (S,M,L)� Choose
the size that ts the most snug in your ear canal. Remember, the
snugger the t, the better the noise reduction. The silicone eartips
are intended for use when NOT in noisy situations�
ISOtunes® TRILOGY™ foam eartips have a threaded core, and the
sound port of the earbud is also threaded�
1� Twist the foam eartip counterclockwise to remove and clockwise
to place on a new foam eartip�
2� Carefully compress the foam eartip on the stem/sound port�
3� Insert the foam/eartip into your ear as deeply as
is comfortable and hold for 5 seconds while the
foam expands�
4� Repeat with second eartip�
Hint: To open your ear canal wider, lift the top of your ear up and
away from your head, as shown in FIG 1�
Please Note: should the included Universal sized eartips not t your
ears, all ISOtunes® TRILOGY™ eartips t this product. Eartips
other than the TRILOGY™ Universal size are not NRR/SNR rated
for ISOtunes PLUS, but should oer reasonable attenuation and
performance�
Introduction
Thank you for purchasing ISOtunes® PLUS Professional Noise
Isolating headphones. These headphones have been specically
designed for use in noisy environments, allowing you to block out
much of the surrounding noise so that you can listen to your music or
talk on the phone without interruptions� This product has been tested
and meets the European Safety Standard EN352-2:2002 and the
ANSI standards for a hearing protector, with a Single Number Rating
(SNR) of 36 dB and a Noise Reduction Rating (NRR) of 26 dB� Full
testing details are available in the Noise Attenuation section of this
booklet�
Noise Attenuation
APPROVAL: ISOtunes® PLUS is tested and approved in accordance
with ANSI S3.19-1974 Specications and tested to the European
Safety Standard EN 352-2:2002�
Legalities

EN |12
ANSI
S3.19-1974
The level of noise entering a person’s ear, when ISOtunes® PLUS
headphones are worn as directed, is closely approximated by the
dierence between the A-weighted environmental noise level and
the Noise Reduction Rating (NRR). Improper t of this device will
reduce its eectiveness in attenuating noise. Consult the enclosed
instructions for proper tting.
A1: Frequency (Hz)
A2: Mean Attenuation (dB)
A3: Standard Deviation (dB)
Example:
1� The surrounding noise level measured at the ear is 100 dB�
2� The NRR of ISOtunes® PLUS is 26 dB�
3� The noise level entering the ear is approximately equal to 74dB�
Please note that the NRR is based on the attenuation of continuous
noise and may not be an accurate indicator of the protection
attainable against impulsive noise, such as gunre.
EN 352
B1: Frequency (Hz)
B2: Mean Attenuation (dB)
B3: Standard Deviation (dB)
B4: Assumed Protection Value (APV) (dB)
B5:
H = Hearing protection estimation for high
frequency sounds (f ≥ 2000Hz)
M = Hearing protection estimation for medium
frequency sounds (500 Hz < f < 2000Hz)
L = Hearing protection estimation for low
frequency sounds (f ≤ 500Hz)
The EU declaration of conformity for IT-19 can be accessed at www.
isotunes.co.uk/EU-declaration-of-conformity
The products will be certied to the Product standard EN 352-2:2002
and the PPE Regulation 2016/425
SafeMax™ Technology
ISOtunes® PLUS incorporates SafeMax™ Technology, meaning its
output volume is limited to 85 decibels ( IT-06)� ISOtunes® devices
with SafeMax™ Technology are OSHA and ANSI compliant and,
when designated, meet the European Safety Standard EN 352�
Cleaning and Maintenance
Trilogy foam eartips are disposable� To ensure peak performance,
we recommend replacing TRILOGY™ Foam Tips every three months
or when they become soiled� In order to purchase additional tips,
please go to www.ISOtunes.com or ww.ISOtunes.co.uk
Clean your ISOtunes® PLUS by gently wiping them with a clean
damp cloth� Mild soap can be applied to the cloth�
Do not use abrasive cleaning solvents to clean the headset� Avoid
scratching the headset with sharp objects, as this may cause
damage� Keep the headset away from high temperature areas�
The TRILOGY™ foam eartips should be regularly inspected for
deterioration, cracking, or other damage� The eartips can be cleaned
in between uses with a damp cloth and water� Overtime, the eartips
should be replaced�
WARNINGS
ISOtunes® PLUS does an excellent job of blocking outside noise�
As such, ISOtunes® PLUS should NOT be used in environments
where users need to be fully aware of their surroundings for personal
safety reasons� For example, do NOT use them while driving a car or
riding a motorcycle� Similarly, do NOT use them when riding a bicycle
outside� The user is solely responsible for ensuring that ISOtunes®
PLUS is used ONLY in safe environments�
This product may be adversely aected by certain chemical
substances� Further information may be sought from the

EN |13
manufacturer�
These earplugs should not be used in situations where there is a risk
that the connecting cord could be caught up during use�
Recommendations
The wearer should ensure that the product is properly cleaned
and dry before and after use� Storage should be in a clean and dry
location between -20 °C and 50 °C�
The battery should not be fully discharged before long term storage�
The wearer should ensure that:
• The hearing protector is tted, adjusted, and
maintained in accordance with the
manufacturer’s instructions�
• The hearing protector is worn at all times in noisy
surroundings�
• The hearing protector is regularly inspected for
serviceability�
If these recommendations are not adhered to, the protection aorded
by the hearing protector maybe severely impaired�
Additional Notes
ISOtunes® PLUS is compliant with Bluetooth® V5� We do not
guarantee the compatibility of all functions on every Bluetooth®-
enabled device� Please check your device’s user manual for
compatibility and functionality�
For additional information or questions about ISOtunes® products or
spare parts and accessories, please contact our support team�
Mean Mass: approximately 16 grams
Date of Obsolescence: 3 years from purchase date
Not to be used in Explosive Atmospheres
Included Eartip Sizes Nominal Diameter
UNIVERSAL 7-14 mm
FCC
This device complies with Part 15 of the FCC Rules� Operation is
subject to the following two conditions:
1� This device may not cause harmful interference, and
2� This device must accept any interference received, including
interference that may cause undesired operation�
Warning: Changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment�
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules� These limits are designed to provide reasonable protection
against harmful interference in a residential installation� This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications� However,
there is no guarantee that interference will not occur in a particular
installation� If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver�
• Connect the equipment into an outlet on a
circuit dierent from that to which the receiver
is connected�
• Consult the dealer or an experienced radio/TV
technician for help�

EN |14
RF warning statement: The device has been evaluated to meet
general RF exposure requirements� The device can be used in
portable exposure conditions without restriction�
UK & Europe
uk-eurosupport@isotunesaudio�com
North America
support@isotunesaudio�com
1-844-396-3737
Monday-Friday 9-5 ET

ES |15
Localización de los controles
1� Aumento del volumen
2� Botón multifunción
3� Bajada del volumen
4� Luz indicadora led
5� Micrófono Bluetooth
6� Puerto de carga
2
1
5
3
46
Español (ES)

ES |16
Indicador de luz LED
Producto Operación Luz indicadora LED Tono de aviso de voz Patrón de parpadear
Cargando l----- Fijo
Carga completa l----- Fijo
Apagado l«Power O» Intermitente
Encendido l«Power On» Intermitente
Conexión ll«Bluetooth Pairing Mode» Intermitente
Modo de conexión doble ll«Bluetooth Pairing Mode» Intermitente
ISOtunes PLUS

ES |17
Carga
Los auriculares se cargan con un cargador micro-USB y tienen una capacidad de
hasta 10 horas de música y conversación entre cargas.
Cárguelos con el cable micro-USB incluido,
que se conecta al puerto de carga (6)(6)� *La
tensión de carga no debe superar los 5 V.
1 2
Mientras el cable está conectado al puerto de
carga (6)(6), la luz indicadora led (4)(4) advierte si la
batería se está cargando o está completamente
cargada�
Luz indicadora led (4)
Rojo jo = cargando (cable conectado)
Azul jo = carga completa (cable conectado)
6
4
Consulte la página Luz indicadora LED para obtener más información.

ES |18
Encendido/apagado
Encendido: Mantenga presionado el botón multifunción
(2)(2) durante 3 segundos�
(escuchará «Power On»)
Apagado: Mantenga presionado el botón multifunción
(2)(2) durante 3 segundos�
(escuchará «Power O»)
Luz indicadora led (4)(4)
Azul intermitente = encendido
Rojo intermitente = apagado
2
4
Consulte la página Luz indicadora LED para obtener más información.

ES |19
Conexión Bluetooth
Diríjase a los ajustes de Bluetooth de su
dispositivo�
1 2
Busque «ISOtunes PLUS».
Conéctelo�
Una vez conectado, escuchará
«Bluetooth Connected».
Cuando se encienden, los auriculares activan automáticamente el modo de conex-
ión.
Escuchará «Bluetooth Pairing Mode» y la luz indicadora led (4)(4) parpadeará
en azul y rojo de forma alterna�

ES |20
Modo de conexión doble
Este producto puede conectarse a dos dispositivos al mismo tiempo, como su telé-
fono y su ordenador.
1� Conecte su primer dispositivo como se
describe en Conexión Bluetooth�
Este será el dispositivo A�
2� Mantenga pulsado el botón multifunción
(2)(2) durante 7 segundos hasta que escuche
«Bluetooth Pairing Mode» (escuchará «Power
O», pero deberá seguir presionando el botón
hasta que escuche «Bluetooth Pairing Mode»).
3� Conecte su segundo dispositivo como se
describe en Conexión Bluetooth� Este será el
dispositivo B�
4� En el dispositivo A, diríjase al menú
Bluetooth y conéctese manualmente a
ISOtunes PLUS�
5� Ya están los dos dispositivos conectados�
Restablecimiento de la conexión
Si tiene problemas para conectarse a cualquier dis-
positivo, recomendamos que restablezca la conexión:
1� Los auriculares deberán estar encendidos�
2� Mantenga pulsados los botones de aumento de
volumen (1) y de bajada de volumen (3) durante 4
segundos�
3� Déjelos pulsados y suéltelos cuando escuche
un tono doble�
Luz indicadora led (4)(4)
Azul y rojo intermitente = modo de conexión
Consulte la página Luz indicadora LED para obtener más información.
