ISOtunes AirFefender User manual

THE NEXT GENERATION OF HEARING PROTECTION™

Table of Contents
TABLE OF CONTENTS 2
ENGLISH (EN)
Location of Controls � � � � � � � � � � � � � � � 3
Power On/O � � � � � � � � � � � � � � � � � � � � � 4
Bluetooth Pairing � � � � � � � � � � � � � � � � � � 5
Bluetooth Reset � � � � � � � � � � � � � � � � � � � 6
Music & Volume � � � � � � � � � � � � � � � � � � � 7
Line Input Option� � � � � � � � � � � � � � � � � � 7
Phone Calls � � � � � � � � � � � � � � � � � � � � � � � 8
Charging � � � � � � � � � � � � � � � � � � � � � � � � � 9
Legalities � � � � � � � � � � � � � � � � � � � � � � � � 10
TABLE OF CONTENTS

EN | 3
Location of Controls
1. Power Button
2. Volume Up Button
3. Volume Down Button
4. Multifunction Button (MFB)
5. LED Indicator Light
6. Line Input
7. Charging Port
2
5
43
1
6
76
ENGLISH (EN)

EN | 4
Power On/O
Power On: Press and hold the power button
(1) (you will hear “Power On”)
Power O: Press and hold the power button
(1) (you will hear “Power O”)
1

EN | 5
Bluetooth Pairing
Open the Bluetooth settings on
your device.
A B
Search for “ISOtunes AIR
DEFENDER.” Pair and connect. You
will hear “Bluetooth Connected”
once connected.
Press and hold the Multifunction Button (4) to enable Bluetooth. You will hear
“Bluetooth On” and the headphones will automatically enter Pairing Mode.

EN | 6
Bluetooth Reset
Press and hold the Multifunction Button (4) for ten seconds. The Bluetooth LED (4)
will ash quickly eight times if successful.
3

EN | 7
Music & Volume
Play/Pause: Short Single Press MFB (4)
Next Track: Short Double Press MFB (4)
Previous Track: Short Triple Press MFB (4)
Volume Up: Press + button (2)
Volume Down: Press – button (3)
Line Input Option
To listen to music via the line input (6), use the
3.5mm audio cable included. Insert one end into the
ISOtunes AIR DEFENDER and insert the other end
into your phone or other personal media device. Will
not work for phone calls with line input.
4
2
3
6

EN | 8
Phone Calls
Answer Call: Short Press MFB (4)
End Call: Long Press MFB (4)
Reject Call: Press and hold MFB (4)
Mute/Unmute Microphone: Short Press MFB (4)
4

EN | 9
Charging
This product is charged with a micro-USB charger and hold up to 10 hours of music
and talk time between charges.
Charge the ISOtunes AIR DEFENDER by
plugging the included micro-USB cable
into the product and a USB Port (6). The
built in battery will charge, as indicated
by a solid blue light. The light will turn o
once charging is complete.
1 2
Only charge your ISOtunes AIR DEFENDER with
a maximum 5 Volt charger. Using a charger
higher than 5 Volts could be dangerous and
may damage your ISOtunes AIR DEFENDER
product. Be especially careful with “quick
charge” or “turbo charge” chargers, which
often supply 9, 12, or 15 Volts.
LED Indicator Light (5)
Solid Red = Charging
(Cable Plugged In)
No Light = Fully Charged
(Cable Plugged In)
6

EN | 10
Fitting
ANSI S3.19-1974 Table (NRR Table)
EN 352-2:2002 Table (SNR Table)
B5:
SNR: 27 dB
H= 29 dB
M= 24 dB
L= 19 dB
APVf=MF-SF9 (dB)
Models
IT-46 AIR DEFENDER
IT-47 AIR DEFENDER EN 352
Important
Please read, understand, and follow all safety information.
Full manual can be found at
ISOtunes.com/AIRDEFENDERManual
Fitting
1. Pull the earcups apart
2. Place the product on your head
3. Adjust the earcup position by extending the headband to
ensure a good t around the ears
Introduction
Thank you for purchasing ISOtunes® AIR DEFENDER professional
noise isolating headphones. These headphones have been
specically designed for use in noisy environments – allowing you
to block out much of the surrounding noise so that you can listen
to your music or talk on the phone with less interruption.
Noise Attenuation APPROVAL
This product has been tested to the European Safety Standard
EN352-1:2002 and the ANSI S3.19-1974 standard for a hearing
protector, with a Single Number Rating (SNR) of 30 dB and a Noise
Reduction Rating (NRR) of 24 dB. Full testing details are available
in the Noise Attenuation section of this booklet.
ANSI
S3.19-1974
The level of noise entering a person’s ear, when ISOtunes®
AIR DEFENDER headphones are worn as directed, is closely
approximated by the dierence between the A-weighted
environmental noise level and the Noise Reduction Rating
(NRR). Improper t of this device will reduce its eectiveness in
attenuating noise. Consult the enclosed instructions for proper
tting.
A1: Frequency (Hz)
A2: Mean Attenuation (dB)
A3: Standard Deviation (dB)
Example:
1. The surrounding noise level measured at the ear is 100 dB.
2. The NRR of ISOtunes® AIR DEFENDER is 24 dB.
3. The noise level entering the ear is approximately equal to 76dB.
Please note that the NRR is based on the attenuation of
continuous noise and may not be an accurate indicator of the
protection attainable against impulsive noise, such as gunre.
LEGALITIES
FIG 1 FIG 2 FIG 3
R
