iStorage DISKASHUR M2 User manual

www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
User Manual........................................................................................... 2
Manuel de l’utilisateur............................................................................. 39
Benutzerhandbuch.................................................................................. 76
Manualed’uso......................................................................................... 113
ユーザーガイド....................................................................................... 150
Gebruikershandleiding............................................................................ 187
Manual del usuario.................................................................................. 224

#2
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
Please make sure you remember your PIN (password), without it, there
is no way to access the data on the drive.
If you are having difficulty using your diskAshur M2please contact our support team by
email - [email protected] or by phone on [phone].
User Manual

#3
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
Copyright © iStorage Limited 2020. All rights reserved.
Windows is a registered trademark of Microsoft Corporation.
All other trademarks and copyrights referred to are the property of their respective owners.
Distribution of modified versions of this document is prohibited without the explicit permission of the copyright holder.
Distribution of the work or derivative work in any standard (paper) book form for commercial purposes is prohibited unless prior permission is
obtained from the copyright holder.
DOCUMENTATION IS PROVIDED AS IS AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID
All trademarks and brand names are the property of their respective owners
Trade Agreements Act (TAA) Compliant

#4
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
Table of Contents
Introduction ...........................................................................................................................................................................................5
Box contents .........................................................................................................................................................................................5
diskAshur M2Layout .............................................................................................................................................................................5
1. LED indicators and their actions .....................................................................................................................................................6
2. LED States ......................................................................................................................................................................................6
3. First Time Use.................................................................................................................................................................................7
4. Unlocking diskAshur M2with the Admin PIN .................................................................................................................................8
5. How to Enter Admin Mode .............................................................................................................................................................8
6. Changing the Admin PIN ................................................................................................................................................................9
7. Setting a User PIN Policy ...............................................................................................................................................................10
8. How to delete the User PIN Policy ..................................................................................................................................................11
9. How to check the User PIN Policy ..................................................................................................................................................11
10. Adding a New User PIN in Admin Mode .........................................................................................................................................12
11. Changing the User PIN in Admin Mode .......................................................................................................................................... 13
12. Deleting the User PIN in Admin Mode ...........................................................................................................................................13
13. How to Unlock diskAshur M2with User PIN ................................................................................................................................... 14
14. Changing the User PIN in User Mode ............................................................................................................................................14
15. Creating a One-Time User Recovery PIN ........................................................................................................................................15
16. Deleting the One-Time User Recovery PIN .....................................................................................................................................15
17. Activating Recovery Mode and Creating New User PIN ..................................................................................................................16
18. Set User Read-Only in Admin Mode ..............................................................................................................................................16
19. Enable User Read/Write in Admin Mode ........................................................................................................................................17
20. Set Global Read-Only in Admin Mode ............................................................................................................................................17
21. Enable Global Read/Write in Admin Mode .....................................................................................................................................18
22. How to configure a Self-Destruct PIN .............................................................................................................................................18
23. How to delete the Self-Destruct PIN ...............................................................................................................................................19
24. How to Unlock with the Self-Destruct PIN ......................................................................................................................................19
25. How to Configure an Admin PIN after a Brute Force attack or Reset ..............................................................................................20
26. Setting the Unattended Auto-Lock ..................................................................................................................................................20
27. Turn off the Unattended Auto-Lock .................................................................................................................................................21
28. How to check the Unattended Auto-Lock......................................................................................................................................... 22
29. Set Read-Only in User Mode ..........................................................................................................................................................22
30. Enable Read/Write in User Mode ....................................................................................................................................................23
31. Brute Force Hack Defence Mechanism ...........................................................................................................................................23
32. Admin PIN Brute Force Hack Defence Mechanism .........................................................................................................................24
33. How to set the User PIN Brute Force Limitation .............................................................................................................................24
34. How to check the User PIN Brute Force Limitation .........................................................................................................................25
35. How to perform a complete reset ...................................................................................................................................................26
36. How to configure diskAshur M2as Bootable .................................................................................................................................. 26
37. How to disable the diskAshur M2Bootable feature ......................................................................................................................... 27
38. How to check the Bootable setting ..................................................................................................................................................27
39. Initialising and formatting diskAshur M2for Windows .................................................................................................................. 28
40. Initialising and formatting diskAshur M2in Mac OS ......................................................................................................................30
41. Initialising and formatting diskAshur M2in Linux OS ....................................................................................................................32
42. Hibernating, Suspending or Logging off from the Operating System ............................................................................................35
43. How to check Firmware in Admin Mode .........................................................................................................................................35
44. How to check Firmware in User Mode ............................................................................................................................................36
45. Technical Support ..........................................................................................................................................................................37
46. Warranty and RMA information ......................................................................................................................................................37

#5
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
Introduction
Box Contents
• diskAshur M2 portable SSD & Protective Sleeve
• Protective carry case
• USB C & A Cables
• Quick start guide & Product disclaimer
Thank you for purchasing the new iStorage diskAshur M2, an ultra-secure and easy to use, hardware encrypted, PIN authenticated
portable Solid State Drive (SSD) with capacities of 120GB to 2TB and rising.
Designed to be FIPS 140-3 Level 3, the diskAshur M2encrypts data in transit and at rest using AES-XTS 256-bit full disk hardware
encryption.
The diskAshur M2incorporates a Common Criteria EAL 5+ (Hardware Certified) secure microprocessor, which employs built-in physical
protection mechanisms designed to defend against external tamper, bypass attacks and fault injections.
Unlike other solutions, the diskAshur M2reacts to an automated attack by entering the deadlock frozen state, which renders all such
attacks as useless. In plain and simple terms, without the PIN there’s no way in!
diskAshur M2Layout
Hard anodised and ruggedised
extruded aluminium housing LED lights - Red: Standby/locked
Green: User mode/unlocked
Blue: Admin mode
Polymer coated, wear resistant
alphanumeric keypad
Epoxy coating
Key button
Shift button
Rubber gasket - making the drive
waterproof when sleeve is fitted
The diskAshur M2incorporates a
Common Criteria EAL 5+ (Hardware
Certied) secure microprocessor.

#6
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
1. LED indicators and their actions
LED LED State Description LED LED State Description
RED Solid Locked drive (in either
Standby or Reset states)
BLUE Solid Drive in Admin mode
RED Double blink Incorrect PIN entry
RED, GREEN and
BLUE Blinking
together Waiting for User PIN entry
GREEN Solid Drive unlocked
GREEN and BLUE
Blinking together Waiting for Admin PIN entry
GREEN Blinking Data transfer in progress
GREEN and BLUE
Blinking alternately Authentication in progress
2. LED States
To wake from Idle State
Idle state is defined as when diskAshur M2is not being used and all LEDs are off.
To wake diskAshur M2from the idle state do the following.
Connect the diskAshur M2to a powered USB
port on your computer
RED, GREEN and BLUE LEDs blink once in sequence then the GREEN
LED blinks twice and finally switches to a solid RED LED indicating
the drive is in Standby State
To enter Idle State
To force diskAshur M2to enter Idle State, execute either of the following operations:
• Disconnect the drive if connected to a USB port, all LEDs will switch off (idle state).
Power-on States
After the drive wakes from the Idle State, it will enter one of the following states shown in the table below.
Power-on State LED indication Encryption
Key
Admin
PIN Description
Initial Shipment State RED and GREEN
Solid   Waiting for configuration of an Admin PIN (First Time Use)
Standby RED Solid   Waiting for Admin or User PIN entry
Reset RED Solid   Waiting for configuration of an Admin PIN
Note: The normal function of the diskAshur M2may be disturbed by strong Electro-Magnetic Interference. If so, simply
power cycle the product (power off then power on) to resume normal operation. If normal operation does not resume,
please use the product in a different location.

#7
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
To configure an Admin PIN and unlock the diskAshur M2for the first time, please follow the simple steps in the table below.
Instructions - First Time Use LED LED State
1. Connect the diskAshur M2to a powered USB port on your
computer
RED, GREEN and BLUE LEDs blink once in
sequence then the GREEN LED blinks twice and finally
switches to solid RED and GREEN LEDs indicating the
drive is in the Initial Shipment State
2. Press and hold down both KEY ( ) + 1 buttons LEDs turn to blinking GREEN and solid BLUE
3. Enter a New Admin PIN (7-15 digits) and press the
KEY ( ) button once
Blinking GREEN and solid BLUE LEDs switch to a
GREEN blink then back to Blinking GREEN and solid
BLUE LEDs
4. Re-enter your New Admin PIN and press the KEY ( )
button again
BLUE LED rapidly blinks then switches to a solid BLUE
LED and finally to a solid GREEN LED indicating the
Admin PIN has been successfully configured and drive
unlocked
Locking the diskAshur M2
To lock the drive, safely eject the diskAshur M2from your host operating system and then unplug from the USB port. If data is being
written to the drive, unplugging the diskAshur M2will result in incomplete data transfer and possible data corruption.
3. First Time Use
PIN Requirements:
• Must be between 7-15 digits in length
• Must not contain only repetitive numbers, e.g. (3-3-3-3-3-3-3)
• Must not contain only consecutive numbers, e.g. (1-2-3-4-5-6-7), (7-8-9-0-1-2-3-4), (7-6-5-4-3-2-1)
Examples of these types of Alphanumerical PINs are:
• For “Password”press the following buttons:
7 (pqrs) 2 (abc) 7 (pqrs) 7 (pqrs) 9 (wxyz) 6 (mno) 7 (pqrs) 3 (def)
• For “iStorage”press the following buttons:
4 (ghi) 7 (pqrs)8 (tuv) 6 (mno) 7 (pqrs) 2 (abc) 4 (ghi) 3 (def)
Using this method, long and easy to remember PINs can be configured.
Password Tip: You can configure a memorable word, name, phrase or any other Alphanumerical PIN combination
by simply pressing the button with the corresponding letters on it.
diskAshur M2is supplied in the ‘Initial Shipment State’ with no pre-set Admin PIN. A 7-15 digit Admin PIN must be
configured before the drive can be used. Once an Admin PIN has been successfully configured, it will then not be possible to switch the
drive back to the ‘Initial Shipment State’.

#8
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
4. Unlocking diskAshur M2with the Admin PIN
To unlock the diskAshur M2with the Admin PIN, please follow the simple steps in the table below.
1. Connect the diskAshur M2to a USB port on your
computer
RED, GREEN and BLUE LEDs blink once in
sequence then the GREEN LED blinks twice and finally
switches to a solid RED LED indicating the drive is in
Standby State
2. In Standby State (solid RED LED) press the
KEY ( )button once GREEN and BLUE LEDs blink together
3. With the GREEN and BLUE LEDs blinking together,
enter the Admin PIN and press the KEY ( )button
again
GREEN and BLUE LEDs will alternately blink
several times and then to a solid BLUE LED
and changing to a solid GREEN LED indicating the drive
has been successfully unlocked as Admin
5. How to Enter Admin Mode
To Enter Admin Mode, do the following.
1. Connect the diskAshur M2to a powered USB port on your
computer
RED, GREEN and BLUE LEDs blink once in
sequence then the GREEN LED blinks twice and finally
switches to a solid RED LED indicating the drive is in
Standby State
2. In Standby State (solid RED LED) Press and hold down
both KEY ( ) + 1 buttons GREEN and BLUE LEDs blink together
3. Enter your Admin PIN and press the KEY ( )button
once
GREEN and BLUE LEDs will rapidly blink together
several times and then switch to a solid GREEN LED
and finally changing to a solid BLUE LED indicating the
drive is in Admin mode
To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the solid BLUE LED
switches to a solid RED LED.
To Exit Admin Mode

#9
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
6. Changing the Admin PIN
PIN Requirements:
• Must be between 7-15 digits in length
• Must not contain only repetitive numbers, e.g. (3-3-3-3-3-3-3)
• Must not contain only consecutive numbers, e.g. (1-2-3-4-5-6-7), (7-8-9-0-1-2-3-4), (7-6-5-4-3-2-1)
1. In Admin mode press and hold down both
the KEY ( ) + 2 buttons
Solid BLUE LED will change to blinking GREEN and
solid BLUE LEDs
2. Enter NEW Admin PIN and then press the
KEY ( )button once
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
3. Re-enter the NEW Admin PIN and then press the
KEY ( )button once
Blinking GREEN and solid BLUE LEDs change to
a rapidly blinking BLUE LED and finally to a solid
BLUE LED indicating the Admin PIN has been
successfully changed
To change the Admin PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode
(solid BLUE LED) proceed with the following steps.
Examples of these types of Alphanumerical PINs are:
• For “Password”press the following buttons:
7 (pqrs) 2 (abc) 7 (pqrs) 7 (pqrs) 9 (wxyz) 6 (mno) 7 (pqrs) 3 (def)
• For “iStorage”press the following buttons:
4 (ghi) 7 (pqrs)8 (tuv) 6 (mno) 7 (pqrs) 2 (abc) 4 (ghi) 3 (def)
Using this method, long and easy to remember PINs can be configured.
Password Tip: You can configure a memorable word, name, phrase or any other Alphanumerical PIN combination
by simply pressing the button with the corresponding letters on it.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#10
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
7. Setting a User PIN Policy
The Administrator can set a restriction policy for the User PIN. This policy includes setting the minimum length of the PIN (from 7 to
15 digits), as well as requiring or not the input of one or more 'Special Characters'. The “Special Character” functions as both the
'SHIFT ( ) + digit' buttons pressed down together.
To set a User PIN Policy (restrictions), you will need to enter 3 digits, for instance '091', the first two digits (09) indicate the minimum
PIN length (in this case, 9) and the last digit (1) denotes that one or more 'Special Characters' must be used, in other
words 'SHIFT ( ) + digit'. In the same way, a User PIN Policy can be set without the need of a 'Special Character', for instance
'120', the first two digits (12) indicate the minimum PIN length (in this case,12) and the last digit (0) meaning no Special Character is
required.
Once the Administrator has set the User PIN Policy, for instance '091', a new User PIN will need to be configured - see
section 10, ‘Adding a New User PIN in Admin Mode’. If the Administrator configures the User PIN as '247688314' with the use of a
'Special Character' (SHIFT ( ) + digit pressed down together), this can be placed anywhere along your 7-15 digit PIN during the
process of creating the User PIN as shown in the examples below.
A. 'SHIFT ( ) + 2', '4', '7', '6', '8', '8', '3', '1', '4',
B. '2', '4', 'SHIFT ( ) + 7', '6', '8', '8', '3', '1', '4',
C. '2', '4', '7', '6', '8', '8', '3', '1', 'SHIFT ( ) + 4',
Note:
• If a ‘Special Character’ was used during the configuration of the User PIN, for instance, example ‘B’ above,
then the drive can only be unlocked by entering the PIN with the ‘Special Character’ entered precisely in the
order configured, as per example ‘B’ above - (‘2’, ‘4’, ‘SHIFT ( ) + 7’, ‘6’, ‘8’, ‘8’, ‘3’, ‘1’, ‘4’).
• More than one ‘Special Character’ can be used and placed along your 7-15 digit PIN.
• Users are able to change their PIN but are forced to comply with the set ‘User PIN Policy’ (restrictions), if
and when applicable.
• Setting a new User PIN Policy will automatically delete the User PIN if one exists.
• This policy does not apply to the ‘Self-Destruct PIN’. The complexity setting for the Self-Destruct PIN and
Admin PIN is always 7-15 digits, with no special character required.
1. In Admin mode, press and hold down both
KEY ( ) + 7 buttons
Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Enter your 3 digits, remember the first two digits
denote minimum PIN length and last digit (0 or 1)
whether or not a special character has been used.
Blinking GREEN and BLUE LEDs will continue to
blink
3. Press the SHIFT ( ) button once
Blinking GREEN and BLUE LEDs will change to a
solid GREEN LED and finally to a solid BLUE LED
indicating the User PIN Policy has been successfully
set.
To set a User PIN Policy, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid BLUE
LED) proceed with the following steps.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#11
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
8. How to delete the User PIN Policy
1. In Admin mode, press and hold down both
KEY ( ) + 7 buttons
Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Enter 070 and press the SHIFT ( ) button once
Blinking GREEN and BLUE LEDs will change to a
solid GREEN LED and finally to a solid BLUE LED
indicating the User PIN Policy has been successfully
deleted
To delete the User PIN Policy, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid
BLUE LED) proceed with the following steps.
9. How to check the User PIN Policy
1. In Admin mode press and hold down both
SHIFT ( ) + 7 buttons Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Press the KEY ( )button and the following happens;
a. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
b. A RED LED blink equates to ten (10) units of a PIN.
c. Every GREEN LED blink equates to a single (1) unit of a PIN
d. A BLUE blink indicates that a 'Special Character' was used.
e. All LED’s (RED, GREEN & BLUE) become solid for 1 second.
f. LEDs return to solid BLUE
The Administrator is able to check the User PIN Policy and can identify the minimum PIN length restriction and whether or not the use of
a Special Character has been set by noting the LED sequence as described below.
To check the User PIN Policy, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid BLUE
LED) proceed with the following steps.
The table below describes the LED behaviour whilst checking the User PIN Policy, for instance if you have set a 12 digit User PIN with
the use of a Special Character (121), the RED LED will blink once (1) and the GREEN LED will blink twice (2) followed by a single (1)
BLUE LED blink indicating that a Special Character must be used.
PIN Description 3 digit Setup RED GREEN BLUE
12 digit PIN with use of a Special Character 121 1 Blink 2 Blinks 1 Blink
12 digit PIN with NO Special Character used 120 1 Blink 2 Blinks 0
9 digit PIN with use of a Special Character 091 0 9 Blinks 1 Blink
9 digit PIN with NO Special Character used 090 0 9 Blinks 0
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#12
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
10. Adding a New User PIN in Admin Mode
PIN requirements:
• Must be between 7-15 digits in length
• Must not contain only repetitive numbers, e.g. (3-3-3-3-3-3-3)
• Must not contain only consecutive numbers, e.g. (1-2-3-4-5-6-7), (7-8-9-0-1-2-3-4), (7-6-5-4-3-2-1)
• The SHIFT ( ) button can be used for additional PIN combinations - e.g. SHIFT ( ) + 1 is a different value
than just 1. See section 7, ‘Setting a User PIN Policy’.
To add a New User PIN, first enter “Admin Mode” as described in section 5. Once the drive is in Admin Mode
(solid BLUE LED) proceed with the following steps.
1. In Admin mode press and hold down both
KEY ( ) + 3 buttons
Solid BLUE LED will change to blinking GREEN and
solid BLUE LEDs
2. Enter New User PIN and press KEY ( )button
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
3. Re-enter the New User PIN and press KEY ( )
button again
Blinking GREEN and solid BLUE LEDs change to a
rapidly blinking GREEN LED and finally to a solid
BLUE LED indicating a New User PIN has been
successfully configured
Important: The creation of a New User PIN must comply with the ‘User PIN Policy’ if one has been configured as
described in section 7, which imposes a minimum PIN length and whether a ‘Special Character’ has been used. The
Administrator can Refer to section 9 to check the user PIN restrictions.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#13
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
11. Changing the User PIN in Admin Mode
To change an existing User PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid
BLUE LED) proceed with the following steps.
1. In Admin mode press and hold down both
KEY ( ) + 3 buttons
Solid BLUE LED will change to blinking GREEN and
solid BLUE LEDs
2. Enter New User PIN and press KEY ( )button once
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
3. Re-enter the New User PIN and press KEY ( )
button once
Blinking GREEN and solid BLUE LEDs change to a
rapidly blinking GREEN LED and finally to a solid
BLUE LED indicating the User PIN has been
successfully changed
12. Deleting the User PIN in Admin Mode
To delete an existing User PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid
BLUE LED) proceed with the following steps.
1. In Admin mode press and hold down both
SHIFT ( ) + 3 buttons
Solid BLUE LED will change to a blinking RED LED
2. Press and hold down both
SHIFT ( ) + 3 buttons again
Blinking RED LED will change to a solid RED LED
and then to a solid BLUE LED indicating the User
PIN has been successfully deleted
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
Important: Changing the User PIN must comply with the ‘User PIN Policy’ if one has been configured as described in
section 7, which imposes a minimum PIN length and whether a ‘Special Character’ has been used. The Administrator
can refer to section 9 to check the user PIN restrictions.

#14
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
13. How to Unlock diskAshur M2with User PIN
1. In a standby state (solid RED LED) Press and hold
down both the SHIFT ( ) +KEY ( ) buttons
RED LED switches to all LEDs, RED, GREEN &
BLUE blinking on and off
2. Enter User PIN and press the KEY ( )button once
RED, GREEN and BLUE blinking LEDs will change
to alternating GREEN and BLUE LEDs then to a
solid GREEN LED indicating drive successfully
unlocked in User Mode
14. Changing the User PIN in User Mode
1. In User mode (GREEN LED) press and hold down
both KEY ( ) + 4 buttons Solid GREEN LED will change to all LEDs, RED,
GREEN & BLUE blinking on and off
2. Enter your Existing User PIN and press the KEY ( )
button once
GREEN and solid BLUE LEDs will alternate on and
off and will then switch to a single GREEN LED
blink and then back to blinking GREEN and solid
BLUE LEDs
3. Enter New User PIN and press the KEY ( )
button once
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
4. Re-enter New User PIN and press the KEY ( )
button once
Blinking GREEN and solid BLUE LEDs will switch
to a rapidly blinking GREEN LED and then to a
solid GREEN LED indicating the User PIN has been
successfully changed
To change the User PIN, first unlock the diskAshur M2with the User PIN as described in section 13. Once the drive is in User Mode
(solid GREEN LED) proceed with the following steps.
Important: Changing the User PIN in User mode (GREEN LED) must comply with the ‘User PIN Policy’ if one has been
configured as described in section 7, which imposes a minimum PIN length and whether a ‘Special Character’ has been
used.
To unlock the diskAshur M2with the User PIN, proceed with the following steps.

#15
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
15. Creating a One-Time User Recovery PIN
1. In Admin mode press and hold down both
KEY ( ) + 4 buttons
Solid BLUE LED will change to blinking GREEN and
solid BLUE LEDs
2. Enter a One-Time Recovery PIN and press
KEY ( )button
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
3. Re-enter your One-Time Recovery PIN and press
KEY ( )button again
Blinking GREEN and solid BLUE LEDs change to a
rapidly blinking GREEN LED and finally to a solid
BLUE LED indicating the One-Time Recovery PIN
has been successfully configured
The User Recovery PIN is extremely useful in situations where a user has forgotten their PIN to unlock the diskAshur M2.
To activate the recovery mode, the user must first enter the correct One-Time Recovery PIN, if one has been configured. The user PIN
recovery process does not impact the data, encryption key and Admin PIN, however the user is forced to configure a new 7-15 digit User
PIN.
To configure a One-Time 7-15 digit User Recovery PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in
Admin Mode (solid BLUE LED) proceed with the following steps.
16. Deleting the One-Time User Recovery PIN
1. In Admin mode press and hold down both
SHIFT ( ) + 4 buttons
Solid BLUE LED will change to blinking
RED LED
2. Press and hold down both
SHIFT ( ) + 4 buttons again
Blinking RED LED will become solid RED and then
switch to a solid BLUE LED indicating that the One-
Time User Recovery PIN has been
successfully deleted
To delete the One-Time User Recovery PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode
(solid BLUE LED) proceed with the following steps.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#16
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
Important: The creation of a new User PIN must comply with the ‘User PIN Policy’ if one has been configured as
described in section 7, which imposes a minimum PIN length and whether a special character has been used. Refer to
section 9 to check the user PIN restrictions.
17. Activating Recovery Mode and Creating New User PIN
The User Recovery PIN is extremely useful in situations where a user has forgotten their PIN to unlock the diskAshur M2.
To activate the recovery mode, the user must first enter the correct One-Time Recovery PIN, if one has been configured. The user PIN
recovery process does not impact the data, encryption key and Admin PIN, however the user is forced to configure a new 7-15 digit User
PIN.
To activate the Recovery process and configure a new User PIN, proceed with the following steps.
1. In Standby State (RED LED) press and hold down both
KEY ( ) + 4buttons Solid RED LED will change to blinking RED and
GREEN LEDs
2. Enter the One-Time Recovery PIN and press the
KEY ( )button
GREEN and BLUE LEDs alternate on and off then to a
solid GREEN LED and finally to blinking GREEN and
solid BLUE LEDs
3. Enter a New User PIN and press the KEY ( )
button
Blinking GREEN and solid BLUE LEDs change to
a single GREEN LED blink then back to blinking
GREEN and solid BLUE LEDs
4. Re-enter your New User PIN and press the
KEY ( )button again
GREEN LED blinks rapidly then becomes solid
GREEN indicating the recovery process has been
successful and a new user PIN configured
With so many viruses and Trojans infecting USB drives, the Read-Only feature is especially useful if you need to access data on the USB
drive when used in a public setting. This is also an essential feature for forensic purposes, where data must be preserved in its original
and unaltered state that cannot be modified or overwritten.
When the Administrator configures the diskAshur M2and restricts User access to Read-Only, then only the Administrator can write to the
drive or change the setting back to Read/Write as described in section 19. The User is restricted to Read-Only access and cannot write to
the drive or change this setting in user mode.
18. Set User Read-Only in Admin Mode
To set the diskAshur M2and restrict User access to Read-Only, first enter the “Admin Mode” as described in section 5. Once the drive
is in Admin Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down both “7 + 6”
buttons. Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Press the KEY ( )button once
GREEN and BLUE LEDs will change to a solid
GREEN LED and then to a solid BLUE LED
indicating the drive has been configured and
restricts User access to Read-Only

#17
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
19. Enable User Read/Write in Admin Mode
To set the diskAshur M2back to Read/Write, first enter the “Admin Mode” as described in section 5. Once the drive is in
Admin Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down both “7 + 9”
buttons.
Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Press the KEY ( )button once
GREEN and BLUE LEDs change to a solid GREEN
LED then to a solid BLUE LED
indicating the drive is configured as Read/Write
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
When the Administrator configures the diskAshur M2and restricts it to Global Read-Only, then neither the Administrator nor the User can
write to the drive and both are restricted to Read-Only access. Only the Administrator is able to change the setting back to Read/Write as
described in section 21.
20. Set Global Read-Only in Admin Mode
To set the diskAshur M2and restrict Global access to Read-Only, first enter the “Admin Mode” as described in section 5. Once the drive
is in Admin Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down both “5 + 6”
buttons. Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Press KEY ( )button
GREEN and BLUE LEDs will change to a solid
GREEN LED and then to a solid BLUE LED
indicating the drive has been configured and
restricts Global access to Read-Only
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#18
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
22. How to configure a Self-Destruct PIN
You can configure a self-destruct PIN which when entered performs a Crypto-Erase on the drive (encryption key is deleted).This process
deletes all configured PINs and renders all data stored on the drive as inaccessible (lost forever), the drive will then show as unlocked
GREEN LED. Running this feature will cause the self-destruct PIN to become the New User PIN and the drive will need to be formatted
before it can be reused.
To set the Self-Destruct PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid BLUE
LED) proceed with the following steps.
1. In Admin mode, press and hold down both
KEY ( ) + 6 buttons Solid BLUE LED will change to blinking GREEN and
solid BLUE LEDs
2. Configure and enter a 7-15 digit Self-Destruct PIN and
press the KEY ( ) button
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
3. Re-enter your Self-Destruct PIN and press
the KEY ( )button
GREEN LED will rapidly blink for several
seconds and then changes to a solid BLUE LED
to indicate the Self-Destruct PIN has been
successfully configured
21. Enable Global Read/Write in Admin Mode
To set the diskAshur M2back to Read/Write from the Global Read-Only setting, first enter the “Admin Mode” as described in section 5.
Once the drive is in Admin Mode (solid BLUE LED) proceed with the following steps.
1. In Admin mode, press and hold down both “5 + 9”
buttons.
Solid BLUE LED will change to blinking GREEN and
BLUE LEDs
2. Press KEY ( )button
GREEN and BLUE LEDs change to a solid GREEN
LED then to a solid BLUE LED
indicating the drive is configured as Read/Write
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#19
www.istorage-uk.com
iStorage diskAshur®M2User Manual v1.9
23. How to Delete the Self-Destruct PIN
1. In Admin mode, press and hold down both
SHIFT ( ) + 6 buttons Solid BLUE LED will change to a blinking RED LED
2. Press and hold down SHIFT ( ) + 6 buttons again
Blinking RED LED will become solid and then
change to a solid BLUE LED indicating the
Self-Destruct PIN was successfully deleted
To delete the Self-Destruct PIN, first enter the “Admin Mode” as described in section 5. Once the drive is in Admin Mode (solid BLUE
LED) proceed with the following steps.
1. In Standby State (solid RED LED), press and hold
down both the SHIFT ( ) + KEY ( ) buttons
RED LED switches to all LEDs, RED, GREEN &
BLUE blinking on and off
2. Enter the Self-Destruct PIN and press the
KEY ( )button
RED, GREEN and BLUE blinking LEDs will change
to GREEN and BLUE LEDs alternating on and off for
a few seconds and finally shifts to a solid GREEN
LED indicating the diskAshur M2has successfully
self-destructed
24. How to Unlock with the Self-Destruct PIN
When used, the self-destruct PIN will delete ALL data, Admin/User PINs and then unlock the drive. Activating this feature will
cause the Self-Destruct PIN to become the New User PIN and the diskAshur M2will need to be formatted before any new data can
be added to the drive.
To activate the Self-Destruct mechanism, the drive needs to be in the standby state (solid RED LED) and then proceed with the following
steps.
Warning: When the Self-Destruct mechanism is activated, all data, the encryption key and the Admin/User PINs are
deleted. The Self-Destruct PIN becomes the User PIN. No Admin PIN exists after the Self-Destruct mechanism is
activated. The diskAshur M2will need to be reset (see ‘How to perform a complete reset’ Section 35, on page 26) first in
order to configure an Admin PIN with full Admin privileges including the ability to configure a new User PIN.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.

#20
iStorage diskAshur®M2User Manual v1.9
www.istorage-uk.com
25. How to Configure an Admin PIN after a Brute Force attack or Reset
It will be necessary after a Brute Force attack or when the diskAshur M2has been reset to configure an Admin PIN before the drive can be
used.
PIN Requirements:
• Must be between 7-15 digits in length
• Must not contain only repetitive numbers, e.g. (3-3-3-3-3-3-3)
• Must not contain only consecutive numbers, e.g. (1-2-3-4-5-6-7), (7-8-9-0-1-2-3-4), (7-6-5-4-3-2-1)
1. In Standby state (solid RED LED), press and hold
down both SHIFT ( ) + 1 buttons
Solid RED LED will change to blinking GREEN and
solid BLUE LEDs
2. Enter New Admin PIN and press KEY ( )
button
Blinking GREEN and solid BLUE LEDs will switch to
a single GREEN LED blink and then back to blinking
GREEN and solid BLUE LEDs
3. Re-enter the New Admin PIN and press
KEY ( )button
Blinking GREEN LED and solid BLUE LED change
to BLUE LED rapidly blinking for a few seconds and
then to a solid BLUE LED indicating the Admin PIN
was successfully configured.
If the diskAshur M2has been brute forced or reset, the drive will be in standby state (solid RED LED). to configure an Admin PIN
proceed with the following steps.
26. Setting the Unattended Auto-Lock
To protect against unauthorised access if the drive is unlocked and unattended, the diskAshur M2can be set to
automatically lock after a pre-set amount of time. In its default state, the diskAshur M2Unattended Auto Lock time-out
feature is turned off. The Unattended Auto Lock can be set to activate between 5 - 99 minutes.
Note: To immediately exit Admin Mode (solid BLUE LED), press and hold down the SHIFT ( ) button for a second - the
solid BLUE LED switches to a solid RED LED.
