ITW Foxjet Marksman Matrix User manual

Marksman
MATRIX & ELITE
High Resolution Printing
for the Real World
2465-623
Revision F
User
Manual
1 Missouri Research Park Drive • St. Charles, MO 63304
Tel: [phone]
Illinois Tool Works Inc © 2019

www.foxjet.com Marksman
MATRIX & ELITE
Ink Jet System
User Manual
2465-623
The information contained in this manual
is correct and accurate at the time of its
publication. ITW reserves the right to
change or alter any information or
technical specifications at any time and
without notice.
©2019 Illinois Tool Works Inc.
All rights reserved

Warranty:
The Marksman© Matrix & Elite Ink Jet system, including all components unless other
wise specified, carries a limited warranty.
The inks and conditioners used with the Marksman© Matrix & Elite Ink Jet system
carry a limited warranty.
For all warranty terms and conditions, contact the Distributor for a complete copy of the
Limited Warranty Statement.

Marksman Matrix & Elite
2465-623 User Manual Rev F
Section 1: Safety and Ink Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Section 2: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Materials Required for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 1: Installing Bracketry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Step 2: Mounting the Print System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 3: Mounting the Photosensor and Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 4: Electrical Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Step 5: Priming the Print Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Section 5: Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Counts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
User Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Info Window / Preview Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Configure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Section 6: BoxWriter© Matrix & Elite Editor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Define . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
ToolBars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Perspective . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Section 7: Maintenance and Shutdowns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
APS - Automatic Priming System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Print Head Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Shutdown Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Ink Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Section 8: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Troubleshooting Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Troubleshooting Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Print Quality Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Appendix A: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Matrix Controller Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Matrix Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Elite Controller Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Elite Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Print Head Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Marksman Matrix & Elite
2465-623 User Manual Rev F
Appendix B: Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
The Marksman© Matrix & Elite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Print Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Photosensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Encoder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Appendix C: Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Matrix Spare Parts Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Elite Spare Parts Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
384e and 768e Print System Service Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Appendix D: Database Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Database Start Task Routine Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Database Lookup Definition - Global Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Database Start Task . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Serial Port Modification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Printer Report Modification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Appendix E: Hand Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Scan and Shoot Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Appendix F: Communicating Directly to the Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Appendix G: Using Serial.cgi Commands through the Serial Port . . . . . . . . . . . . . . . . . . . . . . . 92
Appendix H: Using Marksman Net Software to Communicate to the Matrix . . . . . . . . . . . . . . 92
Appendix I: Using the Marksman Net Protocol to Control the Matrix . . . . . . . . . . . . . . . . . . . . 92
Appendix J Using the Print Monitor Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Appendix K: Standard Operating Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
FJSOP1 - Removal of FoxJet High Resolution Printheads . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
FJSOP2 - Daily Maintenance for AMS/APS Printheads . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
FJSOP4 - Installation of FoxJet High Resolution AMS/APS Printheads . . . . . . . . . . . . . . . . 97

Section 1: Safety and Ink Usage
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 1
Section 1: Safety and Ink Usage
Following is a list of safety symbols and their meanings, which will be found throughout this
manual. Pay attention to these symbols where they appear in the manual.
Wear safety goggles when performing the procedure described!
Caution or Warning! Denotes possible personal injury and/or damage to the equip-
ment.
Caution or Warning! Denotes possible personal injury and/or equipment damage
due to electrical hazard.
NOTE: (Will be followed by a brief comment or explanation.)
Only trained personnel should operate and service the equipment.
NOTE: It is extremely important to:
• Clean up all ink spills with the appropriate conditioners immediately and dispose of all
waste according to local and state regulations.
• Wear safety glasses and protective clothing, including gloves, when handling all inks
and conditioners.
• Store inks and conditioners under the recommended conditions found on the MSDS
(Material Safety Data Sheet).
PRODUCT COMPLIANCE DISCLAIMER NOTE:
This product meets the requirements of UL60950-1:2007/A2:2014, EN60950-1:2006/
A2:2013, CAN/CSA C22.2 No. 60950-1:2007/A2:2014 using FoxJet an ITW Company
approved items. Units are only tested and qualified with FoxJet an ITW Company approved
inks, parts and accessories. Use of other inks, parts or accessories may introduce potential
risks that FoxJet an ITW Company can assume no liability for.
!

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 2
Section 2: Installation
1 Controller, Matrix or Elite
2 Proseries Print Head
3 Conveyor
4 Product
5 Print System Bracketry
6 Encoder
7 Ink Supply
8 Photo Sensor
9 Vacuum Waste Collector Bottle
10 Encoder Cable
11 Alarm Beacon (Strobe)

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 3
The figure below illustrates a typical conveyor-mounted installation. (Cables are not
shown.)
Materials Required for Installation
You will need the following items:
• Lint-free wipes
• Safety goggles
•Level
• Tape measure
Use appropriate safety equipment and procedures. Leave print heads in their shipping car-
tons until all bracketry is in place and tightened down.

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 4
Step 1: Installing Bracketry
Bracketry is the structure that supports the controller, print system and other accessories.
Carefully plan the mounting location of the equipment. Keep in mind bracketry hardware
location and printer equipment size. Assemble all bracketry to the floor, conveyor, or other
bracketry.
This manual details instructions for mounting all system components to a conveyor. Other
mounting options for the controller and print system include the floor mount and the retract-
ing bracket (see “Appendix C: Part Numbers” on page 83). Assembly instructions are
included with mount kits.
Corner brackets are attached to aluminum bars as shown.
Retracting Bracket
Floor Mount
Conveyor Mount
Corner Bracket

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 5
Step 2: Mounting the Print System
Unpack the print head just before mounting to the bracketry.
Attach the print head to the bracketry with a print head mounting bracket. Do not connect to
power outlet.
The print head must be mounted in close proximity to the product. To maintain consistent
print, the head should be mounted no more than 1/8" from the substrate. An optional
retracting bracket is available to mount the head and control the distance from the head to
the substrate. The retracting bracket allows the head to bump the product and retract as
required to maintain a consistent throw distance. (See “System” on page 83 for bracketry
options.)
NOTE: Install optional retracting bracket kit on the print head prior to mounting the print
head to the conveyor bracket.
It may be necessary to vertically adjust each bracket's horizontal bar later to fine-tune mes-
sage placement. This is especially true when using multiple print heads, as message lines
will need to be synchronized with each other.
NOTE: When adjusting the horizontal bar or print head mounting bracket, always support
the print head with your hand to keep it from falling forward onto the conveyor.
NOTE: ProSeries print heads are supplied ink via capillary forces. Print heads must be
mounted in a level position from front to back to prevent leakage and provide proper ink
flow.
INK SYSTEM
WASTE BOTTLE
PRINT HEAD
INK BOTTLE

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 6
Setting Up the Print Head
The Matrix/Classic Series print heads are mounted using the 10-32 tapped holes on the
right or left side of the Ink System bottom case. The print head angle can be set between 0°
and 90°. (See “FJSOP4 - Installation of FoxJet High Resolution AMS/APS Printheads” on
page 97 for additional information.)
To adjust the head to its correct angle:
1. Loosen the two set screws (1/8" hex head) on the print head side of the head mount.
2. Rotate the head to the desired angle.
3. Secure the set screws.

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 7
Ship Caps
NOTE: If you place the Print Head Ship Cap on a hot print head and do not fasten it
securely, the print head will weep ink until the head has cooled down.
NOTE: Ink may accumulate behind the ship cap during shipping.
Remove the Vent Ship
Cap and Install the Fil-
ter. Remove the Res-
ervoir Ship Cap and
Install the Ink Bottle.
Remove Waste Reser-
voir Ship Cap and
install Waste Reser-
voir. Save caps in a
zip-lock bag for
future use.
THUMBSCREWS
SHIP CAP
VENT SHIP CAP
WASTE RESERVOIR

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 8
Inks
Ink is supplied via 500 mL plastic containers. ScanTrue® II PLUS is a pigmented ink formu-
lated for use on porous substrates.
NOTE: Check the label on the Print Head for correct ink type.
Waste Bottle
The APS includes a Waste Collection Bottle mounted on the rear of the Print Head assem-
bly. This bottle must be changed when full to prevent improper operation of the system.
Instructions for waste disposal are on the collection bottle.
Do not reuse waste ink; contaminants will reduce system lifespan.
Step 3: Mounting the Photosensor and Encoder
Photosensor
The photosensor is both a light source and a sensor. It emits light and detects the arrival of
a product when the product reflects the light source back to the sensor. The sensor then
sends a signal to the controller to start the printing cycle.
The product detect Photosensor should be mounted on either side of the print head so that
the product passes by the sensor before the print face. Remove the plugs or set screws (3/
32" hex head) in the photosensor mounting holes, then attach the Photosensor Mounting
Bracket with the 10-32 x 1/2" screws provided with the bracket.
Encoder
The encoder assembly provides conveyor line
speed information to the controller. It also allows
automatic disabling of printing when the line
stops.
The Marksman© Matrix & Elite System uses a
5000 ppr open collector output encoder. The
wheel is sized to provide the correct timing
inputs to allow the print heads to print from 150
to 300 dpi.
ENCODER ASSEMBLY

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 9
The encoder uses a wheel
that rolls against the con-
veyor line to track its speed. It
sends a signal to the control-
ler, which adjusts for changes
in line speed.
It is not necessary to install
the encoder immediately adja-
cent to the print heads. It is
more important to place it
where it will accurately mea-
sure the speed of the con-
veyor. Install it in contact with
the conveyor, or with a wheel
or roller moving the same
speed as the conveyor.
The encoder's mounting
bracket is spring-loaded.
Adjust the spring collar to
ensure that the encoder main-
tains stable contact with the
conveyor.
CAUTION: Do not jam the encoder wheel against the surface of the conveyor. A radial
force of over 40 lbs. will reduce the life of the bearings.
Spring
Mounting
Bracket
Encoder
Wheel
Conveyor
Out to Controller
Mounting Bracket
Shaft
Encoder
ENCODER
ASSEMBLY
!

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 10
Step 4: Electrical Cable Connections
PRINT
SYSTEM
PRINT HEAD CABLE
SENSOR
ENCODER
SYSTEM
PRINT
ALARM
BEACON
(STROBE)
MARKSMAN MATRIX OR ELITE CONTROLLER
24V

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 11
Views
VGA
LINE OUT
HDMI
USB
ETHERNET
12 VDC COM 1
STROBECOM 2 ENCODER
1
2
OUTPUT TO
PRINTHEAD
4
3
PRINT HEAD CARDS
Bottom view of Matrix Controller
(With Optional second PHC Board
Back view of
Print System
Bottom view of
Elite Controller
HEAD 3 & 4
CONNECTIONS
I/O PORT
SYSTEM
CONNECTIONS POWER
CORD
ENCODER
HEAD 1 & 2
CONNECTIONS

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 12
Step 5: Priming the Print Heads
Priming:
1. With the Print Face Cover installed, press and hold
the Prime Button for ~10 seconds (until Ink Supply
LED blinks slowly) to activate the recirculation
function. Allow the system to recirculate for at least
5 minutes before pressing the Prime Button again
to end the cycle.
2. Remove the Print Face Cover and store in a con-
venient nearby location.
3. Use a foam swab to lightly wipe the orifice plate in
a vertical downward motion.
4. Prime the print head by momen-
tarily pressing the Prime Button
to manually activate the APS
(Automatic Priming System)
Cycle. Observe the print face for
bubbles in the ink. In the case of
visible bubbles, activate the
APS cycle 2-3 more times or
until no air is observed.
5. Verify print quality by using the
Marksman Controller to print a
Test Pattern (accessed via.
“Configure” menu) while slowly
passing a sheet of paper in front
of the print face. Ensure that no
gaps are present in the print and
that it has printed the full avail-
able height (2” for 384 and 4” for
768).
6. If gaps are present in the print sample, follow the recommended procedure for Recircu-
lation as necessary until the print head passes the print quality test above.
7. With all channels firing, the print head is ready to begin printing.
Recirculation
This function circulates ink through the print head to draw air out of the system. It is very
effective in recovering print channels.
1. If not installed; reinstall the Print Face Cover. Ensure that ship cap is clean before rein-
stalling by wiping the gasket with a lint-free wipe or a foam swab.
2. Press and hold the Prime Button until the Ink Supply LED blinks slowly (~10 seconds)
to activate the recirculation function. For the first 5 seconds the print head will run
through the Manual Prime cycle, continue holding the button to activate the Recircula-
tion mode. The Ink Supply LED will blink slowly while recirculation is active. Do not
remove the Print Face Cover in this mode.
3. Allow the recirculation function to run for the desired length of time. Five minutes is the
recommended interval.
4. Press the Prime Button to end the recirculation function. If the button is not pressed,
recirculation will shut off automatically after 15 minutes.
PRINT FACE COVER
CORRECT ORIENTATION
RESERVOIR
SHIP CAP
PRIME BUTTON
VENT FILTER
VENT SHIP CAP
INK
BOTTLE
WASTE INK SHIP CAP

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 13
APS Cycle
The APS Cycle is a means of maintaining print quality. The APS system does this by using
a priming pump to force ink out of the channels and a vacuum pump and Waste Bottle to
collect the ink waste. The APS Cycle can be manually started by momentarily pressing the
prime button.
The APS Cycle will automatically activate at a designated time interval, which can be
adjusted using the rotary switch on the side of the Ink System case near the Prime Button.
The table below defines the settings available. Setting the rotary switch to 0 will disable
both automatic and manual APS cycles.
Manual Prime
A manual prime cycle is similar
to an APS cycle, except that it
is a bit more powerful and
uses a bit more ink. The cycle
can be started by pressing and
holding the Prime Button on
the rear of the print head hous-
ing for longer than 1 second.
The cycle will run while the
Prime Button is held, up to 5
seconds total. Make sure to
release the button before 10
seconds have passed, to avoid
entering the Recirculation
mode without the Print Face
Cover attached.
NOTE: The system will not prime either manually or automatically if there is a low ink indi-
cation, which is caused by either low ink in the reservoir or full ink in the waste collection
bottle.
NOTE: Adjustment of Print Head angle should be done according to the procedure outlined
in “Setting Up the Print Head” on page 6.
No APS UJ II Print Heads ProSeries 384/768 (e)
Switch Setting 0 123456789ABCDEF
Interval (hours) 0 246810 12 14 16 181246812
REMOVE PLUG
TO ACCESS
LED
SELECTION
INDICATOR
ROTARY SWITCH
DETAIL

Section 2: Installation
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 14
Auxiliary Photosensor Input
NOTE: The APS Control Cable and Auxiliary Photosensor cannot be used together.
An Auxiliary Photosensor input is available to insure a print cycle is not missed during the
automatic priming sequence. Connecting the Auxiliary Photosensor will delay a prime
sequence until there is enough time to complete the sequence without missing a print
cycle. The default delay setting is three (3) seconds after the product passes the photosen-
sor. Multiple heads can share the Auxiliary Photosensor by using the Photosensor "Y"
Cable. To change the default setting, perform the following steps:
1. Ensure that the rotary switch is not in the "0" position.
2. Place a box in front of the photosensor.
3. While the photosensor is on, set the rotary switch to 0.
4. When the LED stays illuminated continuously, set the rotary switch to a new number (1
through F) representing the number of seconds (1 through 15) you want to delay. Note:
"0" is not an available user setting.
5. Press and hold the Prime button until the LED starts flashing.
6. Release the Prime button.
7. Remove the box from in front of the photosensor.
8. Set the rotary switch back to the desired hour setting.

Section 5: Getting Started
Marksman Matrix & Elite
2465-623 User Manual Rev F Page 15
Section 5: Getting Started
The Marksman Matrix and Elite controllers are standalone units capable of operat-
ing up to four print heads, with the addition of an optional controller card. The soft-
ware has an ICON user interface. The main difference between the two controllers
is the size and the resolution of the displays. The resolutions are 1024 x 1280 for
the Elite and 1024 x 600 for the Matrix. The extra room on the Elite display allows
for the software keyboard to be accessible at all times. To access the keyboard on
the Matrix, simply select a field that requires keyboard input and it will appear.
To Windows Special Function
Change keyboard
language.
Matrix Keyboard
