iWALK RS1 User manual

Instruction Manual TDSRS1Z
Zhejiang iWalk Technology Co., Ltd.
Address: Building 59-1, Juxing Weichuang Technology Park, Xiachen Sud-District,
Jiaojiang District, Taizhou City, Zhejiang Province
Service Hotline: [phone]
Official website:https://www.zjiwalk.com/
Executive standard: GB17761-2018
WeChat public
account
The user should not use the electric bicycle before carefully reading the instruction manual to understand its performance.
Please keep this instruction manual properly. Service Hotline of
Zhejiang iWalk Technology Co., Ltd.: 400-883-9299 Official Website: https://www.zjlwalk.com/
Address: Building 59-1, Juxing Science and Technology Innovation Park, Xiachen Sud-District, Jiaojiang District, Taizhou
City, Zhejiang Province
Some specifications are subject to change without notice when the product is upgraded.
*Note: Due to the possible upgrade of the company's products, some of the content displayed on the actual product you
get will be different from its manual, but it will not affect your normal use.

Bicycle barcode Here is where the
barcode is pasted
PRECAUTIONS FOR USE
Please obey traffic laws and pay attention to driving safety, such as:
1) It is strictly forbidden for persons under the age of 16 to drive electric
bicycles on the road;
2) Electric bicycles should be driven in non-motorized vehicle lanes, and the
maximum speed should not exceed 15km/h; on roads without on-motorized
vehicle lanes, bicycle drivers shall drive on the right side of the roadway;
3) Please do not lend your electric bicycle to someone who cannot operate it to
avoid personal injury or property damage;
4) Electric bicycles shall carry persons or items in accordance with the
provisions of laws and regulations;
5) It is recommended to wear a helmet when riding this electric bicycle;
6) When riding in rainy and snowy days, the braking distance will be
extended, so please pay attention to slow down; try to avoid traveling in
bad weather such as heavy rain. Be sure to pay attention to the safety of
electric bicycles, such as:
1) Electric bicycles should not be parked in building foyers, evacuation stairs,
walkways as well as safety exits;
2) Electric bicycles should not be charged and parked in residential
buildings, and should be kept away from combustibles when charging,
and the charging time should not be too long;
3) Please refer to this manual for the correct use and maintenance of lithium
batteries; Waste lithium batteries cannot be dismantled without
authorization, and should be recycled by relevant professional departments;
4) Please refer to this manual for the safe use of the charger; For the warning
words, please refer to the main body logo of the electrical appliance; When
replacing the charger, the new charger should match the battery model;
5) Please refer to this manual for the precautions related to washing;
6) When adjusting the handlebars or saddles, be careful not to expose the
safety line markings of the handlebar tube and saddle tube. Precautions for
inspection before riding (if there is any abnormality, please repair it in time
or seek the help of professional maintenance personnel), such as:
1) Check the status of the power circuit, lighting circuit, etc.;
2) Check whether the front-wheel brake and rear-wheel brake can work normally;
3) Check the tightness of the handlebars and front and rear wheels;
4) Check the tire pressure, the recommended range is 240-310kpa;
5) Check the reflector for damage or soiling.
Battery and Charging
· Charge at 0°C to 45°C, discharge at -20°C to 60°C, and be sure to keep the battery dry;
· It is strictly forbidden to put the battery in acid or alkaline liquid, and please
keep the battery away from rain, heat and high humidity and make sure the
battery is kept away from fire.
· It is strictly forbidden to connect the positive and negative poles in reverse,
to damage, dismantle or short-circuit the battery;
·When charging, please use the original special charger, do not use other
brands of chargers without authorization, and the charging current should
not exceed 3A. When not in use for a long time, please keep the battery in
a cool and dry place, and charge the battery once a month;
·When charging, the electric bicycle should be placed in a ventilated
environment, and it is strictly forbidden to charge in a confined space or
in a high temperature environment under the scorching sun;
·When charging, plug in the battery first, and then turn on the mains
power for charging; after charging is completed, first cut off the mains
power, and then unplug the battery;
·When the green light is on, the power supply should be cut off in time,
and it is forbidden to connect the charger to the AC power supply with
no load for a long time without charging;
·During the charging process, if the indicator light is abnormal, there is a
peculiar smell or the case of the charger is overheated, the charging should
be stopped immediately, and the charger should be repaired or replaced;
·During the use and storage of the charger, be careful to avoid the entry
of foreign objects, especially the inflow of water or other liquids, so as
to avoid short circuit inside the charger;
·Do not disassemble or replace the components inside the charger by
yourself.
Maintenance and riding
·Check whether the front and rear wheel screws are locked, and whether
the pattern of the outer wheel is worn or cracked;
·It is forbidden to rinse with water, so as to avoid the hidden danger of
accidents caused by internal electronic components and lines due to
water seepage;
·Please use a cloth to wipe the stains of paint or plastic parts with a
neutral detergent, and then wipe it with a dry cloth;
·Check whether the joints of various parts are normal, and whether the
zipper of the brake cable is used in a lubricated state;
·If you do not use this electric bicycle for a long time, please pay
attention to regular charging (generally every two months) to maintain
your battery life;
·Please use lubricating oil to wipe the metal parts of the electric bicycle
body for maintenance;
It is strictly forbidden to fill the front and rear brakes, wheel steel and tires

If there is any change in the relevant information of this card,
please refer to the website
Product Information-03
Model: Repaired Part(s):
Cause of fault:
Repair outlet name:
Repaired Part(s):
Cause of fault:
Repair outlet name:
Product Information-04
Model:
Fault condition when
returning for repair:
Fault condition when
returning for repair:
Date of return:
Date of return:
Repairman's signature:
Repairman's signature:
Maintenance
certificate
Seal of Repair
department
RS1 Diagram
Power switch and horn
/headlight switch
Speed control handle
Seat tube folding lock
Headlight
Front fork
Crank
Crankset
Foot pedal
Front wheel
Vehicle coding position
Cushion
Quick release of seat cushion
Tail light
Rear fender
Motor rear wheel
Rear parking bracket
Brake lever

If there is any change in the relevant information of this card,
please refer to the website
Packing list
Body
Put down the parking bracket
Charger Other accessories
User manual, Certificate of conformity,
Three-guarantee card, After-sales service card
Battery (built-in
non-removable)
RS1 installation
Take out the body of the
electric bicycle and put
down the foot support
(as shown by the arrow
on the right side of the
picture)
Insert head tube
Insert the folded seat
tube into the head tube
and orient it as shown.
Maintenance
certificate
User Information
Product Information-01
Product Information-02
Name:
Address:
Model:
Fault condition when
returning for repair:
Contact: Email:
Date of return:
Repairman's signature:
Model:
Fault condition when
returning for repair:
Date of return:
Repairman's signature:
Repaired Part(s):
Cause of fault:
Repair outlet name:
Repaired Part(s):
Cause of fault:
Repair outlet name:

Please obey traffic laws and pay attention to driving safety, such as:
1) It is strictly forbidden for persons under the age of 16 to drive electric
bicycles on the road;
2) Electric bicycles should be driven in non-motorized vehicle lanes, and the
maximum speed should not exceed 15km/h; on roads without on-motorized
vehicle lanes, bicycle drivers shall drive on the right side of the roadway;
3) Please do not lend your electric bicycle to someone who cannot operate it to
avoid personal injury or property damage;
4) Electric bicycles shall carry persons or items in accordance with the
provisions of laws and regulations;
5) It is recommended to wear a helmet when riding this electric bicycle;
6) When riding in rainy and snowy days, the braking distance will be
extended, so please pay attention to slow down; try to avoid traveling in
bad weather such as heavy rain. Be sure to pay attention to the safety of
electric bicycles, such as:
1) Electric bicycles should not be parked in building foyers, evacuation stairs,
walkways as well as safety exits;
2) Electric bicycles should not be charged and parked in residential
buildings, and should be kept away from combustibles when charging,
and the charging time should not be too long;
3) Please refer to this manual for the correct use and maintenance of lithium
batteries; Waste lithium batteries cannot be dismantled without
authorization, and should be recycled by relevant professional departments;
4) Please refer to this manual for the safe use of the charger; For the warning
words, please refer to the main body logo of the electrical appliance; When
replacing the charger, the new charger should match the battery model;
5) Please refer to this manual for the precautions related to washing;
6) When adjusting the handlebars or saddles, be careful not to expose the
safety line markings of the handlebar tube and saddle tube. Precautions for
inspection before riding (if there is any abnormality, please repair it in time
or seek the help of professional maintenance personnel), such as:
1) Check the status of the power circuit, lighting circuit, etc.;
2) Check whether the front-wheel brake and rear-wheel brake can work normally;
3) Check the tightness of the handlebars and front and rear wheels;
4) Check the tire pressure, the recommended range is 240-310kpa;
5) Check the reflector for damage or soiling.
Battery and Charging
· Charge at 0°C to 45°C, discharge at -20°C to 60°C, and be sure to keep the battery dry;
· It is strictly forbidden to put the battery in acid or alkaline liquid, and please
keep the battery away from rain, heat and high humidity and make sure the
battery is kept away from fire.
· It is strictly forbidden to connect the positive and negative poles in reverse,
to damage, dismantle or short-circuit the battery;
Three Guarantees Certificate
Three Guarantees Policy
The after-sales service of electric-assisted folding bicycles implements the after-sales three-guarantee service strictly in accordance with the
provisions of the "Consumer Rights Law of the People's Republic of China" and the "Product Quality Law of the People's Republic of China".
The specific services are as follows:
1. The "Three Guarantees" period is calculated from the date of sale of the electric bicycle (Vehicle Purchase Document must be issued). "
During the "Three Guarantees" period, customers can enjoy the "Three Guarantees" service by presenting the "Vehicle Purchase Document"
and "Warranty Certificate" to the after-sales service station.
2. During the "Three Guarantees" period, if the motor of the electric bicycle has a related failure that affects its performance, and it still
cannot be used normally after two repeated repairs within one month, consumers can apply to the seller for replacement of the same model
of electric bicycle with the repair record and certificate of the i-Walk service station. If there are no products of the same model and
consumers are unwilling to exchange products of other models, consumers can get a refund for return. When returning the product, the
depreciation fee will be charged according to the relevant regulations in the "Three Guarantees" of electric bicycle products and parts.
Depreciation charges are calculated from the date of invoice to the date of return.
3. The validity period of the "Three Guarantees" after replacement of electric bicycle and charger at the same time will be recalculated from
the date of replacement. Consumers should obtain a new vehicle purchase receipt from the dealer. The "Three Guarantees" period after the
replacement of the new battery (after the maintenance of the battery) shall be calculated according to the purchase date of the first
payment, and the "Three Guarantees" period shall be accumulated.
4. The electric bicycle has irreparable faults such as cracking of the motor shell and damage to the winding caused by quality problems, or
non-human factors such as welding, de-soldering and fracture of the frame and handlebar of the whole vehicle. Consumers can choose to
repair, replace or return the electric bicycle within 7 days from the date of sale of the product. When returning the bicycle, the payment will
be refunded according to the price of the vehicle purchase document; Within 8 to 15 days from the date of sale of the product, consumers
can choose to repair or replace the bicycle. If the consumer chooses replace, the seller should replace the electric bicycle of the same model.
5. The faulty parts will be replaced free of charge during the "Three Guarantees" period.
6. If the last day of the "Three Guarantees" period is a statutory holiday, the "Three Guarantees" period will be extended to one working day
after the statutory holiday.
7. After the product is sold, for the appearance damage of the electric bicycle that meets the conditions for Changing or Refunding([Note]
including but not limited to not belonging to the scope of ''Three Guarantees''), consumers should bear the corresponding accessories costs.
8. The after-sale service station will still provide repair and maintenance services for the failure of electric bicycles and its major parts
beyond the scope of the "Three Guarantees" or beyond the "Three Guarantees" period , but will charge the repair service fee and the cost of
the parts.
9. The daily depreciation rate of the complete vehicle and parts under "Three Guarantees" service are as follows: 0.2% for the complete
vehicle; 0.3% for battery parts; 0.2% for other parts;
Those who meet the conditions of Changing or Refunding shall be charged depreciation fee according to the following standards:
depreciation fee = invoice price x number of days of purchase x depreciation rate.
If your beloved electric bicycle has a non-human damage performance failure, please contact the seller to solve it at the first time (if the
seller does not solve it or the service attitude is bad, you can complain directly through the official channel).
*The e-bikes sold overseas are excluded from this warranty term, as the standards vary in different countries.
After-sales service phone number: 400-883-9299
Twist the fastener
Adjust seat height
Secure with the
L-shaped M6 internal
hexagonal wrench that
comes with the e-bike.
Push the seat tube of the
bicycle head until it is
vertically closed (in the
direction of the arrow on
the right side of the figure)
Close the lock (in the
direction of the arrow on
the right side of the figure),
and you can hear a "click"
sound (the lock is slightly
tight, and you need to
press it hard).
Install the pedals
Take out the right pedal (R),
align it with the crank, and
use an open-end wrench to
rotate the pedal clockwise
to install and tighten(in the
direction of the arrow in the
figure).
Take out the left pedal (L),
align it with the crank of
the crankset, and use an
open-end wrench to rotate
the pedal counterclockwise
to install and tighten.
Open the seat tube lock
(in the direction of
arrow ① as shown in the
figure), adjust the height
of the seat cushion (in
the direction of arrow ②
in the figure), and lock
the lock of the seat
tube.
Push up the seat tube
of the bicycle head
Install the pedals

Parts
RS1 Meter Instructions for Use
Eco-friendly low-speed gear
Headlight
Temperature
Speed/gear display
Economical and comfortable gear
Power display
Sports gear
APP Bluetooth connection
Settings
1.In the off state, press and hold the power button for 3 seconds to turn on (there is a power-on prompt tone) / in the power-on state,
press and hold the power button for 3 seconds to turn off(buzzer beeping prompt).
2.Keep the electric bicycle turned on, press the power button switch (short press) to turn on the headlights and taillights of the bicycle
(the panel icon turns on and off with the lights, and the taillights are highlighted when braking).
3.Keep the electric bicycle turned on. Double-click the power button (short press 2 times in a row) to switch gears (low
speed/comfort/sport) back and forth, and you can also switch gears through the mobile APP interface.
4.Through the APP mobile phone connection, the body atmosphere light can be turned on and off, and the flashing mode and light color
of the body atmosphere light can also be customized.
5.Switch the speed unit through the APP mobile phone connection or by pressing the power button 3 times in a row on the
instrument(default Km/h).
6.Battery displays real-time battery/vehicle speed displays real-time vehicle speed.
7.The mobile phone is connected to the vehicle through the APP, and the Bluetooth icon is turned on (the APP can set the vehicle, which
can realize electronic locking, atmosphere light control, gear switching and other rich functions).
8.Non-zero start, the motor with speed greater than 5Km/h provides assistance (or start) (Press the power switch 5 times continuously to
switch to zero start, the default is non-zero start when booting).
9.After the automatic cruise function is turned on through the APP mobile phone connection, the speed is maintained at a certain speed
for 8S to enter the constant speed cruise, and exit cruise by toggling the thumb shifter or applying the brakes.
In addition: In line with 3C standards, the alarm will sound when the speed reaches 15Km/h, and the maximum speed provided is
25Km/h. If the taxiing speed exceeds this speed, the buzzer will give an alarm.
Warranty Policy
Serial
number
Battery 10.4AH
Excluding 10.4AH
Motor
Controller/Charger/Instrument
Frame
Pedal/Disc Brake/Brake/Foot Support
Brake line / mudguard / inner and outer tires / spokes / saddle / plastic wearing parts are not guaranteed
6 months warranty for other unspecified parts
Warranty period (months)
Scope of warranty
Less than 60% battery capacity detected within 12 months
Less than 60% battery capacity detected within 18 months
Performance failure (man-made unauthorized disassembly, water ingress will not be guaranteed)
Performance failure (man-made unauthorized disconnection and disassembly will not be guaranteed)
Performance failure
Performance failure
Disclaimer of the Three Guarantees Policy
1. The validity period of the three guarantees has expired,
2. Damage caused by force majeure;
3. If there is no "vehicle purchase document" and "warranty card" or the purchase document and warranty card do not match the actual vehicle,
4. The frame number and motor number do not match the certificate;
5. The serial number of the frame has been damaged in the case of unauthorized repair, misuse, collision, negligence, abuse, accident, modification, improper use of this product
without the authorization of the company;
6. Failure to present valid document(valid invoices) or purchase document does not match the actual vehicle data;
7. Failure to perform proper maintenance in accordance with the instruction manual;
8. The sound or vibration produced by the rotatable parts of the pedals, front and rear hubs, steering system, shock absorbers, flywheels, etc. will not affect the general function;
9. Due to external environmental factors such as sweat, collision, friction, etc., the paint surface of the frame and parts is corroded or peeled off, or due to poor storage or long-term
use, the paint peels off, and the metal surface or plastic parts naturally fade;
10. When the electric bicycle is used beyond the specified scope of use (such as performing stunts, going down stairs, jumping, etc.), causing damage to its parts or failure of its
functions;
11. Deformation or cracking of the frame due to over-use is not covered by the warranty;
12. The built-in non-rechargeable battery (dry battery, button battery) of the sensor is not covered by the warranty; the user needs to replace the battery at his/her own expense;
13. Consumables and wearing parts, such as chains, bells, handlebar grips, wire buckles, and tool accessories provided are not covered by the warranty;
14. Changes in battery capacity due to temperature changes in the use environment, battery power loss, bulging and damage caused by external factors, battery water ingress,
charging with a charger not specified by IWALK, and modification and disassembly without the company's authorization, resulting in damage to the battery structure, are not
covered by the warranty;
15. Chargers, controllers, etc. with trademarks and strip seals that have been torn up without permission will not be entitled to "Three Guarantees" service, and if the set of lock keys
is broken and keys are lost, "Three Guarantees" service will not be granted;
16. Failures caused by force majeure ([Note] such as floods, fires, earthquakes, lightning strikes, typhoons, inundation, chemical corrosion, etc.);
17. Consumables, such as insurance sheets, light bulbs, etc., exceed the specified warranty period;
18. Maliciously alter the "Three Guarantees" verification date of parts;
19. Advertising promotions, gift items, noise levels, soft and hard feelings and other human perception categories.
6
6
12
12
12
1
1
2
3
4
5
6
7
8

RS1 Electrical schematic diagram
Controller Left brake lever
Shifter
Instrument electronic lock
Booster sensor
Right brake lever
Battery pack
Charger
Note: PU2 and PU1 are all fuses
RS1 Battery installation location diagram Install the rear fender Stabilize frame, fold the seat
tube of the e-bike head
Battery pack
The battery pack (as shown above) is fastened
to the frame with four screws.
Take out two M5 screws
and round washers and
fix them with the
L-shaped 4mm internal
hexagonal wrench
provided with the
vehicle.
Straighten the handle
and fasten the e-bike
head lock.
Fold down the head tube of the
electric bicycle (as shown in the
left direction of the figure) to
complete the folding of the
whole vehicle.
Open the e-bike head
lock (as shown by the
arrow on the right side
of the figure).

Install the pedals
Take out the right pedal (R),
align it with the crank, and
use an open-end wrench to
rotate the pedal clockwise
to install and tighten(in the
direction of the arrow in the
figure).
Take out the left pedal (L),
align it with the crank of
the crankset, and use an
open-end wrench to rotate
the pedal counterclockwise
to install and tighten.
RS1 Starts RS1 Product parameters (TDSRS1Z)
Other function description
Power button
1． Press the black starter
button under the handlebars
to turn on the power.
2. Open the foot support and ride on the RS1. When
the riding speed reaches 5 yards, the electric assist
effect will start, and press the speed control thumb
shifter to respond in pure electric mode.。
Speed control thumb shifter
RS1 Body atmosphere light on and off
The body atmosphere light will automatically remember the lighting state of the last ride
If you want to turn off the body atmosphere light, you can do the following:
1. Keep the electric bicycle turned on.
2. Turn on the bluetooth on the mobile phone to connect the vehicle through the APP;
3. You can view the body atmosphere light switch options through the APP interface, and
turn it on and off.
In addition: the flashing mode of the body atmosphere light can be controlled through
the APP interface, and supports rich modes such as monochrome, monochrome
breathing, music rhythm, etc.
Product Size
Total bicycle
weight
Load capacity
Frame material
Tire
Saddle
Top speed
Power consumption
per 100 kilometers
Charging time
Charging voltage
Endurance mileage
Front and rear
wheel center distance
L1260mmx H1056mmx W540mm Brake system
Motor type Permanent magnet motor
36V/250W
420rpm 士 10
KCF06G2Uv201707-36/250//6F3D-
SA02AWK
30 土 1V
13±1A
Single speed
Intelligent kinetic energy recovery system
Intelligent battery management system
Lithium battery
Electric mode/assist mode/riding mode
Speed display/battery display/
Bluetooth APP/fault prompt
Rated voltage/
nominal power
Rated speed
Motor Controller
Undervoltage
protection value (V)
Overcurrent
protection value (A)
Speed control system
Kinetic energy recovery
Battery management
system
Battery type
Three modes
LCD instrument
Mechanical brake + electronic brake
Nominal voltage/
battery capacity
Aluminum-magnesium alloy
20kg
75kg
36V/10.4Ah
25km/h
4-5h
220V
910mm
40KM (pure electric) / 60KM (assist)
0.80kw.h/100km
New ergonomically comfortable model
14x2_125 (thick anti-skid tires
for electric vehicles)
