Iwata Tech Master S User manual

User’s Manual
Model:MA-03

Ｍaster Ｓ
Bag x1
Charging Cable x1
Quick Start Guide x1
Silicone Ring x2
1/4" Screw x2 Hook & Loop x1
Thank you for purchasing iwata Master S photography light!
Please read this Quick Start Guide carefully before using the product and keep it for reference.
Package Contents
Iron sheetsx3
Quick Start Guide
Model: MA-03
-1-

1. CCT Range：2000K~10000K(±200K)
2. CCT Color Rendering Index: CRI≥96,TLCI≥98
3. Maximum Power：6W
4. LED Beam Angle：120°
5. Illuminance (lx/fc)：1ft: 1586/147; 2ft: 418/39; 3ft: 193/18
6. Operating Mode：CCT/ HSI/ EFFECT
7. Internal Lithium Battery Capacity：7.4V/2200mAh
8. Battery Life：about 2 hours at 100% power, about 50 hours at 1% power
9. Input Voltage and Current： 5V/1A ,5V/2.1A
9V/2A,12V/1.5A(quick charge/work with a power source)
10. Dimensions：260mmxΦ38mm
11. Weight：370g
12. Allowable Temperature Range: In use between -5~35℃
During charging between 0~35℃
Storage between -20~60℃
-2-
Specifications

Layout of MA-03
Adjustment Buttons USB Charging Port
Function Button
Power Switch
Display Screen
Mode Button
-3-

Slide the power switch to "green"/"red" to turn on/off the power.
Description of power switch
Description of Buttons
Adjustment Button: press and hold to change continuously, tap to change
step by step.
Mode Button: press and hold to cycle through CCT, HSI and EFFECT modes; tap
to change current adjustment parameters.
Function Button : press and hold to enter setting; tap to turn on/off the light.
-4-

Screen Icons
CCT Mode
INT range: 1%-100%;
CCT range: 2000K-10000K;
G/M range: Under different color temperatures,
the adjustment range of G/M is different.
2h
CCT(K)
100 5500
INT(%) G/M
+00
CCT
Tap button to select or adjust between INT(%),
CCT (K) and G/M, tap or press and hold buttons
to adjust the parameters.
-5-

EFFECTHSI Mode
100 360 100
INT(%) HUE(°) SAT(%)
100 1
INT(%) EFFECT PRESET
1.5h 2h
HSI
Fire
Tap button to select the INT(%), HUE(°)
or SAT(%), tap or press and hold
buttons to adjust the parameters.
INT range:1%-100%;
HUE range:0-360°;
SAT range:0-100%.
Tap button to select the INT(%), EFFECT
or PRESET, tap or press and hold
buttons to adjust the parameters.
INT range:1%-100%;
PRESET range:1-3.
-6-

Fire 1:Candle 2:Fireplace 3:Bonfire
Lightning 1:Intermittent Lightning 2:Frequent Lightning 3:Continuous Lightning
Firework 1:Short Fireworks 2:Continuous Fireworks 3:Fireworks Show
Warning Light 1:Police Car 2:Fire Truck 3:Ambulance
Color Chase 1:Slow 2:Medium 3:Fast
Party 1:Birthday Party 2:Home Party 3:Club
Photoflash 1:Product Launch 2:Press Conference 3:Paparazzi
-7-
Scene Effect Description

Status Icon Description
2h
1.Remaining Battery Time
3.Remaining Battery Capacity
X
2.Insufficient Power Supply
5500 +00
56m
100 4300 +00
CCT(K)
INT(%) G/MCCT(K)
INT(%) G/M
100
CCT
CCT
1.Remaining Battery Time: "m" for minute and "h" for hour.
2. X icon comes out, When Master S works with insufficient power supply, for example,
connected to a 5V / 1A charger or a charging cable of low quality. It is recommended to
use a quick charger and the original charging cable.
3. Remaining Battery Capacity is shown in the display screen.
A
A
6.External Power Connected
7.Remaining Charging Time
5.Art-in system
4.Grouping
-8-

4.The remote control/APP sets the grouping mode, displays ,and the grouping range: A-Z.
for devices with the same remote control or APP configuration, the photography light
status under the same group is synchronized.
5.After the remote control or APP configures the network, Art-in icon is displayed.
6. This icon is displayed when an external power supply is connected. The icon will appear
when using a fast charger.
7. Remaining Charging Time: It shows the estimated remaining time for full charge, "m" for
minute and "h" for hour. When it is full, the "OK" icon will be displayed.
Temperature Icon Description
2h
5500 +00
CCT(K)
INT(%) G/M
100
CCT
A
-9-
A

The low temperature warning icon appears when ambient temperature is below the
lowest allowable temperature. Master S may not work properly under this circumstance.
Language
Factory Reset
Screen Lock
Standby Time
Art-in
Setting Interface Description
10m/30m/60m/120m
Art-in System
Screen Orientation Lock
Language: English/Chinese
The high temperature warning icon appears when ambient temperature is above the
highest allowable temperature. If the temperature keeps rise,Master S will be automatically
switched off. After turning off the light, You need to press any key to clear the warning icon.
-10-
10m
On
EN
Off

Tap or press and hold button to enter or exit setting menu.
Tap buttons to select the current menu item.
Tap button to enter the setting, exit the menu to save.
Screen Lock On-current screen orientation is fixed.
Standby Time When the light is off and not operated, system will be
automatically standby.
Art-in On/Off/Reset. (Reset :Clear network configuration and
information)
Language Select "English" or "Chinese"
Factory Reset Select "Yes" and tap button to reset default settings.
-11-

Battery Use and Maintenance
1. When the battery of Master S is fully charged, please detach Master S from the USB cable.
2. Please do not charge the battery, when the ambient temperature is beyond the allowable
range, otherwise Master S can be damaged or battery life can be shortened.
3. The battery may gradually run down and not be switched on properly, if the product is
long-term unused. Please recharge the battery in this circumstance and recharge the
battery at least once three months.
4. If the battery capacity indicator has an error in displaying the actual capacity, please fully
discharge and recharge the battery to correct it.
5. The echargeable battery has a limited lifespan and should only be replaced by the
manufacture. When the performance of battery is obviously decreased after years, please
contact the local distributor.
-12-

Disposal Information
The left symbol indicates that your product and/or its battery must be treated
separately from household waste, in accordance with local laws and regulations.
When the service life of this product is at an end, please send it to the collection
point designated by the local management. When handling your products and/or
their batteries, separate collection and recycling will help conserve natural
resources and ensure recycling in a way that protects human health and the
environment.
（Waste electrical appliances and equipment）
3. Do not hit or hammer this product with hard objects.
4. Master S’s temperature may increase, when it works. Please make room for heat dissipation.
5. Do not expose this product to the environments with drastic changes in temperature and
humidity.
1. Do not disassemble or modify this product.
2. Not immerse this product in water or put it into the fire.
-13-
