iWave iW-RainboW-G33D-i.MX8M SMARC SOM User manual

i.MX8M SMARC SOM
Development Platform
iW-RainboW-G33D
Quick Start Guide

Disclaimer
iWave Systems reserves the right to change details in this
publication including but not limited to any product specification
without notice.
No warranty of accuracy is given concerning the contents of the
information contained in this publication. To the extent
permitted by law no liability (including liability to any person by
reason of negligence) will be accepted by iWave Systems, its
subsidiaries or employees for any direct or indirect loss or
damage caused by omissions from or inaccuracies in this
document.
Trademarks
Certification
iWave Systems Technologies Pvt. Ltd. is an ISO 9001:2015
Certified Company.
All registered trademarks, product names mentioned in this
publication are the property of their respective owners and used
for identification purposes only.

Introduction
Quick Start Guide (QSG)
This Quick Start Guide (QSG) is designed for users to quickly
understand the iW-RainboW-G33D-i.MX8M SMARC SOM
Development Board and start the evaluation. It provides the
instructions for setting-up the Development Board from the
packed box.
Development Platform Description
gi.MX8M Processor Configuration
= i.MX8M Quad : 4 x Cortex-A53, 1x Cortex-M4, GPU&VPU Decode
= i.MX8M QuadLite : 4 x Cortex-A53, 1 x Cortex-M4 & GPU
= i.MX8M Dual : 2 x Cortex-A53, 1x Cortex-M4, GPU&VPU Decode
The iW-RainboW-G33D i.MX8M SMARC SOM Development
platform incorporates with NXP's i.MX8M Application
Processor based SMARC SOM and SMARC V2.0 carrier board
with all necessary interface connectors for developing an
embedded application based on NXP's i.MX8M Application
Processor.
g2GB LPDDR4 memory (Expandable)
Some Key Features of the Board Include:
gDual Gigabit Ethernet
gIEEE 802.11a/b/g/n/ac Wi-Fi & BT 5.0
g5.5" HD AMOLED Display with CAP touch
gSMARC V2.0 Standard
g8GB eMMC Flash (Expandable)
Quick Start Guide
03
01

Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28DiW-RainboW-G33D
03
02
This Development Platform is ESD sensitive. Handle this
product only in accordance with the installation instructions
given in the manual. Therefore ESD precautions should be
taken care during transport and handling. User must use a ESD
ground strap or other grounded source before unpacking or
handling the hardware. This Development Platform is not
water proof. Water damage is not covered under the warranty.
ESD Protection
Do not assemble or use this Development Platform before
reading the installation procedure.
Safety
iW-RainboW-G33D-i.MX8M SMARC Development Board is
designed by using RoHS and REACH compliant components
and manufactured on lead free production process.
Environmental Compliance
Check the local regulations for disposal of electronic products
before disposing.
Product Disposal

Remove the Development board from box and place above the
ESD free area. Use anti-static pad/mat with proper grounding
to place the Development Platform. Also make sure that,below
Deliverables are received without any physical damage.
USB OTG Cable
DVD
Development Board
Step 1 - Unpacking
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
03
Quick Start Guide
12V,2A Power Supply
QSG
03
03

Step 2 -Quick View-SOM
TOP View
BOTTOM View
1
2
3 4 5
1
7
03
04
1. SMARC Edge
2. Fan Header
3. Wi-Fi & BT Module
4. eMMC
5. i.MX8M CPU
6. LPDDR4
7.Expansion Conn.
6
iW-RainboW-G28D
iW-RainboW-G33D

Step 3-Quick View-Carrier Board
8
7
6
5
4
3
2
1
20
21
22
23
24
25
26
27 28 29 30 31 32 33 34
Top View
9
10
11
12
13
14
1516
171819
35
36
37
38
39
Bottom View
1.Power IN Jack
2.USB Debug Conn.
3.USB OTG Conn.
4.USB Type C Conn.
5.USB 3.0 Conn.
6.SMARC MXM Conn.
7.USB 2.0 Conn.
8.Ethernet Jack
9.Cap. Touch Conn.
10.MIPI DSIO Conn.
11.UART Header
12.Backlight Conn.
13.CAN0 Conn.*
14.CAN1 Conn.*
15.A&V Expansion Conn.
16.PCIe Selection Switch
17.Reset IN Button
18.Power Button
19.PCIe x4 Conn.
20.Mini PCIe Slot
21.SIM Slot
22.Recovery Button
23.Dipslay Port
24.Audio IN Conn.
25.Audio OUT Conn.
26.HDMI Connector
27.2-Lane MIPI CSI Conn.
28.4-Lane MIPI CSI Conn.
29.Expansion Conn. 1
30.SOM Expansion Conn.
31.Expansion Conn. 2
32.Boot Mode Switch
33.Configuration Switch
34.ON/OFF Switch
35.Standard SD Slot
36.M.2 Module Conn.
37.LVDS Conn.*
38.RTC Battery Holder
39.SATA Conn.*
03
05
Quick Start Guide
* Not supported.

iW-RainboW-G28D
Step 4 - Read DVD Contents
Given DVD contains below deliverable folders.
1. Binaries
2. Documents
3. Programming Tool
4. Source Code
Content inside the each deliverable folder will be changed
based on the operating system on particular delivery. Source
code can be customized according to user wish and
corresponding binaries can be generated. Once the binaries
generated, user can download the binaries into the
development platform using programming tool. Also
“Documents” folder contains of User Guides (both hardware
and software), Release Note and Quick Start Guide.
iW-RainboW-G33D
03
06

Step 5- Setting-Up
On Board Switch Setting
Make sure On-Board Switch (SW5) set properly as shown in
below image.
SW5- Boot Selection Switch
SW5
(1000)
Note :
0 - OFF
1 - ON
08
Note : Refer the Hardware User Guide for detailed information of
each switch.
Quick Start Guide
03
07

Quick Start Guide
Install the driver for Debug Port in Host PC/Laptop using the
below link.
http://www.ftdichip.com/Products/ICs/FT232R.html
Connect Type-A end of USB cable to PC and Micro-B end of USB
cable to Development Platform's Debug USB Micro-AB
Connector (J22) as shown below.
iW-RainboW-G28D
Debug Port Setting
Setup the Debug Terminal parameters.
Baud Rate : 115200
Data bits : 8
Parity : None
Stop Bits : 1
Flow Control : None
09
iW-RainboW-G33D
03
08
