User Guide
Heat • Vent • Light
Eco Tastic®
Model: 11341 Eco Triumph
Model: 12343 Eco Sensation
Model: 12341 Eco Silhouette
Electrical Rating: 230~240 V. 50 Hz.
Model: 12341 Eco Silhouette
Model: 12343 Eco SensationModel: 11341 Eco Triumph
2
Welcome
Thank you for buying this IXL Eco Tastic. Even if you have used a Tastic before, there are very good
reasons to read this user guide before using this one:
• Youandyourfamily,propertyandhomewillbesafefromharm.
• Youwilllearnhowthisappliancemaydifferfromothers.
• ByusingtheTasticfullyandproperly,youwillgetmaximumlifeandvaluefromit.
• OurwarrantydependsonyouusingtheTasticaccordingtothisuserguide.
Itwillonlytakeyouafewminutes,sopleasereadon!
Contents
Eco Tastic Range ............................................................. Pg 3
Safety ............................................................................... Pg 4
How it Works ................................................................... Pg 5
Ventilation Requirements................................................ Pg 6
Clearances ....................................................................... Pg 7
Flat Roof Installations (with insufficient clearances) .... Pg 8
Electrical Requirements .................................................. Pg 8
Wiring Diagrams........................................................ Pg 9-10
Installation................................................................Pg 10-11
Replacement Lamps...................................................... Pg 12
Cleaning ......................................................................... Pg 12
Troubleshooting ........................................................Pg 13-14
Products......................................................................... Pg 15
Warranties.................................................................Pg 16-17
Record Your Model ........................................................ Pg 18
Notes .........................................................................Pg 18-19
Model: 11341 Eco Triumph
Eco Tastic Range
Tastic®
11341 Eco Triumph
2x275WHeat,Vent&Light
15WCFLCentreGlobe
Cutout Template Supplied
200mmFan,257m3/hror72l/s
12343 Eco Sensation
4x275WHeat,Vent&Light
15WCFLCentreGlobe
HalfHeatFunction
Cutout330mmx330mm
200mmFan,348m3/hror97l/s
12341 Eco Silhouette
4x375WHeat,Vent&Light
15WCFLCentreGlobe
HalfHeatFunction
Cutout330mmx330mm
200mmFan,396m3/hr or 110l/s
Model: 12343 Eco Sensation
Model: 12341 Eco Silhouette
4
Safety
Tastic®
NOTE: This product must be installed by a qualified installer.
Read through these instructions completely before commencing installation.
The infra-red lamps heat by direct radiation rather than by heating the air in the room, so the Tastic
shouldbelocateddirectlyoverwheredryingoffoccurs.
LocatetheTasticinaccordancewiththerequirementsofthecurrentAustralian/NewZealandWiring
RulesAS/NZS3000relatingtodampsituations.
In some installations this may mean that no part of the Tastic may be located directly above any part of
abathorshowerrecessorenclosure.
ForunenclosedshowersrefertoWiringRulesconditions.
Switchesandothercontrolsmustnotbelocatedwheretheycanbetouchedbyapersoninthebath
orshower.
NOTE: Tastic products must only be installed horizontally in ceiling.
•Donotlookdirectlyintoheatlampswheninuse.
•Tasticproductsarenottanninglamps.
•
MakesurethelampshavecooledandpowerisofftotheTasticbeforeremovinglampsforreplacement.
•Donotoperatethisappliancewithouttheplasticlampsurroundinposition.
•Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensory
ormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervision
or instruction concerning use of the appliance by a person responsible for their safety.
•Youngchildrenshouldbesupervisedtoensuretheydonotplaywiththeappliance.
•Thisappliancemustbemountedwiththelowestpointatleast2.1metresfromtheoor.
WARNING:Curtainsorcombustiblematerialmayigniteifincontactwiththeheater.
SAFETYFEATURES
Thermal switch:
WhenEcoTasticworksinFANOFFmodeandthetemperatureinsidetheunitreaches55°C,the
thermalswitchwillswitchonthefanautomatically.Whenthetemperaturedrops,thethermalswitch
willswitchoffthefan.
Thermal fuse:
Whenforanyreasonthetemperatureinsidetheunitreaches93°C,thethermalfusewillcutoffpower
to the Eco Tastic. In such a case the Service Centre should be called to replace the thermal fuse.
Do not allow insulation material to rest against the sides or top
of the Tastic unit when installed. This Tastic must not be installed
where there is a possibility of water splashing on to the lamps.
There is no IP rating on any IXL Tastic.
How it Works
Tastic®
TheIXLTasticrangehasbeendesignedtoexactingstandardstogiveyoumanyyearsoftrouble-free
operation.ToensureyougetthemostfromyourTasticthereareafewsimplepointstokeepinmind.
HEATLAMPS
TheIXLTasticHeatLampshavenowarmupperiodbecausetheinfraredlampsprovideinstantaneous
heat,andaredesignedtoheatyouandnotyourbathroom-that’stheefcientwayinfraredheat
works.You’llsavemoneyandenergy,withanaveragecostofaroundonecentashowerifused
correctly,(basedonaverage5minutedryingtime).Also,togetthefullbenetofTastic’sinfrared
warmth,standdirectlyundertheheatlamps.IXL’sexclusiveclearheatlampshavebeendesigned
specicallyforthisapplication,andconcentratetheirheatformaximumeffectiveness.
Make sure you have the Tastic model that suits your bathroom ceiling height. This Tastic is
manufacturedtoofferpeakperformancewithbathroomceilingheightsupto2.4mfortheTriumph
11341,2.7mfortheSensation12343and3.3mfortheSilhouette12341.
TheTastichalfheatfunctionisavailableonthe4lampmodels,andisanotherenergysaver,allowing
you to adjust the heat level to suit prevailing conditions or personal preference.
VENTILATION
Toensureoptimumperformanceoftheexhaustfan,itisessentialthatthereisadequateairowinto
yourbathroomtohelptheTastic’spowerfulandefcientexhaustfantoquicklyremovesteamwhile
youshower.YourTasticworksbydrawingsteam-ladenairfromtheroom,andaswithallexhaustfans
itisessentialthatsufcientairinletisprovided.Ensureadequateinletsexistthroughwindows,vents
orunderthedoor.Airowpathfrominlettofanshouldideallypassoverthesteamsource.
CENTRELIGHT
The centre light in all Tastic models is designed to provide general illumination in your bathroom.
Forspecictaskslikeshavingorputtingmake-upon,youmayneedextralightingtosuityour
individual needs.
Heat lamps can also be used to provide additional bright illumination for your bathroom. Lighter
colouredwallsanddecoralsohelpbrightenyourbathroombyreectingmorelight.
