J.Burrows JB5TMTLSWE User manual

Q u a lit y As s u ra n c e Gu id e
1 / 10
ASSEMBLY INSTRUCTIONS
COBALT 5 SHELF METAL SHELVING UNIT
JB5TMTLSWE
For spare parts or hardware call 1300 OFFICE （1300 633 423）
This design and instruction booklet is subject to copyright.
www.officeworks.com.au 1 Carton

Furni
ture Assembly In s t ru c t io n s St y le Gu id e
2 / 10
Estimated Assembly Time: 60 minutes
Customer Service Contact Details
People Required
General Advice
Spare Parts & Hardware
1300 OFFICE （1300 633 423）

Furniture Assembly In s t ru c t io n s St y le Gu id e
3 / 10
NOTE
• Please check you have all hardware before assembling.
• If you are missing any hardware, please contact 1300 OFFICE（1300 633 423）.
• Please ensure you have the name of the item, required hardware part and quantity.
• Please retain your receipt as proof of purchase to validate your warranty.
CAUTION
• Do not use this product unless all couplers and post caps are firmly secured.
• Check that all couplers and post caps are securely in place at least every 4 months.
WARNING
• If parts are missing, broken, damaged or worn stop using the product until all repairs are made
using manufacturer authorised parts.
• Failure to follow these warnings could result in serious injury.
DANGER
• In an environment where infants and children are present, this product should be anchored to a wall or
other suitable surface to avoid serious injury.
Officeworks Ltd. | 236-262 East Boundary Road | Bentleigh East VIC 3165 | AUSTRALIA
Tools Required
CAUTION: Do not use tools other than those required, as this
can damage your new item.
To secure the unit to a wall you need following tools:
Tools Required

Furniture Assembly In s t ru c t io n s St y le Gu id e
4 / 10
Included Hardware: Anchor Kit – Part HWANTITIPK
A
ST3.5*38 Screw x4
B
Expansion rubber
head plugs x4
C
N
ylon cable ties x2
D
N
ylon part x2
Parts List / Hardware List
1
2 3
4 5 6
Post x8 Short beam x10 Long beam x10
Shelf x5
Coupler
x8
Post cap
x16
Part Number:
HWCOUPTMWE
Part Number:
HWENDCAPTM
Part Number:
HWTMTLSSHB

Furniture Assembly In s t ru c t io n s St y le Gu id e
5 / 10
Assembly
Step 2
Step 1
Step 3 Step 4
x1
6
1
6 x1
2
3
x1
4

Furniture Assembly In s t ru c t io n s St y le Gu id e
6 / 10
Step 6
Step 5
3
2
4
x1
Step 7 Step 8
x1
5
1
3
2
5 x8
x1

Furniture Assembly In s t ru c t io n s St y le Gu id e
7 / 10
Step 9
4
Step 10
x1
3
2
Step 11
4
Step 12
x1
3
2

Furniture Assembly In s t ru c t io n s St y le Gu id e
8 / 10
Step 14
Step 13
4
6
Step 15 WALL
.
B C
A
D
6 x4
4pcs
A
2pcs
D
2pcs
C
4pcs
B
To prevent this item from tipping over it must be permanently fixed to wall.
WARNING: Serious or fatal crushing injuries can occur from furniture tip-over.
a
An anchor kit suitable for plaster walls is included with this item. Different wall materials may
require a different anchor kit. If necessary, seek independent advice on suitable anchor kits or
wall safety straps.

Furniture Assembly In s t ru c t io n s St y le Gu id e
9 / 10
CAUTION
• The shelving unit is designed to carry up to 90kg per shelf.
• The product is intended to hold the maximum weight indicated. Exceeding the maximum weight
will result in instability and may cause injury.
• Place equipment onto shelves evenly and ensure items do not overhang at sides, as that can
affect the stability of the unit.
Also can be assembled as workbench

10 / 10
Thank you for your purchase. Please retain your receipt to validate warranty.
If you would like to know more about our furniture products, please visit www.officeworks.com.au
•
