Jäger Z33-D060.02 K0,9a User manual

Manual
Z33-D060.02 K0,9a
High Frequency Spindle
Pneumatic direct change

Item no. 10300023, Revision 082 ( 36 )
Identification of HF spindle
Spindle type
Pmax S6-60%
Item no. .... Serial no.
Rated rotation speed
Serial no.
Item no.
Power data
Spindle type
S1-100%
As we always ensure that our HF spindles are at the cutting edge of techno-
logical development, we reserve the right to make technical modifications
and variations from the exact design described in the manual.
The text in this manual has been compiled with the utmost care. However,
Nakanishi Jaeger GmbH cannot assume any legal responsibility or liability of
any kind for incorrect information and any consequences thereof.
Translations and reproductions – including of extracts – are prohibited with-
out the express written approval o Nakanishi Jaeger GmbH.

Item no. 10300023, Revision 08 3 ( 36 )
Contents:
Translation of the original manual
1 Preliminary information 4
1.1 Purpose of the manual ...................................................... 4
1.2 Explanation of symbols used .......................................... 4
2 Transport and packaging 5
2.1 Scope of supply of HF spindle ........................................ 5
2.1.1 Optional accessories............................................. 5
2.1.2 Documentation supplied.................................... 5
2.2 Packaging of HF spindle.................................................... 6
3 Designated use 6
3.1 Permissible types of machining ..................................... 6
3.2 Permissible materials ......................................................... 6
4 Safety instructions 7
4.1 Safe working.......................................................................... 8
4.2 Shutdown of HF spindle ................................................... 9
4.3 Installation and maintenance ......................................... 9
4.4 Modification and repair..................................................... 9
4.5 Improper operation ............................................................ 9
5 Technical description 10
5.1 Connections of HF spindle.............................................10
5.2 Electrical connection........................................................10
5.3 Cooling..................................................................................11
5.3.1 Cooling via spindle holder................................11
5.4 Sealing air.............................................................................11
5.5 Pneumatic tool change ...................................................11
6 Technical Specifications 12
6.1 Dimensions..........................................................................13
6.2 Technical data sheet (KL 1001, AC motor)................14
6.2.1 Performance Diagram........................................15
6.3 Wiring diagram...................................................................16
6.4 Air-borne noise emissions..............................................17
7 Operating location 18
8 Installation 19
8.1 Installing the HF spindle .................................................19
8.2 Diameter of media supply line .....................................19
8.3 Compressed air...................................................................20
8.3.1 Air purity classes (ISO 8573-1) .........................20
8.3.2 Setting the sealing air ........................................20
8.3.3 Setting values........................................................21
9 Commissioning 22
9.1 Running-in schedule ........................................................ 22
9.2 Daily start-up....................................................................... 23
9.3 Shutdown signal................................................................23
9.4 Commissioning after storage........................................ 23
10 Tool change 24
10.1 Clockwise.............................................................................. 24
10.2 Pneumatic direct change................................................24
10.2.1 Changing the collet.............................................25
10.3 Tool changing station (optional accessory).............26
10.3.1 pneumatic direct change..................................26
10.3.2 Installing the changing station....................... 26
10.3.3 Maintenance..........................................................26
11 Tools for high speed cutting 27
11.1 Broken-off tool....................................................................27
12 Maintenance 28
12.1 Ball bearings........................................................................28
12.2 Daily cleaning .....................................................................28
12.2.1 Before commencing work ................................28
12.2.2 With every tool change .....................................28
12.2.3 Every time the clamping device is changed
....................................................................................29
12.3 In the case of storage....................................................... 29
12.4 Monthly maintenance .....................................................29
12.5 Long periods of storage..................................................29
12.6 Maximum storage time................................................... 29
13 Dismantling 30
13.1 Disposal and environmental protection................... 30
14 Service and repairs 31
14.1 Service partners .................................................................31
14.2 Malfunctions........................................................................32
15 Declaration of Incorporation 35

Preliminary information
Item no. 10300023, Revision 084 ( 36 )
1 Preliminary information
The high frequency spindle (HF spindle) is a high quality precision tool for
high speed machining.
1.1 Purpose of the manual
The manual is an important component of the HF spindle.
ÜStore the manual carefully.
ÜMake the manual available to all persons who work with the HF spindle.
ÜRead the documentation supplied in full.
ÜBefore carrying out any work, read the corresponding section of the man-
ual carefully again.
1.2 Explanation of symbols used
To enable quick classification of information, this manual uses visual aids in
the form of symbols and text markings.
Notes are marked with a signal word and a colored box:
DANGER
Dangerous situation!
Results in serious injury or death.
uMeasure to avert the danger.
WARNING
Dangerous situation!
May result in serious injury or death.
uMeasure to avert the danger.
CAUTION
Dangerous situation!
May result in minor to moderate injury.
uMeasure to avert the danger.
Note
May result in material damage. This warning symbol is not a warning for per-
sonal injury.
Tip
Tips indicate useful information for users.

Transport and packaging
Item no. 10300023, Revision 08 5 ( 36 )
2 Transport and packaging
Exampleofdesign: Inserting the
shank
Note: Ensure functionality
uWhen transporting the HF spindle, always fit an appropriate shank in the
collet.
Avoid strong vibrations or impacts during transportation, as these could dam-
age the ball bearings of the HF spindle.
ÜAny damage reduces the accuracy of the HF spindle.
ÜAny damage restricts the functionality of the HF spindle.
ÜAny damage shortens the service life of the HF spindle.
2.1 Scope of supply of HF spindle
The following parts are supplied with the HF spindle:
qHigh Frequency Spindle
qCollet
qTransport packaging
ÜCheck the high frequency spindle for completeness upon delivery.
2.1.1 Optional accessories
Available on request:
qSpindle holder
qFrequency converter
qService set
qFurther accessories on request.
Only approved accessories have been tested for operational safety and func-
tionality.
ÜDo not use any other accessories – this may invalidate any warranty claims
and compensation claims for damages.
ÜIf the spindle holder is to be produced in-house, it is essential to contact
Nakanishi Jaeger GmbH before starting production to request the toler-
ances and production plan for the spindle holder.
2.1.2 Documentation supplied
The documents listed below are supplied with the HF spindle:
qManual
qThe declaration of incorporation is part of the manual.
qInspection protocol
ÜCheck that the documentation supplied is complete when the spindle is
delivered. If necessary, request a new copy.

Designated use
Item no. 10300023, Revision 086 ( 36 )
2.2 Packaging of HF spindle
All transport packaging materials can be recycled in appropriate disposal facil-
ities.
3 Designated use
The HF spindle is an “incomplete machine” in accordance with the Machinery
Directive and cannot perform any function independently. The HF spindle can
only be operated in conjunction with a machine tool and a frequency con-
verter.
3.1 Permissible types of machining
The HF spindle has been developed only for the following types of machining.
qCutting
qDrilling
qEngraving
qGrinding
ÜContact Nakanishi Jaeger GmbH if other types of machining are required.
3.2 Permissible materials
The HF spindle has been developed only for the following materials.
qMetals (such as alloys, cast metals etc.)
qSintered materials
qPlastics
qWood
qGraphite
qStone (marble, etc.)
qPaper and cardboard
qCircuit boards
qGlass and ceramic
ÜContact Nakanishi Jaeger GmbH if other materials are to be machined.

Safety instructions
Item no. 10300023, Revision 08 7 ( 36 )
4 Safety instructions
The high frequency spindle is a state of the art product and is safe to operate.
However, the HF spindle may pose a risk in the following cases:
qIf it is installed by untrained personnel.
qIf it is used incorrectly.
qIf it is not used in accordance with its intended use.
The high frequency spindle may only be installed, commissioned, and main-
tained by specialist personnel.
Definition: Specialist personnel are persons who are familiar with the assem-
bly, installation, commissioning, and operation of the product and have the
relevant qualifications for their area of activity. The operator must closely con-
trol the responsibility, training, and monitoring of these personnel.
DANGER: Due to explosion.
HF spindles are not approved for use in areas at risk of explosion. Use in such
areas may result in explosions.
uDo not use the HF spindle in potentially explosive atmospheres.
DANGER: Due to flying parts.
The HF spindle operates at high speeds and may therefore be flung away by
these.
uOperate the HF spindle only if it is installed in the machine or system in a
fixed manner.
Note: Adhere to the limit values.
uObserve the limit values specified in the technical data.
Note: Take account of the machine.
uObserve the manual of the machine in which the HF spindle is installed.
uObserve all safety instructions specified by the machine manufacturer.
uEnsure that the machine does not cause any hazards (e.g. uncontrolled
movements). Do not install the HF spindle in the machine until this has
been done.
Note. Do not damage the HF spindle.
uAny damage reduces the accuracy of the HF spindle.
uAny damage restricts the functionality of the HF spindle.
uAny damage shortens the service life of the HF spindle.

Safety instructions
Item no. 10300023, Revision 088 ( 36 )
4.1 Safe working
Observe all safety instructions set out in the manual, the applicable national
accident prevention regulations, and the valid company work, operation, and
safety guidelines.
DANGER: Due to flying parts.
Tools that are not clamped correctly will be flung away by the centrifugal
forces that occur during machining.
uUse the full clamping depth of the collet.
uClamp the tool securely.
DANGER: Due to flying parts.
If the wrong rotational direction is used, the clamping system releases and
the tool is flung away.
uIt is essential to adhere to the rotational direction of the HF spindle.
WARNING: Risk of injury due to flying parts.
The HF spindle operates at high speeds which may cause chips to fly out
with great force.
uNever remove the protective devices of the machine or system.
uAlways wear protective goggles during work.
Exampleofdesign: Inserting the
shank
Note: Ensure functionality.
uNever operate the HF spindle without a clamped tool shank.
If no tool shank is clamped:
qThe clamping system is damaged by the centrifugal forces.
qThe clamping system is shifted.
qThe balance of the HF spindle is affected.
qThe bearing is damaged.
ÜTake the relevant measures to protect against splashes and spray accord-
ing to the type of machining, the type of material being machined, and the
type of tool selected.
ÄObserve the manual of the machine in which the HF spindle is installed.
ÜObtain the maximum circumferential speeds of the tools used from the
tool supplier.
Single-point tools are not suitable for high speed cutting.
If they are required for production reasons:
ÜOnly use a balanced tool.
ÄDIN ISO 1940
ÄBalance grade 2,5

Safety instructions
Item no. 10300023, Revision 08 9 ( 36 )
The tool cutting diameter (X) must not be greater than the maximum
clamping range (Y).
ÜAlways clamp the tool so that it is as short as possible.
ÜKeep the dimension (Z) small.
Ä(Y) See section: Technical Specifications [}12].
4.2 Shutdown of HF spindle
The procedure for shutting down the high frequency spindle for installation
and maintenance work is as follows:
ÜCompletely disconnect the power supply.
ÜCompletely disconnect the media supply (air and liquid).
ÜMake sure that the shaft of the HF spindle has come to an absolute stand-
still.
If the HF spindle is being shut down to be cleaned:
ÜReconnect only the sealing air.
Tip: Forward the data to the controller.
uUse the option on the frequency converter of detecting the shutdown
signal from the shaft and forwarding this to the machine controller for
evaluation.
4.3 Installation and maintenance
ÜCarry out installation, cleaning, and maintenance work only after shutting
down the HF spindle and after the shaft has come to a standstill.
ÜInstall all safety and protective devices of the machine immediately after
completing work.
4.4 Modification and repair
Modifications or alterations to the HF spindle are only permitted after prior
consultation with Nakanishi Jaeger GmbH.
Only the service partners listed in the “Service and repair [} 31]” section are
authorized to open and repair the HF spindle.
Only approved accessories have been tested for operational safety and func-
tionality.
4.5 Improper operation
The high frequency spindle is only safe to operate for its designated use.
ÜObserve the safety instructions in all sections of the manual to prevent
hazards to persons, the environment, the machine, or the HF spindle itself.
Failure to observe the safety instructions may invalidate any warranty claims
and compensation claims for damages.

Technical description
Item no. 10300023, Revision 0810 ( 36 )
5 Technical description
5.1 Connections of HF spindle
7 1 3
1Electrical connection
3Sealing air G 1/8"
7Pneumatic system for tool change G 1/8"
5.2 Electrical connection
The HF spindle may only be operated with a frequency converter (FC).
ÜCheck whether the current, voltage, and frequency data of the HF spindle
match the raw data for the frequency converter.
ÜUse a motor supply line that is as short as possible.
ÜAdjust the speed of the HF spindle using the FC.
ÜRefer to the frequency converter manual for further information.
The FC detects the following operating states of the HF spindle, depending on
the version:
qHF spindle rotating.
qHF spindle too hot.
qHF spindle at a standstill, etc.
The FC forwards the operating states of the HF spindle to the machine con-
troller.

Technical description
Item no. 10300023, Revision 08 11 ( 36 )
5.3 Cooling
The HF spindle does not feature built-in cooling. However, this means that it
has a lower power than an HF spindle with cooling.
Note: Extension of the service life through heat dissipation.
Heat is produced during operation of the HF spindle. The temperature of the
HF spindle should not exceed + 45° C as this shortens the service life of the
bearing.
uCheck the temperature of the HF spindle on the housing.
uDissipate the heat using the spindle holder.
5.3.1 Cooling via spindle holder
Exampleofdesign:
Air-cooled spindle holder
Exampleofdesign:
Liquid-cooled spindle holder
To increase the power of the HF spindle, the heat generated must be dissi-
pated via the spindle holder (optional accessory).
If the spindle holder is to be produced in-house:
ÜContact Nakanishi Jaeger GmbH.
ÜRequest the tolerances and production plan for the spindle holder.
ÜProduce the spindle holder from a thermally-conductive material (e.g. alu-
minum).
ÜObserve the dimensions of the clamping range in the Technical Specifica-
tions [}12] section. Make sure that the HF spindle is enclosed by the spin-
dle holder to the specified length.
ÜAdd cooling fins or holes (greater heat dissipation) to the external surface
of the spindle holder.
5.4 Sealing air
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}20]" section.
The sealing air prevents foreign bodies such as chips and liquids (e.g. emul-
sions) from entering the HF spindle.
ÜCheck that air escapes at the front between the housing and the rotating
parts of the HF spindle.
5.5 Pneumatic tool change
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}20]" section.
The tool change or tool taper change is performed pneumatically.
During this, a mechanism is operated inside the HF spindle which clamps, re-
leases, or ejects the tool taper or collet.

Technical Specifications
Item no. 10300023, Revision 0812 ( 36 )
6 Technical Specifications
Bearings Steel ball bearing (pcs) 2
Lifetime lubricated maintenance free
Power values
Uncooled
Pmax./5s S6-60% S1-100%
Rated power 0,24 0,24 0,18 [kW]
Torque 0,059 0,047 0,036 [Nm]
Voltage 46 46 44 [V]
Current 6,5 6,5 5,5 [A]
Motor data Motor technology 3-phase asynchronous drive
(no brushes or sensors)
Frequency 1.000 Hz
Motor poles (pairs) 1
Rated rotation speed 60.000 rpm
Acceleration/braking value
Per second
10 000 rpm
(other values by consultation)
Characteristics Housing Aluminium
Housing diameter 33 mm
Cooling Uncooled
Heat dissipation Via the spindle holder
Housing temperature < + 45° C
Ambient temperature + 10°C … + 45°C
Sealing air
Protection category
(sealing air turned on) IP54
Tool change Pneumatic direct change
Collet type 5,1P-5°
Clamping range up to 3.5 mm (1/8")
Clockwise
Connection Cable
length 0,9 m
Weight ~ 1,1 kg
Inner taper run out < 1 µ

Technical Specifications
Item no. 10300023, Revision 08 13 ( 36 )
6.1 Dimensions
(*) = Clamping range

Technical Specifications
Item no. 10300023, Revision 0814 ( 36 )
6.2 Technical data sheet (KL 1001, AC motor)
The power values (S1, S6, S2)
are valid for sinusoidal cur-
rents and voltages.
The power values of the HF
spindle are dependent on the
frequency converter used and
may vary from the indicated
values.
Motor type 1/4-2
Rated power 0,18 kW
Rated rotation speed 60.000 rpm
Cooling Uncooled
Heat dissipation via the mount
Motor temperature < 100°C
Winding resistance 1,2 Ω
Power dissipation 100 W – max. (S1)
Measured values: S1-100%
Rated rotation speed 10,000 20,000 30,000 40,000 50,000 60,000 rpm
Speed 8,637 18,719 28,166 38,256 48,489 58,211 rpm
Frequency 167 333 500 667 833 1,000 Hz
Rated power 0.032 0.071 0.101 0.131 0.153 0.181 kW
Torque 0.035 0.036 0.034 0.033 0.03 0.03 Nm
Voltage 11 17 23 30 37 44 V
Current 5.5 5.5 5.5 5 5.5 5.5 A
Cos φ 0.77 0.76 0.73 0.7 0.66 0.64
Measured values: S6-60%
Rated rotation speed 10,000 20,000 30,000 40,000 50,000 60,000 rpm
Speed 8,339 18,068 27,390 37,786 48,019 57,353 rpm
Frequency 167 333 500 667 833 1,000 Hz
Rated power 0.039 0.089 0.136 0.178 0.213 0.243 kW
Torque 0.044 0.047 0.047 0.045 0.042 0.041 Nm
Voltage 11 18 25 32 40 46 V
Current 6.5 6.5 6.5 6.5 6.5 6.5 A
Cos φ 0.79 0.8 0.77 0.73 0.69 0.71

Technical Specifications
Item no. 10300023, Revision 08 15 ( 36 )
Measured values: S2-Pmax./5 s
Rated rotation speed 10,000 20,000 30,000 40,000 50,000 60,000 rpm
Speed 8,660 17,237 26,307 38,767 48,816 57,353 rpm
Frequency 167 333 500 667 833 1,000 Hz
Rated power 0.049 0.107 0.162 0.209 0.229 0.243 kW
Torque 0.054 0.059 0.059 0.051 0.045 0.041 Nm
Voltage 12 19 25 29 36 46 V
Current 7.0 7.7 7.8 7.5 6.8 6.5 A
Cos φ 0.84 0.83 0.82 0.80 0.77 0.71
Note on operation with static frequency converters:
For operation with a frequency converter, the effective fundamental voltage
must correspond to the specified motor voltage.
The measured currents may be greater than the specified values due to the
harmonic content.
6.2.1 Performance Diagram

Technical Specifications
Item no. 10300023, Revision 0816 ( 36 )
6.3 Wiring diagram
Note: Do not change the ex-works configuration.
Any change may cause overvoltage on the electrical components (e.g. PTC,
differential magneto resistor).
g
f
e
d
c
b
a
4 5 6
1 32
a
b
c
d
e
f
g
Bl.von 1
Ü b e r s e t z u n g e n , V e r v i e l f ä l t ig u n g en u n d d i e W e i te r ga b e a n D r i t te , a u c h n u r a u s z ug s w e is e ,
i s t o h n e s c h r i f t l i c h e G e h n e h m i g u n g d e r F a . A l f r e d J ä g e r G m b H u nt e r sa g t
Datum
Gepr.
Bearb.
Norm System Technologie
Blatt 1
1.0
Projekt Nr.:
Version Nr.:
Zeichn.Nr.:
Hr Fischer
Alfred Jäger GmbH
Siemensstraße 8
61239 Ober Mörlen 29041570
Kabelanschluss Typ 1
0,5 mm²
0,5 mm²
0,5 mm²
0,5 mm²
U
W
0,5mm²
0,5 mm²
0,5 mm²
0,5 mm²
4 x 0,5 mm²
4adrig
07.05.2009
0,2 mm²
0,2 mm²
0,2 mm²
(*)
(*)
(*)
Schutzleiter
Protective earth
Motorphase U
Motor phase U
Motorphase V
Motor phase V
Motorphase W
Motor phase W
braun
brown
Ader
wire
Funktion
function
Funktionsbeschreibung - Motorkabel
Wire specification - motor cable
PE
PE
Spindel
spindle
V
Stator
Stator
braun
brown
grün
green
weiss
white
Motorkabel
Motor cable
Schirm / Schield
grün
green
weiss
white
gelb
yellow
gelb
yellow
braun
brown
blau
blue
schwarz
black
(*) grün bis 31.05.2009
(*) green up to 31.05.2009

Technical Specifications
Item no. 10300023, Revision 08 17 ( 36 )
6.4 Air-borne noise emissions
CAUTION: Noise has an impact on health.
uOnly operate the HF spindle if you are wearing hearing protection.

Operating location
Item no. 10300023, Revision 0818 ( 36 )
7 Operating location
DANGER: Due to flying parts.
If the HF spindle is incorrectly attached, it may come loose during operation
and be flung away by the forces that occur.
uClamp the HF spindle firmly.
WARNING: Risk of injury due to flying parts.
The HF spindle operates at high speeds which may cause chips to fly out
with great force.
uNever remove the protective devices of the machine or system.
uAlways wear protective goggles during work.
Exampleofdesign: Mounting
surface
Note the following points before installing the HF spindle:
ÜMake sure that the correct spindle holder for the HF spindle is fitted in the
machine.
ÜCheck the connecting hoses for damage.
ÜCheck the connecting cables for damage.
ÜOnly use undamaged hoses and cables.
ÜDo not allow the HF spindle to run in the vicinity of a heat source.

Installation
Item no. 10300023, Revision 08 19 ( 36 )
8 Installation
Before installation:
ÜCheck the HF spindle for damage and ensure that it is complete.
If the HF spindle has been stored for a long period:
ÜCarry out all steps in the Commissioning after storage section.
8.1 Installing the HF spindle
Connect media and cables with a
flexible connection.
Complete the following steps in sequence to install the HF spindle:
ÜRemove the sealing plugs that protect the connections against damage
and contamination during transportation.
ÜInstead of these sealing plugs, install the appropriate hose fittings.
ÜInstall the corresponding hoses in the hose fittings
ÜMake sure that the connections are flexible and free of strain.
ÜSeal all connections for compressed air axially in relation to the tightening
direction.
ÜIf the HF spindle is equipped with sealing air:
ÄMake sure that no air flow can occur in the bearing area.
ÄAlways use sealed cable boxes when connecting electrical lines.
ÜMount the HF spindle on the machine.
ÜConnect the hoses to the connection of the respective media.
ÜRemove the protective cap that protects the shaft against damage and
contamination during transportation.
ÜConnect the connector of the operating connection lines to the relevant
connection of the HF spindle and to the frequency converter.
ÜLock the connectors.
8.2 Diameter of media supply line
ÜThe nominal size of the media supply lines can be found in the following
table:
DN Medium D1 D2
2.8 Compressed air 2.8 mm 7/64" 4 mm 5/32"
4Compressed air 4 mm 5/32"6 mm 15/64"
6Compressed air 6 mm 15/64"8 mm 5/16"

Installation
Item no. 10300023, Revision 0820 ( 36 )
8.3 Compressed air
8.3.1 Air purity classes (ISO 8573-1)
Solid impurities Class 3
Filter grade at least 5 µm for solids
Water content Class 4
Max. pressure dew point +3 °C
Total oil content Class 3
Max. oil content 1 mg/m3
8.3.2 Setting the sealing air
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}20]" section.
The adjustment value for the sealing air depends on the hose diameter and
length.
ÜHose diameter: DN 4
ÜThe setting value can be found in the following diagram.
ÜTo ensure effective control, turn on the sealing air and cooling when turn-
ing on the machine. This protects the HF spindle even when it is stationary.
Lowest sealing air supply Dry machining
Medium sealing air supply Machining with spray water
Highest sealing air supply Machining with hose water
