Jäger Z80-H530.08 S8J1VW3 User manual

Manual
Z80-H530.08 S8J1VW3
High Frequency Spindle
Pneumatic taper change

Item no. 10405047-05, Revision 032 ( 48 )
Identification of HF spindle
Spindle type
Pmax S6-60% S1-100%
Item no. .... Serial no.
Rated rotation speed
Serial no.
Item no.
Power data
Spindle type
As we always ensure that our HF spindles are at the cutting edge of techno-
logical development, we reserve the right to make technical modifications
and variations from the exact design described in the manual.
The text in this manual has been compiled with the utmost care. However, Al-
fred Jäger GmbH cannot assume any legal responsibility or liability of any
kind for incorrect information and any consequences thereof.
Translations and reproductions – including of extracts – are prohibited with-
out the express written approval of Alfred Jäger GmbH.

Item no. 10405047-05, Revision 03 3 ( 48 )
Contents:
Translation of the original manual
1 Preliminary information 5
1.1 Purpose of the manual ...................................................... 5
1.2 Explanation of symbols used .......................................... 5
2 Transport and packaging 6
2.1 Scope of supply of HF spindle ........................................ 6
2.1.1 Optional accessories............................................. 6
2.1.2 Documentation supplied.................................... 7
2.2 Packaging of HF spindle.................................................... 7
3 Designated use 8
3.1 Permissible types of machining ..................................... 8
3.2 Permissible materials ......................................................... 8
4 Safety instructions 9
4.1 Safe working........................................................................10
4.2 Shutdown of HF spindle .................................................11
4.3 Installation and maintenance .......................................11
4.4 Modification and repair...................................................11
4.5 Improper operation..........................................................11
5 Technical description 12
5.1 Connections of HF spindle.............................................12
5.2 Electrical connection........................................................13
5.3 Cooling..................................................................................13
5.4 Sealing air.............................................................................13
5.5 Taper cleaning....................................................................13
5.6 Pneumatic tool change ...................................................13
6 Technical Specifications 14
6.1 Dimensions..........................................................................15
6.2 Technical data sheet (KL7003 , AC-Motor) ...............16
6.2.1 Performance Diagram........................................17
6.3 Wiring diagram...................................................................18
6.4 Motor protection PTC 160°C..........................................21
6.5 Tool change monitoring.................................................21
6.6 Displacement measuring system (Ott-Jakob).........22
6.6.1 Technical Specifications....................................22
6.6.2 Signals......................................................................23
6.6.3 Installation..............................................................23
6.6.4 Scaling......................................................................24
6.7 Speed and position sensor (MiniCoder)....................24
6.7.1 Technical Specifications....................................24
6.8 Eddy current sensor..........................................................25
6.8.1 Measurement principle .....................................25
6.8.2 Technical Specifications....................................25
6.9 Air-borne noise emissions..............................................26
7 Operating location 27
8 Installation 28
8.1 Installing the HF spindle .................................................28
8.2 Diameter of media supply line .....................................29
8.3 Cooling water......................................................................29
8.3.1 Quality of cooling water....................................29
8.3.2 Setting the cooling..............................................29
8.4 Compressed air...................................................................30
8.4.1 Air purity classes (ISO 8573-1).........................30
8.4.2 Setting the sealing air ........................................30
8.4.3 Setting values........................................................31
8.5 Sensor electronics of measuring system (optional
accessory).............................................................................31
8.5.1 Wiring of measuring system............................31
9 Commissioning 32
9.1 Running-in schedule ........................................................32
9.2 Daily start-up.......................................................................33
9.3 Shutdown signal................................................................33
9.4 Commissioning after storage........................................33
10 Tool change 34
10.1 Clockwise and counter-clockwise ...............................34
10.2 Pneumatic taper change ................................................35
10.2.1 Automatic hollow shank taper tool clamp
....................................................................................35
10.3 Tool changing station (optional accessory).............36
10.3.1 pneumatic taper change...................................36
10.3.2 Installing the changing station.......................36
10.3.3 Maintenance..........................................................36
10.4 Workflow ..............................................................................37
10.4.1 Pneumatic workflow...........................................37
10.4.2 Electrical workflow ..............................................38
10.4.3 Signals......................................................................38
11 Tools for high speed cutting 39
12 Maintenance 40
12.1 Ball bearings........................................................................40
12.2 Daily cleaning .....................................................................40

Item no. 10405047-05, Revision 034 ( 48 )
Contents:
Translation of the original manual
12.2.1 Before commencing work ................................40
12.2.2 With every tool change......................................41
12.2.3 Every time the clamping device is changed
....................................................................................41
12.3 In the case of storage.......................................................41
12.4 Monthly maintenance .....................................................41
12.5 Long periods of storage..................................................41
12.6 Maximum storage time...................................................41
13 Dismantling 42
13.1 Disposal and environmental protection...................42
14 Service and repairs 43
14.1 Service partners..................................................................43
14.2 Malfunctions........................................................................44
15 Declaration of Incorporation 47

Preliminary information
Item no. 10405047-05, Revision 03 5 ( 48 )
1 Preliminary information
The high frequency spindle (HF spindle) is a high quality precision tool for
high speed machining.
1.1 Purpose of the manual
The manual is an important component of the HF spindle.
ÜStore the manual carefully.
ÜMake the manual available to all persons who work with the HF spindle.
ÜRead the documentation supplied in full.
ÜBefore carrying out any work, read the corresponding section of the man-
ual carefully again.
1.2 Explanation of symbols used
To enable quick classification of information, this manual uses visual aids in
the form of symbols and text markings.
Notes are marked with a signal word and a colored box:
DANGER
Dangerous situation!
Results in serious injury or death.
uMeasure to avert the danger.
WARNING
Dangerous situation!
May result in serious injury or death.
uMeasure to avert the danger.
CAUTION
Dangerous situation!
May result in minor to moderate injury.
uMeasure to avert the danger.
Note
May result in material damage. This warning symbol is not a warning for per-
sonal injury.
Tip
Tips indicate useful information for users.

Transport and packaging
Item no. 10405047-05, Revision 036 ( 48 )
2 Transport and packaging
Avoid strong vibrations or impacts during transportation, as these could dam-
age the ball bearings of the HF spindle.
ÜAny damage reduces the accuracy of the HF spindle.
ÜAny damage restricts the functionality of the HF spindle.
ÜAny damage shortens the service life of the HF spindle.
2.1 Scope of supply of HF spindle
The following parts are supplied with the HF spindle:
qHigh Frequency Spindle
qFelt cleaning taper
qTransport packaging
ÜCheck the high frequency spindle for completeness upon delivery.
2.1.1 Optional accessories
Available on request:
qSpindle holder
qFrequency converter
qChiller
qController
qCollet grease
qFurther accessories on request.
Only approved accessories have been tested for operational safety and func-
tionality.
ÜDo not use any other accessories – this may invalidate any warranty claims
and compensation claims for damages.
ÜIf the spindle holder is to be produced in-house, it is essential to contact
Alfred Jäger GmbH before starting production to request the tolerances
and production plan for the spindle holder.

Transport and packaging
Item no. 10405047-05, Revision 03 7 ( 48 )
2.1.2 Documentation supplied
The documents listed below are supplied with the HF spindle:
qManual
qThe declaration of incorporation is part of the manual.
qInspection protocol
ÜCheck that the documentation supplied is complete when the spindle is
delivered. If necessary, request a new copy.
2.2 Packaging of HF spindle
All transport packaging materials can be recycled in appropriate disposal facil-
ities.

Designated use
Item no. 10405047-05, Revision 038 ( 48 )
3 Designated use
The HF spindle is an “incomplete machine” in accordance with the Machinery
Directive and cannot perform any function independently. The HF spindle can
only be operated in conjunction with a machine tool and a frequency con-
verter.
3.1 Permissible types of machining
The HF spindle has been developed only for the following types of machining.
qCutting
qDrilling
qEngraving
qGrinding
ÜContact Alfred Jäger GmbH if other types of machining are required.
3.2 Permissible materials
The HF spindle has been developed only for the following materials.
qMetals (such as alloys, cast metals etc.)
qSintered materials
qPlastics
qWood
qGraphite
qStone (marble, etc.)
qPaper and cardboard
qCircuit boards
qGlass and ceramic
ÜContact Alfred Jäger GmbH if other materials are to be machined.

Safety instructions
Item no. 10405047-05, Revision 03 9 ( 48 )
4 Safety instructions
The high frequency spindle is a state of the art product and is safe to operate.
However, the HF spindle may pose a risk in the following cases:
qIf it is installed by untrained personnel.
qIf it is used incorrectly.
qIf it is not used in accordance with its intended use.
The high frequency spindle may only be installed, commissioned, and main-
tained by specialist personnel.
Definition: Specialist personnel are persons who are familiar with the assem-
bly, installation, commissioning, and operation of the product and have the
relevant qualifications for their area of activity. The operator must closely con-
trol the responsibility, training, and monitoring of these personnel.
DANGER: Due to explosion.
HF spindles are not approved for use in areas at risk of explosion. Use in such
areas may result in explosions.
uDo not use the HF spindle in potentially explosive atmospheres.
DANGER: Due to flying parts.
The HF spindle operates at high speeds and may therefore be flung away by
these.
uOperate the HF spindle only if it is installed in the machine or system in a
fixed manner.
Note: Adhere to the limit values.
uObserve the limit values specified in the technical data.
Note: Take account of the machine.
uObserve the manual of the machine in which the HF spindle is installed.
uObserve all safety instructions specified by the machine manufacturer.
uEnsure that the machine does not cause any hazards (e.g. uncontrolled
movements). Do not install the HF spindle in the machine until this has
been done.
Note. Do not damage the HF spindle.
uAny damage reduces the accuracy of the HF spindle.
uAny damage restricts the functionality of the HF spindle.
uAny damage shortens the service life of the HF spindle.

Safety instructions
Item no. 10405047-05, Revision 0310 ( 48 )
4.1 Safe working
Observe all safety instructions set out in the manual, the applicable national
accident prevention regulations, and the valid company work, operation, and
safety guidelines.
DANGER: Due to flying parts.
Tools that are not clamped correctly will be flung away by the centrifugal
forces that occur during machining.
uUse the full clamping depth of the clamping system.
uClamp the tool securely.
DANGER: Due to flying parts.
If the wrong rotational direction is used, the clamping system releases and
the tool is flung away.
uIt is essential to adhere to the rotational direction of the HF spindle.
WARNING: Risk of injury due to flying parts.
The HF spindle operates at high speeds which may cause chips to fly out
with great force.
uNever remove the protective devices of the machine or system.
uAlways wear protective goggles during work.
Exampleofdesign: Inserting the
shank
Note: Ensure functionality.
uNever operate the HF spindle without a clamped tool shank.
If no tool shank is clamped:
qThe clamping system is damaged by the centrifugal forces.
qThe clamping system is shifted.
qThe balance of the HF spindle is affected.
qThe bearing is damaged.
ÜTake the relevant measures to protect against splashes and spray accord-
ing to the type of machining, the type of material being machined, and the
type of tool selected.
ÄObserve the manual of the machine in which the HF spindle is installed.
ÜObtain the maximum circumferential speeds of the tools used from the
tool supplier.
Single-point tools are not suitable for high speed cutting.
If they are required for production reasons:
ÜOnly use a balanced tool.
ÄDIN ISO 1940
ÄBalance grade 2,5

Safety instructions
Item no. 10405047-05, Revision 03 11 ( 48 )
The tool cutting diameter (X) must not be greater than the maximum
clamping range (Y).
ÜAlways clamp the tool so that it is as short as possible.
ÜKeep the dimension (Z) small.
Ä(Y) See section: Technical Specifications [}14].
4.2 Shutdown of HF spindle
The procedure for shutting down the high frequency spindle for installation
and maintenance work is as follows:
ÜCompletely disconnect the power supply.
ÜCompletely disconnect the media supply (air and liquid).
ÜMake sure that the shaft of the HF spindle has come to an absolute stand-
still.
If the HF spindle is being shut down to be cleaned:
ÜReconnect only the sealing air and the taper cleaning air.
Tip: Forward the data to the controller.
uUse the option on the frequency converter of detecting the shutdown
signal from the shaft and forwarding this to the machine controller for
evaluation.
4.3 Installation and maintenance
ÜCarry out installation, cleaning, and maintenance work only after shutting
down the HF spindle and after the shaft has come to a standstill.
ÜInstall all safety and protective devices of the machine immediately after
completing work.
4.4 Modification and repair
Modifications or alterations to the HF spindle are only permitted after prior
consultation with Alfred Jäger GmbH.
Only the service partners listed in the “Service and repair [} 43]” section are
authorized to open and repair the HF spindle.
Only approved accessories have been tested for operational safety and func-
tionality.
4.5 Improper operation
The high frequency spindle is only safe to operate for its designated use.
ÜObserve the safety instructions in all sections of the manual to prevent
hazards to persons, the environment, the machine, or the HF spindle itself.
Failure to observe the safety instructions may invalidate any warranty claims
and compensation claims for damages.

Technical description
Item no. 10405047-05, Revision 0312 ( 48 )
5 Technical description
5.1 Connections of HF spindle
1a
1c
1b
2
2
3
4
8
7
1d
1a Electrical connection for: motorphases
1b Electrical connection for: Displacement measuring system
1c Electrical connection for: Vector control
1d Electrical connection for: Eddy current sensor
2Cooling water G 1/8"
3Sealing air G 1/8"
4Taper cleaning G 1/8"
7Pneumatics for tool change (cylinder forward) G 3/8"
8Pneumatics for tool change (cylinder back) G 1/4"

Technical description
Item no. 10405047-05, Revision 03 13 ( 48 )
5.2 Electrical connection
The HF spindle may only be operated with a frequency converter (FC).
ÜCheck whether the current, voltage, and frequency data of the HF spindle
match the raw data for the frequency converter.
ÜUse a motor supply line that is as short as possible.
ÜAdjust the speed of the HF spindle using the FC.
ÜRefer to the frequency converter manual for further information.
The FC detects the following operating states of the HF spindle, depending on
the version:
qHF spindle rotating.
qHF spindle too hot.
qHF spindle at a standstill, etc.
The FC forwards the operating states of the HF spindle to the machine con-
troller.
5.3 Cooling
Liquid cooling keeps the HF spindle at a constant temperature during opera-
tion.
Note: Extension of the service life through heat dissipation.
Heat is produced during operation of the HF spindle. The temperature of the
HF spindle should not exceed + 45° C as this shortens the service life of the
bearing.
uCheck the temperature of the HF spindle on the housing.
5.4 Sealing air
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}30]" section.
The sealing air prevents foreign bodies such as chips and liquids (e.g. emul-
sions) from entering the HF spindle.
ÜCheck that air escapes at the front between the housing and the rotating
parts of the HF spindle.
5.5 Taper cleaning
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}30]" section.
Taper cleaning prevents chips and liquids from entering the shaft during a
tool change and causing contamination and damage to the inner taper and
the clamping system.
5.6 Pneumatic tool change
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}30]" section.
The tool change or tool taper change is performed pneumatically.
During this, a mechanism is operated inside the HF spindle which clamps, re-
leases, or ejects the tool taper or collet.

Technical Specifications
Item no. 10405047-05, Revision 0314 ( 48 )
6 Technical Specifications
Bearings Hybrid ball bearing (pcs) 4
Lifetime lubricated maintenance free
Power values
Liquid cooled
Pmax./5s S6-60% S1-100%
Rated power 6,9 5,2 4,6 [kW]
Torque 2,94 2,02 1,88 [Nm]
Voltage 351 354 366 [V]
Current 16 11 10 [A]
Motor data Motor technology 3-phase asynchronous drive
(no brushes or sensors)
Frequency 1.000 Hz
Motor poles (pairs) 2
Rated rotation speed 30.000 rpm
Acceleration/braking value
Per second
10 000 rpm
(other values by consultation)
Characteristics Speed sensor Vector control
Toothed wheel Teeth = 110
Module = 0,3
Motor protection PTC 160°C
Housing Stainless steel
Housing diameter 80 mm
Cooling Liquid cooled
Ambient temperature + 10°C … + 45°C
Sealing air
Protection category
(sealing air turned on) IP54
Taper cleaning
Eddy current sensor
Tool change Pneumatic taper change
Tool Holder HSK-E 32
Tool change monitoring inductive
3 positions clamped, unclamped, ejected
Clamping range up to 13 mm
Clockwise and anticlockwise

Technical Specifications
Item no. 10405047-05, Revision 03 15 ( 48 )
Connector plug
18-pin metal
(Motor phases)
17-pin metal
Cable length 2 m
(Sensors)
Weight ~ 12 kg
Inner taper run out < 1 µ
Axial run-out < 1 µ
6.1 Dimensions
(*) = Clamping range

Technical Specifications
Item no. 10405047-05, Revision 0316 ( 48 )
6.2 Technical data sheet (KL7003 , AC-Motor)
The power values (S1, S6, S2)
are valid for sinusoidal cur-
rents and voltages.
The power values of the HF
spindle are dependent on the
frequency converter used and
may vary from the indicated
values.
Motor type 7/7-4
Rated power 4,6 kW
Rated rotation speed 30.000 rpm
Cooling Liquid cooled
Motor protection PTC 160°C
Winding resistance 1,6 Ω
Measured values: S1-100%
Rated rotation speed 5.000 10.000 15.000 20.000 25.000 30.000 rpm
Speed 3.888 8.766 14.002 18.910 23.868 28.294 rpm
Frequency 167 333 500 667 833 1.000 Hz
Rated power 0,766 1,671 2,641 3,398 4,043 4,621 kW
Torque 1,88 1,82 1,8 1,72 1,62 1,56 Nm
Voltage 86 154 228 297 366 365 V
Current 10 10 10 10 10 10 A
Cos φ 0,25 0,41 0,57 0,67 0,71 0,8
Measured values: S6-60%
Rated rotation speed 5.000 10.000 15.000 20.000 25.000 30.000 rpm
Speed 3.892 8.902 13.816 18.793 23.522 28.362 rpm
Frequency 167 333 500 667 833 1.000 Hz
Rated power 0,821 1,876 2,816 3,792 4,644 5,156 kW
Torque 2,02 2,01 1,95 1,93 1,89 1,74 Nm
Voltage 85 153 221 289 353 354 V
Current 11 11 11 11 11 11 A
Cos φ 0,88 0,83 0,8 0,79 0,78 0,86

Technical Specifications
Item no. 10405047-05, Revision 03 17 ( 48 )
Measured values: S2-Pmax./5s
Rated rotation speed 5.000 10.000 15.000 20.000 25.000 30.000 rpm
Speed 2.925 7.795 12.512 17.612 22.885 27.113 rpm
Frequency 167 333 500 667 833 1.000 Hz
Rated power 0,739 2,333 3,842 5,425 6,871 6,893 kW
Torque 2,41 2,86 2,93 2,94 2,87 2,43 Nm
Voltage 81 151 217 286 351 348 V
Current 14 15 15 15 15 16 A
Cos φ 0,93 0,91 0,89 0,88 0,88 0,9
Note on operation with static frequency converters:
For operation with a frequency converter, the effective fundamental voltage
must correspond to the specified motor voltage.
The measured currents may be greater than the specified values due to the
harmonic content.
6.2.1 Performance Diagram

Technical Specifications
Item no. 10405047-05, Revision 0318 ( 48 )
6.3 Wiring diagram
Note: Do not change the ex-works configuration.
Any change may cause overvoltage on the electrical components (e.g. PTC,
differential magneto resistor).
g
f
e
d
c
b
a
4 5 6
1 32
a
b
c
d
e
f
g
Bl.von 1
Ü b e r s e t z u n g e n , V e r vi e l f ä l t i g u n ge n u n d d i e W e i te rg a be a n D r i t te , a u c h n u r a us z ug sw e i se ,
i s t o h n e s c h r i f t l i c h e G e h n e h m i g u n g d e r F a . A l f r e d J ä g e r G m b H u n t e rs ag t
Datum
Gepr.
Bearb.
Norm System Technologie
Blatt 1
1.0
Projekt Nr.:
Version Nr.:
Zeichn.Nr.:
Hr Fischer
Alfred Jäger GmbH
Siemensstraße 8
61239 Ober Mörlen 29027070
Flanschstecker FS18
0,75 mm²
U
W
0,14 mm²
0,14 mm²
0,25 mm²
0,25 mm²
0,25 mm²
B
A
W
V
U
PE
1
2
3
4
5
6
7
8
9
10
11
12
grün-gelb
green-yellow
PTC
PTC
VStator
Stator
rot
red
blau
blue
weiss
white
rot
red
blau
blue
Spindelstecker FS18 Spindle plug FS18
Spindelerkennung (nach Bedarf)
spindle ID (according to requirements)
22.10.2013
U V
W
A
B198
2
3
4 5
6
710 12
11
UV
1
B
2
W
8
A
7
12
64 5
10
3
PTC+
Motorphase U
Motor phase U
Motorphase V
Motor phase V
PE Schutzleiter
PE conductor
Feldplatte+
Transmitter+
Motorphase W
Motor phase W
Kundenseite
Customer side
-----
-----
-----
-----
---------------
-----
-----
PTC-
Kundenseite
Customer side
Rückseite
Back side

Technical Specifications
Item no. 10405047-05, Revision 03 19 ( 48 )
g
f
e
d
c
b
a
4 5 6
1 32
a
b
c
d
e
f
g
Bl.
Ü b e r s e t z u n g e n , V e r v i e l f ä l t i gu n g en u n d d i e W ei t er g ab e a n D r i t te , a u c h n u r a u s z u gs w ei s e ,
i s t o h n e s c h r i f t l i c h e G e h n e h m i g u n g d e r F a . A l f r e d J ä g e r G m b H u n t e rs a gt
Datum
Gepr.
Bearb.
Norm System Technologie
Blatt 1
1.0
Projekt Nr.:
Version Nr.:
Zeichn.Nr.:
Hr Fischer
Alfred Jäger GmbH
Siemensstraße 8
61239 Ober Mörlen
USB 40 / Sauer
29025970
10.10.2008
UB+
+5V
0,25 mm²
0,25 mm²
GND
0,25 mm²
UN+
0,25 mm²
UA-
UA+
UB-
0,25 mm²
0,25 mm²
0,25 mm²
0,25 mm²
UN-
0,25 mm²
GND
1
2
5
9
10
11
12
13
14
16
3
4
6
7
8
17
15
Schield
von 1
Kabelstecker SA17
11
10
9
8
7
6
5
4
3
212
14
1
13 17 16
15
12 11
10
1
2
16
9
8
6 75
15
14
4
----
rosa
pink
rot
red
blau
blue
grau
grey
braun
brown
Sense
Sense
weiss
white
schwarz
black
grün
green
gelb
yellow
Kabelstecker SA17
Cable plug SA17
Zahnradgeber GEL 2442
Precision encoder GEL 2442
Schirm
Nullspur UN-
Reference UN-
Nullspur UN+
Reference UN+
---- ----
----
----
UB+ Spur B
UB+ track B
Versorgungsspannung Masse
supply voltage erath
Versprgungsspannung
supply voltage
UB- Spur B
UB- track B
Brücke zu Pin 4 (Masse)
Jumper to pin 5 (earth)
UA- Spur A
UA- track A
UA+ Spur A
UA+ track A
17
----
3
13
Sense
Sense
+5V (+/- 5%)
---- Rückseite
Back side
Kundenseite
Customer side

Technical Specifications
Item no. 10405047-05, Revision 0320 ( 48 )
g
f
e
d
c
b
a
4 5 6
1 32
a
b
c
d
e
f
g
Bl.von 1
Ü b e r s e t z u n g e n , V e r v i e l f ä l t i gu n g en u n d d i e W ei t er g ab e a n D r i t te , a u c h n u r a u s z u gs w ei s e ,
i s t o h n e s c h r i f t l i c h e G e h n e h m i g u n g d e r F a . A l f r e d J ä g e r G m b H u n t e rs a gt
Datum
Gepr.
Bearb.
Norm System Technologie
Blatt 1
1.0
Projekt Nr.:
Version Nr.:
Zeichn.Nr.:
Hr Fischer
Alfred Jäger GmbH
Siemensstraße 8
61239 Ober Mörlen 29041370
Kabelanschlussplan SA5 (SGS)
1
2
4
5
3
0,014 mm²
0,014 mm²
0,0053 mm²
rot
red
gelb
yellow
weiss
white
Schirm
Signal +
Signal -
Ground
Data
Kabelstecker SA5
Cable plug SA5
Schielding
Schielding
Schirm
22.10.2008
5
4
3
2
1
43
2
1
Kundenseite
Customer side
Sensor Signal-
Sensor signal-
Sensor Signal+
Sensor signal+
Masse (Schirm Koaxialkabel)
Ground (schielding coaxiale cable) Gemeinsamer Schirm
Total schielding
5
Daten (Innenleiter)
Data (inner conductor)
