J-Tech Digital JTD-657 User manual

H.264 / H.265 HDMI Encoder with NDI
JTD-657 | jtech-ench5ndi
USER MANUAL
J-TECH DIGITAL INC.
9807 EMILY LANE
STAFFORD, TX 77477
TEL: [phone]
E-MAIL: [email protected]

2 | P a g e
Table of Contents
1. Features.........................................................................................4
2. Package Contents..........................................................................4
3. Hardware Description.....................................................................4
4. Typical Application .........................................................................5
5. Connection Configuration...............................................................6
5.1 Change the IP Address of PC ....................................................................6
5.2 Login for Configuration ...............................................................................6
5.3 Check the Stream Address ........................................................................7
6. Encoder Setting .............................................................................8
6.1 Encoder Setting..........................................................................................8
6.2 Audio Setting..............................................................................................8
6.3 Advanced .................................................................................................10
7. OSD Setting .................................................................................11
7.1 Streaming OSD Setting ............................................................................11
7.2 Logo Uploading ........................................................................................11
8. System.........................................................................................12
8.1 Network ....................................................................................................12
8.2 Change Password ....................................................................................13
8.3 Reset........................................................................................................13
8.4 Reboot......................................................................................................14
9. Application ...................................................................................14
9.1 User Application Example ........................................................................14
9.1.1 Web Video Preview ..........................................................................14
9.1.2 VLC ..................................................................................................16
9.2 NDI Stream ..............................................................................................18
9.3 Multi Local User Application –Multicast ...................................................19
9.4 Local Surveillance System Application NVR Connection .........................21
9.5 Remote Multi User: RTMP Connection ....................................................22
9.6 RTMP: Stream to YouTube Live ..............................................................23

3 | P a g e
10. Maintenance ..............................................................................25
11. Warranty ....................................................................................25
12. Main-In Service ..........................................................................25
13. Limited Warranty Limits and Exclusions .....................................25

4 | P a g e
Dear Customer
Thank you for purchasing the JTECH-ENCH5NDI Encoder. For optimal performance and
safety, please read these instructions carefully before connecting, operating, or adjusting
this product. Please keep this manual for future reference.
1. Features
•Supports H.265 | H.264 | MJPEG Encoding
•Supports Audio Input
•Supports HDMI Local Loop Output
•Supports UDP, HTTP, RTSP, RTMP, ONVIF, NDI HX2 Protocols
•Supports MPEG1 Audio Layer 2
•CBR/VBR Rate: 16Kbps~16Mbps
•1000M Network Interface (full duplex mode)
•Supports up to 1080p@60Hz HD Video Input
•Supports Image Parameter Settings
•Supports Remote Management in WAN (webGUI)
•Supports Customized Resolution Settings
2. Package Contents
•(1) x J-Tech Digital JTECH-ENCH5NDI Encoder
•(1) x Power Adapter DC12V 1A
•(1) x User Manual
3. Hardware Description

5 | P a g e
4. Typical Application

6 | P a g e
5. Connection Configuration
5.1 Change the IP Address of PC
Assign the PC (or laptop) an IP address. On a Windows PC: Press the +R on your keyboard
→Enter “control netconnections” in the run box and press enter → Right click on your wired
ethernet adapter → Select “Properties” → Double click “Internet Protocol Version 4 (TCP/IPv4)”
→ Enter the IP address with 192.168.1.11 (0-255) and Subnet mask 255.255.255.0. Press OK
twice to save the configuration.
5.2 Login for Configuration
Enter the unit’s IP address (192.168.1.168) in your browser’s address bar, to open the web GUI.
Login with the default credentials, User Name –admin | Password –admin

7 | P a g e
5.3 Check the Stream Address
Stream addresses populate in the “Main Stream” category show in the red box below:

8 | P a g e
6. Encoder Setting
6.1 Encoder Setting
Click “Encoder” setting → “Main stream” → Configure your settings → Click Apply
6.2 Audio Setting
Audio from HDMI Port: Click “Encoder” → “Audio” → Select “HDMI” from the drop-down menu for
Audio Input →Click “Apply

9 | P a g e
Audio from the 3.5mm audio port: Click “Encoder” → “Audio” → Select “ANALOG” from the drop-
down menu for Audio Input →Click “Apply”

10 | P a g e
6.3 Advanced
Click “Encoder” → “Advanced” → Configure your settings →Click “Apply”.

11 | P a g e
7. OSD Setting
7.1 Streaming OSD Setting
Click “OSD” → “Network” → Configure your settings →Click “Apply”
7.2 Logo Uploading
“LOGO upload” → Choose a bmp file that matches the requirements →Click “Apply”

12 | P a g e
*Note: The above interface screenshot examples may show a difference with actual operation
interface due to software upgrades. All screenshots are for reference only.
8. System
8.1 Network
Click System → Network → Modify the network settings to match those of your network
Click apply. Note: Please change your DNS server to use Google’s DNS servers. (Provided in
the picture below.)

13 | P a g e
8.2 Change Password
System → Change password → Set your password →Apply
8.3 Reset
System → Reset → Reset Note: This will set your device to the factory default.

14 | P a g e
8.4 Reboot
System → Reboot → Reboot (please refresh the web page after 1 minute)
9. Application
9.1 User Application Example
9.1.1 Web Video Preview
Status → Main Stream →Preview
Note: For Internet Explorer , you can get preview window directly.
For Chrome , you must install an extension called "Native HLS Playback" to get the
preview window.

15 | P a g e

16 | P a g e
Picture below shows the stream preview:
9.1.2 VLC
Connect an HDMI source to the JTECH-ENCH5NDI encoder. Open VLC media player
(Download link：
http://www.videolan.org/)，Click “Media”, then click “Open Network Stream”.

17 | P a g e
Enter the Stream URL from the page of “Main stream”, click “Play”. Note: Please make sure that
the stream type you choose is enabled in the encoder.

18 | P a g e
VLC Example:
9.2 NDI Stream
Enable NDI URL and turn off the firewall on your computer.

19 | P a g e
Open NDI player to play “stream1”. NDI player is available for download here
(https://www.ndi.tv/tools/)
9.3 Multi Local User Application –Multicast
If more than one local user needs to stream the video of the encoder simultaneously, you
may enable multicast IP, then reboot the JTECH-ENCH5NDI encoder.

20 | P a g e
After the reboot, copy the multicast IP address from the Status page, and paste the IP address
into VLC Player. This stream can be viewed by more than one user at the same time.
