USER MANUAL
J-Tech Digital®
IPTV H264 Encoder
JTD-ID:220
RoHS

2
Table of Contents
1. Features........................................................................................................................3
2. Package Contents........................................................................................................3
3. Hardware Description...................................................................................................4
4. Typical Application........................................................................................................4
5. Environment Configuration...........................................................................................5
5.1. Software.............................................................................................................5
5.1.1. Change the IP Address of PC ...........................................................................5
5.1.2. Login for configuration.......................................................................................6
5.1.3. Check the stream address ................................................................................6
6. Encoder Setting ............................................................................................................6
6.1. Encoder Setting .................................................................................................6
6.2. Audio Setting .....................................................................................................7
6.3. Advanced...........................................................................................................7
7. OSD Setting..................................................................................................................8
7.1. Stream OSD Setting..........................................................................................8
7.2. LOGO Uploading...............................................................................................8
8. System Setting .............................................................................................................9
8.1. Network..............................................................................................................9
8.2. Change password..............................................................................................9
8.3. Reset ...............................................................................................................10
8.4. Reboot.............................................................................................................10
9. Application ..................................................................................................................11
9.1. User Application Example...............................................................................11
9.1.1. Web Video Preview .........................................................................................11
9.1.2. VLC Play..........................................................................................................12
9.2. Multi Local User Application Multicast Way.....................................................13
9.3. Local Surveillance System Application NVR Conncetion ...............................14
9.4. Remote Multi User Application RTMP Connection.........................................15
WARRANTY......................................................................................................................15

3
Dear Customer
Thank you for purchasing the JTECH-ENCH4. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
1. FEATURES
➢Supports H.264 encoding.
➢Supports UDP, HTTP, RTSP, RTMP, ONVIF protocol.
➢Supports MPEG1 Audio Layer 2.
➢CBR/VBR rate: 16Kbps~16Mbps.
➢1000M network interface uses full duplex mode.
➢Supports up to 1080p@60HZ HD video input.
➢Supports image parameter settings.
➢Supports remote management in WAN (webGUI).
➢Supports customized resolution settings.
2. PACKAGE CONTENTS
1). Main Unit. H.264 HD HDMI Encoder
2). 1x Power adapter DC 12V 1A
3). Operating Instruction manual

4
3. HARDWARE DESCRIPTION
① Power input port ② HDMI input
③ Reset button ④ LAN output
⑤ Indicator of power input ⑥ Indicator of LAN output
⑦ Indicator of HDMI input
Note: . Reset to the factory default setting: press “Reset” for 10 seconds till all three
indicators go out.
. LAN: default IP is 192.168.1.168 for the unit.
4. Typical Application

5
5. Connection Configuration
5.1 Software
5.1.1 Change the IP Address of PC
Assign the PC (or laptop) an IP address. On a Windows PC: Press the +R on your
keyboard →Enter “control netconnections” in the run box and press enter → Right click
on your wired ethernet adapter → Select “Properties → Double click “Internet Protocol
Version 4 (TCP/IPv4)” → Enter the IP address with 192.168.1.11 (0-255) and Subnet
mask 255.255.255.0. Press OK twice to save the configuration.
5.1.2 Login for configuration
Enter the unit IP 192.168.1.168 in your browser, to open the web GUI. Login with the default
user name and pass word as admin.

6
5.1.3 Check the stream address
As below, the stream address is in the red frame.
6. Encoder Setting
6.1 Encoder Setting
Click “Encoder” setting → “Main stream” → Configure your settings → Click Apply

7
6.2 Audio setting
Click “Encoder” → “Audio” → Configure your settings → Click “Apply”
6.3 Advanced
Click “Encoder” → “Advanced” → Configure your settings → Click “Apply”.

8
7. OSD Setting
7.1 Streaming OSD Setting
Click “OSD” → “Network” → Configure your settings → Click “Apply”
7.2 LOGO uploading
“LOGO upload” → Choose a bmp file that matches the requirements → Click “Apply”
※Note: The screenshots might have some difference with actual operation interface due
to software upgrade, all the screenshots are for reference only.

9
8. System
8.1 Network
Click system → Network → Modify the network settings to match those of your network
→ Click apply. Note: Please change your DNS server to use Google’s DNS servers.
(Provided in the picture below.)
8.2 Change password
System → Change password → Set your password → Apply

10
8.3 Reset
System → Reset → Reset Note: This will set your device to the factory defaults.
8.4 Reboot
System → Reboot → Reboot (please refresh the web page after 1 minute)
