Jøtul F 602 ECO User manual

Jøtul F 602 ECO
UK - Installation and Operating instructions 3
FR - Manuel d’installation et d’utlisation 21
ES - Instrucciones para montaje e instalación 37
IT - Manuale di installazione ed uso 54
Jøtul F 602 ECO
Manual Version P02
The manuals which are enclosed with the product must be kept throughout the product’s entire service life. Les
manuels fournis avec le produit doivent être conservés pendant toute la durée de vie du produit. Los manuales
suministrados con este producto deben guardarse durante todo el ciclo de vida del producto. I manuali inclusi con
il prodotto vanno conservati per l’intera durata di vita del prodotto.

2
EU no. 215/1186 - 24/04/2015
Datasheet / Fiche Technique / Ficha técnica /
Scheda dati / Datenblatt / Dane techniczne
Requirements / Exigences / Requisitos / Requisiti /
Vereisten / Forderungen / Wymagania
Supplier /
Fabricante /
Fornitore /
Vereisten /
Lieferant/
Producent:
Jøtul AS
Product models
Produits concernés
Modelos
Modelli
Product modellen
Varianten der Feuerstelle
Modele produktu
Jøtul F 602 ECO
Energy efficiency class / Classe énergétique / Clase de
eficiencia energética / Classe energetica / Energie
efficiëncy klasse / Energieeffizienz-Klasse / Klasa
efektywnści energetycznej
A+
Direct heat output / Puissance réelle de sortie / Potencia
calorifica emitida / Emissione di calore diretta / Directe
warmte afgifte / Nennwärmeleistung / Bezpośrednia moc
grzewcza
4,9 kW
Energy efficiency index / Index de rendement énérgétique/
Índice de eficiencia energetica / Indice di efficienza
energetica / Energie efficiëncy index / Energieeffizienz-
Index / Indeks efetywności energetycznej
108,5
Efficiency at nominal heat output / Rendement à
puissance nominale / Eficiencia al rendimiento nominal /
Efficienza alla potenza nominale / Efficiency bij nominale
warmte afgifte / Wirkungsgrad bei Nennheizleistung /
Sparawność dla mocy znamionowej
81 %
xAny specific precautions that shall be taken when the
local space heater is assembled installed or
maintained.
xToutes les précautions spécifiques doivent être prises
lors de l’assemblage, l’installation ou l’entretien de
l’appareil.
xCualquier precaución específica que deba tenerse en
cuenta durante el montaje, instalación o
mantenimiento del equipo de calefacción
xPrecauzioni specifiche da prendere quando il
riscaldatore viene assemblato, installato o mantenuto
in uno spazio.
xEventuele specifieke voorzorgsmaatregelen die
worden genomen wanneer de plaatselijke
ruimteverwarming wordt gemonteerd, geïnstalleerd of
onderhouden.
xBesondere Maßnahmen bei Montierung, Installation
und Wartung.
xWaszelkie szczególne środki ostrożności, które
należy podjać, gdy lokalny ogrzewacz pomieszczeń
jest zamontowany lub konserwowany.
xFire safety precautions such as safety distances when
installing, national standards, local codes and
regulations. See the Instructions manual.
xLes précautions d'incendie telles que les distances de
sécurité lors de l'installation, le suivi des normes, les
codes locaux et les règlementations nationales.
Veuillez lire le manuel d’installation.
xPrecauciones frente a incendios como distancia de
seguridad en la instalación, estándares nacionales,
códigos locales y reglamentos. Lea el manual de
instalación.
xPrecauzioni per la sicurezza antincendio come le
distanze di sicurezza durante l'installazione, le
normative nazionali e locali. Leggere il manual.
xBrandveiligheidsmaatregelen, zoals veiligheids-
afstanden bij installatie, nationale normen, lokale
codes en voorschriften. Lees de
installatiehandleiding.
xFür brenntechnische Verhältnisse, wie z.B.
Aufstellbedingungen und nationale Forderungen.
Siehe die Montage- und Bedienungsanleitung.
Środki bezpieczeństwa przeciwpożarowego, takie jak
odległości od materiałów palnych jakie należy zachować
podczas instalacji, normy krajowe, lokalne przepisy i
regulacje. Patrz instukcja obsługi..

3
ENGLISH
1.0 Relationship to the
authorities
Installation of a fireplace must be according to local codes and
regulations in each country.
All local regulations, including those which refer to national
and European standards, must be observed when installing
the product.
The installation can only be put into use after it has been
checked by a qualified inspector. Contact your local building
authorities before installing a new fireplace.
A product approval plate of heat-resistant material is to
be found in the ash pan. This contains information about
identification and documentation for the product.
2.0 Technical data
Material: Cast iron
Finish: Black paint
Fuel: Wood
Log length, max.: 40 cm
Flue outlet: Top, rear
Flue pipe dimension: Ø125 mm
Outside air connection: Alu. flex. - Ø80 mm
Approx. weight:
- Jøtul F 602 ECO: 86 kg
Optional extras: External air supply cover, Heat
shield, Hotplate, External air
adaptor, External air kit
Dimensions, distances: See fig. 1
Technical data in acc. with EN 13240 / NS 3058
Nominal heat output: 4,9 kW
Flue gas volume: 3,8 g/s
Chimney draught, EN 13240: 12 Pa
Recommended negative pressure
in smoke outlet: 16-18 Pa
Efficiency: 81%@4,9 kW
CO emissions (13% O2): 0.09%
CO emissions (13% O2): 1132 mg / Nm3
NOx at 13% O2: 87 mg / Nm3
OGC @ 13 % O2: 55 mg/Nm3
Air consumption: 3,1 litre/sec
Chimney temperature, EN 13240: 259 oC
Dust: 25 mg/Nm3@13%O2
Particle emission NS 3059: 2,7 g / kg
Type of fuel: Wood
Recommended log length: 19-33 cm
Max. log length: 40 cm
Fuel consumption: 1,4 kg/h
Max. kindling amount: 2,2 kg
Nominal kindling amount: 1.2 kg
Operation: Intermittent
Intermittent combustion in this context means normal use
of the fireplace, i.e. fuel is added as soon as the fuel has
burnt down to a suitable amount of embers.
Table of contents
Installation manual with technical data
1.0 Relationship to the authorities ............................ 3
2.0 Technical data .................................................... 3
3.0 Safety ................................................................. 4
4.0 Installation ......................................................... 8
5.0 Daily use............................................................. 13
6.0 Maintenance....................................................... 14
7.0 Service................................................................ 14
8.0 Operational problemes -
troubleshooting......................................................... 17
9.0 Optional Equipment ........................................... 18
10.0 Recycling.......................................................... 18
11.0 Guaranee terms................................................ 18
Register your fireplace at jotul.com for a
25-year warranty.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC SP
EN
Serial no.
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number when
contacting your retailer or Jøtul.

4
ENGLISH
3.0 Safety
NB! To guarantee optimal performance and safety, Jøtul
recommends that its stoves are fitted by a qualified
installer (see www.jotul.com for a complete list of dealers).
Any modifications to the product may result in the product
and safety features not functioning as intended. The same
applies to the installation of accessories or optional extras not
supplied by Jøtul. This may also be the case if parts that are
essential to the functioning and safety of the fireplace have
been disassembled or removed.
In all these cases, the manufacturer is not responsible or liable
for the product and the right to make a complaint becomes null
and void.
The Clean Air Act
“The Clean Air Act 1993 and Smoke Control Areas”
Under the Clean Air Act local authorities may declare the
whole or part of the district of the authority to be a smoke
control area. It is an offence to emit smoke from a chimney of
a building, from a furnace or from any fixed boiler if located in a
designated smoke control area. It is also an offence to acquire
an “unauthorised fuel” for use within a smoke control area
unless it is used in an “exempt” appliance (“exempted” from
the controls which generally apply in the smoke control area).
In England appliances are exempted by publication on a list
by the Secretary of State in accordance with changes made to
sections 20 and 21 of the Clean Air Act 1993 by section 15 of
the Deregulation Act 2015. Similarly in Scotland appliances are
exempted by publication on a list by Scottish Ministers under
section 50 of the Regulatory Reform (Scotland) Act 2014.
In Northern Ireland appliances are exempted by publication
on a list by the Department of Agriculture, Environment and
Rural Affairs under Section 16 of the Environmental Better
regulation Act (Northern Ireland) 2016.
In Wales appliances are exempted by regulations made by
Welsh Ministers.
Further information on the requirements of the Clean Air Act
can be found here: https://www.gov.uk/smoke-control-area-
rules
Your local authority is responsible for implementing the Clean
Air Act 1993 including designation and supervision of smoke
control areas and you can contact them for details of Clean Air
Act requirements.
The Jøtul F 602 ECO has been recommended as suitable for
use in smoke control areas when burning wood logs.
3.1 Fire Prevention Measures
There is a certain element of danger every time you use
your fireplace. The following instructions must therefore be
followed:
• The minimum safety distances when installing and using
the fireplace are given in fig. 1. The specified distance to
flammable materials, applies to this stove. The stove must
be installed with a CE approved flue. The distance of the
flue pipe to combustible materials must also be observed.
• Ensure that furniture and other flammable materials are not
too close to the fireplace. Flammable materials should not
be placed within 550 mm of the fireplace.
• Allow the fire to burn out. Never extinguish the flames with
water.
• The fireplace becomes hot when lit and may cause burns
if touched.
• Only remove ash when the fireplace is cold. Ash can contain
hot embers and should therefore be placed in a non-
flammable container.
• Ash should be placed outdoors or be emptied in a place
where it will not present a potential fire hazard.
In case of chimney fire:
• Close all hatches and vents.
• Keep the firebox door closed.
• Call the fire service.
• Before use after a fire an expert must check the fireplace
and the chimney in order to ensure that it is fully functional.
•
3.2 Floor
Foundation
You need to make sure the foundation is suitable for a fireplace.
See “2.0 Technical Data” for specified weight.
We recommend the removal of any flooring that is not attached
to the foundation (“floating floors”) beneath the installation.
Requirements for protection of wooden
flooring beneath the fireplace
The product can be placed directly on a wooden floor,
protected by a floor plate made from non combustible material
(recommended thickness - minimum 0,9 mm)
Jøtul recommends that any flooring made of combustible
material, such as linoleum, carpets, etc. should be removed
from under the floor plate.
Requirements for protection of
inflammable floors in front of the fireplace
The front plate must comply with national laws and
regulations.
Contact your local building authorities regarding restrictions
and installation requirements.
3.3 Walls
• The product should be placed so that it is possible to clean
the stove, flue pipe and chimney outlet.
• Make sure furniture and other combustible materials do not
get too close to the stove.
• Make shure furniture and other items are not placed too
close to the stove, to prevent them from drying out.
Distance to walls made of combustible material - see fig. 1a
The stove must be installed with a CE approved flue pipe.
The distance from flue pipes to combustible materials must
also be taken into account.
Combustible wall protected by firewall
Distance to combustible wall protected by firewall: See fig. 1b
. Distances with semi-inslulated chimney/shielded flue pipe
are shown in fig. 1a.

5
ENGLISH
Jøtul F 602 ECO
Ø80
Min. distance to combustible wall
Outside air connection Plassering på underside Ø80mm (optional extra)
68
105
547
637
320 540
480
515
307
Min. height of firewall
* semi-insulated chimney / shielded flue pipe right down to the stove
Distance to combustible ceiling
Min. measurement floorplate X/YAcc. to national standards
Min 1337
840
With heat shield Without heat shield
250
200*
427 377*
350 300*
527
477*
300 250*
460 410*
500
660
250*
300
355*
405
405
355*
300
250*
1039
604
745
1180
550
Combustible wall Firewall
Fig. 1a

6
ENGLISH
Combustible wall Firewall
Without heat shield With heat shield
Min. distance to firewall
Integrated firewall External firewall Integrated firewall External firewall
845
410
250
675
250 410
933 733
873 531
1002
100
205
640
140
933
317
640
205 100
640
100
205
733
317
140
824
205
100
640
500
300
500
300
500
448
500
448
883
883
300
695
100
260
933
525
100
260
733
100
205
640
1065
819
100
640
933
100
277
277
733
100
500
500
392 827
392
827
500
300
500
300
Fig. 1b

7
ENGLISH
Non-combustible wall (all the way through)
The fireplace can be installed with a minimum of 100 mm to
non-combustible wall if the distance from the fireplace to all
combustible materials are a minimum of 300 mm.
Non-combustible materials mean materials like brick, clinker,
concrete, mineral wool, cilicate plates etc (materials that do
not burn). Note! A short distance to non-combustible wall
may lead to desiccation and discoloration of paint and cause
cracking.
3.4 Ceiling
There must be a minimum distance of 700 mm to a combustible
ceiling above the fireplace.
Fresh air supply
The air used for combustion in any well-insulated house needs
to be replaced. This is particularly important in houses with
mechanical ventilation. Such replacement air can be procured
in several ways. The most important thing is to supply the air
to the room where the stove is placed. Place the outside wall
valve as close to the stove as possible and make sure that it
can be closed when the stove is not in use.
For the fresh air supply connection, follow the national and
local building regulations.
Important! Ensure that air vents in the room where the
fireplace is located are not blocked.
Closed combustion system
Use the stove’s closed combustion system if you live in recently
built, airtight dwellings. Connect the external combustion air
through a ventilation pipe through the wall or the floor.
Air supply
The amount of combustion air for Jøtul’s products is approximately
20-40 m3/h. The outside air connection may be fitted directly to
the Jøtul F 602 ECO through:
• the bottom
• through a flexible supply hose from the outside/chimney
(only if the chimney has its own duct for external air) and to
the product’s outside air connector.
Through an outside wall
Through the floor and ground plate
Through the floor and basement

8
ENGLISH
Indirectly through an outside wall
4.0 Installation
• Before installing the fireplace, check it carefully for any
signs of damage.
• The product is heavy! Ask someone to help you when
positioning and installing it.
• Make sure that furniture and other household items
are at a safe distance from the fireplace to protect
them from drying out.
4.1 Prior to installation
1. The standard product comes in one package.
2. Remove thebag of screws and smoke outlet from the stove.
3. When the product is unpacked, release from the pallet.
Make sure everything is in order.
Fig. 2 Release from pallet
4. Remove the 4 transport screws
Requirement for UK
“The Jotul F 602 ECO stove has been recommended as
suitable for use in smoke control areas when burning wood
logs and when fitted with a mechanical stop to prevent
secondary air control closure less than 360 mm2
Fig. 3 Requirement for UK
12
1. Put the valve edge-to-edge with the ash lip.
2. Us the screw from the bag of screws and screw it into the
burnchamber.
4.2 Installation
Fig. 4a Assemble the handle - parts
Fig. 4b Assemble the handle
1. Mount the wooden knob on the door handle. The parts
are in the bag of screws.

9
ENGLISH
Fig. 5 Installing heat shield (optional extra)
1
2
1. Hook the heat shield into the groove under the top plate.
2. Bend the shield plate towards the oven.
3. The heat shield can be mounted on either the right or left
side (possibly both sides if required).
Fig. 5b Attach the heat shield
1. Screw the heat shield to the underside of the product, with
the screw included in the bag of screws.
Fig. 6 Mount the smoke outlet on the top outlet
1. Tighten the smoke outlet with the screws that are screwed
into the product from the factory.
Fig. 7a Switch from top outlet to rear outlet
A
B

10
ENGLISH
Fig. 7b
B
1. Switch places between smoke outlet (A) and smoke outlet
cover (B). Unscrew the two screws with an Allen key.
4.3 Assembly with an external air
supply (optional extra)
Fig. 8 Loosen the screws for the external air supply
adaptor.
1. The screws to be used for the external air supply adaptor
are mounted in the oven from the factory. These must be
loosened and used as shown in Fig. 10 if fresh air supply
is to be used.
Fig. 9 Installation of gasket on the external air
supply adaptor
1. Remove the protective paper from the supplied gasket
and place the gasket in the slot on the external air supply
adaptor.
Fig. 10 Mounting of the external air supply
1. The screws loosened in Fig. 8 are used to secure the
external air supply adaptor.

11
ENGLISH
Fig. 11 Mounting of external air supply connection
1
2
1. Place the external air supply connection on the outside of
the external air supply adaptor.This works the same way
for both wall and floor outlet.
2. Tighten with screwdriver.
4.4 Location of approval label
Fig. 12 Approval label
A
1. The approval label (A) is located on the bottom of the
stove.
4.5 Chimney and flue pipe
• The fireplace must only be connected to a chimney and
flue pipe approved for solid fuel fireplaces with flue gas
temperatures as specified in «2.0 Technical Data».
• For flue pipe dimension see “2.0 Technical Data”. NB:
The chimney’s diameter must be at least just as big as the
flue pipe.
• Connection to the chimney must be carried out in
accordance with the chimney supplier’s installation
instructions.
• Before a hole is made in the chimney, the product should
be test-mounted in order to correctly mark the position of
the fireplace and the hole in the chimney. See fig. 1 for
minimum dimensions.
• Use a flue pipe bend with a sweep hatch to allow sweeping.
• Please note that it is extremely important for connections
to have a degree of flexibility. This is to prevent any
movement in the installation leading to the formation of
cracks.
• For recommended chimney draught, see «2.0 Technical
Data».
NB! The minimum recommended chimney length is 3.5 m
from the flue pipe insert. If the draught is too strong, a flue
pipe damper can be installed and used to reduce the draugh
If a flue damper is fitted it shall be of a type, which does not
block the flue totally. The damper shall be easy to operate and
incorporate an aperture within the blade, which in a continuous
area occupies at least 20 cm2 or 3 % of the cross-sectional
area of the blade if this is greater.
The position of the damper shall be recognizable from the
setting of the device.
If a draught regulator is fitted the minimum cross sectional
area requirement shall not be applicable but the device shall
be easily accessible for cleaning.
Assembly of flue pipe
The product is assembled for a top outlet as standard.
Fig. 13 Assembling the flue pipe
1
2
1. Pull offthe protective paper from the supplied gasket
and attach it to the outside of the flue pipe
2. Insert the flue pipe into the smoke outlet.
Flue pipe is installed in the same way for top and rear outlet.

12
ENGLISH
4.6 Performance check
Once the product has been assembled, always check the
control handles. These should move easily and work in a
satisfactory manner.
Fig. 14 The Jøtul F 602 ECO is equipped with the
following operating options:
A
B
Air and ignition vent (A). Adjusts in and out in the horizontal
direction (see fig. 15-17)
Door handle (B). Opens by lifting the handle up and pulling
out.
Valve adjustment
Fig. 15
20mm
1
1. Pulled out completely : Open (used during ignition)
Fig. 15b
A
When the match symbol (A) is displayed, the valve is open for
ignition.
Fig. 16
2
2. Edge-to-edge with ash lip: Max air after ignition
Fig. 17
-25mm
3
3. Pushed in: Closed

13
ENGLISH
4.7 Use
• Open the air vent and the ignition vent by pulling it out all
the way (A). If necessary, keep the door slightly open. (Use
a glove, for example, as the handle can become hot.)
• Place two medium sized logs in/out on each side of the
base. N.B. In order to avoid sooting on the glass, it is
important that the log is not placed adjacent to the glass
on the product.
• Put 2-3 briquettes (or birch bark) between these and add
some kindling wood in a criss-cross pattern on top and
light the newspaper.
• Gradually increase the size of the woodlogs.
• Finally, place a medium-sized log on the top of the pile.
• Then regulate the rate of combustion to the desired level of
heating by adjusting the air vent.
• Close the stove door. It must always be closed when the
fire is lit.
• Operation with the air controls or appliance dampers open
can cause excess smoke. The appliance must not be
operated with air controls, appliance dampers or door left
open except as directed in the instructions.
• Operation with the door open can cause excess smoke.
The appliance must not be operated with the appliance
door left open except as directed in the instructions.
Fig. 18
Adding firewood
Stoke the stove frequently but only add small amounts of fuel
at a time. If the stove is filled too full, the heat created may
cause extreme stress in the chimney. Add fuel to the fire in
moderation. Avoid smouldering fires as this produces the most
pollution. The fire is best when it is burning well and the smoke
from the chimney is almost invisible.
If there is insufficient burning material in the firebed to light
a new fuel charge, excessive smoke emission can occur.
Refuelling must be carried out onto a sufficient quantity of
glowing embers and ash that the new fuel charge will ignite
in a reasonable period. If there are too few embers in the fire
bed, add suitable kindling to prevent excessive smoke.
Danger of overheating
The fireplace must never be used in a manner that causes
overheating.
Overheating occurs when there is too much fuel and/or too
much air so that too much heat develops. A sure sign of
overheating is when parts of the fireplace glow red. If this
happens, reduce the air vent opening immediately.
Seek professional advice if you suspect that the chimney is
not drawing properly (too much/too little draught). For further
information, see «4.0 Installation» (Chimney and flue pipe).
Condensation
Condensation in a fireplace / flue pipe / chimney may occur.
This may be caused by moist firewood or differences in
temperature in the fireplace and environment.
Condensed water coming from the fireplace appears as a
black, tar-like liquid. This should be wiped offimmediately
to avoid discoloration of the fireplace, floor or surrounding
building components.
It is important to get the wood burning quickly to avoid
condensation
.
If the condensation continues, mineral sand can be placed on
the bottom plate.
Removing the ashes
• Only remove ashes when the fireplace is cold.
• Use a showel to scrape the ashes out, but always leave
a little ash at the bottom of the combustion chamber as a
protective insulating layer.
• Ashes should be placed outside in a metal container.
5.0 Daily use
Odours when using the fireplace for the
first time
Odours when using the fireplace for the first time
When the fireplace is used for the first time, it may emit an
irritating gas which may smell slightly. This happens because
the paint dries.The gas is not toxic but the room should be
thoroughly ventilated. Let the fire burn with a high draught
until all traces of the gas have disappeared and no smoke or
odours can be detected.
Heating advice
NB: Logs that have been stored outdoors or in a cold room
should be brought indoors 24 hours before use to bring them
up to room temperature.
There are various ways of heating the stove but it is always
important to be careful about what you put in the stove. See
the section on “Wood quality”.
NB! Combustion with too low air supply can lead to poor
combustion, poorer efficiency, high particulate emissions, black
carbon and other health and climate hazardous compounds.

14
ENGLISH
Wood quality
By quality wood we mean most well-known types of wood
such as birch, spruce and pine.
The logs should be dried so that the moisture content is no
more than 20%.
To achieve this, the logs should be cut during the late winter.
They should be split and stacked in a way that ensures good
ventilation. The wood stacks should be covered to protect the
logs from rain. The logs should be brought indoors during early
autumn and stacked/stored for use in the coming winter.
Be especially careful never to use the following
materials as fuel in your fireplace:
• Household rubbish, plastic bags, etc.
• Painted or impregnated timber (which is extremely toxic).
• Laminated wooden planks.
• Driftwood
These may harm the product and are also pollutants.
NB: Never use petrol, paraffin, methylated spirit or similar
liquids to light the fire. You may cause serious injury to
yourself and damage to the product.
Wood consumption
Jøtul F 602 ECO has a nominal heat output of ca. 5 kW. Use
of wood, with nominal heat emission: Approx. 1,5 kg/h. The
size of the logs should be:
Kindling:
Length: 25-33 cm
Diameter: 5 cm
Amount per fire: 5-8 pieces
Firewood (split logs):
Length: Ca 19 - 33 cm
Diameter: Approx. 4-7 cm
Intervals for adding wood: Approximately every 50 minutes
Size of the fire: 1.4 kg (nominal efficiency)
Amount per load: 2 pieces
The given testresults have been obtained by loading 2 logs á
19 cm, total weight of 1,4 kh.The logs are laid across. Valve
set for about 40 % air, about 10 mm in from the edge.
The maximum amount of fuel specified in this manual
should not be exceeded, overloading can cause excess
smoke.
5.1 How wind and weather affect the
stove
The performance of the stove can be affected considerably by
the wind acting on the chimney at different strengths. It may
therefore be necessary to adjust the air supply to ensure good
combustion performance. It might also be a good idea to install
a damper in the flue pipe so that the chimney draught can be
regulated according to the strength of the wind.
Fog and mist can have a significant impact on the chimney
draught and it might be necessary to use other combustion air
settings to ensure good performance.
5.2 The importance of the chimney
The chimney is the engine that drives the fireplace and it’s
essential to have a good chimney in order for the fireplace
to function properly.
The draught in the chimney creates a vacuum in the stove.
The combustion air is also used for the airwash system that
keeps the window clear of soot.
The draught in the chimney is caused by the difference in
temperatures inside and outside the chimney. The greater
the temperature difference, the better the draught in the
chimney. It is therefore important to allow the chimney to reach
operating temperature before adjusting the air vents to restrict
combustion in the stove (a brickwork chimney takes longer to
reach operating temperature than a steel chimney).
It is particularly important to reach operating temperature
as quickly as possible on days on which the draught in the
chimney is poor due to unfavourable wind and weather
conditions. Make sure the fuel ignites as quickly as possible.
Practical tip: Chop the wood into much smaller pieces and use
an extra firelighter.
NB: If the stove has not been used for some considerable
time, it is important to check the chimney pipe for blockage.
6.0 Maintenance
6.1 Cleaning the glass
The product is equipped with an air wash for the glass. Air is
sucked in through the air vent on the top of the product and
down along the inside of the glass.
However, some soot will always stick to the glass, but the
quantity will depend on the local draught conditions and
adjustment of the air vent. Most of the soot layer will normally
be burned offwhen the air vent is opened all the way and a fire
is burning briskly in the fireplace.
Good advice! For normal cleaning, moisten a paper towel
with warm water and add some ash from the burn chamber.
Rub it over the glass and then clean the glass with clean water.
Dry well. If it is necessary to clean the glass more thoroughly
we recommend using a glass cleaner (follow the instructions
on the bottle).
6.2 Cleaning and soot removal
Soot deposits may build up on the internal surfaces of the
fireplace during use. Soot is a good insulator and will therefore
reduce the fireplace’s heat output. If soot deposits accumulate
when using the product, they can be easily removed by using
a soot remover.
In order to prevent a water and tar layer from forming in the
fireplace you should regularly allow the fire to burn hot in order
to remove the layer. An annual internal cleaning is necessary
to get the best heating effect from the product. It is a good idea
to do this in connection with the sweeping of the chimney and
flue pipes.

15
ENGLISH
6.3 Sweeping of flue pipes to the
chimney
On certain free-standing fireplaces the top plate can be lifted
offand the pipe swept through the top.
Otherwise, flue pipes must be swept through the flue pipe
sweeping hatch or through the product’s door opening. Then,
the baffle must be removed.
6.4 Inspection of the fireplace
Jøtul recommends that you personally inspect your fireplace
carefully after sweeping/cleaning. Check all visible surfaces
for cracks. Also check that all joints are sealed and that the
gaskets are in the correct position. Any gaskets showing signs
of wear or deformation must be replaced.
Thoroughly clean the gasket grooves, apply ceramic glue
(available from your local Jøtul dealer), and press the gasket
well into place. The joint will dry quickly.
6.5 Exterior maintenance
Painted products may change colour after several years
usage. The surface should be cleaned and brushed free of
any loose particles before new paint is applied.
Important! Never place anything on the top plate of the
stove. This could cause permanent damage to the paint
or enamel.
7.0 Service
Any unauthorised modifications to the product are prohibited!
Only original spare parts may be used!
Fig. 19
Exhaust deflector
Baffle plate
Burn plates
Inner bottom
7.1 Replacing parts in the burn
chamber
Use tools with great care.
Replacing the baffle plate
Fig. 20 Removing the hot plate and smoke outlet cover
A
B
1. Lift the hot plate (A)
2. Unscrew the smoke outlet cover (B)
Fig. 21 Loosen nuts on the baffle plate
A
3. Loosen the nut (A) on top/back of the baffle plate

16
ENGLISH
Fig. 22 Loosen nuts on the baffle plate
4. Loosen the two nuts on top of the baffle plate
5. Remove the left and right burn plate(see figur 26)
Fig. 23 Unscrew the screws in the baffle plate
6. Unscrew the three screws holding the baffle plate in place.
Fig. 24 Removing the baffle plate
7. Tilt the baffle plate out of the stove.
8. When refitting, follow the same procedure in reverse order.
(first see fig. 25)
Fig. 25 Replace gasket against backplate
A
9. The gasket (A) will break when removing the baffle
plate. This must be replaced by putty / fiber pulp when
reassembling a new baffle plate.

17
ENGLISH
7.2 Replacing the burn plates/inner
bottom
Fig. 26 Replacing the burn plates
A
1. Remove the burn plate (A) by lifting and tilting the burn plate
out of the stove.This is done on both sides of the combustion
chamber. When refitting, follow the same procedure in
reverse order.
Fig. 27 Replacing the inner bottom
1. Tilt up the left inner bottom, then tilt it out of the stove. Do
the same with the right inner bottom.When refitting, follow
the same procedure in reverse order.
Fig. 28 Replacing the exhaust reflector
A
1. Remove the hot plate (see fig. 20)
2. Lift the exhaust reflector (A) up from the slot and tilt it out.
1. When refitting, follow the same procedure in reverse order.
8.0 Operational problems -
troubleshooting
Poor draught
Check the length of the chimney and that it complies with
national laws and regulations. (See also «2.0 Technical
data» and «4.0 Installation» (Chimney and flue pipe) in the
installation manual for information.)
Make sure that the minimum cross section on the chimney is
according to «2.0 Technical data» in the installation manual.
Make sure that there is not anything preventing the smoke
gasses from escaping: branches, trees, etc.
Upon suspicion of excessive/poor draught in the chimney,
seek professional help for measurement and adjustment.
The fire extinguishes after a while
• Make sure that the firewood is sufficiently dry.
• Find out whether there is negative pressure in the house,
close mechanical fans and open a window close to the
fireplace.
• Check that the air vent is open.
• Check that the flue outlet is not clogged by soot.
Unusual amount of soot accumulates on
the glass
Some soot will always stick to the glass, but the quantity
depends on:
• Moisture in the fuel.
• The local draught conditions.
• Air vent opening.
Most of the soot will normally burn offwhen the air vent is
opened all the way and a fire is burning briskly in the fireplace.

18
ENGLISH
9.0 Optional equipment
9.1 External air supply cover
Cat. no. 10055054
9.2 Heat shield
Cat. no. 10054507
9.3 Hotplate Ø125
Cat. no. 51054941
9.4 External air adaptor
Cat. no. 51054938
9.5 External air kit Ø80
Cat. no. 51047509
10.0 Recycling
10.1 Recycling packaging
Your fireplace is delivered with the following packaging:
• A wooden pallet that can be cut up and burned in the
fireplace.
• Cardboard packaging that should be taken to a local
recycling facility.
• Plastic bags that should be taken to a local recycling facility.
10.2 Recycling the fireplace
The fireplace is made of:
• Metal that should be taken to a local recycling facility.
• Glass that should be disposed of as hazardous waste.
The glass in the fireplace must not be placed in a regular
source segregation container.
• Vermiculite burn plates that can be disposed of in regular
waste containers.
11.0 Guarantee terms
1. Our guarantee covers:
Jøtul AS guarantees that the external cast-iron parts are
free from defects in materials or manufacturing at the time of
purchase. You may extend the guarantee on the external cast-
iron parts to 25 years from the date of delivery by registering
the product on jotul.com, and print out the extended guarantee
card within three months of purchase. We recommend that
the guarantee card be kept together with the receipt. Jøtul AS
also guarantees that steel plate parts are free from defects in
materials or manufacturing at the time of purchase for a period
of 5 years from the date of delivery.
The guarantee applies on the condition that the stove has been
installed by a qualified installer in accordance with applicable
laws and regulations and Jøtul’s installation and operating
instructions. Repaired products and replacement items are
guaranteed within the original guarantee period.
2. The guarantee does not cover:
2.1. Damage to consumables such as burn plates, fire grates,
flue baffles, gaskets and similar as these deteriorate over
time due to normal wear and tear.
2.2. Damage caused as a result of improper maintenance,
overheating, use of unsuitable fuel (e.g of unsuitable fuel
are, but not limited to driftwood, impregnated wood, plank
offcuts, chipboard ) or too moist / wet wood.
2.3. Installation of optional extras for the purpose of rectifying
local draught conditions, air supply or other circumstances
beyond Jøtul’s control.
2.4. Cases involving alterations / modifications to the fireplace
without Jøtul’s consent or the use of non-original parts.
2.5. Damage caused during storage at a distributor, transport
from a distributor or during installation.
2.6. Products sold by unauthorized sellers in areas where
Jøtul operates a selective distribution system.
2.7. Associated cost (e.g.but not limited to, transport,
manpower, travel) or indirect damages.
Pellets stoves, glass, stone, concrete, enamel and paint
finish (e.g. but not limited to chipping, cracking, bubbling or
discolouration and crazing) are applicable to the national
legislation governing the sale of consumer goods. This
guarantee is valid for purchases made within the territory of
the European Economic Area. All guarantee inquiries must
be addressed to your local authorized Jøtul dealer within a
reasonable amount of time, which shall not be later than 14
days from the date on which the fault or defect first became
apparent. See list of importers and dealers on our web site
www.jotul.com.
If Jøtul is unable to meet the obligations outlined in the above
guarantee terms, Jøtul will offer a replacement product with a
similar heating capacity free of charge.
Jøtul reserve the right to decline of any replacement of parts
or service in the event that the guarantee is not registrated
online. This guarantee does not affect any rights under
applicable national legislation governing the sale of consumer
goods. The national complaint right applies from the purchase
date and only in exchange for a receipt / serial number.

19
ENGLISH

20
ENGLISH
