Jabra GO 6470 Installation and user guide

How to connect my Jabra PRO 9400 / GO 6470 with Siemens
OpenStage 30,40,60,80
Jabra GO 6470
Prerequisite:
Jabra PRO 9460 / Jabra PRO 9470 + Jabra LINK 14201-10
In combination with one of the following phones:
Siemens OpenStage 30/40/60/80
Connection:
1. Plug the 1-sided end of the DHSG cable marked blue into the phone
socket marked with a "headset" symbol.
2. Insert the RJ9 plug of the DHSG cable into the headset base socket
marked with a "phone" symbol and the RJ45 plug into the socket
marked with "AUX".
Then follow the instructions of the Jabra PRO 9400 / Jabra GO 6470 base
SmartSetup Wizard.
Select phone settings, "Desk phone", then "Connect to a desk phone?",
"Manual".
06/04/2021 08:59
https://www.jabra.co.nz/supportpages/jabra-go-6470/6470-15-207-503/faq/6d386e88-
c460-4f09-8ac6-00eb36f71030
Page 1 of 3

Select adapter type "DHSG"
Base setup:
Set the phone setup switch to position "A".
Microphone volume setting:
We recommend setting the microphone volume to 6 out of 13.
Guided set-up:
As part of the installation you can dial into the local Jabra Setup Server
that takes care of configuring the audio path. Please follow the
06/04/2021 08:59
https://www.jabra.co.nz/supportpages/jabra-go-6470/6470-15-207-503/faq/6d386e88-
c460-4f09-8ac6-00eb36f71030
Page 2 of 3

instructions shown on the display. If your Jabra Setup Server is
unavailable, please contact your local Jabra support team.
Phone setup:
Important: For the equipment software 3.18 the headset operation must
be set up additionally on the phone.
OpenStage 30/40: Menu> Audio Accessories> Headset> Cordless
OpenStage 60/80: Menu> User> Audio> Settings> Headset> Cordless
Important: The dial tone signal in the headset is transmitted only if the
standard ringtones are used. No ringtone is transmitted for mp3 ringtones.
