Jabra STONE User manual

User manual
www.jabra.com
Jabra®STONE

1
english
JABRA STONE
Contents
THANK YOU....................................................2
ABOUT YOUR JABRA STONE....................................2
WHAT YOUR HEADSET CAN DO ................................2
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CHARGE YOUR HEADSET.......................................5
TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 5
PAIRING IT WITH YOUR PHONE .................................6
WEARING STYLE ...............................................7
HOW TO .......................................................7
WHAT THE LIGHTS MEAN ......................................8
USING YOUR JABRA STONE WITH TWO MOBILE DEVICES .......9
TROUBLESHOOTING & FAQ ...................................10
NEED MORE HELP?............................................12
TAKING CARE OF YOUR HEADSET .............................13
GLOSSARY ....................................................13

2
english
JABRA STONE
tHAnK YoU
Thank you for purchasing the Jabra STONE headset. We
hope you enjoy it! This instruction manual will get you started and
ready to make the most of your headset.
ABoUt YoUR JABRA stone
A Answer/End button
B StatusDisplayTM on headset
C Light indicator on portable charging unit
D Charging socket
E Volume control touch panel
F Microphones
G Earhook
H Eargel
I Clothing clip
A
BE
F
G
H
I
C
D
WHAt YoUR HeADset CAn Do
Jabra STONE is a headset with a completely new shape
that sits discreetly on your ear. It comes with an integrated portable
charger that both functions as a holder and a portable charger
when you are not on a call.

3
english
JABRA STONE
Your Jabra STONE lets you do all this:
- Answer or end phone calls
- Last number redialling
- Adjust volume up or down
- Voice dialling
- Three way calling
- MultiUseTM – be connected to two devices at the
same time (for instance your PC and mobile phone)
- Listen to music in your headset through your
enabled phone
Specifications:
Call:
- Talk time up to 8 hours (2 hours in headset and 6 additional
hours in the portable charging unit)
- Dual Microphone solution for Noise BlackoutTM Extreme
- Digital sound enhancement via DSP technology
- Noise reduction on transmitted and received audio
- Noise dependent volume control* (Volume is adjusted
automatically when you enter a noisy environment)
- Automatic volume adjustment on received audio (Volume is
adjusted automatically if incoming voice is too low)
- Audio shock protection
- Qualified for Specification version 2.1, supporting
Headset and Hands-free Profiles for phone conversations,
Advanced Audio Distribution Profile (A2DP) for streaming
music and Simple Secure Pairing for pairing functionality with
mobile phone without pincode
- e-SCO for enhanced audio quality
- Up to 128-bit encryption
* Refer to phone’s user manual

4
english
JABRA STONE
Music:
- Music time up to 2 hours in headset and up to 6 hours extra
music time in portable charging unit, standby time up to 12 days
(charging unit and headset together)
- A2DP (Advanced Audio Distribution Profile) for streaming
music
The device:
- On/off function is automatic. When the headset is taken out of
portable charging unit, it is on, and when it is inserted into the
portable charger, it is off. When your phone rings, you can take
the headset out of the portable charging unit and take the call
on the headset
- Charging is intelligent. The headset charges automatically
when inserted into the portable charging unit ensuring that
your headset is always fully charged ready for your next
conversation
- StatusDisplayTM with indicators for both connectivity
and battery status ensures that you always know the status of
your headset and your portable charging unit
- Size of portable charging unit and headset clicked together:
H 58 mm x W 51 mm x D 25 mm
- Weight: Total weight is 33g (Headset weighs 7g and portable
charging unit weighs 26g)
- Operating range up to 10 meters (approximately 33 feet)
GettInG stARteD
You should follow three steps before using your new headset:
1 Charge your headset (approximately 2 hours)
2 Activate on your mobile phone (refer to the
manual for your Mobile phone)
3 Pair your headset to your mobile phone

5
english
JABRA STONE
CHARGe YoUR HeADset
Make sure that your Jabra STONE is fully charged before you start
using it. Place the headset in the portable charging unit to charge
both headset and portable charger fully for the first time before
start using it. Use the AC power supply to charge from a power
socket. While charging, the battery indicator on the portable
charging unit shows solid red light and when the light indicator
turns off, the headset and portable charger are fully charged.
Charging time for both units clicked together is 2 hours. You can
use the headset during recharge of the portable charging unit.
Use only the charger provided in the box – do not user chargers
from any other devices as this may damage your headset.
Please note: The lifetime of the battery will be significantly
reduced if your device is left uncharged for a long period. We
therefore recommend that you recharge your both headset and
portable charger together at least once a month.
tURnInG YoUR HeADset on AnD oFF
Taking the headset out of the portable charging unit will turn it on.
Inserting the headset into the portable charging unit will turn it off.
- Taking it out: Place a finger on the backside of the portable
charging unit and press lightly on the headset sliding it free
of the charging unit. This way you easily can take it out of the
charging unit with the other hand.
- Inserting it: Place the headset in the charging unit and press lightly
on the headset to click the headset into the charging unit.
Please note: It is possible to turn off the headset manually without
using the portable charging unit. Press answer/end button for
4-5 seconds to turn it on/off.

6
english
JABRA STONE
PAIRInG It WItH YoUR PHone
Headsets are connected to phones using a procedure called
‘pairing’. By following a few simple steps, a phone can be paired
with a headset in a matter of seconds.
1 Put the headset in pairing mode
1.a First time pairing
- Take the headset out of the portable charging unit. The
headset will automatically start up in pairing mode (showing
flashing blue light on the Jabra StatusDisplayTM) and start
searching for a device.
1.b Pairing with another phone or re-pairing
- Take headset out of the portable charging unit. Turn the
headset off by long press on Answer/End button. Turn the
headset on again by long press on Answer/End – keep pressing
until StatusDisplayTM show flashing blue light.
2 Set your phone to‘discover’ the Jabra STONE
- Follow your phone’s instruction guide. First make sure that
is activated on your mobile phone. Then set your
phone to discover the headset. This usually involves going
to a‘setup,’‘connect’or‘ ’menu on your phone and
selecting the option to ‘discover’or‘add’ a device.*
3 Your phone will find the Jabra STONE
- The phone will find the headset under name“Jabra STONE”.
- Your phone then asks if you want to pair with the headset.
- Accept by pressing ‘Yes’or‘OK’on the phone. If your phone
asks for passkey or PIN confirm with 0000 (4 zeros). Your phone
will confirm when pairing is complete. Jabra STONE supports
version 2.1 including Simple Secure Pairing meaning
that the headset can be paired with a phone or other
device without using PIN or passkey but only if the other
device supports version 2.1 also.
CONNECTIVITY
SELECT
MobilSurf
BLUETO O T H
Infrared port
Wap options
Synchronization
Networks
DEVICES FOUND
Jabra STONE
Jabra STONE
OK
Passkey:
****
HANDSFREE
SELECT
Jabra STONE
added.
The handsfree is
now ready for use
SELECT
* Refer to phone’s user manual

7
english
JABRA STONE
WeARInG stYLe
Wear Jabra STONE on your right ear and enjoy the comfort.
HoW to
THe Jabra STONE is easy to operate. The Answer/End button
performs different functions depending on how long you press it:
Instruction Duration of press
Tap Press briey
Double tap Press briey two times within 1/2
second
Press Approx: 1-3 second
Long press Approx: 4-5 seconds
Extra long press Approx: 5-10 seconds
Answer a call
- Tap the Answer/End button
End a call
- Tap the Answer/End button
Reject a call*
- Press the Answer/End button when the phone rings to reject
an incoming call. Depending on your phone settings, the
person who called you will either be forwarded to voice mail or
hear the busy signal
Make a call*
- When your Jabra STONE is connected to your phone, all calls
made from your phone will automatically be transferred to
your headset. (Subject to phone settings)
Last number redial**
- Double tap the Answer/End button
* Refer to phone’s user manual
** Phone dependent

8
english
JABRA STONE
Adjust volume**
- Slide your finger upwards on the front of the headset to turn
up the volume and slide your finger downwards to turn the
volume down
Activate voice dialling*
- Press Answer/End to activate voice dialling
Three way calling
- Press Answer/End to switch to call on hold. Press Answer/End
again to switch back to first call
Show display
- Insert headset into Jabra STONE charger and take it out again
to check battery status and connectivity status
Play music (Some phones may require that you start a Media
Player first)*
- Music is controlled on the mobile phone
Answer a call while playing music**
- When listening to music and receiving a call, the music will
pause and you will hear your ringtone
WHAt tHe LIGHts MeAn
There are light indicators on the headset and on the portable
charging unit to ensure ease of use.
Light indicators on headset:
On the inside of the headset the Jabra StatusDisplayTM indicates
different states of the product. The Jabra StatusDisplayTM consists
of 2 light indicators – a battery indicator and a
connection indicator. That way you will always know if the headset
is connected to your phone and if your battery in your headset
needs to be charged.
Headset - light indicators
Battery
indicator
Solid green light Battery OK
Solid red light Less than 10 min talk
time left
indicator
Flashing blue light In pairing mode
Solid blue light Paired with phone
* Refer to phone’s user manual
** Phone dependent

9
english
JABRA STONE
Jabra STONE StatusDisplayTM will turn off after 4 seconds of
non-activity to save battery. Only when in pairing mode the
StatusDisplayTM will remain turned on for longer time (3 min).
The headset is still active.
Light indicator on charging unit:
By the charge plug on the charging unit a light indicator shows
different states of the charging unit. That way you will always
know if the charging unit needs to be charged.
Portable charging unit - light indicator
Solid red light Is charging (red light will turn o when
fully charged)
Single green ash Enough battery to charge headset
1 full time or more
Single red ash Portable charger needs to be charged
UsInG YoUR JABRA stone WItH tWo MoBILe
DeVICes
The Jabra STONE is capable of having two mobile phones (or
devices) connected to the headset at the same time.
This will give you the freedom of having only one headset to
operate both of your mobile phones.
How to pair your Jabra STONE with 2 devices:
1 Pair device number 1 with your headset using the pairing
instruction above for re-pairing your headset (if device 1 is
paired to your headset already go to step 2)
2 Turn your headset off manually by pressing the Answer/End
button for 4-5 seconds
3 Pair device number 2 with your headset using the same pairing
instruction again
4 Connect to device 1 again
Please note that it is important to connect to device 1 again after
pairing device 2 to ensure connection to both devices.

10
english
JABRA STONE
tRoUBLesHootInG & FAQ
I hear crackling noises
- is a radio technology, which means it is sensitive to
objects between the headset and the connected device. It is
designed for the headset and the connected device to be used
within 33 feet (10 meters) of each other, with no major objects
in the way (walls, etc.).
I cannot hear anything in my headset
- Increase the volume in the headset
- Ensure that the headset is paired to a device that is playing
- Make sure your phone is connected to the headset by tapping
the Answer/End button
I am having pairing problems
- You may have deleted your headset pairing connection in your
mobile phone - follow the pairing instructions in ‘Pair Your
Headset to a Phone or other Device’
Will the Jabra STONE work with other equipment?
- The Jabra STONE is designed to work with mobile
phones. It can also work with other devices that are
compliant with version 1.1 or higher and support a
headset, hands-free and/or advance audio distribution profile
(A2DP)
I cannot use Reject call, call on hold, Redial or voice dialling
These features are dependent on the ability of your phone to
support a hands-free profile. Even if the handsfree profile is
implemented reject call, call hold and voice dialling are optional
features which are not supported by all devices. Please consult
your device manual for details
Please note that some features can only be operated from the
primary device e.g. voice dial using Jabra STONE with 2 mobile
phones

11
english
JABRA STONE
I cannot hear music in the headset
- Ensure that the headset is connected to your
enabled device
- You may have been out-of-range (10 meters) to your
enabled device or the headset might have experienced an
ESD (Electrostatic discharge) incidence. Press the Answer/End
button to re-establish the audio link
- Increase the volume on your device
- Make sure that the Jabra STONE is charged
- Turn the headset off. Wait a couple of seconds, press the answer/
end button until yellow light comes on. Set your phone to
discover Jabra STONE and your phone will find it. Connect and
you should now be able to listen to music
The music I hear sounds very poor
Make sure the other device supports 1.1 or higher
including the Advanced Audio Distribution Profile (A2DP) for
music streaming. If the above procedure did not help then it is
possible that your phone is using the stereo audio connection
in a different way. You can enable this mode on Jabra STONE by
performing pairing in the following way:
- Remove the connection to Jabra STONE on your
phone
- Make sure the headset is charged
- Take the headset out of the portable charging unit
- Press the Answer/End button for 10-15 seconds until the
connection indicator shows solid yellow light
- Go through the regular steps in pairing the headset to a
device
Be aware that standby time of the Jabra STONE can be lower when
using this pairing compared to the regular one.
The music player starts immediately upon connection and
I hear music in the headset
- Turn the headset off. Wait a couple of seconds, press the answer/
end button until yellow light comes on. Set your phone to
discover Jabra STONE and your phone will find it. Connect and
music should start only when asked for.

12
english
JABRA STONE
neeD MoRe HeLP?
1. Web: www.jabra.com
(for the latest support info and online User Manuals)
2. E-mail:
Deutsch suppor[email protected]
English suppor[email protected]om
Español suppor[email protected]om
Français suppor[email protected]
Italiano suppor[email protected]
Nederlands suppor[email protected]
Polska suppor[email protected]om
Scandinavian suppor[email protected]om
Россия suppor[email protected]
Information: [e-mail]
3. Phone:
Belgique/Belgie 00800 722 52272
Danmark 70 25 22 72
Deutschland 0800 1826756
Die Schweiz 00800 722 52272
España 900 984572
France 0800 900325
Italia 800 786532
Luxembourg 00800 722 52272
Nederland 0800 0223039
Norge 800 61272
Österreich 00800 722 52272
Polska 0801 800 550
Portugal 00800 722 52272
Suomi 00800 722 52272
Sverige 020792522
United Kingdom 0800 0327026
Россия [phone]
International 00800 722 52272

13
english
JABRA STONE
tAKInG CARe oF YoUR HeADset
- Always store the Jabra STONE with the power off and safely
protected
- Avoid storage at extreme temperatures (above 45°C/113°F –
including direct sunlight – or below -10°C/14°F). This can shorten
battery life and may affect operation. High temperatures may
also degrade performance.
- Do not expose the Jabra STONE to rain or other liquids.
GLossARY
1. is a radio technology that connects devices, such
as mobile phones and headsets, without wires or cords over
a short distance (approx. 10 meters/33 feet). is safe
to use. It is secure too, so once a connection has been made
no-one can listen in and there is no interference from other
devices either. Get more information at
www.bluetooth.com.
2. profiles are the different ways that
devices communicate with other devices. phones
support the headset profile, the hands-free profile or both. In
order to support a certain profile, a phone manufacturer must
implement certain mandatory features within the phone’s
software.
3. Pairing creates a unique and encrypted link between two
devices and lets them communicate with each other.
devices will not work if the devices have not been
paired.
4. Passkey or PIN is a code that you enter on your enabled
device (e.g. a mobile phone) to pair it with your Jabra STONE.
This makes your device and the Jabra STONE recognize each
other and automatically work together.
5. Standby mode is when the Jabra STONE is passively waiting for
a call. When you‘end’a call on your mobile phone, the headset
goes into standby mode.
Dispose of the product according
to local standards and regulations.
www.jabra.com/weee

81-03033 D
© 2009 GN Netcom A/S. All rights reserved. Jabra®is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth®word
mark and logos are owned by the Bluetooth SIG, Inc. and any use
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
www.jabra.com
MADE IN CHINA
TYPE: BTE2
© 2009 GN Netcom US, Inc. All rights reserved. Jabra®is a registe-
red trademark of GN Netcom A/S. All other trademarks included
herein are the property of their respective owners. The Bluetooth®
word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by GN Netcom A/S is under license. (Design
and specifications subject to change without notice).
