Operating Manual

POWER JUICER ELITE
4
5
6
7
10
11
13
14

POWER JUICER ELITE
Contents 3
Contents
Important Safety Information
Helpful Hints
Parts/Main Unit
Assembly/Main Unit
Assembly/E-Z Loader Attachment
Disassembly/Main Unit
Cleaning Your Power Juicer
Troubleshooting
4
5
6
7
10
11
13
14

READ THESE SAFEGUARDS CAREFULLY
BEFORE USING THIS PRODUCT!
When using electrical appliances, basic safety precautions should always
be followed including the following:
• Always remove power cord from electrical outlet before assembly or disassembly.
• NOT FOR USE BY CHILDREN! Keep out of the reach of children to avoid injury.
This appliance is not a toy.
• Consult your physician before giving fresh juice to children, especially infants.
• Be sure to turn to OFF position after each use of your juicer
• TO AVOID PERSONAL INJURY: Never look inside the chute while the machine is running.
Especially when using fruits or vegetables that contain pits. Shut down the machine and wait
for the blade to stop spinning. Remove power cord from electrical outlet before removing
the pits from the chute.
• Make sure the lid is attached properly and securely locked before operating the Juicer.
• Do not unfasten the locking bar during operation.
• To avoid risk of injury keep hands and utensils out of the juicer and away from its sharp blade
during operation.
• Use the pusher, not fingers or utensils, to propel the food into the juicer.
• Should food become lodged in the opening use pusher to push it down. If food remains stuck, turn
the power off, wait until motor stops, unit shuts down completely, and is unplugged
before disassembling the juicer and removing the blocked food.
• Make sure the motor stops completely and the unit is unplugged from the electrical
outlet before cleaning, putting on or removing parts.
• To protect against risk of electrical shock or injury, never immerse power cord,
plug, or main unit in water, or other liquids.
• If juicer stops due to improper operation or if there is excessive noise, turn power off, wait for
blade to stop spinning, unplug from electrical outlet, disassemble and clean all components then
reassemble machine.
• Do not use outdoors.
• Do not operate this or any appliance with a damaged cord or plug.
• Do not operate if appliance malfunctions, is dropped or damaged in any manner. Let a qualified
appliance repair person examine and or repair appliance before using.
• To avoid electric shock or serious injury do not use any attachments that were not recommended
or sold by the manufacturer.
• Do not let power cord hang over the edge of table, counter, or let cord touch hot surfaces
such as stoves.
• To reduce the risk of injury, never place blade on base without properly assembling the unit.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not
modify or force the plug in any way.
• The motor will not run if unit is not properly assembled. The motor has a built-in safety
feature that will not let the power turn on unless the locking bar is locked in place.
SAVE THESE INSTRUCTIONS
Important Safety Information
POWER JUICER ELITE
4Important Safety Information

Additional Safeguards
Follow these helpful hints to obtain the best results from your Power Juicer Elite.
• Do not put any fruit or vegetables in your machine until power is turned on and the motor is spinning.
• Allow unit to run for at least 10 seconds before juicing.
• Do not force food into the juicer. Allow food to pass through slowly and steadily using the pusher. You do not
need to apply pressure unless the juicer starts to vibrate. Then only a slightly harder push should bring it back
to balance.
• Any fruit or vegetable that will fit the chute can be put through whole. The only time it is necessary to cut is
when something is too large. Then it should be cut into large enough pieces to fit in the chute. Do not cut
pieces too small.
• Remove large pits such as peach, mango, etc. as they will damage the blade and possibly the unit. Before
juicing cherries we recommend you remove the pits using a cherry pitter.
• Cleaning can be made easy by placing a plastic bag inside the pulp collector container. When you are done
juicing, the bag can be lifted out and disposed of easily leaving the pulp collector easier to clean.
• Let the Juicer run for a few minutes before turning off to allow any excess juice to be extracted from the
pulp. Once turned off it is quite normal for the juicer to spin for a minute or so due to the very fine precision
balancing of this appliance. Wait until it is done spinning before disassembling.
• Do not use bananas or avocados as they do not contain juice and will clog machine. Add them separately in a
blender.
• We do not recommend using overripe fruit as it will leave too much pulp in the filter and clog the machine.
• Do not pour liquids into the machine at any time unless you are following instructions for making soy, rice, or
nut milk.
• When using smaller or thin items add more. For Example, insert carrots 2 or 3 at a time into the chute for
best results.
• When juicing herbs or wheat grass wrap them in larger leafed vegetables such as spinach, cabbage etc. and
follow by a fruit or vegetable that contains an abundance of juice such as pineapple, apple etc.
• When juicing carrots that are not the same size. Insert carrots into chute. Do not use pusher
until the largest carrot has processed. Once they are the same size you can use pusher to
continue until carrots have been processed.
POWER JUICER ELITE
Helpful Hints 5
Important Safety Information
Helpful Hints
CAUTION
Use caution when handling blade as blades are very sharp.
If juicer jams turn power off immediately and remove power cord from electrical outlet before
disassembling to clean.
The Power Juicer has a thermal cut-off safety feature. If the unit accidentally overheats, it will stop
working temporarily until the Power Juicer cools down. Clear any obstruction. Afterwards, the unit will
continue to work again normally.
The Power Juicer has a thermal cut-off safety feature. If the unit accidentally
overheats, it will stop working temporarily until the Power Juicer cools down.
Afterwards, the unit will continue to work again normally.
In the event the Power Juicer is jammed the motor may shut down. If this occurs
the juicer should be shut off and unplugged. The unit should be thoroughly cleaned
to remove the obstruction. The thermal cut-off safety feature is designed to shut off
the motor when it over heats.
Please use extreme caution when handling the Power Juicer blade as the blades are very sharp.
Always turn power off to the Power Juicer immediately and remove power cord from electrical outlet before
disassembling to clean due to any food obstruction.

POWER JUICER ELITE
6Parts/Main Unit
Lip
Chute
Screw Peg
Micro
Safetyswitch
MAIN UNIT
(Fully Assembled)
Receptacle
Removable
Non-Drip
Spout
Pegs
(Pegs fit into blade.)
Filter
Blade
E-Z Loader Attachment
with E-Z Plug
Lid with Pulp Guard
Pulp
Collector
Pusher
Base
Locking Bar
Assembly
Main Unit
Parts
Main Unit
Micro Reset Switch
Crescent Tool
(for tightening and removing blade)
WARNING: DO NOT OVER TIGHTEN)

Assembly/Main Unit 7
STEP 2:
Place receptacle on the base, with
juicer spout facing the same direction
as locking bar. Settle receptacle
into alignment.
STEP 1:
WARNING: Never plug the
power cord into an electrical outlet
before unit is fully assembled.
Place base on a dry flat surface with
locking bar in down position on
the spout side in front of the
machine (as shown).
STEP 3:
Place filter inside receptacle,
matching the opening on its
bottom to the screw peg
connected to the base.
Note: Refer to page
6 for all part names.
POWER JUICER ELITE
Parts/Main Unit
MAIN UNIT
(Fully Assembled)
Assembly
Main Unit

POWER JUICER ELITE
8Assembly/Main Unit
STEP 4:
Place blade inside filter, centered
over screw peg. Using orange
crescent tool, place its pegs
into the holes on the blade.
Turn clockwise while holding
the filter and receptacle in place
until tight (as shown).
STEP 6:
Place lid with built-in pulp guard on top
of receptacle, making certain it is snugly
aligned with the pulp guard facing in
the opposite direction of the juice spout.
STEP 5:
Place the pulp collector so that it rests under
the backside of the juicer.
POWER JUICER ELITE
IMPORTANT: There are MIN/MAX arrow markings on the
orange rim of the filter. These markings prevent you from
overtightening or undertightening the blade. Crescent
tool should line up between MIN/MAX arrows (as shown).
CAUTION: Remove crescent tool and set
aside. Do not leave tool inside juicer.
Note: Refer to page
6 for all part names.
Main Unit
Assembly
MIN/MAX
Arrow Markings
Filter
Crescent Tool
IMPORTANT: There is a Micro Safetyswitch located
in the back center of the pulp collector base.
This mechanism is an added safety
feature. Once the pulp collector
is in place the Activating Pin on
the bottom of the pulp collector
activates the Micro Safetyswitch.
This will protect you from accidentally
putting hands or fingers under the
machine while the blade is spinning.
Once the pulp collector is removed from
the main base the motor will not run.
Activating Pin
(Bottom of
pulp collector)
Micro
Safetyswitch
Micro
Safetyswitch

POWER JUICER ELITE
Assembly/Main Unit 9
Main Unit
STEP 9:
Insert pusher into chute. Always use
pusher to feed fruits and vegetables
into unit. Push gently, never force.
The blade will do the work.
WARNING: WHEN JUICING
CHERRIES MAKE SURE THE POWER
IS OFF AND BLADE HAS STOPPED
SPINNING BEFORE REMOVING
THE PUSHER FROM
THE CHUTE.
STEP 8:
Lock lid into place by lifting locking
bar up until it clicks into grooves located
on both sides of the lid.
Make sure locking bar is in the full
upright, locked position.
IMPORTANT: The unit will not start until this bar
is properly locked in place.
STEP 7:
Make sure juice spout is
in the downward position.
If the juice spout is left
in the upright position
the juice will not flow.
It will stay in the receptacle
and may overflow from the
sides.
DOWNWARD POSITION
UPRIGHT POSITION
Assembly/Main Unit
STEP 4:
Place blade inside filter, centered
over screw peg. Using orange
crescent tool, place its pegs
into the holes on the blade.
Turn clockwise while holding
the filter and receptacle in place
until tight (as shown).
STEP 6:
Place lid with built-in pulp guard on top
of receptacle, making certain it is snugly
aligned with the pulp guard facing in
the opposite direction of the juice spout.
POWER JUICER ELITE
Note: Refer to page
6 for all part names.
Assembly

Assembly
STEP 1:
Remove pusher from chute. Insert
the E-Z Loader Attachment into the
chute lining up the flat side of the
container base to the flat side of
the chute. Secure attachment.
• TO AVOID PERSONAL INJURY: Never look inside the chute while the machine
is running. Especially when using fruits or vegetables that contain pits. Shut down
the machine and wait for the blade to stop spinning. Remove power cords from
electrical outlet before removing the pits from the chute.
• When using the E-Z Loader Attachment with fruits or vegetables that have pits
such as cherries always replace the E-Z Plug in the bottom of the container to
avoid pits from bouncing out of the chute.
• When juicing you must remove the cherry pits from the chute once the juice
has been extracted. Shut the power off and wait for blade to stop spinning before
disassembling the machine to remove the pits.
E-Z Loader Attachment
STEP 2:
Insert the clear, E-Z Plug into the
opening at the bottom of the container.
Pull the string up over
the top of the container (as shown).
Load ingredients.
Note: When not using E-Z Loader
Attachment replace with pusher.
Important Safety Information
READ THESE SAFEGUARDS CAREFULLY
BEFORE USING YOUR E-Z LOADER ATTACHMENT!
POWER JUICER ELITE
10 Assembly/E-Z Loader Attachment
Note: Refer to page
6 for all part names.

STEP 2:
Lower the locking bar (silver) into
position as shown until it rests on
flat surface.
STEP 3:
Remove lid with pulp guard.
STEP 4:
Remove pulp collector.
Disassembly
STEP 1:
WARNING: Before
disassembling the unit make
sure the power is OFF and remove
power cord from the electrical
outlet.
Place unit on a dry, flat stable surface
Remove pusher from chute.
Main Unit
POWER JUICER ELITE
Disassembly/Main Unit 11
Assembly/E-Z Loader Attachment
Note: Refer to page
6 for all part names.
Note: Refer to page
6 for all part names.

Pusher
STEP 5:
Use the crescent tool to
remove the blade. Place the
two pegs at either end of the
crescent tool into the two
holes on the blade. Press
down and turn counter-
clockwise while holding filter
and receptacle to unlock
the blade. Remove blade
carefully.
Disassembly
STEP 6:
Remove filter.
STEP 7:
Make sure spout is in the upright
position to avoid leakage. Remove
receptacle from base.
STEP 8:
Wipe down with damp sponge.
Never submerge base into water
or any other liquids.
Main Unit
POWER JUICER ELITE
12 Disassembly/Main Unit
Note: Refer to page
6 for all part names.

• Turn off the power switch and wait until the motor completely stops.
• With dry hands, unplug the power cord from electrical outlet.
• Disassemble the machine. (See disassembly instructions.)
• Wipe base with a soft damp cloth or sponge. Do not submerge base in water.
Do not spray with water or any other liquid. Base is not dishwasher safe.
• We recommend washing the pusher by hand in warm soapy water. Due to
temperature differences in dishwashers if you choose to wash the pusher in the
dishwasher, place it on top rack only.
• Clean all other parts in warm, soapy water. A mild detergent is recommended. Rinse
well and dry thoroughly. All components are dishwasher safe with the exception of
the base. Do not use in European Import or a commercial dishwasher.
• To clean the filter and blade, hold them under warm running water. Use a soft-
bristled dish washing brush gently to completely clean pulp from filter. Rinse
the filter from the outside under running water.
• Dry components thoroughly then assemble the machine and turn the power
on to spin out any excess water.
• Make sure unit and parts are completely dry then store in a cool, dry place.
• We recommend removing and washing juice spout after each use.
Cleaning Your Power Juicer
To Clean Main Unit:
To Clean Juice Spout:
STEP 1:
Locate removable juice
spout locking mechanism
on the bottom side of
receptacle.
Note: Juice spout will be
in the locked position.
STEP 2:
To unlock, turn locking
mechanism counter-
clockwise, lining up
notch with juicer spout
hinge pivot arm.
IMPORTANT: When reattaching juice spout back into original position make sure
juice spout is in the locked position and tightly secured before use.
STEP 3:
Lift up juice spout carefully
from receptacle and remove
to clean.
TO REATTACH: insert juice
spout back into original
position and turn the locking
mechanism clockwise to
lock into place.
Locking
Mechanism
Hinge
Pivot Arm Juice Spout
LOCKED POSITION UNLOCKED POSITION
STEP 5:
Use the crescent tool to
remove the blade. Place the
two pegs at either end of the
crescent tool into the two
holes on the blade. Press
down and turn counter-
clockwise while holding filter
and receptacle to unlock
the blade. Remove blade
carefully.
POWER JUICER ELITE
Cleaning Your Power Juicer 13
Disassembly/Main Unit
Note: Refer to page
6 for all part names.

The motor does not run
after being switched on.
The motor is running
with loud noise and
shaking.
The motor overheats
causing the power
to automatically
shut off.
The motor is spinning
and processing fruit/
vegetables but nothing
is coming from spout.
Juice is leaking from the
receptacle but nothing
is coming from the spout.
The unit is assembled
but the motor will not
spin when power is
turned on.
Juice splashes
from the rim of
the receptacle.
• Check to see if unit is plugged in.
• Locking bar is not locked in place properly.
• Check if all parts are assembled properly.
• Check if there is any residue left between blade and
receptacle.
• Check to see if food is stuck to the bottom of the pusher.
• Check that all parts are assembled properly and in the correct
position.
• Juicing overripe fruit may result in too much pulp and will clog
the filter. Turn machine off and clean the filter.
• The motor needs to warm up for 10 seconds before use.
• The fruits and vegetables may be soft or overripe.
• There may be too much pulp in the filter. Turn machine off
and clean the filter.
• Motor stops running due to the built-in feature, the
overheat safety control.
• Press reset switch located on the underside of main base.
• Check silver bar is in the upright position
• Check the spout to make sure it is in the downward
position.
• Check the pulp collector to make sure it is properly
assembled. If it is not properly assembled it will activate
the Micro Safetyswitch and the motor will not operate.
• Press reset switch located on the underside of main base.
• Check that the juice spout is in the downward position.
If the juice spout is left in the upright position the juice
will not flow. It will stay in the receptacle and may overflow
from the sides.
• This is normal.
Problem Possible Reasons and Solution
Troubleshooting
14 Troubleshooting
POWER JUICER ELITE
The motor is running. The
spout is in the downward
position, but no juice is
coming out.
• Turn the power off and unplug the machine. Wait for
blade to stop spinning. Use a toothpick to loosen any
obstruction in the non-drip spout.

PJElite_MAN_TP_ENG_V6_100122
© 2008 Tristar Products, Inc.
All rights reserved.
Distributed by:
Tristar Products, Inc.
Wallingford, CT 06494
