Jackery JE-3000A User manual

Version: JAK-UM-V1.0
Model: JE-3000A
Contact us:
[email protected]
1-888-502-2236(US)
USER MANUAL
Jackery Explorer 3000 Pro

Congratulations on your new Jackery Explorer 3000 Pro. Please read this manual carefully before
using the product, particularly the relevant precautions to ensure proper use. Keep this manual in an
accessible place for frequent reference.
In compliance with laws and regulations, the right of final interpretation of this document and all
related documents of this product resides with the Company.
Please kindly notice that no further notifications will be given in case of any update, revision or
termination.
TECHNICAL SPECIFICATIONS
01
※USB Type-C and USB-C are registered trademarks of USB Implementers Forum.
※Qualcomm Quick Charge is a product of Qualcomm Technologles,Inc. and/or its subsidiaries.
Qualcomm and Quick Charge are trademarks or registered trademarks of Qualcomm Incorporated.
® ®
CERTIFICATIONS
4x AC Output
1x AC Output
Total AC Output
2x USB-C Output
2x USB-A Output
Car Port
120V~ 60Hz 20A Max
120V~ 60Hz 25A Max
3000W Max, 6000W surge peak
100W Max, 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓5A
Quick Charge 3.0, 18W Max, 5-6V⎓3A, 6-9V⎓2A, 9-12V⎓1.5A
12V⎓10A Max
GENERAL INFO
Product Name
Model No.
Capacity
Weight
Dimensions
Cycle Life
Jackery Explorer 3000 Pro
JE-3000A
Lithium-ion 70Ah/ 43.2V DC(3024Wh)
About 63.93 lbs/ About 29 kg
18.6 x 14.1 x 14.7 in/ 47.3 x 35.94 x 37.36 cm
2000 cycles to 70%+ capacity
OUTPUT PORTS
INPUT PORTS
Charge mode AC input
Bypass mode AC input/output
DC Input
120V~ 60Hz 15A Max
120V~ 60Hz 12A Max
2x DC 8mm Ports: 11-17.5V (Working Voltage)⎓8A Max,
Double to 8A Max;
17.5-60V (Working Voltage)⎓12A, Double to 24A/1400W Max
0~40 °C (32~104 ℉)
-20~40 °C (-4~104 ℉)
-20~-10 °C(-4~14 ℉)
Output Power=3000W (Remaining Power≥60%)
Output Power＜3000W (Remaining Power＜60%)
ENVIRONMENTAL OPERATING TEMPERATURE
Charge Temperature
Discharge Temperature

Version:JAK-UM-V1.0
Model:JE-3000A
Contactus:
[email protected]
1-888-502-2236(US)
USER MANUAL
Jackery Explorer 3000 Pro
MODIFICATION: Any changes or modifications not expressly approved by the grantee of this
device could void the user’s authority to operate the device.
PACKAGE LIST
02
Jackery Explorer
3000 Pro
1
USER
MANUAL
Accessories
Bag
5 6
AC Charge
Cable
32
Car Charge
Cable
DC7909 to DC8020
Adaptor x 2
4
GET TO KNOW YOUR GEAR
Product Appearance
AC Output
AC Output
AC Output Button
Retractable Handle
(Press the button on the retractable
handle and pull to extend)
DC Output Button
Main Power Button
USB-C Output
USB-A Output
Car Port
AC Output
Reset Button
DC Input
AC Input
AC Input
Reset Button

03
Battery Power Indicator
When the product is being charged, the orange circle around the battery percentage will
light up in sequence. When charging other devices, the orange circle will stay on.
Low Battery Indicator
When the battery is less than 20%, the Low Battery Indicator will stay on. When less than
5%, the Low Battery Indicator will flash. When it is being charged, the Indicator will be o.
Energy Saving Mode
To avoid forgetting to turn othe output which results in battery consumption, the product
turns the Energy Saving Mode on by default. This occurs when no device is connected or
the connected device is less than or equal to a certain value. (Refer to the table below for
more details), the device will automatically turn o all outputs after 12 hours.
LCD DISPLAY
7
1
4
WiFi
Solar Charging Indicator
Remaining Charge Time
Battery Saving Mode
10
13
Remaining Battery Percentage
AC Wall Charging Indicator
Bluetooth
Battery Power Indicator
2
5
8
11
14
Error Code
16
Low Temperature Warning
17
Energy Saving Mode
19
Output Power
Remaining Discharge Time
18
AC Power Indicator
3
6
9
12
15
Quiet Charging Mode
Input Power
Car Charging Indicator
Low Battery Indicator
High Temperature Warning
12
5
7
13 16
17
18
6
10
1 2
19
11914 158
3 4
Output Output Power Defaults
AC Output The device will automatically shut down after 12 hours
The device will automatically shut down after 12 hours
The device will automatically shut down after 12 hours
≤25W
≤2W
≤2W
USB Output
Car Output
Battery Saving Mode: When this feature is enabled, it limits the battery charging capacity to 85%
and the discharging capacity to 15%, and the battery will only be charged when the capacity is
below 80% to extend the battery life. Use the Jackery App for settings of this function.
Quiet Charging Mode: noise ≤ 30dB in this charging mode, you can set this function in Jackery App.

04
BASIC OPERATIONS
Power On/O
Main power on/o: Press the "Main Power Button" and the working indicator lights up and the LCD display
is illuminated. When this product does not have any operation for 2 minutes, the product will enter the
hibernation state and the display will turn o automatically. If you need to turn o the main power, please
press and hold the "Main Power Button" until the working indicator turns o. The default standby time of
this product is 2 hours. If the other power output switch is not turned on, and the product does not have
any load input, the product will automatically shut down after 2 hours. The automatic shutdown time can
be set on the Jackery App.
AC Output On/O: Ensure that the main power supply is turned on. Press the AC Button, the AC
Output operation indicator lights up. Then you can connect the equipment that needs AC charging.
Press the AC Button again to turn o the AC Output.
USB/Car Port Output On/O: Ensure that the main power supply is turned on. Press the DC Button,
the DC Output operation indicator lights up. Then USB/Car Port Output Ports can be connected to
external load devices. Press the DC Button again to turn o the USB/ Car Port Output.
To turn o the Energy Saving Mode
Long press the AC Button and Main Power Button until the Energy Saving Mode icon
disappears. In Non-Energy Saving Mode, please remember to turn o the products to
avoid battery consumption.
To turn on the Energy Saving Mode
Long press the AC Button and Main Power Button until the Low Power Mode icon lights up
on the screen.
High-temperature warning
If it appears on the screen, do not worry, the battery will restore automatically after cooling.
Low-temperature Warning
If it is displayed on the screen, do not worry. It will automatically restore after the ambient
temperature is restored.
Fault code
In order to quickly solve the user’s feedback, we set up common fault codes F0-F9 in the
system: if you find any fault code of F0、F1、F2、F3、F4、F5、F6、F7、F8、F9 on the
display screen, please contact us for after-sales treatment; If F6 code appears, please
remove the load or unplug the charging plug, the product can restore by itself, if not,
please contact after-sales treatment; If F9 fault code appears, please remove the load
and the product can recover by itself, if not, please contact after-sales service.
LCD Screen On/O
Low Temperature Mode: This product can be used in low temperature environment of -20 ~ -10℃. The
blinking of the icon on the screen indicates that the device is in low temperature mode. The maximum
discharge power in low temperature mode is 3000W when the remaining power is ≥60%, 2000W when the
remaining power is 30%~60%, and 800W when the power is <30%.
Press the "Main Power Button" and the working indicator lights up and the LCD display is illuminated.
When this product does not have any operation for 2 minutes, the product will enter the hibernation
state and the display will turn o automatically. If you want the LCD display to be always on when
charging or discharging, you can press the "Main Power Button" twice after the display is on, and the
display will enter the Steady On mode. To turn o Steady On mode of the LCD display: press the "Main
Power Button" and the LCD display will be turned o.
Note: In the Steady On mode, if the device is not charging or connected to a load, the display will
automatically turn o after 2 hours.

05
CHARGING YOUR JACKERY EXPLORER 3000 PRO
Green energy first: We advocate to use the green energy first. This product supports two modes of
charging at the same time: solar charging and AC wall charging.
When AC wall charging and solar charging are turned on at the same time, the product will give
priority to solar charging and both methods will be used to charge the battery at the maximum
permissible power.
SOLAR ENERGY CHARGING
If one or two solar panels are connected, you can directly connect the DC8020 port of the solar panel
to theDC8020 port of Jackery Explorer 3000 Pro for charging. If three or four solar panels are connect-
ed, please refer to the method shown in the following figure to charge through the solar series connec-
tor (Note: The solar series connector is not in standard configuration, so you need to purchase it separately.
Please refer to the detailed operation instructions of the solar series connector before using it.)
CHARGING FROM THE WALL
Please use the AC cable included in the package.
Jackery SolarSaga 200 or 100 or 60 Solar Panel Connection Guide
SolarSaga ×3
Explorer 3000 Pro
Explorer 3000 Pro
AC Charger
This product supports the connection of Jackery App for intelligent control and operation. Users can
download the Jackery App through App Store or Android application markets. Please refer to the User
Manual for Jackery App for detailed connection instructions.
AC Output Reset Button: When the Reset Button pops up, you need to remove the load and press the
Reset Button to reset.
AC Input Reset Button: When the Reset Button pops up, you need to remove AC charge cable and
press the Reset Button to reset.
APP CONNECTION
EPS: Emergency Power System. Once you have connected the mains and the AC input port of the EPS
via the AC charger cable, you can use the AC output port of the EPS to power your unit (at this point
the AC power comes from the mains, not the EPS battery). In the event of a sudden loss of mains
power, the EPS can automatically switch to battery mode within 20ms. Since this is a non-profession-
al UPS function, it does not support 0ms switching. Do not connect to equipment with high
uninterruptible power requirements such as data servers and workstations. Please test several times
to confirm compatibility before use and it is recommended to connect to only one device. Do not use
more than one unit at a time to avoid triggering the overload protection. Failure to follow these
instructions may result in equipment failure or loss of data for which we cannot be held responsible.

06
Caution: When the two inputs are used at the same time, please make sure to use the same typeof
solar panel and the number of solar panels in the two inputs must be the same to avoiddamage or
charging problems of the equipment due to inconsistent voltages of the twochannels.
SolarSaga×3 SolarSaga ×3
Explorer 3000 Pro
The following way of connections are prohibited to charge this product:
SolarSaga×2 SolarSaga×2Explorer 3000 Pro
SolarSaga×3 SolarSaga×1Explorer 3000 Pro
SolarSaga×2 SolarSaga×1Explorer 3000 Pro

07
All of our solar panels on sale have been upgraded to include a DC7909 to DC8020 adapter. If you
have purchased a Jackery solar panel without a DC7909 to DC8020 adapter, you can charge your
Jackery Explorer 3000 Pro by following the connection instructions below.
DC7909 to DC8020 Adaptor Operation Guide
Users who have purchased Jackery SolarSaga 80 can charge the product by referring to the
connection mode shown below. The Jackery SolarSaga 80 supports the parallel connection or the
parallel and then series connections to charge the product. The single input port of the Jackery
Explorer 3000 Pro supports the input of up to six pieces of SolarSaga 80 solar panels, and two input
ports support the input to up to 12 pieces of SolarSaga 80 solar panels. (When the power is
connected with six solar panels in a single input port, the solar panels shall be divided into two
groups, and each group of three solar panels shall be self-connected in parallel and then connected
to Jackery Explorer 3000 Pro through the solar series connector. The solar series connector needs to
be purchased separately.)
For detailed operation instructions on the self-parallel connection of the Jackery SolarSaga 80 solar
panel, please refer to the user manual.
Jackery SolarSaga 80 Solar Panel Connection Guide
Warm Tip: Users can enter the number of solar panels in their own combination according to the
number of solar panels they purchased. Currently, the product supports charging with 1, 2, 3, 4, 5, 6, 8,
and 12 80W solar panels in combination.
Parallel port（DC 8020 female）
The solar panel charging
output port(DC8020 male,
with DC8020 to DC7909
Adaptor)
SolarSaga×3 SolarSaga×2Explorer 3000 Pro

08
DC7909 male
DC8020 female
Explorer 3000 Pro
DC7909 to
DC8020 Adaptor
The basic safety precautions should be followed when using this product, including:
a. Please read all instructions before using this product.
b. Close supervision is required when using this product near children to reduce the risk.
c. Risk of electric shock may occur if using accessories recommended or sold by non-professional
product manufacturers.
d. When the product is not in use, please unplug the power plug from the product's socket.
e. Do not dismantle the product, which may lead to unpredictable risks such as fire, explosion or
electric shock.
f. Do not use the product through damaged cords or plugs, or damaged output cables, which may
cause electric shock.
g. Charge the product in a well ventilated area and do not restrict ventilation in any way.
h. Please put the product in a ventilated and dry place to avoid rain and water to cause electric
shock.
i. Do not expose the product to fire or high temperature (under direct sunlight or in vehicle under high
heat), which may cause accidents such as fire and explosion.
j. When using the retractable handle to move the Jackery Explorer 3000 Pro, please do not stack or
place other objects on top of it to prevent falling o and causing injury.
CHARGING IN THE CAR
This product can be charged with a 12V car
charger. Please start the vehicle before charging
to prevent draining the car battery and prevent
your vehicle from being unable to start.
Meanwhile, please ensure that the car charger
and the car cigarette lighter provide a good
connection, and ensure that the car charger is
fully inserted. In addition, if the vehicle is running
on bumpy roads, it is forbidden to use the car
charger in case it burns due to a poor connec-
tion. The Company will not be responsible for
any loss caused by non-standard operation.
1) Vehicle charging is only applicable in 12V vehicles, not in 24V ones. Please do not charge this
product in 24V vehicle to avoid personal injury and property loss.
2) It is recommended to use Jackery accessories - solar panels for solar charging. We will not be
responsible for the losses caused by using other brands’ solar panels.
Safety Precautions When Charging
Vehicle
Explorer 3000 Pro
1 3 5
24 6
R
A/C
AUTO
SAFETY PRECAUTIONS WHEN USING

09
WARNING–When using this product, basic precautions should always be followed, including the
following:
a) Read all the instructions before using the product.
b) To reduce the risk of injury, close supervision is necessary when the product is used near children.
c) Do not put fingers or hands into the product.
d) Use of an attachment not recommended or sold by power pack manufacturer may result in a risk
of fire, electric shock, or injury to persons.
e) To reduce risk of damage to the electric plug and cord, pull the plug rather than the cord when
disconnecting the power pack.
f) Do not use a battery pack or appliance that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury.
g) Do not operate the power pack with a damaged cord or plug, or a damaged output cable.
h) Do not disassemble the power pack, take it to a qualified service person when service or repair is
required. Incorrect reassembly may result in a risk of fire or electric shock.
i) To reduce the risk of electric shock, unplug the power pack form the outlet before attempting any
instructed servicing.
j) PERSONAL PRECAUTIONS
1)Have plenty of fresh water and soap nearby in case battery acid contacts skin,clothing, or eyes.
2)Wear complete eye protection and clothing protection. Avoid touching eyes while working near battery.
3)If battery acid contacts skin or clothing, wash immediately with soap and water. If acid enters
eye, immediately flood eye with running cold water for at least 10 minutes and get medical attention
immediately.
4)NEVER smoke or allow a spark or flame in vicinity of battery or engine.
5)Be extra cautious to reduce risk of dropping a metal tool onto battery. It might spark or
short-circuit battery or other electrical part that may cause explosion.
k) When charging the internal battery, work in a well ventilated area and do not restrict ventilation in
any way.
l) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
m) Do not expose a power pack to fire or excessive temperature. Exposure to fire or temperature above
130°C may cause explosion. The temperature of 130°C can be replaced by the temperature of 265°F.
n) Have servicing performed by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the product is maintained.
• Use and store the unit only in a clean and dry environment. DO NOT use and store in dusty and wet
environment.
• Check the unit prior to every use. DO NOT use the unit if it is damaged, broken.
• If rust, peculiar odors, overheating or other abnormal circumstances are observed, stop using the
unit immediately and contact the dealer or our customer service center.
• Make sure that the unit is properly secured when transporting it in a motor vehicle.
• Only charge the E3000 Pro within a ambient temperature 0-40°C (32-104°F),discharge temperature
is -20-40°C (-4~104°F) and Storage temperature is 1 year: -20~25°C (-4~77°F).
• Switch the unit o immediately if it has accidentally fallen, was dropped or was exposed to
vibrations.
• DO NOT use the unit if the power cord is damaged or broken.
• Keep the unit away from children. DO NOT let children use the power supply unit. Keep this product away
from pets.
• DO NOT use the unit in an area or environment with high temperature.
• Should fluid from inside of the unit come in contact with your skin or clothing, wash the aected areas
with tap water.
• In a storm, unplug the power cord from the socket.
• DO NOT place the unit on its side or upside down while in use or storage.
• DO NOT use accessories for other usage.
SAVE THESE INSTRUCTIONS OPERATING INSTRUCTIONS
INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS

10
Warning：Do not remove the battery pack without permission,If you need to repair the battery pack,
contact your local manufacturer as soon as possible
DANGER: This device is for indoor use only (e.g. RV/tent/o-grid cabin, etc.). Do not use outdoors
under any circumstances (e.g. where exposed to rain or snow or use it in wet places by the sea or
waterways).
1.Press the AC button, AC output will be turn on; and press the button again, the AC output will turn
o，while the AC LED will turn o within 1~2seconds.
2.Press the any 1or 2 way DC(USB or 12V) button, output will be turn on; and press the button again,
the DC output will turn o，while the DC LED will turn o within 1~2seconds.
3. If DC or AC output is on LCD will display “OUPUT” icon and output power unless all DC output is o
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
--Consult the dealer or an experienced radio/TV technician for help.
Charging instruction
• DO NOT move the unit if it is recharging or in use.
• DO NOT dispose the unit together with household waste.
• DO NOT place the unit close to or in a fire or expose it to heat. Keep out of direct sunlight.
• DO NOT store the unit in a bathroom or in an area exposed to rain or moisture.
• DO NOT disassemble the power pack, take it to a qualified service person when service or repair is
required. Incorrect reassembly may result in a risk of fire or electric shock.
• DO NOT store the unit in an area or environment with high temperature.
MOVING AND STORAGE INSTRUCTIONS
Before using or storing, plug your Jackery Explorer into the wall until it is fully charged. If you see the
LCD battery is low at any point, plug it into a power source, like an AC outlet or a solar panel as soon
as possible.
USER MAINTENANCE INSTRUCTIONS
Discharging instruction
1.The product supports any 1 way or 2 way charging .
2.Charge the Portable Power Station with charger; the LCD will turn on and display Input power
3.Display will show 100% capacity when fully charged .
• Make sure that the device you are connecting is switched o before you connect it.
• DO NOT expose a power pack to fire or excessive temperature. Exposure to fire or temperature
above 130°C may cause explosion.
• Solar charge times depend on weather conditions, place your solar panel where it will get as much
direct sunlight as possible.
• DO NOT place the power pack on the floor, or at a height less than 457 mm (18 inches) above the
floor, during use in a repair facility.

Warranty Period
Exchange
Exclusions
WARRANTY
Note: We only provide our warranty for the buyer who purchased on Amazon (Jackery
Inc), Jackery website or local authorized dealers.
Jackery Inc. warrants to the original consumer purchaser that the Jackery product will be free from
defects in workmanship and material under normal consumer use during the applicable warranty
period identified in the 'Warranty Period' section below, subject to the exclusions set forth below.
This warranty statement sets forth Jackery's total and exclusive warranty obligation. We will not
assume, nor authorize any person to assume for us, any other liability in connection with the sale of
our products.
3 Years Standard Warranty: The standard warranty period for Jackery Explorer 3000 Pro is 36 months.
In each case, the warranty period is measured starting on the date of purchase by the original
consumer purchaser. The sales receipt from the first consumer purchase, or other reasonable
documentary proof, is required in order to establish the start date of the warranty period.
2 Years Extended Warranty: To activate the Warranty Extension, you must register your product
online or contact our customer service team at [e-mail] to extend the standard warranty
runtime.
Jackery will replace (at Jackery's expense) any Jackery product that fails to operate during the
applicable warranty period due to defect in workmanship or material. A replacement product
assumes the remaining warranty of the original product.
Jackery's warranty does not apply to:
Misused, abused, modified, damaged by accident, or used for anything other than normal consumer
use as authorized in Jackery's current product literature.
Attempted repair by anyone other than an authorized facility.
Any product purchased through an online auction house.
Jackery's warranty does not apply to the battery cell unless the battery cell is fully charged by you
within seven days after you purchase the product and at least once every 6 months thereafter.
Limited Warranty
The warranty on Jackery's product is limited to the original consumer purchaser and is not transfer-
able to any subsequent owner.
Limited to Original Consumer Buyer
Download the Jackery Mobile App

48531 WARM SPRINGS BLVD, STE 408, FREMONT,CA 94539-7793
Tel:[phone](US) E-mail:[e-mail] Website:www.jackery.com
JACKERY INC.
