Jacobsen Eclipse 2 User manual

Technical
Manual
When Performance Matters.
™
WARNING
If incorrectly used, this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its
dangers, and should read the entire manual before attempting to set up,
operate, adjust, or service the machine.
GB
Eclipse® 2
InCommand™
63334 – Eclipse 2 118, 18” 11 Blade Reel, Gen-Set
63343 – Eclipse 2 118, 18” 11 Blade Reel, Battery Pack
63335 – Eclipse 2 118, 18” 15 Blade Reel, Gen-Set
63344 – Eclipse 2 118, 18” 15 Blade Reel, Battery Pack
63336 – Eclipse 2 118F, Floating 18” 11 Blade Reel, Gen-Set
63345 – Eclipse 2 118F, Floating 18” 11 Blade Reel, Battery Pack
63337 – Eclipse 2 118F, Floating 18” 15 Blade Reel, Gen-Set
63346 – Eclipse 2 118F, Floating 18” 15 Blade Reel, Battery Pack
63338 – Eclipse 2 122, 22” 11 Blade Reel, Gen-Set
63347 – Eclipse 2 122, 22” 11 Blade Reel, Battery Pack
63339 – Eclipse 2 122, 22” 15 Blade Reel, Gen-Set
63348 – Eclipse 2 122, 22” 15 Blade Reel, Battery Pack
63340 – Eclipse 2 122F, Floating 22” 11 Blade Reel, Gen-Set
63349 – Eclipse 2 122F, Floating 22” 11 Blade Reel, Battery Pack
63341 – Eclipse 2 122F, Floating 22” 15 Blade Reel, Gen-Set
63350 – Eclipse 2 122F, Floating 22” 15 Blade Reel, Battery Pack
63342 – Eclipse 2 126, 26” 7 Blade Reel, Gen-Set
63351 – Eclipse 2 126, 26” 7 Blade Reel, Battery Pack
4260472-Rev A

© 2012, Jacobsen, A Textron Company/Textron Innovations Inc.
“All rights reserved, including the right to reproduce this material
or portions thereof in any form.”
This manual contains safety, operating, adjustment,
maintenance, troubleshooting instructions and parts list
for your new Jacobsen machine. This manual should be
stored with the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the rear crossbar of the
frame. Jacobsen recommends you record these numbers
below for easy reference.
11524 WILMAR BLVD,
CHARLOTTE, NC 28273
®
kg kW
1-800-848-1636 (US)
PRODUCT OF U.S.A. A Textron Company
2
Proposition 65 Warning
This product contains or emits
chemicals known to State of California
to cause cancer and birth defects or
other reproductive harm.
FOREWORD
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
❑UPS ❑Regular Mail
❑Overnight ❑2nd Day
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
These are the original instructions verified by
Jacobsen, A Textron Company.
LITHO IN U.S.A. 6-2012
Service Parts
Service Support Material
Qty. Part No. Description Qty. Part No. Description
4102780 50 Amp Fuse 2811106 Motor to Pulley Belt
4262910 30 Amp Fuse 2811070 Pulley to Traction Drum Belt
4131618 Ignition Key
Qty. Part No. Description
4260472 Technical Manual
4260475 Operator Training Video
4262930 Floating Head Service Manual
4262932 Fixed Head Service Manual
Qty. Part No. Description

3
Table of Contents
1SAFETY
1.1 Operating Safety . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Important Safety Notes . . . . . . . . . . . . . . . . . 5
2 SPECIFICATIONS
2.1 Product Identification . . . . . . . . . . . . . . . . . . 6
2.2 Mower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Traction and Differential . . . . . . . . . . . . . . . . 7
2.4 Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Gen-Set Power Module . . . . . . . . . . . . . . . . 7
2.6 Battery Power Module . . . . . . . . . . . . . . . . . 8
2.7 Accessories & Support Literature . . . . . . . . . 9
2.8 Declaration of Conformity . . . . . . . . . . . . . . 10
3DECALS
3.1 Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 CONTROLS
4.1 Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Handle Controls . . . . . . . . . . . . . . . . . . . . . 16
4.3 LCD Display . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Frequency of Cut . . . . . . . . . . . . . . . . . . . . 22
4.5 Gas Power Module Controls . . . . . . . . . . . . 27
4.6 Battery Power Module Controls . . . . . . . . . 27
5 OPERATION
5.1 Daily Inspection . . . . . . . . . . . . . . . . . . . . . 28
5.2 Interlock System (O.P.C.) . . . . . . . . . . . . . . 28
5.3 Operating Procedures . . . . . . . . . . . . . . . . . 29
5.4 Starting/Stopping . . . . . . . . . . . . . . . . . . . . 30
5.5 Mowing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.6 Transport Wheels (Optional) . . . . . . . . . . . . 32
5.7 Kickstand . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.8 Grass Catcher . . . . . . . . . . . . . . . . . . . . . . . 33
5.9 Daily Maintenance . . . . . . . . . . . . . . . . . . . 33
6 ADJUSTMENTS (ALL UNITS)
6.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.2 Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.3 Speed Paddle Stops . . . . . . . . . . . . . . . . . . 34
6.4 Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5 Traction Belts . . . . . . . . . . . . . . . . . . . . . . . 35
6.6 Front Roller Weight . . . . . . . . . . . . . . . . . . . 36
6.7 Torque Specification . . . . . . . . . . . . . . . . . . 37
7 FIXED HEAD REEL ADJUSTMENTS
7.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.2 Reel To Bedknife . . . . . . . . . . . . . . . . . . . . 38
7.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . . 39
7.4 Cutting Height . . . . . . . . . . . . . . . . . . . . . . . 39
8 FLOATING HEAD REEL ADJUSTMENTS
8.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
8.2 Bedknife-To-Reel . . . . . . . . . . . . . . . . . . . . .40
8.3 Bedknife Adjustment . . . . . . . . . . . . . . . . . .41
8.4 Reel Bearing . . . . . . . . . . . . . . . . . . . . . . . .41
8.5 Cutting Height . . . . . . . . . . . . . . . . . . . . . . .42
8.6 Reel Assembly Removal . . . . . . . . . . . . . . .42
9 BATTERY POWER MODULE
9.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
9.2 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
9.3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . .44
9.4 Cleaning Batteries . . . . . . . . . . . . . . . . . . . .44
9.5 Battery Charger . . . . . . . . . . . . . . . . . . . . . .45
9.6 Battery Installation . . . . . . . . . . . . . . . . . . . .46
9.7 Replacing Battery Pack . . . . . . . . . . . . . . . .47
10 GEN-SET POWER MODULE
10.1 Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
10.2 Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . .48
10.3 Engine Oil Change . . . . . . . . . . . . . . . . . . . .49
10.4 Engine Speed . . . . . . . . . . . . . . . . . . . . . . .49
10.5 Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
11 MAINTENANCE
11.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
11.2 Tires (Option) . . . . . . . . . . . . . . . . . . . . . . . .51
11.3 Wheel Bearing . . . . . . . . . . . . . . . . . . . . . . .51
11.4 Backlapping and Grinding . . . . . . . . . . . . . .52
11.5 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
12 TROUBLESHOOTING
12.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
13 MAINTENANCE & LUBRICATION CHARTS
13.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
13.2 Maintenance Chart . . . . . . . . . . . . . . . . . . .55
13.3 Lubrication Chart . . . . . . . . . . . . . . . . . . . . 56
14 PARTS CATALOG
14.1 How To Use The Parts Catalog . . . . . . . . . .57
14.2 To Order Parts . . . . . . . . . . . . . . . . . . . . . . .57
14.3 Parts Catalog Table of Contents . . . . . . . . .57
