Jacuzzi Mito 5 User manual

Mito
™5
SOAKING BATH
MODEL NUMBER:
H521
EXTERIOR DIMENSIONS:
60" long x 42" wide x
21" high
INTERIOR DIMENSIONS:
34½" long x 25½" wide
x 22" wide
Mito
™5
WHIRLPOOL BATH
MODEL NUMBER:
H520 – (RH pump)
H519 – (LH pump)
EXTERIOR DIMENSIONS:
60" long x 42" wide x
21" high
INTERIOR DIMENSIONS:
34½" long x 25½" wide
x 22" wide
# OF JETS/TYPE OF JETS:
4 TheraPro™ Jets,
2 AccuPro™ Foot Jets
OPERATING GALLONS:
62 gallons
Mito—in Italian, “myth.” Our Mito™—a whirlpool of fabled
luxury. Think of the Mito™ as a fantastic experience.
Legendary hydrotherapy in a roomy, bow-tie shaped
bathing well.
WHIRLPOOL BATH FEATURES:
• 4fullyadjustableTheraPro™jetswithamaximumow
rateof30GPMperjet
• ElectronicControl
• 2directionallyadjustableAccuPro™footjets
• Sculptedarmrest
• Contouredbackrest
• ExclusiveTru-Level™base
system
• Slip-resistantbottom
Mito
™5 |WHIRLPOOL BATH and SOAKING BATH
Detail: The Mito
®
whirlpool bath’s sculpted
interior features gracious curves, a deep
bathing well, and integral armrests.

Mito™5
WHIRLPOOL BATH
Technical Specifications
DIMENSIONS
60” L x 42” W x 21” H
(1524 mm) L x (1067 mm) W x (533 mm) H
DRAIN/OVERFLOW
A: 17-1/2” (445 mm) B: 11-7/8” (302 mm)
CUTOUT
58” x 40”
TOTAL WEIGHT
H520, H519: 866 lb (393 kg) / 50 lb/sq. ft. (242 kg/m2)
H521: 842 lb (382 kg) / 48 lb/sq. ft. (235 kg/m2)
OPERATING GALLONAGE
62 U.S. Gal. (235 Liters)
PRODUCT WEIGHT
H520, H519: 100 lb (45 kg)
H521: 76 lb (35 kg)
SKIRT MOUNTING
Optional U-Frame
ELECTRICAL SPECIFICATIONS MODELS H520, H519 ONLY
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
HEATER (OPTIONAL) MODELS H520, H519 ONLY
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
© 2008 Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino, CA 91710 • www.jacuzzi.com
INSTALLATION NOTES
Refer to installation instructions included with xture before
beginning installation. Please conrm product availability and
specications before commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
#FR70000 01/08
H520
Mito™ 5 Whirlpool Bath, Right Hand Pump
H519
Mito™ 5 Whirlpool Bath, Left Hand Pump
H521 Mito™ 5 Bath
• Center Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
HTC Jet Trim Kit: #D095
2 X BMH Jet Trim Kit: #J869
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Mito™5
SOAKER BATH
Electrical Components and Electrical Specifications do not apply
to non-jetted baths.
30"
42"
60"
10" x 4"*
2"
11-7/8"
Motor
12" H x 18" L
Service Access
Opt. Service
Access
5-3/8"
END VIEW
H
W
SIDE VIEW
L
2"
DRAIN/OVERFLOW
A
B
Product Shown: Mito™5 Whirlpool Bath Right
Hand Shown Model: H520
* Measurements inside unit represent cutout in
floor to allow for drain/overflow.
Minimum Service Access dimensions given.
