Jacuzzi Tirage Plus PORTABLE WHIRLPOOL SPA User manual

WHIRLPOOL
BATH
R
THETIRAGEPLUS
™
PORTABLE WHIRLPOOL SPA
OWNER'S MANUAL

IMPORTANT SAFETY INFORMATION
Donotremovethesuctiongrille! Itisasafetydeviceand
mustalwaysbeinplaceonthesuctionfittingtominimize
the potential hazard of hair entanglement or body en-
trapment. Keep body, hair, and clothing a minimum of
12 inches away from suction fitting and skimmers at all
times when the spa is operating. Hair longer than
shoulderlengthshouldbesecuredclosetothehead,or
a bathing cap should be worn.
The wet surface of the spa is slippery. Use care when
entering and exiting.
WARNING—Risk of child drowning: Do not permit
children to use this product unless they are closely
supervised. The use of a rigid locked cover is highly
recommended to prevent unattended access.
Owner’s Record
Save These Instructions for Future Use.
DANGER—RISK OF ELECTRICAL SHOCK:
(When using the electrical equipment, basic safety pre-
cautions should always be followed.)
Thisunitisprovidedwithagroundfaultcircuitinterrupter
(GFCI)located intheSystemControlModule. Check to
be sure this is operational once a month. (The proce-
dure for testing described in this manual under under
"OPERATION".)
Do not use electrically connected devices such as
television, radio, or stereo speakers, lights, cooking
devices, or telephones within 5 feet of the spa while the
spa is being used. Lighting fixtures must not be located
directlyaboveorwithin5feetofthespa. Iflocatedwithin
10feet of the spa, theymustbe on a circuitprotectedby
a GFCI.
The spa must be installed with adequate access and
water drainage system, (See Installation Instructions.)
to drain water away from electrical components.
Do not turn on power to the spa unless it is filled with
water to the normal water level, which is to the water
level indicator mark on the skimmer frame. Activating
thespawhenthereisaninsufficientamountofwatercan
damage the circulation pump and may cause a fire.
Read manufacturer’s safety information provided with
all optional equipment.
Jacuzzi Whirlpool Bath does not recommend spa water
temperaturesinexcessof104°F. Highwatertempera-
turesinexcess of 104°F. and prolonged periodsofuse
canraise internal human bodytemperatureexcessively
and impair the body’s ability to regulate its internal
temperature. Limit your initial use of the spa to 10 - 15
minutes. High body temperatures affect people differ-
ently; consult your physician about your safety and
comfort before using the spa.
The elderly, the infirm, and children should not use the
spa unattended. Infants should not be permitted in the
spaat watertemperaturesover100°F.Pregnant women
and people with heart conditions should consult their
physicians before using the spa at water temperatures
over 100°F.
Extra care should be taken when using the spa and
consuming alcoholic beverages. Alcohol, drugs, or
certain medications such as tranquilizers affect a per-
son’s ability to withstand high temperatures and may
produce dangerous effects.
Date Purchased ____________________________________________________________
Purchased From ____________________________________________________________
Installed By ________________________________________________________________
Spa Serial Number ____________________________ Model #8900000
(See page 2 for location of serial number.)

Owner’s Manual
Model 8900000
The Tirage Plus Portable Whirlpool Spa
Installation Instructions _________________________________________ 2-6
Inspection and Shipping Claim ___________________________________________ 2
Unpacking ___________________________________________________________ 2
Positioning Your Spa___________________________________________________ 3
Electrical Requirements ________________________________________________ 3
Electrical Precautions __________________________________________________ 4
Outdoor Installation ____________________________________________________ 4
Drainage ____________________________________________________________ 4
Indoor Installations ____________________________________________________ 4
Equipment Set-Up_____________________________________________________ 5
Operating Instructions __________________________________________ 6-10
Basic Control Set-Up___________________________________________________ 6-7
Setting the Timer______________________________________________________ 7
Controls_____________________________________________________________ 8
Temperature Control ___________________________________________________ 9
Setting the Thermostat _________________________________________________ 9
Note on Determining Water Temperature ___________________________________ 9
Normal Operation _____________________________________________________ 10
Whirlpool System _____________________________________________________ 10
Water Rainbow _______________________________________________________ 10
Air Blower ___________________________________________________________ 10
Silent Air Induction ____________________________________________________ 10
Filtration ____________________________________________________________ 10
Maintenance __________________________________________________ 11-15
Water Quality and Water Chemistry _______________________________________ 11
Filtration ____________________________________________________________ 11
Water Chemistry ______________________________________________________ 11-12
Disinfectin ___________________________________________________________ 12
Balancing pH_________________________________________________________ 12
Balancing Total Alkalinity _______________________________________________ 12
Water Quality Definitions________________________________________________ 12
Water Level/Drain _____________________________________________________ 13
Skimmer Basket Maintenance ___________________________________________ 13
Filter Maintenance_____________________________________________________ 13
Automatic Filtration/Maintenance _________________________________________ 14
Winterizing __________________________________________________________ 14
Factory Installed Redwood Skirt __________________________________________ 14
Spa Light ____________________________________________________________ 15
Covering Your Spa ____________________________________________________ 15
Cleaning Your Spa ____________________________________________________ 15
Repairs to the Acrylic __________________________________________________ 15
Troubleshooting Guide__________________________________________ 16-18
Alternate Use for Water Rainbow _________________________________________ 19
Optional 1-1/2" Permanent Drain _________________________________________ 19
Page
Contents
TM

The Tirage Plus Portable Whirlpool Spa
Specifications and Installation Instructions
TheTiragePlusalsofeaturesaclearlylabeledcontrol
panel concealed by a streamlined, tinted acrylic cover.
Push button controls give you convenient command of
the heater, filter, whirlpool, lights, and air blower func-
tions. Two control panels having knobs for adjustment
of the silent air induction are located on the rim of the
spa. A 7-day timer (located on the System Control
Module)can be setforautomatic controloftemperature
and filtration. The Tirage Plus also features two low
voltage underwater lights and interchangeable colored
lenses,addingevenmoreluxuryandexcitementtoyour
spa experience.
Under this same tinted cover is a dry compartment in
which to store personal items such as eye glasses, or
watches, etc. The Tirage offers the convenience of two
patented front-load skimmer/filters for maximum effi-
ciency. Theunique50sq. ft. filtration system, designed
by Jacuzzi Whirlpool Bath, allows easy access from
inside the spa to both filter cartridges without having to
drain the spa or open the skirt door.
A standard feature of the Tirage Plus is its two Water
Rainbow™ spouts with flow control, which will create a
dazzling,shimmeringwaterfalleffect while recirculating
the water.
The spa shell is foam-insulated to save energy costs,
andthespaistastefullysurroundedbyafactoryinstalled
redwood skirt.
The complete equipment pack of the Tirage Plus is
mounted within the perimeter of the spa, so the spa is
easy to install. The spa requires a 230 VAC 50 AMP 4-
wire grounded, separate circuit and is equipped with a
ground fault circuit interrupter (GFCI). An optional gas
heater is available as an alternate heating source and
can be installed remotely. The Tirage Plud is available
in a wide range of lustrous acrylic colors. (See the
Jacuzzi Whirlpool Bath color guide.)
TheTiragePlus™isasumptuousrectangularwhirlpoolspabyJacuzzi WhirlpoolBath designedwith full-featured
elegancetoprovidethecomfortandluxuriousspaexperienceyouexpectfromaJacuzzi®whirlpoolspa. Itsmulti-level
contours and individualized, connecting loungers allow seating for 7 people. Entry and exit from the spa are made
easierand safer bythebuilt-in exteriorandinterior steps. And forarevitalizing hydromassage, sevenfully adjustable
color coordinated PowerPro™ whirlpool jets and one directionally adjustable jet are located strategically to massage
lumbar and upper back regions, depending on where you are seated. The two sets of stacked jets ensure this
simultaneous hydrotherapy.
OPTIONS
Gas Heater
Rigid Insulating Cover
Pillow
ARCHITECTURAL SPECIFICATIONS
(Short Form)
Whirlpool spa shall be the Tirage whirlpool spa as
manufactured by Jacuzzi Whirlpool Bath in colors and
sizes shown in drawings and schedules.
2.0 HP
230 VAC
10 AMPS
3450 RPM
Single Phase
60 Hz.
WHIRLPOOL
MOTOR/
PUMP SHIPPING WEIGHT
FLOOR
LOADING
FILTER
MOTOR/
PUMP OPERATING GALLONAGE
Tirage
Plus
8900000
375 US Gal.
(1419 Ltrs.)
94" L. (238.8 cm)
87" W. (221 cm)
37" H. (94 cm)
86 lbs./sq. ft.
(384 kg./sq. m.)
Total Weight:
4874 lbs.
(2216 kg.)
ELECTRIC
HEATER
6 Kw
26 AMPS 1100 lbs.
(500 kg.)
PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
ELECTRICAL
REQUIREMENTS
MODEL
230 VAC
50 AMPS
60 Hz.
Separate Circuit
4 Wire
.75 HP
230 VAC
4.8 AMPS
3450 RPM
Single Phase
60 Hz.
DIMENSIONS
SPECIFICATIONS
TM
1
94"
87"
37"
SERIAL NUMBER
LOCATION

2
INSTALLATION
INSTALLATION INSTRUCTIONS
Inspection and Shipping Claim
Check for shipping damage upon receipt of the spa. Jacuzzi Whirlpool Bath is not responsible for damage to the
spasustained during shipping. If damage is evident before unpacking, seeinstructions regardingshipping claimson
the outside of the carton and immediately file a claim with the carrier.
Once the spa has been removed from the carton and before it is permanently installed (see below on this page for
unpacking instructions), check the spa completely for damage. Fill the shell with water and operate the system (see
Operating Instructions) to check for leaks which may have resulted from shipping or handling. All Jacuzzi Whirlpool
Bath spas are factory tested for proper operation and water tight connections prior to shipping. If leaks or other
problems are detected, immediately notify your Jacuzzi Whirlpool Bath dealer or Authorized Service Agent, or call
Jacuzzi Whirlpool Bath, (510)-938-7411, or (510)-938-7070 for Warranty Service.
Note:Damage or defects which could have been discovered and repaired priortoinstallationandwhichare claimed
after final installation of the spa, are excluded from our warranty.
Unpacking the dolly for adequate support. (See Illustration B.)
The spa must not lie on its skirt.
4. When the spa has been moved to its final location,
placea4"x4"x72"woodenblockbesidethepanside
of the spa so it is parallel with the pallet. (See
Illustration C.)
5. Tip the spa over onto its bottom with the block
supporting the spa.
6. Remove the bolts attaching pallet to spa. (See
Illustration D.)
7. Remove the pallet and carefully lower the spa to a
horizontal position at its final location.
8. Attach the loose skirt panel included in skirt box.
Record the spa serial number on the inside front
cover of this manual. (See the illustration on page 2
for the serial number location.)
Important! Read all the instructions contained in
the Owner's Manual before beginning installation.
1. Remove the outer carton by disassembling bracing
and plastic bags. Leave the corrugated wrapping in
place on the skirt to protect the product until equip-
ment set-up.
2. Removetheboxcontainingskirtpanelandtheacces-
sory package which contains the Owner's Manual,
filter cartridges, skimmer baskets, screws for skirt,
lightlenses,andsparebulb.Setasideskirtpaneluntil
equipment set-up. Put filter cartridges in a dry place
until it is time to set up the spa equipment.
3. The spa should be moved on a dolly in its upright
positionwhilestillattachedtoitsshippingpallet. Ifthe
pallet must be detached before the spa is moved (for
example, to allow it to pass through a door), detach it
from the pallet as instructed in steps 4 thru 7. Rein-
forcementshavebeeninstalledonthespa. Notetheir
location at notches in the pan to the right of the
equipment door. Remove the affected skirt panel by
removingscrews from skirt. Then carefully place the
spa on the dolly so only the reinforced area contacts
4" X 4" X 72"
BLOCK
REMOVE
BOLTS
BRACKETS
PAN
SKIRT PALLET
C.
SKIRT REMOVED
(FOR MOVING SPA
WITHOUTAPALLET)
REINFORCED AREA
(FOR MOVING SPA
WITHOUT A PALLET
B.
A.

MINIMUM SERVICE ACCESS
3
Important: Read complete instructions before beginning installation.
Positioning Your Spa
Because your spa is portable, you can locate it just about anywhere you wish--on a deck, patio, or even indoors.
Just be sure to position it above ground in an area with good drainage and on a level, continuous surface which can
support the weight of the spa when filled with water and people; this weight is approximately 4874 lbs. (86 lbs. per
square foot). You must also provide access to the spa's equipment for service and general maintenance.
Electrical Requirements
YourSpa,asitcomesfromthefactory,requiresa230
VAC 60 AMP 4-wire grounded type electrical service
having copper connectors and must be in a separate
circuit having no other appliance connected in that
circuit. If you do not have this kind of circuit, a qualified
electrician should be called in to install the necessary
wiring. Inadequately sized wiring may cause a voltage
dropwhichmightcausetheunittomalfunctionandbring
aboutpermanentdamagetothespa'selectricalsystem.
We recommend that the wire be sized for a 3% voltage
INSTALLATION
drop. (See NEC.) Each "leg" of the incoming power to
neutral must be 105 VAC minimum at the spa when all
the spa equipment is running. The circuit must also
have a ground wire in order to take advantage of the
designed-insafetyfeaturesofthespa.Abondwiremust
also be used. Bond according to procedure described
on the next page.
Caution:Without propergrounding andbonding, a
system malfunction may cause fatal shock.
32"
87"
EQUIPMENT DOOR

4
Electrical Precautions
CAUTION: Do not apply electrical power to the
spa unless it is filled with water to the normal
waterlevel, which is approx. 7"below the spa rim
(see location of water level indicator on face of
skimmeronpage6). Ifthespa'smotor/pumps are
actuated when there is not sufficient water in the
unit, the circulation pump could be irreparably
damaged.Not heeding this caution will nullifythe
warranty. In addition to damaging the unit, oper-
ating the unit with insufficient water could cause
a fire.
Donot locate lighting fixtures directly above the spa;
lighting and electrical receptacles must be located at
least 5 ft. from the spa. Lighting located between 5
and 10 ft. from the spa must be on a circuit protected
by a GFCI. (See National Electrical Code, 680-6.)
Do not use electrically connected devices, such as
television,radio, toys, telephones,stereospeakers,
lights or cooking devices within 5 ft. of the spa when
the spa is being used.
Bonding and Grounding
All fixed metal objects located within 5 ft. of the spa,
such as fence posts, railings, door frames green-
house structures, gutters, etc., must be attached to
the bonding bar on the outside of the spa electrical
cabinet using #8 solid copper wire. With #8 solid
copperwire,bondthespatothehouseelectrical
panel or approved local bond.
An approvedgroundmaybean8ft.longground
rod, a plate electrode, or a buried metal water
pipewithatleast10ft.ofburiedpipe. Checkyour
local building code for requirements. Bonding
lugs are available at your local electrical supply
store. (Bond bar location is shown on page 5 .)
INSTALLATION
Outdoor Installation
If you install the spa outdoors, we recommend
thatyouprovideaconcretepadforittoreston. Todo
this, construct forms for a 8' x 8' x 4" (approx.) thick
levelpad. Installa #10 gauge wire mesh 6" x 6" steel
reinforced grid. Attach a #8 solid copper wire to the
grid with a ground clamp. This wire should be long
enough to reach the bond bar on the spa System
Control Module (min. 36"), but should not be located
under the base of the spa. Then pour the concrete
pad.
Drainage
Whether you install your spa indoors or outdoors,
you can drain it almost completely by attaching a
gardenhoseto the drain valve located on thesuction
teeofthespa. Simplyrunthehosetothehousesewer
lineordrainfieldandopenthedrainvalve.Seeinside
back cover for a quicker, permanent drain method.
Make sure the area surrounding the spa has good
drainagetokeepwaterfromcollectingat thebaseofthe
spa--especially near the equipment area. If drainage is
poor, install a drain line and/or gravel drain field (see
illustration below).
Indoor Installations
Water which splashes on the floor during use of the
spamaycauseawalkinghazard and/or structural dam-
age unless good drainage is provided and proper
waterproof building materials are used in the area sur-
roundingandbeneaththespa. Takeintoconsideration,
also, the high room humidity which will exist due to high
spa water temperatures. Providing natural or forced
ventilation of the room will help maintain comfort and
minimize moisture damage to the building. Jacuzzi
Whirlpool Bath is not responsible for damages resulting
from excess moisture or water spillage. Consult an
architect or engineer for aid in designing your indoor
installation.
HOLE FOR
ELECTRICAL CONDUIT
WIRE MESH GRID
GRAVEL
DRAIN
FIELD
DRAIN VALVE
(HOSE BIBB)
8' X 8' X 4"
THICK
CONCRETE
PAD
HOLE IN PAN FOR
DRAIN HOSE
TO
BOND
BAR
#8 BOND WIRE
(TO HOUSE
ELECTRICAL
PANEL OR LOCAL
BOND)
BOND BAR

5
INSTALLATION
Equipment Set-Up
1. Remove the plastic sheet covering the spa. Use
care; stepping into the spa with shoes will scratch
the acrylic surface.
2. Remove any packing materials from the spa.
3. Remove each filter cartridge from its plastic bag.
4. Pull open each skimmer/filter door by the handle
located in the middle of the door and remove the
skimmerbasket. Theninsertthefiltercartridgeinto
the filter housing and re-insert the strainer so that it
fits in place over the filter cartridge and close the
skimmer/filter door. See illustration on page 13.
5. Clean the interior of the spa of any remaining con-
struction debris. Remove stubborn stains, paint, or
tar with turpentine, isopropyl alcohol or paint thin-
ner. Amildliquiddishwashingdetergentonadamp
clothisfineforcleaningoffotherdirt. Plastercanbe
removed by scraping with a wooden edge; do not
useametalscraper,wirebrush,orothermetaltools,
as they will damage the spa's surface.
6. Install the skirt panel which was not installed on the
spaatthefactory. Todothis,securewiththescrews
provided in your spa accessory package and follow
instructions provided with panels.
7. On initial start-up, it is necessary to purge and
sanitize the system. Carefully follow the procedure
described here to purge and sanitize your spa.
• Remove the optional spa cover completely.
• Close the drain valve located on the suction tee.
• Fill the spa with water to its normal operating
level,whichistothewaterlevelindicatormarkon
the skimmer/filter frame.
• Turn on circuit breakers at the main electrical
panel.
• Select JETS on the SYSTEM switch.
• Add 1/4 cup sodium dichlor (a fast dissolving
granular type of chlorine) to the water and let the
whirlpool run for 15-20 minutes only.
• Turn off JETS.
• Turn off circuit breakers.
• Immediately open the drain valve and drain
the spa completely.
CAUTION: Leave the optional rigid cover off
the spa during this procedure. Do not use the
spa during this procedure. Drain the spa imme-
diately afterward.
8. Close the drain valve and fill the spa with water to
approx. 7 inches below the spa rim, or to water line
indicator mark on the skimmer frame. (See illustra-
tion on this page.)
9. Turn on circuit breakers at the main service panel.
10. Set the heater thermostat for the maximum tem-
perature.
11. Test the spa for proper operation. (Refer to Operat-
ing Instructions.)
12. Refer to Water Quality section of the Operating
Instructions. Test for water quality; then add treat-
ment chemicals to ensure proper levels.
All Jacuzzi Whirlpool Bath spas are factory tested for
proper operation and water tight connections prior to
shipping. If leaks or other malfunctions are detected,
immediatelynotifyyourJacuzziWhirlpoolBathdealeror
Authorized Service Agent, or call Jacuzzi Whirlpool
Bath, [phone] (510-938-7070 in California), for
Warranty Service.
WATER RAINBOW
SPOUT
CONTROL PANEL
THERMOMETER
SKIMMER/FILTER
DOORS
UNDERWATER
LIGHT
FULLYADJUSTABLE
WHIRLPOOL JETS
AIR INDUCTION
CONTROL KNOBS
SUCTION
COVER

OPERATING INSTRUCTIONS
Now that your Tirage Plus spa is in place, you are probably eager to take advantage of its unique designed-in
features—especially the patented Jacuzziº Whirlpool Bath hydromassage performance. Besides being a beautiful
addition to your indoor decor or outdoor landscaping, your Jacuzzi whirlpool spa will provide you with the ultimate in
spa pleasure.
Basic Control Set-Up
Thecontrolset-uponyour Tiragespa isdesignedtogiveyoufingertipcontrol ofthe heater,airinduction,lightsand
whirlpool, filter, and blower systems of your unit from inside or outside your spa. Follow the basic control set-up
described below to familiarize yourself with the several functions of the control panels located on the top of the spa.
CAUTION
Donotturn on powertothe spaunlessit is filledwithwater tothenormal water level.(Seewater line indicator
mark on skimmer frame.) When the power is on, the built-in timer may activate the system even though the
SYSTEM is turned off at the control panel. If the spa’s motor/pump is actuated when there is not sufficient
waterintheunit,the circulation pump andheatercouldbeirreparablydamaged. Not heedingthiscautionwill
nullify the warranty. In addition to damaging the unit, operating the spa with insufficient water could cause
a fire.
6
•Your spa is provided with a ground fault circuit
interrupter (GFCI). At initial start-up and at least
once a month thereafter, with power on, push the
test button located on the System Control Module.
Theresetbuttonshouldpopout. Pushthisbuttonin
to reset. If the interrupter fails to operate in this
manner,thereisagroundcurrentflowingoradevice
malfunctioning, indicating the possibility of electric
shock. Turn off power and do not use the spa
until the source of the breakdown has been
identified and corrected.
•Using a garden hose, fill the spa with water to the
water line indicator mark on the skimmer frame.
•At the house service panel, turn on the circuit
breakeror switch that controls the electrical service
to your spa. (Make sure there is no other appliance
on that circuit.)
•Open the skirt door giving access to the System
Control Module.
OPERATION
HIGH TEMPERATURE SAFETY SWITCH
High temperatures above the thermostat range
will cause the high temperature safety switch to
trip and the system to turn off. See operating
instructions. When water temperature is less
than 100°F., reset by pressing the safety switch
reset button located on the cover of the heater
enclosure.
CAUTION: DO NOT BREAK DOOR SEAL;
OPENING DOOR VOIDS WARRANTY
THIS EQUIPMENT REQUIRES QUALIFIED SERVICE
PERSONNEL FOR PROPER REPAIR. CONTACTYOUR
JACUZZI WHIRLPOOL BATH DEALER FOR SERVICE.
NO USER SERVICABLE PARTS BEHIND THIS DOOR.
CAUTION
This system is GFCI (Ground Fault Circuit Interrupter) pro-tected for your
safety. Bypassing the GFCI or tampering with the system in any way may
cause electrical shock, in-jury or death and will void the warranty. GFCI
protection does not extend to 230 VAC circuit conversion. If test indi-cates
that the GFCI is not functioning, DO NOT USE THE UNIT until the electrical
problem has been corrected. (See installation instructions.) TESTTHE GFCI
ONCE A MONTH.
TEST PROCEDURE
Unit must be filled to proper water level and correct power supplied.
1. Push TEST button of GFCI.
2. RESET button should pop out. This should cut off power
to the system. CAUTION: if RESET button does not
pop out, or if RESET button does pop out and system
is still on, DO NOT USE YOUR SPA.
3. If the GFCI tests okay, restore power by pushing in the
reset button. The RESET button must be pushed until
it locks into place and remains depressed.
IF THE GFCI FAIL TORESET PROPERLY,DO NOT USE
THE SPA! CONTACT A QUALIFIED ELECTRICIAN.
FLOW
SWITCH
TEMP.
SAFETY
SWITCH
INTERLOCK
SWITCH
LIGHT #1
LIGHT #2
M
o
n
d
a
y
T
u
e
s
d
a
y
W
e
d
n
e
s
d
a
y
T
h
u
r
s
d
a
y
F
r
i
d
a
y
S
a
t
u
r
d
a
y
S
u
n
d
a
y
Turn dial to correct time and day. Slide tabs
toward center for desired operating periods.
(One tab = 2 hrs.)
HEATER
BLOWER
JETS
MOTOR/
PUMP
FILTER
MOTOR/
PUMP
GFCI
TIMER
PLUG-IN
C0NNECTORS
FIELD WIRING BOX
(System Control Module P/N 876000
IMPORTANT: THIS UNIT IS FACTORY WIRED FOR USE
ON 115 VAC 30 AMP (3 WIRE) CIRCUIT ONLY.
Converting the electrical system to 230 VAC requires
a 4 wire 230 VAC 50Amp circiut breaker; refer to the
instructions on the rear of this cover. The conversion
should be done by a qualified electrician.
REFER TO N.E.C. (NATIONAL ELECTRIC CODE AND
LOCAL CODES)
115 VAC ONLY
WHIRLPOOL
BATH
R
FIELD WIRING
BOX FOR 230 VOLT
INCOMING POWER
CUIRCUIT BREAKERS
CIRCUIT
PROTECTOR
BUTTONS
TIMER
GFCI

•Makesurethecircuitprotectorbuttonsarepushed
in.
•Locate the HIGH TEMPERATURE SAFETY
SWITCHwhichisaraised buttonon theendofthe
heater. Pushthis buttontobesureit isinthe reset
mode. The purpose of this switch is to shut down
the spa if the water becomes excessively hot. If,
for some reason, the switch is tripped, the reset
buttonmustbepushedinfor the heater to operate
again after the water has cooled to about 100°F.
•Set the built-in timer (see below). Use of the timer
allows two modes of operation: timed HTR/FLTR
and timed FILTER . With the SYSTEM switch
Basic Control Set-Up (Continued) turned OFF and the HEATER knob set to the
desired temperature, the timer will activate the
heater and filter pump to operate during the time
period set on the timer. With the SYSTEM switch
turned OFF and the HEATER knob turned to its
lowest setting, the water will be filtered and the
water temperature will be maintained at the mini-
mumtemperature(approx.50degrees)duringthe
time period set on the timer.
Setting the Timer
The built-in 7-day timer is located in the System
Control Module. The tooth-like tabs that are located on
the dial can be set to activate the filter system for two-
hour periods on any day(s) of the week. First set the
correcttime.Setthetimeofdaybyrotatingtheouterdial
and aligning the correct time with the small arrow in the
inside of the dial. Note: Both correct time and day must
be set. Next slide one of the tabs toward the center of
the dial at the time at which you wish the filter system to
operate.Notethatthetimedmodecanbeginatanytime
of day or night on any specified day of the week.
Note: Iffiltrationisbeingcontrolledbythetimerbutyou
do not want the water heated, adjust the HEATER knob
to its lowest setting. Because the thermostat is con-
nectedin thiscircuit,theheaterwill maintainaminimum
water temperature.
TIMER
7
OPERATION
PUSH IN ONE TAB
FOR EACH TWO
HOUR PERIOD OF
OPERATION
M
o
n
d
a
y
T
u
e
s
d
a
y
W
e
d
n
e
s
d
a
y
T
h
u
r
s
d
a
y
F
r
i
d
a
y
S
a
t
u
r
d
a
y
S
u
n
d
a
y

CONTROLS
A switch panel giving you convenient control of the
JETS, filter, HTR/FLTR, lights and air blower is located
on the spa rim.
Toensureyoursafetyandalloweasyoperation,your
spa is equipped with two air-activated switches. One,
the SYSTEM switch, controls the whirlpool jets, heat,
and filtration. The other switch, ACCESSORY controls
the air blower and optional light. Refer to the Control
Panelillustrationforanexplanationofthevariousswitch
functions.
SYSTEM
TheSYSTEMswitchcontrolsthefollowingfourfunc-
tions in the continuous sequence indicated:
1. OFF
2. JETS
3. HTR/FLTR
4. FILTER
(The next selection is OFF again.)
UsetheJETSfunctionasareferencetoindicateyour
CONTROL PANEL
8
location in the function sequence, since that function is
the most obvious when operating.
For best performance and increased equipment life,
pauseasecondortwobetweenpush-buttonselections.
Not pausing may cause the switch to malfunction.
ACCESSORY
The ACCESSORY switch controls these functions in
the continuous sequence indicated:
1. OFF
2. AIR
3. AIR/LIGHT
4. LIGHT
THERMOMETER
OPERATION
BATTERY
TEMPERATURE
READOUT
A
C
C
E
S
S
O
R
Y
H
E
A
T
E
R
O
F
L
I
G
H
O
F
S
Y
S
T
E
M
J
E
T
H
T
R
/
F
L
T
F
I
L
T
E
R
A
I
R
/
L
I
G
H
T
A
I
R
OFF
(Time clock controls
filter pump. Heater will turn
on with filter
pump if thermostat is set.)
JETS
(Maximum whirlpool
action. Heater will
maintain temperature set
by thermostat if converted
to 230 VAC.)
HTR/FILTER
(Filter pump and heater
will turn on as necessary
to maintain water
temperature setting.)
TEMP.
CONTROL
KNOB
ACCESSORY SWITCH
(Controls Air Blower and
light functions.)
SYSTEM SWITCH
(Controls Jets,
Heater/Filter and Fliter
Only functions.)
FILTER
(Filter pump will run
continuously; heater will
turn on as necessary to
maintain water
temperature setting.)
HEATER
INDICATOR
LIGHT

skirtpanelsin place and if the air temperatureis50°For
warmer. This rate will necessitate a waiting period
before using the spa, the length of which will be deter-
minedby thetemperature ofthewaterbeforeturning on
the heater. For example, if the water in the spa is kept
atabout70°Fwhenthespaisnotinuse,andthedesired
temperatureis100°F,itwilltakeabout5hourstoheatup
sufficiently.
Onceyouhavedeterminedthedesiredsettingonthe
thermostat knob, it is not necessary to change or re-
adjust it again during normal operation unless you
decide on a different setting.
Theoptionalspacoveravailableforyourspawillhelp
control heat loss from the water surface and thereby
reduceenergyconsumption. Youcanimprovethespa’s
heat retention by keeping the spa cover in place on the
spa while heating the water.
Note on Determining Water Temperature:
As spa products generally perform in a narrow range
ofoperating temperatures,werecommendthatyou use
a medical (clinical) type thermometer for an accurate
measurementof spa watertemperature. Othertypes of
thermometers, generally available, such as those used
for swimming pools, are not sufficiently accurate to
determine spa water temperatures. Take water tem-
perature readings in the HTR/FLTR mode when the
heater has just turned off; the indicator lamp on the
control panel will turn off at this time.
9
OPERATION
TEMP. CONTROL
Turn on the heater by selecting the HTR/FLTR mode
with the SYSTEM switch.
Withthisselection,youcanverifythatthespa’sheater
is operating by viewing the indicator light on the spa
control panel.
Set the HEATER knob by rotating it to the desired
temperature. When the water temperature is lower than
thatsetbytheHEATERknob,theheaterandfiltermotor/
pumpwillbeactivated.Theheaterandfilterfunctionswill
automatically turn off when the desired temperature is
reached. When the heater is on, the water is also being
filtered. The heater will also maintain water temperature
in the JETS mode.
The HEATER Control is designed to maintain a mini-
mum temperature of approximately 45 - 50°, its lowest
setting. This does not necessarily protect the spa from
freezing. See page 14 for winterizing procedures.
Setting the Thermostat
You will notice by the indicator light that the heater is
on when the water temperature falls below the desired
temperature and will turn off when that temperature has
been reached.
Whenthespaisnotinuse,youcansetthethermostat
to a lower temperature; then, when you wish to use the
spa, adjust the HEATER knob to the desired tempera-
ture. Thewatertemperaturewill riseat arateofabout6°
perhourwiththeoptional spacover, foaminsulationand
THERMOMETER
TEMPERATURE CONTROL
SYSTEM SWITCH
ACCESSORY SWITCH

Silent Air Induction
The intensity of the whirlpool action is determined by
how much air is inducted into the water. You have
controlofthisbyadjustingtheairinductioncontrolknobs
located on both control panels. For maximum air induc-
tion, rotate each control knob fully counter clockwise to
the largest circle. For fewer air bubbles, decrease the
amount of air induction by rotating the control knob
clockwise. When the knobs are turned to the smallest
circles, only water is being circulated.
10
Water Rainbow™Spout
TheWaterRainbowspoutwilladdthesoothingsound
ofa waterfalltoyourbathingpleasure,aswellasprovide
beautiful cascades of shimmering water for an exciting
visual effect.
Activate the waterfall feature by first turning on the
JETS,HTR/FLTR,orFILTERfunction,thenrotatedown-
ward the flow control lever located on the left side of the
spout. Use this lever to adjust the amount of water
flowingthroughtheWaterRainbowspout. Thewaterfall
effect will be greatest in the JETS mode. Turning off the
flowat the fullyadjustablejets willdramaticallyincrease
Water Rainbow flow.
CAUTION: ThewatercirculatingthroughtheWater
Rainbow spout is not fresh water and therefore is
not suitable for drinking.
Air Blower
The Tirage features a built-in air blower and factory
drilled air holes in the seats of the spa to add to your
enjoyment. The blower sends air to a channel located
under the spa's seats; this air is distributed through the
air holes, forming tiny bubbles which travel upward until
they reach the surface and burst. The exciting visual
effect of the bursting bubbles contributes to the overall
hydromassage experience.
Activate the blower by pushing the ACCESSORY
switch. (Note that the filter pump will also come on
at this time.)
Filtration
When you are ready to leave the spa, push the
SYSTEM switch button to turn off the whirlpool. Then
select the HTR/FLTR mode. Adjust the HEATER knob
to the temperature at which you wish the water main-
tained. In this way, the water will be filtered when the
heatergoesontomaintainthe temperature. Whenever
thewatertemperaturereachesthedesiredtemperature,
the pump will turn off.
For continuous filtration, select FILTER on the SYS-
TEM switch. In this mode, the filter pump will run until it
is manually deactivated while maintaining the water
temperature selected by the HEATER KNOB. Set the
HEATERKNOBtoitslowestsettingunlessyouwishthe
higher temperature to be maintained. Running the filter
pump for at least two hours per day is sufficient.
Another way to be sure the water will be filtered is to
turn the SYSTEM off and set the built-in timer in the
SystemControlModuletoturnthesystemon atacertain
time to filter the water. Be sure there is sufficient water
in the spa (filled to the water line indicator mark on the
skimmer/filter frame) when the timer is set, or the spa’s
motor/pumpcouldbedamaged.(Seepage7forinstruc-
tions on setting the timer.)
HIGH VOLUME FULLY
ADJUSTABLE WHIRLPOOL JET
OPERATION
Normal Operation
Whirlpool System
You can enjoy your spa with or without activating the
whirlpool. Either way, bathing in your spa can be
pleasurable, as well as therapeutic.
For an invigorating spa experience, you can take
advantage of the built-in whirlpool system. To do this,
push the SYSTEM switch button to select the JETS
mode. Sit or recline in the spa so you are comfortable.
The fully adjustable whirlpool jet located on the wall
oppositethecontrolpanelcanbeadjustedtocontrolthe
force of the water coming into the spa. For stimulating
action, increase the force of the flow by rotating the jet
handle to the left. For a more relaxing effect, rotate the
handle to the right (clockwise). The directionally adjust-
able whirlpool jets can be directed toward any location
onthebody,particularlytowardanyareathatfeelstense
or stiff. The warmth of the water and the stimulating
water flow from the jet will pleasantly increase circula-
tion.
Or,forthe total whirlpool effect and all-over feelingof
well-being, you can adjust all jets so they point in a
clockwiseorcounter-clockwisedirectiontocirculatethe
air and water mixture in a circular motion all about the
spa.
Finally, after a busy, stressful day, you can look
forward to soaking in your spa in still water with no
turbulence-only the gentle warmth of the soothing and
relaxing water.

Filtration
The filtration system of your spa will keep your water
clear and clean if used properly. We recommend that
yourunyourfiltersystemforatleasttwohourseachday.
The filter cartridge elements will trap most solid materi-
als and debris in the water. However, the presence of
materials such as body oils or other particles which are
too small to be captured in the filters may bring about
various undesirable water quality conditions. These
conditions can be corrected with the use of spa treat-
ment chemicals which are available from your Jacuzzi
Whirlpool Bath dealer. Such conditions include the fol-
lowing:
Foaming:A defoamer is available to minimize foam-
ingof the water. This condition is usually caused by the
additionof soapsoroils, or otherfatty substances tothe
spa water. The interaction of these with hot water,
especially at high pH (more alkali), will cause the water
to foam. (See Water Quality Definitions.)
OilFilmorCloudyWater:Addclarifiertocongeal
oil film on the water surface into globules sufficiently
large to be trapped by the system’s filter. Cloudiness is
causedbyparticlesthataretoosmalltobetrappedinthe
filter. and is also due to the presence of human body
oils, lotions, and cosmetics. During normal use, these
materials can accumulate on the filter element and clog
its pores. The addition of clarifier will make the water
clearer, but clogged filters must be cleaned as pre-
scribedunderthesectionentitled“FilterMaintenance”in
this manual.
Hard Water: Add a de-mineralizer to break down or
de-ionize mineral particles present in the spa water.
Follow the “Filter Maintenance” procedure described in
this manual to ensure optimum performance of your
spa’s filtration system.
11
MAINTENANCE
MAINTENANCE
Water Quality and Water Chemistry
Maintaining water quality and water chemistry in your spa is extremely important and should be a regular part of
your spa maintenance program, as a neglected spa can be a breeding place for dangerous bacteria.
The water quality of your spa is maintained by a combination of filtration and chemistry. The spa’s integral filter
system helps maintain the water cleanliness and clarity by trapping most solid materials such as body oils, hair, and
other debris resulting from normal use. However, the most important part of maintaining water chemistry is keeping
theproperlevelofdisinfectantinthewateratalltimes. This isaccomplished byadding chlorineor bromine(but never
mix the two!) to the water, which will control particles too small to be trapped by the filter, such as bacteria and algae,
andwilloxidizeany organicmaterials. Followinstructionsprovidedhereandwithwater qualityproducts forthe health
and safety of spa users, as well as to make your spa bathing as enjoyable as possible.
Water Chemistry
Youcanensurebetterwaterchemistrybytestingyour
spawatereverydayandadjustingthechemicalbalance
frequently. Obtain a water quality test kit, designed
especially for spas, from your Jacuzzi Whirlpool Bath
dealer.Thetest kit must be of the type which allows you
to test for the disinfectant (chlorine) level, pH, and total
alkalinity. Make sure, also, that chemicals used in your
spa are especially for spa use, and not for swimming
pools, as water quality maintenance of spas and swim-
ming pools is very different.
Setupadailyprogramatfirsttocheckthedisinfectant
level, pH, and total alkalinity of the water to familiarize
yourself with the amount of chemicals to add and to
determine how often to make chemical adjustments
duringnormaluse.Rememberthatthemoreheavilythe
spa is used, the more often you should check the water
chemistry.
When adding any chemicals, always run the filter
system to ensure complete dilution with the water. Do
not add chemicals directly into the skimmer opening.

Water Chemistry (Continued)
Disinfecting:
Whenfillingthespaforthefirsttime,followthepurge/
sanitizing instructions in the Equipment Set-Up proce-
dure of the Installation Instructions.
Add a disinfectant to the water on a regular basis to
help control the amount of bacteria, algae and organic
materials.Suchbacterialcontaminants,ifnotcontrolled,
could cause skin rashes or other physical problems. To
disinfect the spa for normal use, first establish the
amountofchlorineorbrominetoaddanddeterminehow
often you need to add it.
Werecommendthatyoumaintainafreechlorinelevel
of 2.0 - 5.0 ppm at all times except when you must
exceedthatduringtheinitial purge/sanitizingprocedure
or during superchlorination (see “Water Quality Defini-
tions” below). Superchlorinate your spa every two
weekswith heavy use. If using sodium dichlor, add one
heaping tablespoon for each 150 gallons of spa water.
Scrub the spa surfaces with this solution to remove any
oilydeposits. This willensurethat any bacteriaor algae
which are resistant to the normal disinfectant level are
killed. Afteraddingthe disinfectant,runthefiltersystem
andallowthefreechlorineleveltoreturntothe2.0to5.0
ppm range before using the spa again. Do not install a
rigid cover during this procedure until the disinfec-
tant level is back to normal. High concentrations of
chlorine or bromine will damage spa fitting finishes
if the cover is in place.
Balancing pH:
Forgoodhygiene and equipment longevity, maintain
the pH of your spa water according to the instructions
provided. pH is the measure to determine if the spa
CalciumHypochlorite: Agranularchlorineproductthat
isinexpensiveandeffectivebutnotrecommendedbecause
it often tends to form calcium deposits on heater parts and
plumbingfittings and leaves an unattractive film onthe spa
at the water line.
Sodium Hypochlorite: A liquid chlorine product that is
inexpensive and effective but not recommended because
the liquid is readily spilled onto the spa or a surrounding
area, causing permanent damage.
Total Alkalinity: The measure of amount of alkaline
materials (such as carbonates, bicarbonates and hydrox-
ides) in the water. High alkalinity inhibits the effectiveness
of chemicals to change the pH. If the alkalinity of your spa
water is high (above 150 ppm), it is advisable to drain the
water from the spa and begin the balancing process over
again. Low total alkalinity (below 60 ppm) could be corro-
sive and damage your spa system.
Superchlorination: (also referred to as “shock treatment)
The addition of an above-normal level of disinfectant to kill
any bacteria or algae that might have become resistant to
normal levels of disinfectant.
pH: A chemical term used in expressing relative acidity or
alkalinity in numeric values with 7.0 usually regarded as
neutral, and for purposes of this manual, indicating pure
water. From 7 to 0 indicates increasing acidity, and 7 to 14
indicates alkalinity.
PPM: Parts per million.
FreeChlorine: Chlorinethathasnotcombinedwithother
chemicalsandthatisavailabletodestroybacteriainthespa
water.
TriChlor: A form of chlorine used in pool or spa water
treatment; usually supplied in tablet form. Not recom-
mended because of its higher acidic nature and slow
dissolvingaction. Prolongedcontactwiththespashellmay
bleach or permanently mark the shell.
Sodium DiChlor: The type of chlorine that is recom-
mended for spa use, as it is available in fast dissolving
granular form. It is neither excessively acid nor alkaline in
character and does not readily dissipate in higher water
temperatures.
WATER QUALITY DEFINITIONS
water is too acid (low pH) or too alkaline or basic (high
pH). The ideal range for spa water is 7.2 to 7.6 pH. For
excessiveacidity(below7.2pH)addsodaashorsodium
bicarbonate to the spa water. For excessive alkalinity
(above 7.6 pH) add dry acid to the spa water.
Caution: Refer to the spa chemical manufacturer’s
instructionsfortheinitialmountofchemicalstoadd
for the gallonage of your spa. Low pH can cause
equipment damage, as acid water will dissolve met-
als,whilehighpHcancausescaleorcalciumdepos-
its to build up in the system or on the shell. After
addingchemicals,runthefiltersystemforatleast30
minutes before testing water quality again for accu-
rate readings.
Balancing Total Alkalinity:
Totalalkalinityisthemeasureofbasematerialsinthe
water. The recommended range for total alkalinity is
between 80 ppm and 150 ppm. If the chemistry of the
water is not within this range, you will have difficulty
adjusting your pH level, which will affect your adjust-
ments for the proper amount of free available chlorine.
If the alkalinity of your spa water is high, it is advisable
to drain the water from the spa and begin the balancing
process over again. Purge and sanitize your spa
(according to instructions in Equipment Set-Up section
of the Installation Instructions) and clean the spa sur-
faces thoroughly before refilling with fresh water. Then
re-establish water chemistry. If the spa is used heavily,
change the water at least every month.
12
MAINTENANCE

The suction strainers located in the foot well area
should be checked at least once a week for collected
debris,suchasleaves,hair,etc.,andcleanedasneces-
sary. It may not be necessary to remove the strainer to
cleanit,butshouldyouneedto,removethecenterscrew
withaPhillipstypescrewdriverandcleanthestrainerby
flushing with water from a hose.
CAUTION: Be sure to replace the suction strainer
immediately after cleaning. It is a safety device and
must be in place over the suction fitting to minimize
potential hazard of hair and body entrapment.
If heavy rains raise the spa water level, drain the spa
to its normal level.
A rigid spa cover (available as an option), when in
place over the spa, will help reduce evaporation and
control the amount of debris entering the spa when the
spa is not occupied. In addition, its use will reduce
energy consumption.
Skimmer Basket Maintenance
Thebasketlocatedineachskimmerofthespashould
bechecked atleastonce a weekfor collection ofdebris,
suchasleaves,hair,etc.,andcleanedasnecessary. To
cleanthebasket, remove it from the skimmer by pulling
itout;thenbackflushitwithagardenhoseandre-install.
Make sure the basket is properly seated in the filter
housing, or the door will not close.
13
Water Level/Drain
The water level in the spa must be maintained at its
normal level. Evaporation and splashing will cause the
water level to drop.
Whenconcentrationsofimpuritiesfrom evaporation,
water quality chemicals, body oils, perfumes, dirty feet,
and winds, etc., accumulate in the spa and cannot be
filtered out, it is necessary to drain your spa and refill it
withfreshwater. Thisshouldbedoneevery2monthsor
more often, depending on the amount of use.
To drain the spa, first turn all controls to OFF. Then
turnoffcircuitbreakersatthemainelectricalpanel.Pass
a garden hose through a hole in the pan and connect it
tothehosebibbinthesuctionplumbing.Turnthehandle
and drain the spa.
After draining the spa, clean the spa shell, suction
strainers,skimmers,andfilters;thenclosethehosebibb
and refill the spa with fresh water. Check the pH level
and maintain water quality.
MAINTENANCE
Filter Maintenance
The filters should be checked periodically. In normal
use, check the filters at least once a month. Keep the
filters clean; obstructed filters reduce water quality and
inhibit proper system performance.
A removable filter cartridge is located inside each
skimmer. To remove it, pull open the skimmer door by
the handle located in the middle of the door. Slide the
basket out; then pull the filter cartridge upward and out
of the housing by the loop at the top of the filter. Clean
thefilterbyseparatingthefoldsofthefilterandspraying
with fresh water from a garden hose; then re-install the
cartridge in the housing and replace the basket, revers-
ing the above procedure.
Oilswillcoatthefilters,resultinginareducedflow. To
remove such materials, soak the cartridges in a plastic
pail containing a commercial filter cleaning solution
(available from your Jacuzzi Whirlpool Bath dealer or
most spa supply stores). Follow the manufacturer’s
instructionsfor use. Another method is to soak the filter
cartridgesinaplasticpailcontainingamildsolutionoftri-
sodiumphosphate(TSP)andwater. Anhourofsoaking
time is usually required to break down oil coatings from
thecartridge. Use a stronger solution of TSP and water
to remove algae. Most hardware or paint stores stock
TSP. Usethesamemethodofcleaningwhencartridges
become plugged with clay or vegetation.
Replacement cartridges are available through your
Jacuzzi Whirlpool Bath dealer.
WATER LEVEL
INDICATOR
MARK
FILTER
CARTRIDGE
SKIMMER
BASKET
WATER LEVEL
INDICATOR MARK

In a climate where winter temperatures are below
freezing, follow this procedure when the spa will
NOT be used:
1. Select the OFF mode.
2. Turnoffpowertotheunitatthehousecircuitbreaker.
Drainthe spa completely by attaching a garden hose
to the hose bibb on the suction plumbing. Then
remove the hose and leave the hose bibb open to
completely drain the spa. Close the drain valve.
3. Remove the filter cartridges, clean them, and store
them dry.
4. Keepwateranddebrisoutbycovering witharigidspa
cover.
5. Before using the spa again, review the Operating
Instructions.
CAUTION: Not winterizing will cause irreversible
damage(atfreezingtemperatures)tothepump and/
or plumbing lines.
Automatic Filtration/Maintenance
If you plan to be away, you should maintain minimum water quality by running the filter system. To do this, set the
timertoturnthesystemonforatleasttwohourseachday. Thiswillcausethefiltersystemtoturnonatadesiredtime.
Set the timer according to instructions on page 7 with the SYSTEM switch OFF. If you do not want the water to be
heated, turn the HEATER knob to its minimum setting.
Ifyouwillbeawayforanextendedperiod,however,werecommendthatyoudrainthespa(followingtheprocedure
describedunderWinterizingon this page),as longperiodswithoutmaintenanceofwaterquality couldbe detrimental
to the spa.
Anothermeansofmaintainingminimumwaterqualitywhileawayforlessthan twoweeksistofollowtheprocedure
outlinedforwinterizingyourspainawarmclimate. SeeWinterizing.Note: Wedonotrecommendusingthisprocedure
if you are absent during the summer, when algae build-up is most likely.)
Always keep your spa covered when not in use to reduce heat loss and evaporation and to prevent debris from
falling in.
Winterizing
14
Note: If the spa is to be used during winter in a cold
climate, see warm climate instructions below.
In a warm climate where there are occasional freez-
ing temperatures, follow this procedure:
1. Select the HTR/FLTR mode.
2. Set the thermostat to its minimum temperature (45 -
50°F.) by turning the dial all the way counter-
clockwise.
3. Maintain a chemical balance. (See Water Quality
section.)
4. Keep the spa covered.
MAINTENANCE
Factory Installed Redwood Skirt
Your Tirage spa is supplied with a factory-installed
redwood skirt which completely surrounds the spa. The
doorcanbeopenedforroutinemaintenance,settingthe
timer, and for testing the GFCI before use.
Theskirtismadeofkiln-driedredwoodandcanbeleft
naturaltoweather,oryoumaychoosetoapplyastainor
clear finish. Consult your local paint dealer for the
appropriate product. NOTE: WE RECOMMEND A WA-
TER BASED MATERIAL. OIL OR SOLVENT BASED
FINISHINGMATERIALSDEGRADETHESKIRTBACK-
ING MATERIAL.
It may become necessary to remove one or more of
the skirt panels for major service access, but all the
panels must be securely in place during use of the
spa.
To detach any of the panels, first remove all screws
from the panel being detached.
Thepanelscanbere-attachedtothespabyreversing
the above procedure.
FACTORY INSTALLED
REDWOOD SKIRT
SKIRT PANEL

15
Covering Your Spa
An optional rigid spa cover is available to place on
top of the spa. Use of this cover will help to minimize
heat loss and evaporation, and thus reduce energy
costs. The cover is also an attractive and efficient
meansofpreventingdebrissuchasleavesanddirtfrom
entering your spa when not in use. Follow the instruc-
tions for use and care provided with the spa cover.
CAUTION: While the spa cover is rigid, it is not
designed to support any weight. Therefore, as a
safety precaution and to preserve the life of your
cover, you must not sit, stand, or lie on it; nor
should you place objects of any kind on top of it.
Jacuzzi Whirlpool Bath does not guarantee or war-
rant this cover. REFER TO SPA COVER MANUFAC-
TURERS INFORMATION PROVIDED WITH THE
COVER.
Spa Light
Colored filters are provided with your spa. To
changea filter,simply pullthefilteroutof thefitting and
replace it with the desired colored filter. Replacement
bulbs(#912)arealsoincluded.Puttheminasafeplace
for future use. When a bulb burns out, replace it from
the back of the light fitting, pulling out the bulb recep-
tacle.
MAINTENANCE
LIGHT BULB
REPLACEMENT
LIGHT BULB
NORMAL
LENS
COLORED
FILTER
LIGHT
BEZEL
SHELL
BULB
RECEPTACLE
LOCKING
NUT
Cleaning Your Spa
Your spa shell consists of two layers of plastic
materials. Its smooth top surface of acrylic is tough and
durable and contains concentrated color. This is sup-
ported by a substantial thickness of fiberglass-rein-
forced polyester resin. A catalyst causes a chemical
reaction during manufacture that bonds these layers
permanently into a hard, strong material. With a mini-
mum amount of care and cleaning, your whirlpool spa
will look new for years.
To clean your spa, simply use a mild, non-abrasive
liquid detergent, isopropyl alcohol, or commercially pre-
paredspacleaner. Donotuseabrasivecleaners. You
can protect and restore the gloss to a dulled surface by
applying Meguiar’s #10 Mirror Glaze, which is a product
specifically designed for use on acrylic finishes. If
Meguiar’s is not available, an acrylic polish of equal
quality or automotive paste wax will do.
Use a spa cleaner for residue buildup at the water
level of the spa surface. This may be applied to the
acrylic surface with a soft cloth and wiped clean. Use
sparingly in small amounts to avoid contaminating the
spawater. Ifheavily soiled, it may be advisable tolower
the water level 2-3 inches before cleaning; then refill to
normal level.
Repairs to the Acrylic
Minor scratches which do not penetrate the color
finish (acrylic) can be removed with 600-grit wet/dry
sandpaper. RestoretheglossyfinishwithMeguiar’s#10
Mirror Glaze or comparable automotive paste wax.
Majorscratchesorgougeswhichpenetratetheacrylic
surface will require refinishing. Ask your Jacuzzi Whirl-
pool Bath dealer for special instructions.
TIRAGE SPA WITH
OPTIONAL COVER

16
PROBABLE CAUSE REMEDY
PROBLEM
3. Heater not functioning but
HEATER light on. A. Relay malfunction.
B. Element malfunction.
C. Heater plug loose.
A. *
B. *
C. Check Heater Plug connection
4. Water not clean. A. Clogged or blocked suction
strainer or skimmer basket.
B. Filter clogged (dirty).
C. Poor water chemistry.
D. Insufficient filtering time.
E. Improper maintenance.
F. High content of solids in water.
G. Filter motor plug not connected to
System Control Module.
A. Clean strainer/skimmer basket
B. Clean or replace.
C. See “Chemistry” section.
D. Run filter.
E. See Maintenance section.
F. Use clarifier or drain and refill spa.
G. Check Filter Motor connection on
System Control Module.
5. Abnormal water usage. A. Leak in suction line, discharge line,
or connections.
B. Excessive evaporation and/or
splashing.
A. Repair leak.
B. Use rigid spa cover; lower thermostat
setting.
6. Low water flow from jets. A. Normal operation in FILTER or
HTR/FLTR or AIR mode.
B. Low water level.
C. Clogged or blocked suction strainer
or skimmer basket.
D. Dirty filter.
E. Adjustable jet partially closed.
A. Select JETS mode for maximum flow.
B. Fill to water level indicator mark on
skimmer/filter frame.
C. Clean strainers or skimmer baskets.
D. Clean or replace.
E. Open jet.
1 . Control Switches do not re-
spond. A. Actuated too rapidly
B. No power to the unit.
C. High Temperature Safety Switch is
tripped
A. Wait 60 seconds; system will be
restored automatically.
B. Turn on circuit breakers.
C. Reset button on heater after water has
cooled. See *Note if switch continues
to trip.
2. Heater not functioning. A. Heater mode not selected.
B. No power to heater.
C. Thermostat set lower than water
temperature.
D. High temperature safety switch
tripped.
E. Abnormally low water flow.
F. Heater relay not operating.
G. Heater element failure.
H. Flow switch not operating.
A. Select HTR/FLTR mode.
B. Check house circuit breakerand GFCI.
C. Turn to desired temperature.
D. Reset button on heater after water has
cooled; see *Note if switch continues
to trip.
E. *
F. *
G. *
H. Check flow switch and plug-in connec-
tion on System Control Module
CAUTION: This equipment requires qualified service personnel for proper repair. Contact your Jacuzzi Whirlpool
Bath dealer or Authorized Service Agent for service.
TROUBLESHOOTING GUIDE
*Note: The skills and tools necessary for the safe repair of this spa require the services of qualified
service personnel. Contact your Jacuzzi Whirlpool Bath Authorized Service Agent or Dealer.

17
6. Low water flow from jets.
(Continued)
PROBABLE CAUSE REMEDYPROBLEM
7. No water flow from jets. A. Power turned off.
B. Selector switch in OFF.
C. House circuit breaker tripped;
no power to system.
D. Spa circuit protector tripped.
E. High temperature safety switch
tripped.
F. GFCI tripped.
G. Faulty pump or motor.
H. Motor(s) not connected.
I. Jet (or jets) closed.
A. Turn on power at service panel.
B. Select other function.
C. Reset circuit breaker.
D. Reset circuit protector.
E. Reset button on heater after water has
cooled; see *Note if switch continues to
trip.
F. Reset GFCI
G. *
H. Check motor plug connection on System
Control Module.
I. Open jet.
9. Water leakage at pump shaft
(rotating connection between
pump and motor).
A. Worn or damaged pump seal. A. *
10. Motor will not start. A. Power off.
B. OFF mode selected.
C. House circuit breaker tripped
or in OFF position.
D. Spa circuit protectors tripped.
E. GFCI tripped.
F. Improper or defective wiring.
G. High temperature safety switch
tripped.
A. Turn on power at service
panel.
B. Select FILTER, HTR/FLTR, or JETS
mode.
C. Reset circuit breaker.
D. Reset circuit protectors.
E. Reset GFCI.
F. *
G. Reset button on heater after water has
cooled; see *Note if switch continues to
trip.
F. Suction or discharge line
partially plugged.
G. Pump running at subnormal
speed.
H. Worn or damaged pump seal.
I. Subnormal voltage.
F. Open jet.
G. *
H. *
I. Call an electrician or your power
company.
A. Clogged strainer(s).
B. Leakage of air into suction line.
C. Vibrating parts attached to
motor support brackets
D. Low water level.
E. Damaged or worn motor
bearings.
F. Impeller rubbing inside case.
G. Debris inside pump.
A. Clean strainer(s).
B. Locate and repair leaks.
C. Tighten fasteners.
D. Add water to normal water level.
E. *
F. *
G. *
8. Noisy pump and motor.
*Note: The skills and tools necessary for the safe repair of this spa require the services of qualified
service personnel. Contact your Jacuzzi Whirlpool Bath Authorized Service Agent or Dealer.
TROUBLESHOOTING GUIDE
