JADO Glance 831/701 Series User manual

Single Lever Monoblock
Vessel Faucet
Installation Instructions
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
©JADO USA 2003
Products Luxury Faucets and Accessories
5HELPFUL HINTS FOR CLEANING AND MAINTENANCE
The solid brass product you have just purchased has been designed to give you years of beauty and service. It is
important to bring to your attention proper care and maintenance procedures, which will ensure its lasting beauty.
First and foremost, it is important (as it is with any fine piece of jewe ry or furniture) that the product be wiped c ean and
dry with a soft damp c oth after every use.
Second, under no circumstances shou d an abrasive c eaner or combination c eaner/po ish be used on JADO products.
The abrasive nature of such products wi eventua y destroy the finish and void the warranty.
In the event of stubborn b emishes shown on the finish, we recommend use of Windex window c eaner with a soft c oth,
but we do not recommend it be used on an everyday basis.
It is important to note that it is norma to expect signs of usage over time.
Thank you for selec ing JADO for your home.
109648
4TEST INSTALLED FITTING AND
CONNECTIONS FOR LEAKS
With FAUCET HANDLE in OFF position, turn on
WATER SUPPLIES (1) and check a connections
for eaks.
Remove AERATOR (2) from faucet. Operate
HANDLE (3) to f ush water ines thorough y.
Operate LIFT ROD (4) and fi avatory with
water. Check that DRAIN STOPPER (5) makes a
good sea and retains water in avatory. Adjust
stopper height by repositioning Lift Rod (4)
and tightening SET SCREW (6).
Re ease DRAIN STOPPER (5) and check a drain
connections and "P" trap for eaks. Tighten if
necessary.
Insta AERATOR (2) into faucet.
4
2
1
6
5
3
109648
JADO USA
7845 East Paradise Lane
Scottsdale, AZ 8526O
Phone:(8OO) 227-2734
Fax: (8OO) 552-JADO(5236)
www.jadousa.com
Glance
TO THE PURCHASER OF JADO BRASS PRODUCTS
A en ion ins aller:
Please leave This Pamphlet for The Owner
POLISHED BRASS AND CUSTOM FINISHWARRANTY: A 1YEAR LIMITED FINISH WARRANTY from date of purchase is provided to the
first residential owner against defects in materials and workmanship. Due to the ever-changing finish of Patina products, the finish warranty
is excluded. Warranty shall not include problems related to the installation of the product.
MECHANICS
MECHANICAL WARRANTY: A LIFETIME LIMITED WARRANTY is provided to the first residential owner on parts to be free from failure
related to defects in materials and workmanship but not installation.
CONDITIONSTOWARRANTIES
JADO Bathroom & Hardware Manufacturing Corp.places the following conditions on its finish and mechanical warranties to the first residential owner only.
JADO finish and mechanical warranties are limited to products correctly installed and used in a residential environment.
JADO warranties will not assume liability for damage due to abuse, mishandling, incorrect installation, improper maintenance, or deterioration
due to normal use.
JADO will not be liable for labor or other costs relating to the sale, installation, or replacement of their products.
In the event of a defect in any JADO product covered by this warranty, the product must be returned to the dealer where originally purchased
along with proof of purchase.
JADO's obligation under the warranty shall be limited to the repair or exchange of any product which has been determined by JADO to be
defective after appropriate examination.
The state of California has mandated under Proposition #65 that
manufactures of products, including faucets which come into
contact with potable water, must warn the consumer if the product
contains materials listed by the state as a carcinogen or
reproductive toxin. Lead, which is contained in all brass faucets in
limited amounts appears on the State's list.
Preliminary industry tests have indicated that users of faucets
made from brass face no significant danger, however,
California Proposition #65 requires that we provide you with the
following notice:
NOTICE: JADO products conform to industry
requirements of water conservation under the
ASTM / ANSI A112.18.1M-1994 plumbing code.
Lavatory, bidet, wet bar and kitchen faucet sets
have a maximum flow rate of 2.2GPM. Shower
heads, hand showers and body sprays have a
maximum flow rate of 2.5GPM.
Warning: This product contains an element
known to the State of California to cause cancer
of reproductive harm.
JADO BATHROOM AND HARDWARE MFG.CORP.
7845 East Paradise Lane
Scottsdale, AZ 85260
JADO warrants this product to be free from defects in materials or workmanship for as long as the original consumer purchaser
owns their home.
JADO will provide, free of charge, at it’s sole option, replacement part(s) or product (or if no longer available, a comparable
product) to replace those which have proven defective in materials or workmanship.
Proof of purchase (original sales receipt) from the original consumer purchaser must be made available to JADO for all limited
warranty claims.This limited warranty is non transferable.It does not apply in the event of product damage due to the use of other than
genuine JADO replacement parts, installation error, abuse, misuse, or improper care and maintenance (whether performed by
a plumber, contractor, service provider or member of the purchaser’s household).The limited warranty excludes damage due to aggressive
air or water conditions, or harsh or abrasive cleaners and/or materials.This limited warranty excludes all industrial, commercial and business
usage, whose purchasers are hereby extended a two year limited warranty (with the exception of solenoid valves and other electronic
components which carry a one year limited warranty) applying to all other terms of this limited warranty except duration. This limited warranty
does not cover labor charges incurred and/or damages sustained in installation, repair or replacement, nor incidental or consequential
damages, all of which are expressly disclaimed.This limited warranty is applicable only to JADO faucets manufactured after June 1, 1996
and installed in the United States and/or Canada.
This limited warranty gives the original consumer purchaser of an JADO faucet specific legal rights which may vary from state to
state or from province to province.This limited warranty does not cover any liability for consequential or incidental damages, all of which
are hereby expressly disclaimed, or the extension beyond the duration of this limited warranty of any implied limited warranties, including
those of merchantability or fitness for an intended purpose.In some states or provinces the exclusion or limitation of incidental or consequential
damages is not allowed, so those exclusions may not apply to you.
JADO Bathroom & Hardware Manufacturing Corp. provides the following warranties only to the first residential owner of our products.
FINISHES
JADO FAUCET LIFETIME FUNCTION AND FINISH LIMITEDWARRANTY
4
Product Numbers
831/7O1/...
831/711/...

1CAUTION
ROUGHING-IN DIMENSIONS
Feed FLEXIBLE FAUCET SUPPLIES (4) and SHANKS (5)
through the mounting ho e of avatory, or mounting
surface.
Insta SEAL (3) onto bottom of faucet.
From under side of faucet thread POP-UP ROD (1) into
POP-UP LEVER (2). (Figure "A")
Faucet 31/701 with POP-UP drain
Faucet 31/711 less drain
From be ow, Insta "C" WASHER (6), and LOCKNUTS (7)
onto faucet SHANKS (5). Before fina tightening, adjust
faucet so that it is centered and covers mounting ho e.
Tighten LOCKNUTS (7) using a screwdriver or hex wrench.
109648 109648
INSTALL FAUCET 3WATER SUPPLY CONNECTIONS
Connect HOT water supp y to eft side and Co d to right side.
Faucet supp ies are 15-3/4" in ength. Loop supp ies if they
are to ong. If additiona ength is required, insta er must
provide adapters and supp ies to connect to shut-off va ves.
Use adjustab e wrench to tighten connections.
Do not over tighten.
COLD
HOT
NOTE: FLEXIBLE SUPPLIES OR BULL-NOSE RISERS MUST BE
PURCHASED SEPARATELY.
P umbers' Putty or Cau king
Adjustab e Wrench
Phi ips Screwdriver
Channe Locks
TOOLS REQUIRED
Tubing Cutter
Regular Screwdriver
Basin Wrench
APPLY SEALANT
OR TEFLON TAPE
2
A FOAM SEAL (1) is insta ed on underside of FLANGE (2). (P umbers
Putty may be used in p ace of FOAM SEAL (1) if desired.)
App y sea ant or Tef on tape to threads of TAILPIECE (10) and
thread into DRAIN BODY (7) making a water tight sea .
Drop FLANGE (2) into LAVATORY DRAIN (3). From be ow assemb e
RUBBER GASKET (4), PLASTIC WASHER (5) and LOCK NUT (6) onto
DRAIN FLANGE (2). Do not tighten fu y.
INSTALL POP-UP DRAIN (831/701/...)
FIG. 2a
FIG. 2b
FIG. 2c FIG. 2c
FIG. 2a
FIG. 2b
1
4
3
2
5
6
7
8
6
9
2
Adjust STOPPER (13) height by repositioning POP-UP ROD (16) in SWIVEL (15)
and tightening SET SCREW (18).
Assemb e POP-UP SWIVEL (15) to PIVOT ROD (11) but do not tighten.
Drop POP-UP ROD (16) through other ho e in POP-UP SWIVEL (15) and
tighten SET SCREW (17)
Assemb e PIVOT ROD (11), and PIVOT NUT (12) as shown. Insta CONCAVE
WASHER (19) into PIVOT ROD OPENING (9) if not preinsta ed. Hand tighten
PIVOT NUT (12). Drop STOPPER (13) into drain.
(
To vandal proof drain rotate STOPPER (13) so PIVOT ROD (11) goes
through EYE (14) of STOPPER (13) . Make connection to "P" TRAP.
Inspect inside DRAIN BODY (7) that SEAL (8) is insta ed. Thread
DRAIN BODY (7) tight against FLANGE (2) to make a water tight sea .
10
9
7
6
12
19
16
1517
18 2
10
14
13
11
3
4
5
The PIVOT ROD OPENING (9) in DRAIN BODY (7) shou d face the rear
of the avatory. Tighten LOCK NUT (6) on FLANGE (2) to make a water
tight connection with channe ocks. Do not over tighten.
Turn off ho and cold wa er
supplies before beginning.
6
7
15-3/4"
9-3/4"
11-3/8"
5-3/4"
8-1/4"
3-5/8"
1-1/2"
2"
1
2
FAUCET
RECESS
VIEW "A"
2-1/8"
1-1/4"
max. 2"
max. 7"
