JADO Hatteras 842/485 User manual

Installation Instructions
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
©JADO USA 2004
Products Luxury Faucets and Accessories
109673 109673
6HELPFUL HINTS FOR CLEANING AND MAINTENANCE
The solid brass product you have just purchased has been designed to give you years of beauty and service. It is
important to bring to your attention proper care and maintenance procedures, which will ensure its lasting beauty.
First and foremost, it is important (as it is with any fine piece of jewe ry or furniture) that the product be wiped c ean and
dry with a soft damp c oth after every use.
Second, under no circumstances shou d an abrasive c eaner or combination c eaner/po ish be used on JADO products.
The abrasive nature of such products wi eventua y destroy the finish and void the warranty.
In the event of stubborn b emishes shown on the finish, we recommend use of Windex window c eaner with a soft c oth,
but we do not recommend it be used on an everyday basis.
It is important to note that it is norma to expect signs of usage over time.
Thank you for selec ing JADO for your home.
Pressure Balanced Shower
Trim Kit
JADO USA
7845 East Paradise Lane
Scottsdale, AZ 8526O
Phone:(8OO) 227-2734
Fax: (8OO) 552-JADO(5236)
www.jadousa.com
TO THE PURCHASER OF JADO BRASS PRODUCTS
A en ion ins aller:
Please leave This Pamphlet for The Owner
POLISHED BRASS AND CUSTOM FINISHWARRANTY: A 1YEAR LIMITED FINISH WARRANTY from date of purchase is provided to the
first residential owner against defects in materials and workmanship. Due to the ever-changing finish of Patina products, the finish warranty
is excluded. Warranty shall not include problems related to the installation of the product.
MECHANICS
MECHANICAL WARRANTY: A LIFETIME LIMITED WARRANTY is provided to the first residential owner on parts to be free from failure
related to defects in materials and workmanship but not installation.
CONDITIONSTOWARRANTIES
JADO Bathroom & Hardware Manufacturing Corp.places the following conditions on its finish and mechanical warranties to the first residential owner only.
JADO finish and mechanical warranties are limited to products correctly installed and used in a residential environment.
JADO warranties will not assume liability for damage due to abuse, mishandling, incorrect installation, improper maintenance, or deterioration
due to normal use.
JADO will not be liable for labor or other costs relating to the sale, installation, or replacement of their products.
In the event of a defect in any JADO product covered by this warranty, the product must be returned to the dealer where originally purchased
along with proof of purchase.
JADO's obligation under the warranty shall be limited to the repair or exchange of any product which has been determined by JADO to be
defective after appropriate examination.
The state of California has mandated under Proposition #65 that
manufactures of products, including faucets which come into
contact with potable water, must warn the consumer if the product
contains materials listed by the state as a carcinogen or
reproductive toxin. Lead, which is contained in all brass faucets in
limited amounts appears on the State's list.
Preliminary industry tests have indicated that users of faucets
made from brass face no significant danger, however,
California Proposition #65 requires that we provide you with the
following notice:
NOTICE: JADO products conform to industry
requirements of water conservation under the
ASTM / ANSI A112.18.1M-1994 plumbing code.
Lavatory, bidet, wet bar and kitchen faucet sets
have a maximum flow rate of 2.2GPM. Shower
heads, hand showers and body sprays have a
maximum flow rate of 2.5GPM.
Warning: This product contains an element
known to the State of California to cause cancer
of reproductive harm.
JADO BATHROOM AND HARDWARE MFG.CORP.
7845 East Paradise Lane
Scottsdale, AZ 85260
JADO warrants this product to be free from defects in materials or workmanship for as long as the original consumer purchaser
owns their home.
JADO will provide, free of charge, at it’s sole option, replacement part(s) or product (or if no longer available, a comparable
product) to replace those which have proven defective in materials or workmanship.
Proof of purchase (original sales receipt) from the original consumer purchaser must be made available to JADO for all limited
warranty claims.This limited warranty is non transferable.It does not apply in the event of product damage due to the use of other than
genuine JADO replacement parts, installation error, abuse, misuse, or improper care and maintenance (whether performed by
a plumber, contractor, service provider or member of the purchaser’s household).The limited warranty excludes damage due to aggressive
air or water conditions, or harsh or abrasive cleaners and/or materials.This limited warranty excludes all industrial, commercial and business
usage, whose purchasers are hereby extended a two year limited warranty (with the exception of solenoid valves and other electronic
components which carry a one year limited warranty) applying to all other terms of this limited warranty except duration. This limited warranty
does not cover labor charges incurred and/or damages sustained in installation, repair or replacement, nor incidental or consequential
damages, all of which are expressly disclaimed.This limited warranty is applicable only to JADO faucets manufactured after June 1, 1996
and installed in the United States and/or Canada.
This limited warranty gives the original consumer purchaser of an JADO faucet specific legal rights which may vary from state to
state or from province to province.This limited warranty does not cover any liability for consequential or incidental damages, all of which
are hereby expressly disclaimed, or the extension beyond the duration of this limited warranty of any implied limited warranties, including
those of merchantability or fitness for an intended purpose.In some states or provinces the exclusion or limitation of incidental or consequential
damages is not allowed, so those exclusions may not apply to you.
JADO Bathroom & Hardware Manufacturing Corp. provides the following warranties only to the first residential owner of our products.
FINISHES
JADO FAUCET LIFETIME FUNCTION AND FINISH LIMITEDWARRANTY
5
Remove Hand e and Trim from Va ve. See step 1 for reference.
Shut off water supp y by either c osing off main water supp y, or c osing off the hot and co d CHECK STOPS on va ve, if present.
TO GAIN ACCESS TO VALVE FOR SERVICING
Remove CARTRIDGE (1) by removing CARTRIDGE SCREWS (2). Remove three SCREWS (3) from FIXATION RING (4) and
pu out PRESSURE BALANCING (5) unit.
C ean SEALS (9) on base of CARTRIDGE (1). Check base of PRESSURE BALANCING UNIT (5) and c ean O-RINGS (6). Remove
CAPS (7) and check O-RINGS on inside of CAPS (7). C ean inside sea ing surfaces of VALVE BODY (8).
Re-assemb e PRESSURE BALANCING UNIT (5) and CARTRIDGE (1). Tighten a screws. Turn on water supp y and see
above for insta ing TRIM and HANDLE.
VALVE LEAKS WHEN SHUT OFF
BACK TO BACK INSTALLATION
ROTATE 180˚
Remove PRESSURE BALANCE UNIT (5). Remove CAPS (7) and c ean va ve thorough y.
Examine ba ancing unit and check condition of O-ring on end of piston. Piston shou d move back and forth. Order Repair
Part M952100-0070A if ba ancing unit is defective.
Rep ace CAPS (7) and insta PRESSURE BALANCE UNIT (5). Make sure in ets ine up with two ho es in bottom of casting.
Top f ange shou d butt-up against top of casting.
UNABLE TO MAINTAIN CONSTANT TEMPERATURE
1
2
9
5
5
7
86
4
3
INLETS
LARGE OUTLET
Product Numbers
842/485/...
842/486/...
Hatteras

Remove pipe cap from pipe. App y sea ant or Tef on tape
to threads of shower connections. Insta SHOWER ARM (13)
to shower e bow. Thread SHOWER HEAD (14) onto SHOWER
ARM (13).
109673 109673
P umbers' Putty or Cau king
Adjustab e Wrench Tef on Tape
Phi ips Screwdriver
Channe Locks
TOOLS REQUIRED
Tubing Cutter Regular Screwdriver
BOTTOM OF
TUB
OR SHOWER
STALL
48" TO 54"
OPTIONAL
ROUGHING-IN DIMENSIONS
7-7/8" D.
SHW
TUB
By restricting HANDLE rotation and imiting the amount of hot water a owed to mix with the co d, the HOT LIMIT
SAFETY STOP (1) reduces risk of accidenta sca ding. To set the maximum hot water temperature of your faucet, a
you need to do is adjust the setting on the HOT LIMIT SAFETY STOP (1).
1
5
1
3
1
1
9
7
5
3
1
0
1
5
1
3
1
1
9
7
5
3
1
1
5
1
3
1
1
9
7
5
3
1
2
COLDER
(Larger Numbers)
0 1 3 5 7 9 11 13 15
HOTTER
(Smaller Numbers)
0 1 3 5 7 9 11 13 15
Turn CARTRIDGE STEM (2) to the OFF position (co dest setting) before making adjustment to HOT LIMIT STOP (1). Use
a f at b ade screwdriver to pry free the HOT LIMIT SAFETY STOP (1). Pu forward and rotate counterc ockwise one number
to imit hot water temperature. Use ARROW (3) on CARTRIDGE (4) and NUMBERS (5) on HOT LIMIT STOP (1) for indication.
1
5
1
5
4
1
4
3
3
22
1INSTALL TRIM
Push CAP (1) onto VALVE CARTRIDGE (2). Mount
ESCUTCHEON (3) with gasket to va ve body and secure
with SCREWS (4).
Push the COVER (5) as shown over the CAP (1) and a ign
prongs on COVER (5) with screw ho es in ESCUTCHEON (3).
Important! Make sure COVER (5) snaps over the SCREWS (4).
Push ADAPTER (6) onto CARTRIDGE STEM (7). Push
ESCUTCHEON (8) onto ADAPTER (6). Mount CROSS
HANDLE (9) or LEVER HANDLE (10) and secure with
WASHER and SCREW (11). Cover with CAP (12).
6
3
11
12
1
10
572
4
8
9
CAUTION: Pro ec finish on SHOWER ARM
and SHOWER HEAD when ins alling.
ADJUST HOT LIMIT STOP
TEST INSTALLED FITTING
3
Turn VALVE "off".
With HANDLE (1) in "off" position, turn on water supp ies and check a
connections for eaks.
Operate HANDLE (1) and f ush water ines thorough y. Check the function for
proper operation.
4BACK TO BACK INSTALLATION
(SEE ILLUSTRATION STEP 5 FOR REFERENCE)
Remove Hand e and Trim from Va ve. See step 1 for reference.
Remove PRESSURE BALANCE UNIT (5). Rotate PRESSURE BALANCE UNIT (5) 180˚ so that the in ets face up and the
arge out et port faces down.
Push PRESSURE BALANCE UNIT (5) in casting make sure in ets ine up with ho es in bottom of casting. Top
f ange shou d butt up against top of casting.
Reassemb e FIXATION RING (4) and CARTRIDGE (1).
For reference
2" REF.
FINISHED WALL
2-1/2"
9-3/8"
NOTE: ALL DIMENSIONS
ARE TYPICAL TO B/S
WITH DIVERTER
1/2" NPT
OPTIONAL TO
FINISHED FLOOR
USUALLY
BETWEEN
72'' AND 84"
1-5/8" TO 3-1/4"
APPLY
SEALANT
APPLY
SEALANT
PIPE
CAP
14
13
