JADO Hatteras 842/003 Series User manual

Installation Instructions
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
©JADO USA 2003
P r o d u c t s L u x u r y F a u c e t s a n d A c c e s s o r i e s
6TEST INSTALLED FAUCET AND
CONNECTIONS FOR LEAKS
Remove AERATOR from faucet.
With HANDLES (1) in OFF position, turn on
WATER SUPPLIES (2) and check all
connections for leaks.
Operate both HANDLES to flush water
lines thoroughly.
1
2
2
Operate Lift Rod and fill lavatory with water.
Check that DRAIN STOPPER (1) makes a
good seal and retains water in lavatory. Adjust
stopper height by repositioning Lift Rod (2) and
tightening SET SCREW (3).
Release DRAIN STOPPER (1) and check all drain
connections and "P" trap for leaks. Tighten if
necessary.
Replace AERATOR.
109710 109710
7HELPFUL HINTS FOR CLEANING AND MAINTENANCE
The solid brass product you have just purchased has been designed to give you years of beauty and service. It is
important to bring to your attention proper care and maintenance procedures, which will ensure its lasting beauty.
First and foremost, it is important (as it is with any fine piece of jewelry or furniture) that the product be wiped clean and
dry with a soft damp cloth after every use.
Second, under no circumstances should an abrasive cleaner or combination cleaner/polish be used on JADO products.
The abrasive nature of such products will eventually destroy the finish and void the warranty.
In the event of stubborn blemishes shown on the finish, we recommend use of Windex window cleaner with a soft cloth,
but we do not recommend it be used on an everyday basis.
It is important to note that it is normal to expect signs of usage over time.
Thank you for selecting JADO for your home.
JADO
JADO
Widespread Lavatory Faucets
JADO USA
7845 East Paradise Lane
Scottsdale, AZ 8526O
Phone:(8OO) 227-2734
Fax: (8OO) 552-JADO(5236)
www.jadousa.com
Product Numbers
842/OO3/...
842/8O3/...
Hatteras
TO THE PURCHASER OF JADO BRASS PRODUCTS
Attention installer:
Please leave This Pamphlet for The Owner
POLISHED BRASS AND CUSTOM FINISH WARRANTY: A 1 YEAR LIMITED FINISH WARRANTY from date of purchase is provided to the
first residential owner against defects in materials and workmanship. Due to the ever-changing finish of Patina products, the finish warranty
is excluded. Warranty shall not include problems related to the installation of the product.
MECHANICS
MECHANICAL WARRANTY: A LIFETIME LIMITED WARRANTY is provided to the first residential owner on parts to be free from failure
related to defects in materials and workmanship but not installation.
CONDITIONS TO WARRANTIES
JADO Bathroom & Hardware Manufacturing Corp. places the following conditions on its finish and mechanical warranties to the first residential owner only.
JADO finish and mechanical warranties are limited to products correctly installed and used in a residential environment.
JADO warranties will not assume liability for damage due to abuse, mishandling, incorrect installation, improper maintenance, or deterioration
due to normal use.
JADO will not be liable for labor or other costs relating to the sale, installation, or replacement of their products.
In the event of a defect in any JADO product covered by this warranty, the product must be returned to the dealer where originally purchased
along with proof of purchase.
JADO's obligation under the warranty shall be limited to the repair or exchange of any product which has been determined by JADO to be
defective after appropriate examination.
The state of California has mandated under Proposition #65 that
manufactures of products, including faucets which come into
contact with potable water, must warn the consumer if the product
contains materials listed by the state as a carcinogen or
reproductive toxin. Lead, which is contained in all brass faucets in
limited amounts appears on the State's list.
Preliminary industry tests have indicated that users of faucets
made from brass face no significant danger, however,
California Proposition #65 requires that we provide you with the
following notice:
NOTICE: JADO products conform to industry
requirements of water conservation under the
ASTM / ANSI A112.18.1M-1994 plumbing code.
Lavatory, bidet, wet bar and kitchen faucet sets
have a maximum flow rate of 2.2GPM. Shower
heads, hand showers and body sprays have a
maximum flow rate of 2.5GPM.
Warning: This product contains an element
known to the State of California to cause cancer
of reproductive harm.
JADO BATHROOM AND HARDWARE MFG. CORP.
7845 East Paradise Lane
Scottsdale, AZ 85260

JADO warrants this product to be free from defects in materials or workmanship for as long as the original consumer purchaser
owns their home.
JADO will provide, free of charge, at it’s sole option, replacement part(s) or product (or if no longer available, a comparable
product) to replace those which have proven defective in materials or workmanship.
Proof of purchase (original sales receipt) from the original consumer purchaser must be made available to JADO for all limited
warranty claims. This limited warranty is non transferable. It does not apply in the event of product damage due to the use of other than
genuine JADO replacement parts, installation error, abuse, misuse, or improper care and maintenance (whether performed by
a plumber, contractor, service provider or member of the purchaser’s household). The limited warranty excludes damage due to aggressive
air or water conditions, or harsh or abrasive cleaners and/or materials. This limited warranty excludes all industrial, commercial and business
usage, whose purchasers are hereby extended a two year limited warranty (with the exception of solenoid valves and other electronic
components which carry a one year limited warranty) applying to all other terms of this limited warranty except duration. This limited warranty
does not cover labor charges incurred and/or damages sustained in installation, repair or replacement, nor incidental or consequential
damages, all of which are expressly disclaimed. This limited warranty is applicable only to JADO faucets manufactured after June 1, 1996
and installed in the United States and/or Canada.
This limited warranty gives the original consumer purchaser of an JADO faucet specific legal rights which may vary from state to
state or from province to province. This limited warranty does not cover any liability for consequential or incidental damages, all of which
are hereby expressly disclaimed, or the extension beyond the duration of this limited warranty of any implied limited warranties, including
those of merchantability or fitness for an intended purpose. In some states or provinces the exclusion or limitation of incidental or consequential
damages is not allowed, so those exclusions may not apply to you.
JADO Bathroom & Hardware Manufacturing Corp. provides the following warranties only to the first residential owner of our products.
FINISHES
JADO FAUCET LIFETIME FUNCTION AND FINISH LIMITED WARRANTY
A 865 270 / 0603

1SPOUT ASSEMBLY
2TEE ASSEMBLY
Insert SPOUT SHANK (1) through center hole of sink or mounting
surface. Seat O-RING (2) into groove in SPOUT ESCUTCHEON
BASE (3)
Assemble RUBBER WASHER (4), FIBER WASHER (5) and
LOCKNUT (6) onto threads of SPOUT SHANK (1) from
underside of lavatory or mounting surface.
Grease the 0-RINGS (1&2) .
Slide the TEE (3) onto SPOUT SHANK (4) until it makes contact
with the 0-RING (1).
Thread LOCK NUT (5) onto SPOUT SHANK (4). Rotate TEE (3) about
10 degrees from center and tighten securely.
Align SPOUT (7) and tighten LOCKNUT (6). Insert
LIFT ROD (8) through SPOUT (7).
1
2
4
5
3
Turn off hot and cold water
supplies before beginning.
CAUTION
LEVER HANDLECROSS HANDLE
G 1" D.
6" TO 12" MAX.
7
8
2
5
1
3
4
GROOVE IN TEE
5
3
WATER SUPPLY CONNECTIONS
Connect water supply to VALVE BODIES (1) with 1/2" IPS
FLEXIBLE SUPPLIES (3) or 3/8" O.D. BULL-NOSE RISERS (4).
Use wrench to tighten connections.
Do not over tighten. Be careful not to kink copper supply when
bending. Use tubing cutter to cut to proper length.
1
4
FERRULE
NOTE: FLEXIBLE SUPPLIES OR BULL-NOSE RISERS MUST BE
PURCHASED SEPARATELY.
COUPLING
NUT
5-3/8"
4-3/4"
G 3/8"
Ø 2-3/8"
2-1/8" D.
2" MAX.
7" MAX.
109710 109710
ROUGHING-IN DIMENSIONS
Plumbers' Putty or Caulking
Adjustable Wrench
Phillips Screwdriver
Channel Locks
TOOLS REQUIRED
Tubing Cutter Regular Screwdriver
Basin Wrench
GROOVE
6
3INSTALL VALVE BODIES
1-1/4'' MAX.
"O" RING
Thread LOCKNUT (8) to bottom of VALVE BODY (2). Make sure
FIBER WASHER (9) and RUBBER WASHER (10) are installed.
Insert VALVE BODY (2) through mounting hole from underside
of lavatory or mounting surface.
Note: VALVE BODY marked Hot is installed in the left mtg. hole,
VALVE BODY marked Cold in the right when facing front of fitting.
Maximum mounting surface thickness is 1-1/4".
HANDLE ASSEMBLIES (1) are installed on VALVE BODIES (2) and must
be removed to install VALVE BODIES (2) from under lavatory or mounting
surface.
To remove HANDLE ASSEMBLY (1), unthread HANDLE BASE (3) with
LEVER (4) from VALVE BODY (2). Pull HANDLE ASSEMBLY(1) off
VALVE STEM (5).
Unthread and remove MOUNTING RING (6) and SPACER (7).
From top install SPACER (7) onto VALVE BODY (2). Thread
MOUNTING RING (6) on VALVE BODY (2) until seated tightly against
SPACER (7). Set VALVE BODIES (2) so that their outlets are facing
toward SPOUT TEE (11) and then tighten LOCKNUT (8) using 35mm
or adjustable wrench.
Insert FIBER WASHERS (12) into COUPLING NUTS (13) of
SUPPLY HOSES (14) and tighten making water tight connection.
Important: Loop SUPPLY HOSES (14) as illustrated so they do not kink.
6
8
12
HOT
13
14
911
10
7
5
2
JADO
"O" RING
TUB DECK OR
MOUNTING SURFACE
HOT
1-1/4" MAX.
1-1/2" MAX.
COLD
APPLY SEALANT
OR TEFLON TAPE
4
A FOAM SEAL (1) is installed on underside of FLANGE (2). (Plumbers
Putty may be used in place of FOAM SEAL (1) if desired.)
Apply sealant or Teflon tape to threads of TAILPIECE (10) and
thread into DRAIN BODY (7) making a water tight seal.
Drop FLANGE (2) into LAVATORY DRAIN (3). From below assemble
RUBBER GASKET (4), PLASTIC WASHER (5) and LOCK NUT (6) onto
DRAIN FLANGE (2). Do not tighten fully.
INSTALL POP-UP DRAIN
FIG. 4a
FIG. 4b
FIG. 4c
FIG. 4c
FIG. 4a
FIG. 4b
1
4
3
2
5
6
7
8
6
9
2
Adjust STOPPER (13) height by repositioning POP-UP ROD (16) in SWIVEL (15)
and tightening SET SCREW (18).
Assemble POP-UP SWIVEL (15) to PIVOT ROD (11) but do not tighten.
Drop POP-UP ROD (16) through other hole in POP-UP SWIVEL (15) and
tighten SET SCREW (17)
Assemble PIVOT ROD (11), and PIVOT NUT (12) as shown. Install CONCAVE
WASHER (19) into PIVOT ROD OPENING (9) if not preinstalled. Hand tighten
PIVOT NUT (12). Drop STOPPER (13) into drain.
(To vandal proof drain rotate STOPPER (13) so PIVOT ROD (11) goes
through EYE (14) of STOPPER (13). Make connection to "P" TRAP.
Inspect inside DRAIN BODY (7) that SEAL (8) is installed. Thread
DRAIN BODY (7) tight against FLANGE (2) to make a water tight seal.
10
9
7
6
12
19
16
1517
18
2
10
14
13
11
The PIVOT ROD OPENING (9) in DRAIN BODY (7) should face the rear
of the lavatory. Tighten LOCK NUT (6) on FLANGE (2) to make a water
tight connection with channel locks. Do not over tighten.
INSTALL HANDLES (LEVER and CROSS)
Turn VALVE BODIES (2) to off position. Align HANDLES as shown or as desired and install
HANDLE ASSEMBLY(1, 1A) onto VALVE STEM (5). Thread HANDLE BASE (3) onto VALVE
BODY (2) until seated tightly against mounting surface.
1-1/4" O.D.
NOTE: MOUNTING HOLES
ARE 1-1/4" D.for Spout and
for Side valve
Ø 2-1/4"
11A
3
4
Make sure both O-RINGS (1&2) are seated into grooves of TEE (3). 10 °
BACK
