Jaeger-leCoultre REVERSO CLASSIC MONOFACE User manual

ENGLISH
CONTENTS
Introduction 21
Accuracy and precautions for use 21
Water resistance 23
“1000 Hours Control” test 25
Use of the Mechanical Model 27
Use of the Quartz Model 29
International Guarantee 33
Limited Warranty 36
(United States of America and Canada)
Guarantee for Australia 40
Customer Service 45

20
12
3
1Hour hand
2Minute hand
3Crown

ENGLISH
21
INTRODUCTION
We would like to thank you for the confi-
dence you have placed in Jaeger-LeCoultre.
Our Maison has applied all its expertise and
exacting standards to the creation of this
model.
We invite you to consult the operating ins-
tructions and hope your Jaeger-LeCoultre
timepiece brings you great joy.
ACCURACY AND
PRECAUTIONS FOR USE
MANUALLY-WOUND OR AUTOMATIC
MECHANICAL WATCHES
The accuracy of watch models with
mechanical movements is determined by
the balance wheel. This oscillates at a rate
of 21,600 vibrations per hour. Despite all
the care that the master watchmakers of
the Jaeger-LeCoultre Manufacture have
lavished on building and assembling your

22
watch, its accuracy is subject to the in-
fluence of gravity, magnetic fields, acci-
dental impacts, and the ageing of the oils.
The accuracy of a watch is measured by its
regularity of rate in various positions.
Your individual activities could be the cause
of slight irregularities in the working of
your timepiece. If you observe a discrepan-
cy in the way your watch runs, we advise
you to entrust it to an authorised Jaeger-
LeCoultre retailer who will make the neces-
sary adjustments. Watches with mecha-
nical movements must not be used for
sports involving significant risk of impact
or abrupt actions, such as golf or tennis.
QUARTZ MODELS
Quartz models are accurate to wit-
hin 2 to 3 minutes a year. Jaeger-
LeCoultre quartz watches contain a
battery and electronic components. When
performing a maintenance service, your
Jaeger-LeCoultre authorised Technical As-
sistance Centre or your authorised Jaeger-

ENGLISH
23
LeCoultre retailer will recover such com-
ponents and ensure they are disposed of
in accordance with the standards in force.
WATER RESISTANCE
Your Jaeger-LeCoultre watch is water-
resistant to 3 bar. Its water resistance can
be identified by the symbol and/or
the engraving: “3 bar” on the caseback.
This means that your model has been
tested at an overpressure of 3 bar, corre-
sponding to an immersion pressure of 30
metres (1 bar = ±10 metres).
In accordance with the ISO 22810/NIHS
92-20 standard, in order to guarantee the
durability of the watch’s characteristics
over time, and as water resistance may be
aected by certain activities, it is recom-
mended that you:
- have the watch’s water resistance checked
by an authorised Jaeger-LeCoultre retailer
at least once every two years. It is essen-
tial to have such a check carried out each

24
time your watch is opened, and before any
period in which it is liable to undergo pro-
longed and/or regular immersions.
- check when making the purchase that the
bracelet is suitable for the intended use.
- avoid subjecting the watch to excessively
abrupt temperature changes.
- protect the watch from being dropped or
suering other accidental impacts, and
have the water resistance checked after
any severe impact.
- avoid using the controls, push-piece, or
time-setting crown while under water, or
outside the water, if the watch is not yet
dry after immersion.
- restore the time-setting crown and the
push-pieces to their normal positions, (or
where applicable, close the compression
keys) after every manipulation.
- rinse the watch with fresh water after use
in sea water.

ENGLISH
25
You may use your watch while swimming
as long as you do not exceed the immer-
sion pressure and do not engage in any
water sports that could cause impacts.
This watch is not a piece of diving equip-
ment and should not be used as such. Also,
note that leather straps are not suited for
aquatic activities.
“1000 HOURS CONTROL”
TEST
The Jaeger-LeCoultre Manufacture pays
close attention to the quality and to the
final checks of its watches.
The 1000 Hours Control is a series of in-
ternal qualification tests for each of the
models in our collection, as well as inter-
nal tests on the production of your watch,
which go beyond ocial timing tests.
These tests include checks of the move-
ment before and after being cased up
in the watch and cover the whole watch

26
once it has been assembled, in the condi-
tions closest to daily wear.
The “1000 Hours Control” legend, or the
“” seal engraved on the back of the
watch certifies that each of the models
from our collection has successfully under-
gone all of the qualification tests, and that
your watch has successfully undergone
all of the production tests. These ensure
regularity of rate, resistance to variations
in temperature and atmospheric pressure,
ability to withstand shocks and magnetic
fields, as well as water resistance.

ENGLISH
27
MANUALLY WOUND
MECHANICAL MODEL
TECHNICAL
SPECIFICATIONS
- Manually wound mechanical movement,
Calibre 822A/2
- 21,600 vibrations/hour
- Power reserve: approximately 42 hours
MOVEMENT
Jaeger-LeCoultre Calibre 822A/2

28
USE
0 1
WINDING
Crown in position 0.
The watch is wound by turning the crown
clockwise. It is fully wound when the crown
locks.
Do not attempt to wind a manually wound
watch beyond the locking point.
To ensure good operating accuracy, it is
advisable to wind your watch regularly, at
least once a day.

ENGLISH
29
SETTING THE HOUR AND MINUTES
Pull the crown out to position 1.
Move the hands clockwise until the de-
sired time is displayed.
When the operation is complete, push the
crown back into position 0.
QUARTZ MODEL
TECHNICAL
SPECIFICATIONS
- Quartz movement, Calibre 657
- 32,768 Hz
- The battery reference is 364

30
MOVEMENT
Jaeger-LeCoultre Calibre 657
USE
0 1
SETTING THE HOUR AND MINUTES
Pull the crown out to position 1.

ENGLISH
31
Move the hands clockwise until the de-
sired time is displayed.
When the operation is complete, push the
crown back into position 0.

32
JAEGER-LECOULTRE
WATCHES
In order to benefit from the Internation-
al Guarantee and/or the Limited War-
ranty and/or the Manufacturer’s Guar-
antee for Australia, Jaeger-LeCoultre
products must be purchased exclusively
from authorised Jaeger-LeCoultre retail-
ers or from Jaeger-LeCoultre Boutiques.
Maintenance and repair work must be en-
trusted to an authorised Jaeger-LeCoultre
retailer, a Jaeger-LeCoultre Boutique, or
an authorised Jaeger-LeCoultre Service
Centre. If these conditions are not met,
the manufacturer’s guarantee does not
apply. Please contact Jaeger-LeCoultre
to obtain the list of authorised Jaeger-
LeCoultre retailers across the world.

ENGLISH
33
INTERNATIONAL
GUARANTEE
The International Guarantee applies to
Jaeger-LeCoultre products sold or pre-
sented for guarantee repairs in all coun-
tries, except the United States of Ameri-
ca and Canada (for these two countries,
see the Limited Warranty) and Australia
(for this country, refer to the Guarantee
for Australia).
TERMS AND CONDITIONS OF
THE J AEGER-LE C OULTRE
INTERNATIONAL GUARANTEE
Your Jaeger-LeCoultre watch is guaran-
teed to protect against all manufacturing
defects for two years from the date of pur-
chase, subject to the following conditions.
Any part found by our technical services
to be defective as a result of a manufac-
turing defect will, at the sole discretion of
Jaeger-LeCoultre, be repaired or replaced
free of charge. The Jaeger-LeCoultre In-

34
ternational Guarantee is valid only if the
guarantee certificate enclosed with this
booklet has been duly completed, dated,
stamped, and signed by the authorised
Jaeger-LeCoultre retailer or the Jaeger-
LeCoultre Boutique, which sold you your
watch.
The Jaeger-LeCoultre International Guar-
antee does not cover defects resulting
from accidents, mishandling, or incorrect,
abusive use (for example, knocks, dents,
crushing, excessive temperatures, power-
ful magnetic fields), the use of or eect
of using batteries other than those des-
ignated by Jaeger-LeCoultre, unauthor-
ised alteration or repair, the consequences
of normal wear and ageing of the watch,
strap, or glass, the loss of water resistance
after two years from the date of purchase,
if your watch is water-resistant, or any de-
fect resulting from contact with water, if
your watch is not water-resistant.
Jaeger-LeCoultre water-resistant watches
can be identified by the symbol and/or

ENGLISH
35
by “3, 5, 10, or 20 bar” (or another number
depending on the model) engraved on
the caseback. Their water resistance is
guaranteed for two years from the date
of purchase, provided that the glass, bez-
el, back, middle part, and crown have not
been damaged. It is nevertheless essen-
tial to have the water resistance of your
watch checked at least once every two
years, and in any event, prior to any period
of intensive use, either by an authorised
Jaeger-LeCoultre retailer, a Jaeger-
LeCoultre Boutique, or an authorised
Jaeger-LeCoultre Service Centre (for
further information please see your User
Manual).
For quartz watches, this guarantee does
not cover the battery life.
As a consumer, you may have legal rights
under applicable national legislation gov-
erning the sale of consumer goods; those
rights are not aected by this guarantee.

36
LIMITED WARRANTY
(UNITED STATES OF
AMERICA AND CANADA)
The following Limited Warranty applies to
Jaeger-LeCoultre products sold or pre-
sented for warranty repairs in the United
States of America and Canada only.
TERMS AND CONDITIONS OF
THE J AEGER-LE C OULTRE
LIMITED WARRANTY
Your Jaeger-LeCoultre watch is guaran-
teed against all manufacturing defects for
two years from the date of purchase, sub-
ject to the following conditions. Any part
found by our technical services to be de-
fective as a result of a manufacturing de-
fect will, at the sole discretion of Jaeger-
LeCoultre, be repaired or replaced free of
charge. The Jaeger-LeCoultre Limited War-
ranty is valid only if the warranty certificate
enclosed with this booklet has been duly

ENGLISH
37
completed, dated, stamped, and signed by
the authorised Jaeger-LeCoultre retailer or
the Jaeger-LeCoultre Boutique, which sold
you your watch.
This Jaeger-LeCoultre Limited Warranty
does not cover defects resulting from ac-
cidents, mishandling, or incorrect, abusive
use (for example, knocks, dents, crushing,
excessive temperatures, powerful mag-
netic fields), the use of or eect of using
batteries other than those designated by
Jaeger-LeCoultre, unauthorised alteration
or repair, the consequences of normal wear
and ageing of the watch, strap, or glass,
the loss of water resistance after two years
from the date of purchase, if your watch
is water-resistant, or any defect resulting
from contact with water, if your watch is
not water-resistant.
Jaeger-LeCoultre water-resistant watch-
es can be identified by the symbol
and/or by “3, 5, 10, or 20 bar” (or another
number depending on the model) en-
graved on the caseback. Their water resist-

ance is guaranteed for two years from the
date of purchase, provided that the glass,
bezel, back, middle part, and crown have
not been damaged. It is nevertheless es-
sential to have the water resistance of your
watch checked at least once every two
years, and in any event, prior to any pe-
riod of intensive use, either by an author-
ised Jaeger-LeCoultre retailer, a Jaeger-
LeCoultre Boutique, or an authorised
Jaeger-LeCoultre Service Centre (for fur-
ther information please see your User
Manual).
For quartz watches, this guarantee does
not cover the battery life.
Except insofar as prohibited by applica-
ble law, this Limited Warranty shall be
the exclusive manufacturer warranty. Nei-
ther this Limited Warranty nor any other
warranties, whether expressed or implied,
including, but not limited to, any implied
warranty of merchantability or of fitness
for any particular purpose, shall extend
